Page 1: Table Of Contents
Table of Contents Introduction Safety and environment protection Symbol glossary Vehicle Inspection Guide Instrument Cluster Warning and control lights Gauges Entertainment Systems AM/FM stereo AM/FM stereo cassette with CD AM/FM stereo with in-dash six CD Climate Controls Heater only Manual heating and air conditioning Lights Headlamps Turn signal control...
Page 2 Table of Contents Locks and Security Keys Locks Seating and Safety Restraints Seating Safety restraints Child restraints Driving Starting Brakes Air suspension Transmission operation Vehicle loading Roadside Emergencies Hazard flasher switch Fuses and relays Jump starting Wrecker towing Customer Assistance Getting assistance outside the U.S.
Page 4: Introduction
State of California to cause cancer and birth defects or other reproductive harm. CONGRATULATIONS Congratulations on acquiring your new Ford. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it.
Page 5: Safety And Environment Protection
Introduction SAFETY AND ENVIRONMENT PROTECTION Warning symbols in this guide How can you reduce the risk of personal injury and prevent possible damage to others, your vehicle and its equipment? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol.
Page 6 In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may access vehicle diagnostic information through a direct connection to your vehicle when diagnosing or servicing your vehicle.
Page 7 Introduction Cell phone use The use of Mobile Communications Equipment has become increasingly important in the conduct of business and personal affairs. However, drivers must not compromise their own or others’ safety when using such equipment. Mobile Communications can enhance personal safety and security when appropriately used, particularly in emergency situations.
Page 8: Symbol Glossary
Introduction VEHICLE SYMBOL GLOSSARY These are some of the symbols you may see on your vehicle. Safety Alert See Owner’s Guide Fasten Safety Belt Air Bag-Front Air Bag-Side Child Seat Child Seat Installation Child Seat Lower Warning Anchor Child Seat Tether Brake System Anchor Brake Fluid -...
Page 9 Introduction Interior Luggage Child Safety Door Compartment Release Lock/Unlock Symbol Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid Power Steering Fluid Level Emission System Engine Air Filter...
Page 10 Introduction FEDERAL HIGHWAY ADMINISTRATION REGULATION Regulations such as those issued by the Federal Highway Administration or issued pursuant to the Occupational Safety and Health Act (OSHA), and/or state and local laws and regulations may require additional equipment for the way you intend to use the vehicle. It is the responsibility of the registered owner to determine the applicability of such laws and regulations to your intended use for the vehicle, and to arrange for the installation of required equipment.
Page 11: Vehicle Inspection Guide
Vehicle Inspection Guide To be sure your vehicle is ready to operate, conduct a pre-trip inspection at the beginning of each work period. Follow the steps listed in this section to ensure a proper vehicle inspection procedure. The pages in this section may be produced locally and used on a regular basis.
Page 12 Vehicle Inspection Guide Engine compartment (with engine stopped) Any leaks: Check for signs of fluid puddles, dripping fluid on the ground under the engine or the underside of the engine. HVAC air inlet: Check for debris, leaves, etc. that may have collected on the HVAC air inlet grille or inside the exterior module as this may cause reduced system performance.
Page 13 Vehicle Inspection Guide Engine starting (parking brake applied) Safety/Emergency Prior to entering the cab, verify that the vehicle is equipped with spare electrical fuses equipment: (if used), three red reflective triangles, a properly charged and rated fire extinguisher and wheel chocks. Walk around the vehicle and check that all steps and grab handles, inside and out as well as behind, are tight and clean.
Page 14 Vehicle Inspection Guide Engine starting (parking brake applied) Ammeter/Voltmeter: Check the gauge to see if the alternator is charging. Check for excessive free play in the steering Steering linkage free play: linkages. The steering wheel should have less than two inches (five cm) of free play at rim of steering wheel.
Page 15 Vehicle Inspection Guide Engine starting (parking brake applied) Air brake check: Check the air brakes in the following manner (Chock the wheels, if necessary. Push in the parking brake and on tractors, also push in the tractor parking brake knob): 1.
Page 16 Vehicle Inspection Guide Engine starting (parking brake applied) Automatic With the engine idling at normal operating temperature and the parking brake applied, transmission fluid: check the automatic transmission fluid. If fluid needs to be added, place the transmission in the appropriate gear as specified in the transmission operator’s manual and refer to Transmission fluid in the Maintenance and specifications chapter.
Page 17 Vehicle Inspection Guide Front suspension Spring: Inspect for missing, broken or shifted leaves or leaves that are in contact, or nearly contacting a tire, rim, brake drum, frame or body components. Spring mount: Inspect spring hangers, bolts, bushings, axle mounting bolts and nuts for cracks, breaks, wear, damage and tightness.
Page 18 Vehicle Inspection Guide Front wheels Rims: Check for damaged or bent rims. Rims should not have welding repairs and no rust trails that indicate it is loose on the wheel. Lug nuts: Make sure all lug nuts are present and not loose (look for rust trails around the lug nuts).
Page 19 Vehicle Inspection Guide Underbody of vehicle Driveshaft: Make sure that the driveshaft is not bent or cracked. Ensure all driveshaft couplings are secure. Exhaust system: Make sure the outside visible parts are securely mounted. Make sure there are no cracks, holes or severe dents. Frame: Check for cracks or bends in longitudinal frame members.
Page 20 Vehicle Inspection Guide Rear of vehicle Lights, reflectors: Make sure all lights illuminate and are clean. Make sure headlights function on both high and low beams. Make sure reflectors are clean and unbroken and of proper color (red on rear, amber elsewhere). Make sure the running lights are also clean and unbroken.
Page 21 Vehicle Inspection Guide Rear springs Torsion, shocks: Make sure torsion arm is not cracked, broken or missing. Check the shock absorber for cracks or leaks; there should be no missing or broken mounting bolts or worn bushings. Rear brakes Hoses: Checked for cracked, worn or frayed hoses.
Page 22 Vehicle Inspection Guide Trailer If you are pulling a trailer, an inspection of the trailer similar to that of the tractor should be done. Such an inspection should follow trailer manufacturer recommendation and should include at a minimum: general condition, landing gear, doors, sides, lights, reflectors, suspension, brakes, tires, wheels, cargo placement, stability and tie-downs.
Page 23: Instrument Cluster
Instrument Cluster WARNING LIGHTS AND CHIMES Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works.
Page 24 Instrument Cluster Stop engine: This light is used in STOP conjunction with the electronic ENGINE engine control. Refer to the Engine Operator’s Manual for specific information regarding this feature. If the engine shuts down, it can be restarted and operated for 30 seconds at a time or until the problem is corrected.
Page 25 Instrument Cluster Wait to start: Indicates the air WAIT START intake heater is in operation and special starting procedures are required. Refer to the Driving chapter. If equipped with an air intake heater, DO NOT use ether or any other starting fluids. The use of starting fluids (ether) in an engine equipped with an air intake heater could result in damage and/or personal injury.
Page 26 Instrument Cluster Differential lock: Illuminates when the main differential is locked (engaged). Parking brake warning: BRAKE Momentarily illuminates when the ignition is turned to the ON position and the engine is off. Also illuminates when the parking brake is engaged. If the brake warning lamp does not illuminate at these times, seek service immediately.
Page 27 Instrument Cluster Check trans (Allison automatic CHECK transmission only): The lamp will TRANS illuminate for several seconds after the ignition is turned to the ON position. Illumination of this light indicates that a problem has been detected and shifting may be restricted. Depending upon the severity of the problem, the read-out digit on the shifter display may be blank.
Page 28: Gauges
Instrument Cluster Headlamps on warning chime: Sounds when the headlamps or parking lamps are on, the ignition is off (and the key is not in the ignition) and the driver’s door is opened. GAUGES Some of the gauges shown are optional based on vehicle equipment; your vehicle may not have some of the gauges shown in this section.
Page 29 Instrument Cluster Trip odometer: Registers the miles (kilometers) of individual journeys. To reset, depress the control. Engine coolant temperature gauge: Indicates engine coolant temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section, the engine is overheating.
Page 30 Instrument Cluster Hourmeter (if equipped): Registers the hours the engine has been operating. Battery voltage gauge: Indicates the battery voltage when the ignition is in the ON position. If the pointer moves and stays outside the normal operating range (as indicated by arrows), have the vehicle’s electrical system checked as soon as possible.
Page 31 Instrument Cluster Fuel gauge: Indicates approximately how much fuel is left in the fuel tank (when the ignition is in the on position). If your vehicle is equipped with dual fuel tanks, the engine will draw fuel from the passenger-side fuel tank only. With dual fuel tanks, the vehicle will be equipped with a fuel transfer pump system that will draw fuel from the driver-side fuel tank and send fuel to the passenger-side fuel tank.
Page 32 Instrument Cluster Do not drive the vehicle when the low air pressure buzzer is sounding or the warning light is lit. These warnings indicate there is not enough air pressure for the brake or suspension system to operate properly. Vehicles equipped with hydraulic brakes and an air compressor have a single-pointer air gauge.
Page 33: Entertainment Systems
Entertainment Systems AUDIO SYSTEMS AM/FM stereo (if equipped) PUSH SEEK TONE TONE VOL TUNE AM/FM 1. SEEK: Press to find the next strong station down/up the frequency band. 2. TUNE: Press to manually change radio frequency down/up. 3. AM/FM: Press to choose a AM/FM frequency band in radio mode.
Page 34 Entertainment Systems 5. Power/Volume: Press to turn ON/OFF; turn to increase or decrease volume levels. 6. TONE: Press TONE until the PUSH desired level — Bass, Treble, Fade TONE appears on the display. Turn the volume control to raise/lower the levels, or to move the audio sound from the right to left or the front to back (if equipped).
Page 35 Entertainment Systems 1. SEEK: Press and release SEEK for previous/next strong station or track. 2. TEXT: The filename (Fi), song title (So), artist text (Ar) or album text (AL) may be viewed while playing an MP3 selection. When MP3 selection text is shown on the message display, its corresponding text indicator (Fi, So, Ar, or AL) is shown in the elapsed time display.
Page 36 Entertainment Systems 7. Select: Use with Bass, Treble, Balance, Fade and other menu selections. 8. Balance: Press BAL; then press to shift sound to the left/right speakers. Fade: Press FADE; then press to shift sound to the rear/front speakers. 9. Menu: Press MENU and SEL to access AUTOSET, Speed sensitive volume and Setting the clock.
Page 37 Entertainment Systems 13. FOLDER : Press to access the previous MP3 directory. 14. FF(Fast forward): In CD/MP3 mode, press until desired selection is reached. 15. REW(Rewind): In CD/MP3 mode, press until desired selection is reached. 16. SAT (if equipped): Your radio comes equipped with Satellite Ready capability.
Page 38 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 39: Am/Fm Stereo Cassette With Cd
Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 40 Entertainment Systems 3. Mute: Press to MUTE playing media; press again to return to the playing media. 4. Tape Eject: Press to eject the cassette. The radio will resume playing. 5. Tape 1–2/CD: Press to begin tape play. If a cassette is already playing, press to change playing sides.
Page 41 Entertainment Systems Autoset: Press MENU until AUTOSET appears in the display. Press SEL to toggle on/off. Allows you to set the strongest local stations without losing your original memory preset stations for AM/FM1/FM2. When the six strongest stations are filled, the station stored in preset 1 will begin playing.
Page 42 Entertainment Systems 12. FOLDER : Press to access the next MP3 directory folder. 13. FOLDER : Press to access the previous MP3 directory folder. 14. Bass: Press BASS; then press to decrease/increase the bass output. Treble: Press TREB; then press to decrease/increase the treble output.
Page 43 Entertainment Systems 19. Tune/CAT: TUNE: Works in radio mode only. Press TUNE to change frequency down/up. CAT: CAT is only available when equipped with Satellite Radio. Your radio comes equipped with Satellite ready capability. The kit to enable Satellite reception is available through your dealer. Detailed Satellite instructions are included with the dealer installed kit.
Page 44: Am/Fm Stereo With In-Dash Six Cd
Entertainment Systems Premium Satellite Compatible AM/FM Stereo In-Dash Six CD/MP3 Radio (if equipped) 1. SEEK: Press and release SEEK for previous/next strong station or track. 2. TEXT: The filename (Fi), song title (So), artist text (Ar) or album text (AL) may be viewed while playing an MP3 selection.
Page 45 Entertainment Systems 3. AUX: Press to toggle between the current playing media and DVD (if equipped). 4. MUTE: Press to MUTE playing media; press again to return to playing media 5. EJ: Press to eject a CD. Press EJ and a memory preset to eject a specific disc.
Page 46 Entertainment Systems 9. Menu: Press to access the following functions: Compression: Brings soft and loud CD passages together for a more consistent listening level when in CD mode. Press MENU until compression status is displayed. Press the SEL control to enable the compression feature when COMPRESS OFF is displayed.
Page 47 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 48 Entertainment Systems 22. Scan: Press SCAN to hear a brief sampling of radio stations or CD/MP3 tracks. Press again to stop. 23. Disc/Tune: Press manually tune down/up the radio frequency band, or to listen to the previous/next CD. CAT: CAT is only available when equipped with Satellite Radio. Your Audiophile radio comes equipped with Satellite ready capability.
Page 49 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 50: Climate Controls
Climate Controls HEATER ONLY SYSTEM (IF EQUIPPED) 1. Fan speed adjustment: Controls the volume of air circulated in the vehicle. 2. Temperature selection: Controls the temperature of the airflow in the vehicle. 3. Air flow selections: Controls the direction of the airflow in the vehicle.
Page 51: Manual Heating And Air Conditioning
Climate Controls 4. Direct the outer instrument panel vents towards the side windows To increase airflow to the outer instrument panel vents, close the vents located in the middle of the instrument panel. Do not place objects on top of the instrument panel as these objects may become projectiles in a collision or sudden stop.
Page 52 Climate Controls • Do not put objects under the front seats that will interfere with the airflow to the back seats. • Remove any snow, ice or leaves from the air intake area at the base of the windshield. To aid in side window defogging/demisting in cold weather: 1.
Page 53: Lights
Lights HEADLAMP CONTROL Turns the lamps off. Turns on the parking lamps, instrument panel lamps, license plate lamps and tail lamps. Turns the headlamps on. High beams/Flash-to-pass Push the lever toward the instrument panel to activate the high beams. Pull the lever towards you to deactivate.
Page 54: Turn Signal Control
Lights PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel and all applicable switches in the vehicle during headlamp and parklamp operation. Move the control to the full upright position, past the detent, to turn on the interior lamps. Move the control to the full down position, past the detent, to prevent the interior lights from illuminating when the doors are opened.
Page 55: Interior Lamps
Lights INTERIOR LAMPS Map lamps (if equipped) To turn on the map lamps, press the control next to each lamp. EXTERIOR BULBS Checking operation of lamps, safety equipment and warning signals It is a good safety practice to check operation of headlamps, parking lamps, turn signals, clearance and marker lamps, instrument panel and control lamps each day.
Page 56 Lights 2. Remove the four screws and move the parking lamp assembly away from the headlamp bulb. 3. Remove the four screws and the retaining bracket from the headlamp bulb. 4. Pull the headlamp bulb out of the housing, disconnect the electrical connector and remove the headlamp bulb.
Page 57 Lights 2. Remove the four screws from the lamp assembly. 3. Carefully lower the lamp assembly and pull the bulb socket straight out of the lamp assembly. 4. Carefully pull the bulb straight out of the socket and push in the new bulb.
Page 58: Driver Controls
Driver Controls WINDSHIELD WIPER/WASHER CONTROLS Rotate the windshield wiper control to the desired interval, low or high speed position. The bars of varying length are for intermittent wipers. When in this position rotate the control upward for fast intervals and downward for slow intervals.
Page 59: Power Windows
Driver Controls Never adjust the steering wheel when the vehicle is moving. AUXILIARY POWER POINT Power points are designed for accessory plugs only. Do not POWER POINT hang any type of accessory or accessory bracket from the plug. Improper use of the power point can cause damage not covered by your warranty.
Page 60 Driver Controls • Press the bottom portion of the rocker switch to open. AUTO One touch down • Press AUTO completely down and release quickly. The driver’s window will open fully. Depress again to stop window operation. AUTO Window lock The window lock feature allows only the driver to operate the power windows.
Page 61: Mirrors
Driver Controls MIRRORS With the doors closed and the seat adjusted for proper comfort, move the mirrors to maximize rear viewing area by adjusting the western mirrors left or right as required. Adjust the auxiliary convex mirrors. Convex mirrors are a ball-stud design for precise adjustment to maximize viewing area.
Page 62 Driver Controls 2. Move the control in the direction you wish to tilt the mirror. MIRRORS 3. Return to the center position to lock mirrors in place. 4. Adjust spotter mirrors (if equipped) manually. Heated outside mirrors (if equipped) Both main mirrors are heated automatically to remove ice, mist and fog and are automatically activated when the vehicle is started.
Page 63: Speed Control
Driver Controls Fold-away mirrors The mirrors can be manually folded forward or backwards for narrow spaces like driving through an automatic car wash or backing out of a garage with the trailer tow mirror. The telescoping feature (if equipped) allows the mirror to extend approximately three inches (76 mm).
Page 64 Driver Controls To turn speed control off Press OFF or turn off the ignition. Once speed control is switched off, CRUISE the previously programmed engine RPM will be erased. Do not use the speed control in heavy traffic or on roads that are winding, slippery, or unpaved.
Page 65 Driver Controls To set a higher set speed Press and hold SET +. If the vehicle is moving, this will increase vehicle speed; if the vehicle is stationary, this will increase engine RPM. Release the control when the desired vehicle speed/engine RPM is reached.
Page 66 Driver Controls To disengage speed control • Depress the brake pedal or • Depress the clutch pedal (if equipped). Disengaging the speed control will not erase the previously programmed set speed or engine RPM. Pressing OFF will erase the previously programmed engine RPM. CRUISE To return to a previously set speed Press RESUME -.
Page 67: Locks And Security
Locks and Security KEYS The key operates all locks on your vehicle. In case of loss, replacement keys are available from your dealer. You should always carry a second key with you in a safe place in case you require it in an emergency. POWER DOOR LOCKS (IF EQUIPPED) Press U to unlock all doors and L to lock all doors.
Page 68: Seating And Safety Restraints
Seating and Safety Restraints SEATING Notes: Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. Do not pile cargo higher than the seatbacks to reduce the risk of injury in a collision or sudden stop.
Page 69 Seating and Safety Restraints Rotate control to adjust seatback. Using the manual lumbar support For more lumbar support, turn the lumbar support control toward the front of the vehicle. For less lumbar support, turn the lumbar support control toward the rear of the vehicle.
Page 70 Seating and Safety Restraints Pull handle out to move the seat cushion forward or backward. Rotate control to adjust seatback. Pump handle to raise seat height. Push handle full down to lower. Always adjust the seat height before fastening seat belt.
Page 71 Seating and Safety Restraints Adjusting the front power seat (if equipped) The control is located on the outboard side of the seat cushion. Press to raise or lower the front portion of the seat cushion. Press to raise or lower the rear portion of the seat cushion.
Page 72 Seating and Safety Restraints Air-Ride seat (if equipped) Move handle to the left to move seat forward or backward. Push up on the switch to raise the seat height. Press down on the switch to lower the seat height. Always adjust the seat height before fastening seat belt. Press up on the switch to increase the firmness (lumbar support) of the seatback.
Page 73 Seating and Safety Restraints Press down on the switch to reduce the firmness (lumbar support) of the seatback. Heated seats (if equipped) To operate the heated seats: • Push control to activate. • Push again to deactivate. REAR FLIP-UP SEAT (IF EQUIPPED) Flipping-up the seat The rear seatback has a split 60/40 seat.
Page 74: Safety Restraints
Seating and Safety Restraints Make sure the safety belts are accessible and not trapped behind the seat when the seat is returned to its horizontal position. Before returning the seatback to its original position, make sure that cargo or any objects are not trapped underneath the seatback.
Page 75 Seating and Safety Restraints In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a safety belt. Each seating position in your vehicle has a specific safety belt assembly which is made up of one buckle and one tongue that are designed to be used as a pair.
Page 76 Seating and Safety Restraints Vehicle sensitive retractor The vehicle sensitive retractor allows free shoulder belt length adjustment to your movements and locks in response to vehicle movement. For example, if the driver brakes suddenly or turns a corner sharply, or the vehicle receives an impact of approximately 5 mph (8 km/h) or more, the combination safety belts will lock to help reduce forward movement of the driver and passengers.
Page 77 Seating and Safety Restraints • Crew Cab To lower the shoulder belt height, push the button and slide the height adjuster down. To raise the height of the shoulder belt, slide the height adjuster up. Pull down on the height adjuster to make sure it is locked in place.
Page 78 Seating and Safety Restraints Insert the tongue into the correct buckle (the buckle closest to the direction the tongue is coming from). To lengthen the belt, turn the tongue at a right angle to the belt and pull across your lap until it reaches the buckle.
Page 79 Seating and Safety Restraints BeltMinder The BeltMinder feature is a supplemental warning to the safety belt warning function. This feature provides additional reminders to the driver that the driver’s safety belt is unbuckled by intermittently sounding a chime and illuminating the safety belt warning lamp in the instrument cluster.
Page 80 Seating and Safety Restraints Reasons given... Consider... “Belts are uncomfortable” We design our safety belts to enhance comfort. If you are uncomfortable - try different positions for the safety belt upper anchorage and seatback which should be as upright as possible;...
Page 81 Seating and Safety Restraints Do not sit on top of a buckled safety belt to avoid the Belt Minder chime. Sitting on the safety belt will increase the risk of injury in an accident. To disable (one-time) or deactivate the Belt Minder feature please follow the directions stated below.
Page 82 Seating and Safety Restraints 4. Turn on the parklamps/headlamps, turn off the parklamps/headlamps. 5. Buckle then unbuckle the safety belt three times, ending with the safety belt unbuckled. • After step 5 the safety belt warning light will be turned on for three seconds.
Page 83: Child Restraints
Ford Motor Company recommends that all safety belt assemblies used in vehicles involved in a collision be inspected for proper function and replaced, if necessary. Safety belt assemblies not in use during a collision should also be inspected and replaced if either damage or improper operation is noted.
Page 84 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster. Booster seats position a child so that safety belts fit better. They lift the child up so that the lap belt rests low across the hips and the knees bend comfortably.
Page 85 Seating and Safety Restraints • Can the child sit all the way back against the vehicle seat back with knees bent comfortably at the edge of the seat without slouching? • Does the lap belt rest low across the hips? •...
Page 86 Seating and Safety Restraints The shoulder belt should cross the chest, resting snugly on the center of the shoulder. The lap belt should rest low and snug across the hips, never up high across the stomach. If the booster seat slides on the vehicle seat, placing a rubberized mesh sold as shelf or carpet liner under the booster seat may improve this condition.
Page 87 • Place seat back in upright position. Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position with a tether anchor. For more information on top tether straps and anchors, refer to Attaching safety seats with tether straps.
Page 88 Seating and Safety Restraints Installing child safety seats with combination lap and shoulder belts 1. Position the child safety seat in a seat with a combination lap and shoulder belt. Children under 12 are safer when properly restrained in the rear seat, to the extent this is possible.
Page 89 Rebuckle the belt. Obtain the locking clip kit (part number FO3Z-5461248–A) at no charge from an authorized Ford or Lincoln Mercury dealer. 5. Before placing the child in the seat, forcibly tilt the seat forward and back to make sure the seat is securely held in place. To check this, grab the seat at the belt path and attempt to move it side to side and forward and back.
Page 90 Tether anchorage hardware kits (part number 613D74) including instructions, may be obtained at no charge from any Ford or Lincoln Mercury dealer. If you have a SuperCab or Crew Cab, Ford recommends you attach...
Page 91: Driving
Driving STARTING Positions of the ignition 1. ACCESSORY, allows the electrical accessories such as the radio to operate while the engine is not running. 2. LOCK, locks the steering wheel, automatic transmission gearshift lever and allows key removal. For vehicles equipped with a manual transmission, you must depress the ignition release lever to release the key.
Page 92 Driving Note: When starting the engine, do not press the accelerator as engine damage may result. 1. Ensure headlamps and all accessories are turned off, the parking brake is applied and the transmission is in the neutral position (or P [Park] for Allison 2200 transmissions).
Page 93 Driving • Do not increase engine speed until the oil pressure gauge indicates normal pressure; this should be indicated on the gauge within 15 seconds after starting. • Idle the engine for three to five minutes before operating with a full load.
Page 94 Driving a buildup of heavy deposits of carbon and rust on valve stems causing them to stick which, in turn, can cause valvetrain damage. The following cold weather idling guidelines must be followed: • Avoid idling the engine for more than 10 minutes at a time. •...
Page 95 Driving disengage the clutch and try to increase engine RPM as this may damage driveline components. The engine will recover as the vehicle begins moving. Engine shutdown Allow the engine to idle for three to five minutes before shutting it down.
Page 96 Driving Backing up To reduce the risk of the possibility of personal injury while backing the vehicle, always be sure your vehicle’s path is clear. Before backing your vehicle, be sure you can do so safely. If anything behind the cab limits your view, do not rely on mirrors alone to ensure that your intended path is clear.
Page 97 Driving ENGINE AUTOMATIC SHUTDOWN WARNING LIGHT OR CHIME (IF EQUIPPED) Your vehicle may be equipped with an automatic shutdown feature that stops the engine in the event of high coolant temperature, low engine oil pressure or low engine coolant level. A warning light in the instrument cluster and a warning chime will indicate high engine coolant temperature or low engine oil pressure.
Page 98 Driving road dust, salt or mud. If a “metal-to-metal,” “continuous grinding” or “continuous squeal” sound is present while braking, the brake linings may be worn-out and should be inspected by a qualified service technician. Know the required stopping distances for all driving conditions that may be encountered.
Page 99 Driving The reserve system provides reduced braking power, so the vehicle should be operated under these conditions with caution, and only to seek service repair and remove the vehicle from the roadway. If braking performance or pedal response becomes very poor, even when the pedal is strongly applied, this may indicate the presence of air in the hydraulic system or fluid leakage.
Page 100: Brakes
Driving Parking brake Apply the parking brake whenever the vehicle is parked. To set the parking brake, pull handle up until it snaps into the locked position. Do not use the gearshift selector in place of the parking brake. Always set the parking brake fully AND make sure the gearshift selector is in R (Reverse) for vehicles equipped...
Page 101 Driving Push the palm release lever on the parking brake handle and push down as far as possible to release the brake. Driving with the parking brake on will cause the brakes to wear out quickly and reduce fuel economy. If the parking brake is fully released but the parking brake warning lamp remains...
Page 102 Driving Releasing the parking brake Note: Read and understand the following steps and perform them whenever you prepare to drive the vehicle. Note: The parking brake will not disengage unless sufficient system air pressure is available. For vehicles with automatic transmissions - dash-mounted push button (Allison 3000 Series) and steering column-mounted (Allison 2200 and 2500) gear selection: 1.
Page 103 Driving yellow control knob is pulled out again, the light will blink and the chime will sound as a reminder that immediate service is required to the parking brake system. Releasing spring manually Do not attempt to disassemble the parking brake chamber under any circumstances.
Page 104 Driving AIR BRAKES (IF EQUIPPED) General air brake information After starting the engine, give the air compressor time to build up the air pressure to 60 psi (414 kPa) before moving the vehicle. Do not drive or continue to drive if the low air pressure buzzer is sounding or the brake warning light is lit.
Page 105 Driving Air chamber stroke indication Air chamber push rods have orange stroke indicator stripes that alert the operator when the braking system requires adjustment or repair. The orange stripe is painted on the air chamber push rod at the slack adjuster readjustment stroke dimension.
Page 106 Driving Drain all the air brake reservoirs daily, completely to 0 psi/kPa, by opening the draincock at the ends of the tanks (where accessible. Pull-chains are used when the drains are undercab or otherwise inaccessible). Close draincock after complete draining. Air tanks equipped with automatic moisture ejector valves may also be drained manually as required to maintain a...
Page 107 Driving Parking brake control (knob) Pull the yellow parking brake knob out to apply the parking brake. Push the knob in to release the parking brake. This control is used for parking only. Do not leave the vehicle unattended after setting the parking brake without placing the transmission in R (Reverse) for manual...
Page 108 Driving Releasing spring brake manually Do not attempt to disassemble the parking brake chamber under any circumstances. The high spring load may cause serious injury if the chamber clamps are removed. If air pressure is released from the spring brake chamber the power spring applies the brake and, unless air pressure can be re-established, the spring brake must be released as follows in order to move the vehicle.
Page 109 Driving 4. Turn the release stud one-quarter turn to engage the stud tangs with the slot in the pressure plate. Keep the stud engaged and install the nut on the release stud. 5. Tighten the nut until the spring is fully caged and the brakes are released.
Page 110 Driving The exhaust brake is a butterfly type valve mounted in the exhaust pipe. When the operator’s foot is not on the accelerator pedal and the exhaust brake switch is in the ON position, an air cylinder shuts the butterfly valve, restricting the flow of exhaust gases and retarding the engine.
Page 111 Driving Note: Maximum exhaust brake performance is related to the type of transmission your vehicle is equipped with. Note: Manual transmissions should be downshifted to the lowest gear possible, without exceeding the maximum RPM limit of the engine. This will maximize the exhaust brake’s retarding effect. Note: Exhaust brakes will operate effectively with automatic transmission, but performance will vary with engine speed and the gear selected by the transmission.
Page 112 Driving • Depending on the grade and vehicle load, you may or may not feel the retarding force acting against your body when the brake is applied. The brake’s retarding force is actually preventing the vehicle from going much faster. •...
Page 113 Driving To apply the trailer brakes using the hand control, move the lever downward. The further the lever is pushed downward, the greater the air pressure is applied to the brakes. The lever will remain in place until manually moved. To release the trailer brakes, move the lever upward completely.
Page 114 Driving Initial charge With the air system completely discharged, both knobs (1 and 2) will be out. When the air pressure reaches 70 psi (483 kPa) the trailer air supply (1 – red knob) may be pushed in and should stay in charging the trailer air system and releasing the trailer brakes.
Page 115 Driving Normal driving position With both knobs pushed in, air is then supplied to both trailer and tractor spring brakes, and all brakes are released. System park With both knobs pushed in (normal driving position), the parking brakes for both the tractor and trailer can be applied by pulling the parking brake knob (2) out, exhausting air from the tractor spring brakes, simultaneously causing the trailer air supply valve to pop out, applying the trailer brakes.
Page 116 Driving Trailer charge If both knobs are out, and you want to recharge the trailer while leaving the tractor spring brakes applied, the trailer air supply (1) can be pushed in to recharge the trailer air supply line. This mode may also be used to park a combination vehicle with tractor spring brakes.
Page 117 Driving Actuation of trailer park (emergency) or tractor bobtail position To actuate the trailer brakes only, pull out the trailer air supply knob (1). The trailer brakes are now applied whether emergency or spring brakes are used on the trailer. This mode is also used when the tractor or truck with trailer is used during bobtail operation.
Page 118 Driving illuminate momentarily at start up, remains on after the vehicle reaches 5–10 mph (10–15 km/h), or continues to flash, the ABS needs to be serviced. With the ABS light on, the anti-lock brake system is disabled and normal braking is still effective unless the brake warning light also remains illuminated.
Page 119: Air Suspension
Driving If you should become stuck in snow or ice or on a very slippery road surface, try switching the Traction Control system off. This may allow excess wheel spin to “dig” the vehicle out and enable a successful “rocking” maneuver. Aggressive driving in any road conditions can cause you to lose control of your vehicle increasing the risk of severe personal injury or property damage.
Page 120 Driving Tractor-trailer connections To reduce the risk of personal injury, use extreme caution when making brake and light connections. Inclement weather and accumulated road contamination deposits on handhold and stepping surfaces require extra care to avoid slip and falls. Provide adequate lighting of working areas.
Page 121: Transmission Operation
Driving AUTOMATIC TRANSMISSION OPERATION (IF EQUIPPED) Main transmission, auxiliary transmission, transfer case and power take-off (PTO) control shift patterns can be found on a placard or decal on the driver’s sun visor, on the instrument panel or on the shift control itself.
Page 122 Driving Always set the parking brake fully. Do not use the gearshift in place of the parking brake. To avoid sudden, unexpected vehicle movement and possible personal injury or death: 1. Bring the vehicle to a complete stop. 2. Shift the transmission into P (Park). Slowly lift your foot from the brake pedal to engage the transmission parking pawl mechanism.
Page 123 Driving Allison 3000 Series push-button shifter To shift the transmission into R (Reverse) or D (Drive), depress the brake pedal, then press R or D, then release the brake pedal. To select a lower range when in D (Drive), press the down-arrow button. To select a higher range when in D (Drive), press the up-arrow button.
Page 124 Driving • Never coast with the clutch disengaged. The high RPM (sometimes over 10,000), can actually burst the facing material of the clutch. • Never engage the clutch while coasting. Re-engaging the clutch after coasting may not only cause a great shock to the clutch, but the whole drivetrain.
Page 125 Driving If downshifting, accelerate the engine until the engine speed matches the input speed of the gear you are selecting. Depress the clutch pedal immediately and shift into the desired gear, then release the clutch pedal. MANUAL TRANSMISSION OPERATION (IF EQUIPPED) Note: Continued use of a damaged or worn clutch, prolonged clutch slippage or downshifting at excessive speeds can result in a failure of the engine, transmission or clutch components.
Page 126 Driving • Do not lug the engine. • Do not slam or jerk the gearshift lever into gear. • When more power is required, shift to a lower gear and accelerate the engine near the governed speed. Shifting with a synchronized transmission With the clutch pedal depressed, use 2 (Second) gear synchronizer to stop the clutch disc rotation;...
Page 127 Driving Operating the Eaton FS–5406A, FS–5406N, FS–6406A and FS–6406N 6-speed transmissions These 6-speed transmissions are equipped with six forward gears and one reverse. All the forward gears are synchronized. The shift pattern is embossed on the gear shift knob. Do not shift the transmission into 1 (First) or R (Reverse) while the vehicle is moving as this could damage the transmission.
Page 128 Driving To go backward Reverse is obtained by putting the gearshift lever in R (Reverse) and engaging the clutch while pressing lightly on the accelerator. Operating the Eaton 8908LL 10-speed transmission These transmissions have five forward speeds in the LO range, and four forward speeds in the HI range.
Page 129 Driving To start forward, place the gearshift lever in LO gear and disengage the clutch while slightly depressing the accelerator. Operate the clutch and upshift through the shift pattern (up to 4th) as required by driving conditions. To shift into the HI range from 4th gear (LO range), place the range control button in the HI range, then shift to 5th gear.
Page 130 Driving Operating the Eaton 9210B 10–speed transmissions These transmission have five forward speeds in both the LO and HI ranges, and two reverse speeds. Study the instruction plate on the sun visor and learn the shift pattern Neutral of your transmission. To go forward With the engine idling, depress the clutch pedal and push the range...
Page 131 Driving POWER TAKE-OFF (PTO) OPERATION Vehicles equipped with an Allison automatic transmission (except 3000 Series applications and vehicles equipped with a Caterpillar engine) The PTO can be operated while the vehicle is standing or moving. To engage the PTO, apply the brakes and shift to any gear other than N (Neutral), then engage the PTO.
Page 132 Driving Vehicles equipped with an Allison 3000 Series automatic transmission The PTO drive gear is engine driven and provides direct engine power. The PTO can be operated when the vehicle is either stationary or moving. The PTO gear is in constant mesh with the drive gear in the torque converter housing.
Page 133 Driving Rear axles with locking or limited-slip differentials If your vehicle is equipped with a locking or limited-slip differential, note the following: • Power will be transmitted to the opposite wheel should one of the wheels begin to slip. • Both wheels must be raised off the ground should it be necessary to operate one wheel with the vehicle stationary.
Page 134 Driving are not slipping. The differential must not be locked when the vehicle is traveling down steep grades and traction is minimal. Note: Never use the differential lock at vehicle speeds above 25 mph (40 km/h). Note: The driver-controlled differential lock function will vary with some transmissions.
Page 135 Driving Note: Do not shift between ranges when the speed control is on. Never shift a two-speed axle when descending a steep grade as this may cause loss of vehicle control and result in personal injury. Axle shifting Manual transmissions: •...
Page 136: Vehicle Loading
Axle High MAXIMUM VEHICLE LOADING Every vehicle manufactured by Ford Motor Company is supplied with information on the Vehicle Rating Decal listing the maximum loading for the vehicle (GVWR), and its axle systems (GAWR) at the tire to ground interface.
Page 137 Driving • U.S. • Canada Under no circumstances should your vehicle be loaded in excess of the GVWR or GAWR. It is the operator’s responsibility to ensure that neither the axle capacities, spring capacities, tire capacities nor the vehicle rated GVWR is exceeded.
Page 138 Driving When operating empty or lightly loaded, sudden or hard braking may induce wheel lockup with loss of vehicle control and the possibility of accident and serious injury, especially on wet or slippery road surfaces. TRAILER TOWING Towing a trailer places an additional load on your vehicle’s engine, transmission, axle, brakes, tires and suspension.
Page 139 Driving Safety chains Always connect the trailer’s safety chains to the frame or hook retainers of the vehicle hitch. To connect the trailer’s safety chains, cross the chains under the trailer tongue and allow slack for turning corners. If you use a rental trailer, follow the instructions that the rental agency gives to you.
Page 140 Driving Trailer towing tips • Practice turning, stopping and backing up before starting on a trip to get the feel of the vehicle trailer combination. When turning, make wider turns so the trailer wheels will clear curbs and other obstacles. •...
Page 141 Driving Before hook-up, make sure: • The fifth wheel jaws are fully opened. • The fifth wheel is fully tilted back to prevent body damage when the tractor is backed under a trailer. • The trailer wheels are blocked and the trailer spring brakes are adjusted and applied.
Page 142 Driving Un-hook 1. Try to keep the tractor and trailer in a straight line. 2. Apply the parking brakes. 3. Lower the trailer landing gear, making sure it is on solid, level ground. The weight of the trailer is to be on the landing gear. 4.
Page 143: Roadside Emergencies
Roadside Emergencies GETTING ROADSIDE ASSISTANCE To fully assist you should you have a vehicle concern, Ford offers a complimentary roadside assistance program. This program is separate from the New Vehicle Limited Warranty and is not applicable to vehicles sold in Canada. The service is available: •...
Page 144: Hazard Flasher Switch
Roadside Emergencies HAZARD FLASHER The hazard flasher control is located on the steering column, just behind the steering wheel. The hazard flashers will operate when the ignition is off. Push in the flasher control and all front and rear direction signals will flash.
Page 145 Roadside Emergencies Passenger compartment fuse panel Fuse/Relay Fuse Amp Fuse Description Location Rating Horn Turn/Hazard lamps Cigar lighter Diagnostic connectors Back-up lamps, DRL relays, Blend door actuator, Heated seat module, Trailer ABS relay — Not used — Not used Radio, GEM Switch illumination (Headlamp, Power windows, Power door locks), Power window relay Heated/Lighted mirrors...
Page 146 Roadside Emergencies Fuse/Relay Fuse Amp Fuse Description Location Rating High beams — Not used Headlamp switch, GEM Engine ECM (Caterpillar and Cummins engines) Engine ECM, Accel, Crank (6.0L Power Stroke engine only) Starter relay, GEM Daytime Running Lamps (DRL) Air solenoid 4–pack (Air horn, Air suspension dump, Differential lock axle and Two-speed axle) Electronic flasher...
Page 147 Roadside Emergencies Power distribution box Always disconnect the battery before servicing high current fuses. Fuse/Relay Fuse Amp Fuse Description Location Rating 15A* Park lamps, Roof lamps 30A* Power seat (driver) 30A* Power seat (passenger) 15A* Washer pump 15A* Exhaust brake (Caterpillar and Cummins engines only) 15A* Air intake heater (Caterpillar engine only)
Page 148 Roadside Emergencies Fuse/Relay Fuse Amp Fuse Description Location Rating 20A* Daytime Running Lamps (DRL), Blend door actuator, Climate mode, Back-up, Heated seats, Trailer ABS, Exhaust brake — Not used — Not used 7.5A* Body builder prep/trailer socket stop (6.0L Power Stroke engine only) WABCO hydraulic ABS Run feed —...
Page 149 Roadside Emergencies Fuse/Relay Fuse Amp Fuse Description Location Rating 30A** Wiper power relay (Park, Low/High speed) 30A** Body builder prep 40A** Blower motor 30A** Heated seats 25A** WABCO ABS battery feed (Hydraulic brake vehicles only) 20A** Ignition switch, Central Junction Box fuses 8, 9, 10, 11, Starter motor relay 30A** Body builder prep...
Page 150 Roadside Emergencies Fuse/Relay Fuse Amp Fuse Description Location Rating — Air ABS relay Hydraulic modulator relay — Not used — Not used — Not used — Not used * Mini fuse **Maxi fuse Air brake trailer tow relays (if equipped) Fuse/Relay Fuse Amp Description...
Page 151: Jump Starting
Roadside Emergencies Fuse/Relay Fuse Amp Description Location Rating — Trailer tow stop lamp relay — Trailer tow park/marker lamp relay — Trailer tow tail lamp relay — Not used — Not used — Trailer tow left turn/stop lamp relay (combined) Trailer tow left turn lamp relay (separate) —...
Page 152 Roadside Emergencies Before connecting a fast-charger, booster battery or installing a new battery, make sure the ground polarities of the fast-charger, booster battery or alternator (when installing a battery) are matched to the ground polarity of the vehicle battery. Improper usage of the fast-charger, hook-up of booster battery or installation of a new battery can cause damage to the electrical system or to the alternator.
Page 153 Roadside Emergencies 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery. 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system.
Page 154 Roadside Emergencies Jump starting 1. Start the engine of the booster vehicle and run the engine at moderately increased speed. 2. Start the engine of the disabled vehicle. 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables.
Page 155: Wrecker Towing
Roadside Emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 156 Roadside Emergencies To reduce the risk of personal injury or property damage when manually releasing the spring brakes, be sure to block the wheels so the vehicle cannot move once the brakes are released. Towing the vehicle with the front wheels suspended When it is necessary to tow a vehicle with the front wheels suspended, extra precautions must be taken to avoid transmission or differential damage.
Page 157 Roadside Emergencies 1. Shift collar in the locked position 2. Actuator assembly and shift fork 3. Axle shaft 4. Interference between the shift collar and housing 5. Shift collar in the unlocked position 6. Outer splines - axle shaft to collar 7.
Page 158 Roadside Emergencies Installing the axle shafts 1. Remove the covers from the wheel ends 2. Shift the differential lock to the unlocked position (disengaged) position. 3. Install the axle shafts • Place the gaskets on the wheel hub studs. • Push the right-hand axle shaft and gasket into the wheel end and housing until the shaft stops against the differential shift collar.
Page 159: Customer Assistance
It is preferred that you return to the authorized dealer where your vehicle was purchased when warranty repairs are needed. However, you may also take your vehicle to another Ford Motor Company or Ford of Canada dealership authorized for warranty repairs.
Page 160 Customer Assistance In order to help you service your Ford vehicle, please have the following information available when contacting the Commercial Vehicle Hotline: • Your telephone number (home and business) • The name of the dealer and the city where the dealership is located •...
Page 161: Getting Assistance Outside The U.s And Canada
If your vehicle must be serviced while you are traveling or living in Central or South America, the Caribbean, or the Middle East, contact the nearest Ford dealership. If the dealership cannot help you, write or call: FORD MOTOR COMPANY...
Page 162: Ordering Additional Owner's Literature
Obtaining a French owner’s guide French Owner’s Guides can be obtained from your dealer or by writing to Ford Motor Company of Canada, Limited, Service Publications, P.O. Box 1580, Station B, Mississauga, Ontario L4Y 4G3. REPORTING SAFETY DEFECTS (U.S. ONLY)
Page 163: Cleaning
Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral pH shampoo, such as Motorcraft Detail Wash (ZC-3–A), which is available from your dealer. • Never use strong household detergents or soap, such as dish washing or laundry liquid.
Page 164 Cleaning • Remove particles such as bird droppings, tree sap, insect deposits, tar spots, road salt and industrial fallout before repairing paint chips. • Always read the instructions before using the products. ALUMINUM WHEELS AND COVERS • Clean with Motorcraft Wheel and Tire Cleaner (ZC-37–A), which is available from your dealer.
Page 165 For fabric, carpets, cloth seats and safety belts: • Remove dust and loose dirt with a vacuum cleaner. • Remove light stains and soil with Ford Extra Strength Upholstery Cleaner (E8AZ-19523–AA). • If grease or tar is present on the material, spot-clean the area first with Motorcraft Spot and Stain Remover (ZC-14).
Page 166: Underbody Preservation
Flush the complete underside of your vehicle frequently. Keep body and door drain holes free from packed dirt. FORD CAR CARE PRODUCTS Your vehicle’s dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs;...
Page 167 Cleaning Motorcraft Deluxe Leather and Vinyl Cleaner (U.S. only) (ZC-11–A) Motorcraft Detail Wash (ZC-3–A) Motorcraft Dusting Cloth (ZC-24) Motorcraft Engine Shampoo and Degreaser (U.S only) (ZC-20) Motorcraft Engine Shampoo (Canada only) (CXC-66-A) Motorcraft One Step Wash and Wax Concentrate (ZC-6-A) Motorcraft Paint Sealant (ZC-45) Motorcraft Premium Car Wash Concentrate (U.S.
Page 168: Maintenance And Specifications
Maintenance and Specifications GENERAL SERVICING GUIDELINES AND PRECAUTIONS As with any machine, care should be taken to avoid being injured when performing maintenance, repairs or system checks. Improper or incomplete service could result in the vehicle not working properly which, in turn, may result in personal injury or damage to the vehicle or equipment.
Page 169 Maintenance and Specifications vehicle at least once a year. Remember that regular maintenance and replacement of worn components will usually prevent serious problems from developing later. Making modifications to various parts, components and systems of the vehicle, such as brake and steering systems can adversely affect the quality, reliability and operation of your vehicle and could result in property damage, personal injury or death.
Page 170 Maintenance and Specifications Check to make sure that the axle mounting U-bolt nuts, attaching or mounting bolts and nuts are securely tightened. Regularly check front axle for damage, binding, worn parts and adequate lubrication. At regular intervals, or during other scheduled maintenance, (tire rotation/service, wheel bearing service, alignment, etc.) the kingpins should be checked for excessive wear.
Page 171 Maintenance and Specifications non-asbestos, fiberglass, mineral wool, aramid or carbon) may be a potentially serious health hazard. Avoid breathing brake lining fiber dust as it may be extremely hazardous to your health. Always use a respirator during brake maintenance. Note: Persons handling brake linings should follow all precautions listed below: 1.
Page 172 Maintenance and Specifications interval to determine if adjustment is necessary. Brake chamber push rods on original equipment chambers now incorporate a stroke indicator to aid in adjustment checks; an orange paint marker near the base of the push rod. If the push rod is clean and the brakes require adjustment, the orange marker can be seen protruding from the chamber when the brakes are applied.
Page 173 Maintenance and Specifications Air brakes - desiccant air dryer Inspect for moisture in the air system by opening reservoirs, drain cocks or valves and checking for presence of water. The presence of small amounts of water due to condensation is normal and should not be considered as an indication that the dryer is not functioning properly.
Page 174 Maintenance and Specifications power steering fluid and hydraulic brake fluid. Failure to observe precautions preventing the contamination of either system with fluid from the other will result in swelling and deterioration of rubber parts leading to reduced brake performance and eventual brake failure. To avoid fluid contamination, the following should always be observed: 1.
Page 175: Hood
Maintenance and Specifications Note: If your vehicle is equipped with a vertical exhaust pipe, it is very important to have and maintain a rain cap on the exhaust pipe to prevent water from entering the exhaust system and catalytic converter. Any water entering the catalytic converter may damage the catalyst and affect the function of the converter.
Page 176 Maintenance and Specifications If you must leave the engine running while checking under the hood, do not allow any loose clothing, jewelry, hair or other items to get near moving engine components or possible personal injury may occur. To open the hood: 1.
Page 177: Engine Oil
Maintenance and Specifications 4. Tilt the hood forward until stopped by the retaining cables. To lower the hood: 1. Push the hood rearward at the top center of the hood above the grille until closed. 2. Engage the latch on each fender. 3.
Page 178 Maintenance and Specifications 5. Open the hood. 6. Locate and carefully remove the engine oil dipstick. 7. Wipe the dipstick clean. Insert the dipstick fully, then remove it again. • If the oil level is between ADD and OPERATING RANGE, the oil level is acceptable.
Page 179 Diesel engine oils with improved fuel economy properties (energy conserving) are currently available. If you use an energy conserving oil, be sure it meets Ford specification WSS-M2C171–D or API service category designation CI-4/SL and is of the proper viscosity grade for the temperature range in which you expect to operate your vehicle.
Page 180 CI-4 PLUS. The center section of the API symbol shows the SAE viscosity grade. Use a Ford engine oil filter, part number FL-1995 or equivalent. This filter protects your engine by filtering harmful, abrasive or sludge particles. 2006 F-650/750 (f67)
Page 181 Maintenance and Specifications ENGINE COOLING SYSTEM If your vehicle is equipped with a Caterpillar or Cummins engine, refer to your engine operator’s manual for engine coolant check and adding instructions as well as fluid specifications and capacities. Inspect cooling system daily Note: The engine coolant reservoir requires air space for expansion volume.
Page 182 Extended life engine coolant Note: Add the coolant type originally equipped in your vehicle. The cooling system in your vehicle is filled with yellow-colored Motorcraft Premium Gold Engine Coolant meeting Ford Specification WSS-M97B51–A1. • Add Motorcraft Premium Gold Engine Coolant (yellow-colored), VC-7–A (VC-7–B in CA, NM and OR).
Page 183 • Do not add extra inhibitors or additives to the coolant. These can be harmful and compromise the corrosion protection of the engine coolant. • Do not mix with recycled coolant unless from a Ford-approved recycling process (see Use of Recycled Engine Coolant section). Coolant condition inspection Engine cooling systems should be checked twice a year to ensure proper glycol/water concentrations.
Page 184 Maintenance and Specifications • It may be necessary to increase the coolant concentration above 50%. • NEVER increase the coolant concentration above 60%. • Engine coolant concentrations above 60% will decrease the overheat protection characteristics of the engine coolant and may cause engine damage.
Page 185 Maintenance and Specifications WINDSHIELD WASHER FLUID The reservoir capacity is 4.0 quarts (3.8L); use windshield washer fluid that meets the Ford specification listed. Refer to Lubricant specifications in this chapter. Inspect the fluid level in the washer reservoir when insufficient fluid is sprayed.
Page 186: Battery
Maintenance and Specifications BRAKE FLUID Check and refill the HydroMax brake fluid reservoir using the following procedure. Refer to the Scheduled Maintenance Guide chapter for the service interval. 1. Clean the reservoir caps before removal to prevent dirt or water from entering the reservoir.
Page 187 Maintenance and Specifications • Covered battery tray shown. Battery tray with steps similar. The two rubber straps on top of the cover must be pulled up and moved to the side of the battery in order to remove the lid. •...
Page 188 Maintenance and Specifications If the engine cranks but does not start, remove the battery box cover and check the 40A inline fuse loacted on the battery cable above the battery. Batteries normally produce explosive gases which can cause personal injury. Therefore, do not allow flames, sparks or lighted substances to come near the battery.
Page 189 Maintenance and Specifications • Check tie rod, drag link end clamp bolts and ball joints. They must be tight. • Check for installation and spread of cotter pins and tightness of nuts at both ends of the tie rod and drag link. •...
Page 190 Maintenance and Specifications 2. Open the hood. 3. Clean the top of the power steering fluid reservoir. 4. Remove the dipstick from the reservoir and wipe the dipstick clean. 5. Reinstall the dipstick. Remove it again and check the fluid level. •...
Page 191 Maintenance and Specifications During normal operation, the fluid level in the clutch reservoir should remain constant. If the fluid level drops, maintain the fluid level at the step in the reservoir. Use only a DOT 3 brake fluid designed to meet manufacturer specifications.
Page 192 Maintenance and Specifications 4. Lubricate clutch release wear pads at the two locations where they contact the clutch release bearing using a brush or similar tool. 5. Install the inspection cover onto the clutch housing. TRANSMISSION FLUID Always dispose of used automotive fluids in a responsible manner. Follow your community’s standards for disposing of these types of fluids.
Page 193 Maintenance and Specifications Use of a non-approved automatic transmission fluid may cause internal transmission component damage. Manual transmission fluid Refer to the Scheduled Maintenance Guide chapter for transmission fluid level checks and fluid change intervals. Your manual transmission may be filled with an optional synthetic fluid which allows the use of extended service intervals.
Page 194 Maintenance and Specifications FUEL FILTER/WATER SEPARATOR Do not drain water separator while engine is running. Fuel may ignite if separator is drained while engine is running or vehicle is moving. The fuel filter/water separator removes any contaminated particles and/or water from the fuel before the fuel enters the engine. The fuel filter/water separator should be drained as recommended in the Scheduled Maintenance Guide chapter.
Page 195 Maintenance and Specifications DRAINING THE FUEL FILTER/WATER SEPARATOR - CUMMINS B ENGINE Refer to your engine operator’s manual for service procedures. DRAINING THE FUEL FILTER/WATER SEPARATOR - CATERPILLAR ENGINE 1. With the engine off, open the drain valve located at the bottom of the fuel filter/water separator by turning it counterclockwise.
Page 196 Maintenance and Specifications INSTALLATION The engine will not run properly if the fuel filter is not installed in housing. 1. Install new fuel filter into the fuel filter housing. 2. Tighten cap onto fuel filter housing slowly, allowing fuel to soak into the fuel filter element.
Page 197: Fuel Information
Maintenance and Specifications REMOVAL 1. Using an oil filter wrench, remove the filter. 2. Carefully clean the mating surfaces. INSTALLATION 1. Fill the filter with clean, fresh diesel fuel. 2. Coat the filter seal with clean, fresh diesel fuel. 3. Hand-tighten the filter until it seats firmly against the mount, then tighten (by hand) an additional ⁄...
Page 198 If you must replace the fuel filler cap, replace it with a genuine Ford or Motorcraft part. The customer warranty may be void for any damage to the fuel tank or fuel system if a genuine Ford or Motorcraft fuel filler cap is not used.
Page 199 Maintenance and Specifications agricultural and non-highway use. Damage to the fuel injection system, engine and exhaust catalyst can occur if an improper fuel is used. Do not add gasoline, gasohol or alcohol to diesel fuel. This practice creates a serious fire hazard and engine performance problems.
Page 200 Maintenance and Specifications • If your vehicle is equipped with a Caterpillar engine, the fuel system must be primed before attempting to restart the engine. Refer to the engine operator’s manual for instructions on priming the engine. • Use caution not to overheat and damage the starter by cranking the engine for an excessive period of time.
Page 201 Maintenance and Specifications this chapter. The advertised capacity is the amount of the Indicated Capacity and the Empty Reserve combined. Indicated Capacity is the difference in the amount of fuel in a full tank and a tank when the fuel gauge indicates empty.
Page 202 Maintenance and Specifications • Multiply liters used by 100, then divide by total kilometers traveled. Keep a record for at least one month and record the type of driving (city or highway). This will provide an accurate estimate of the vehicle’s fuel economy under current driving conditions.
Page 203 Maintenance and Specifications Air Intake System • Air Cleaner: should be inspected and its location should not be altered. Do not alter inlet and outlet piping. Body • Wheel Well: splash shields, cab shields and under-hood insulation should be inspected for deterioration, dislocation, and orientation. Cooling System •...
Page 204 Maintenance and Specifications • Turbocharger-to-charge air cooler • Charge air cooler-to-intake manifold pipe • Mounting bracket • Chassis-mounted charge air cooler core Inspect air intake piping • Check for accumulation of salt deposits (where applicable). If present, disassemble and clean the complete air intake piping system. If the intake piping is pitted, use Motorcraft Silicone Gasket and Sealant TA-30 to seal joints against leakage.
Page 205 Maintenance and Specifications Verify drive axle air suspension height and height control valve performance at engine lube oil change intervals. Periodically: • Check condition of spring leaves for evidence of fatigue, bending or breakage. • Check condition of suspension mounting brackets and bushings. •...
Page 206 Maintenance and Specifications FRAME AND TOW HOOKS Your vehicles chassis is manufactured with frame rails of either HSLA steel or heat-treated steel. Each must be handled in a specific manner to ensure maximum service life. Before attempting frame repair or modification, consult the service manual or your dealer.
Page 207 Maintenance and Specifications 6. Re-torque the nuts to 425 ft. lb (576 N•m), using a diagonal pattern. (For vehicles equipped with 14ACC, 14 ADN and 14ADP axles.) 7. Use the same diagonal pattern with each U-bolt nut re-torque. Spring U-bolt checks Check U-bolt nuts and re-torque every 36,000 miles (58,000 km) after initial 1,000 miles (1,600 km) re-torque.
Page 208 Maintenance and Specifications Draining and refilling the rear axle lubricant 1. Drain the rear axle while the lubricant is warm. 2. Park the vehicle on level ground. 3. Set the parking brake and shift into N (Neutral) (automatic transmission) or 1 (First) (manual transmission) and turn the engine off. 4.
Page 209 Maintenance and Specifications Normal maintenance Over a period of time, if not routinely cleaned, a slight film of oil can collect dirt around the rubber fill plug and face, which could appear to be a leak. Routine cleaning ensures that the lube level can be easily observed through the clear window as intended.
Page 210 Maintenance and Specifications After the rim or wheel has been properly tightened, it should be checked for alignment. Rotate the wheel with a piece of chalk attached to a steady, firm surface, and placed to just barely clear the outside surface of the tire bead seat.
Page 211 Maintenance and Specifications 1. Slide inner rear or front tire and wheel in position over studs and push it back as far as possible. Use care so that the threads on studs are not damaged. 2. Position the outer rear tire and wheel in place over the studs and push it back as far as possible.
Page 212 Maintenance and Specifications Aluminum rear disc wheel with flange nuts (hub-piloted) 1. Flange nut 2. Wheel(s) 3. Brake drum 4. Wheel stud (22 mm) 5. Wheel hub 6. Wheel locator pad Prior to re-installing rear aluminum hub-piloted wheels, clean each wheel locator pad on the hub from all dirt, rust and foreign material.
Page 213 Maintenance and Specifications • Always loosen rim clamps before complete removal of nut from stud (cast spoke wheels). With loosened nuts on stud, strike clamps with a heavy hammer and be sure each clamp is loose. • Always deflate tires completely before removing locks or side rings. •...
Page 214 Maintenance and Specifications WHEEL NUT TORQUE Torque Size Nut mounting Ft. lb. N•m 22 mm Flange 450–500 610–678 Note: Do not use lubrication on dry threads. Where excessive corrosion exists, a light coat of lubricant on the first three threads of the stud bolt is permitted.
Page 215 Maintenance and Specifications Axle capacity Load Approved Front - lb. Rear - lb. Tire size range rim widths (kg)/psi (kg)/psi (kPa) (kPa) 10000 (4536) / 20000 (9072) / 6.75 115 (793) 115 (793) 10R22.5 11350 (5148) / 21420 (9716) / 7.50 115 (793) 115 (793)
Page 216 Maintenance and Specifications Axle capacity Load Approved Front - lb. Rear - lb. Tire size range rim widths (kg)/psi (kg)/psi (kPa) (kPa) 14400 (6531) / 27760 (12591) 8.25 120 (827) / 120 (827) 295/80R22.5 14780 (6704) / 27760 (12591) 9.00 120 (827) / 120 (827) Tire inflation information...
Page 217 Maintenance and Specifications Stay out of the trajectory as indicated in the illustration. Under some circumstances, the trajectory may deviate from the suspected path. 2006 F-650/750 (f67) Supplement USA (fus)
Page 218: Lubricant Specifications
Maintenance and Specifications LUBRICANT SPECIFICATIONS Viscosity / Equivalent Lubrication Ambient Component Ford part type temperature / name / number Notes Non-driving front axle Eaton-Spicer Multipurpose EP SAE 75W: –40°F Motorcraft SAE axle (generic) - gear lube of API to –15°F (–40°C...
Page 219 Maintenance and Specifications Viscosity / Equivalent Lubrication Ambient Component Ford part type temperature / name / number Notes Spicer axle - Multipurpose EP SAE 75W: –40°F Motorcraft SAE front axle wheel gear lube of API to 32°F (–40°C 75W-90 Fuel...
Page 220 Maintenance and Specifications Viscosity / Equivalent Lubrication Ambient Component Ford part type temperature / name / number Notes Eaton-Spicer EP2 Lithium Note: Motorcraft axle, Spicer axle complex-based Eaton-Spicer Premium Long - Front axle moly grease (or and Meritor Life Grease /...
Page 221 Maintenance and Specifications Viscosity / Equivalent Lubrication Ambient Component Ford part type temperature / name / number Notes Propeller shaft U-joint GC/LB NLGI #2 — Motorcraft lithium Premium Long complex-based Life Grease / moly grease or XG-1-C multi-purpose lithium complex...
Page 222 Maintenance and Specifications Viscosity / Equivalent Lubrication Ambient Component Ford part type temperature / name / number Notes Transmission Eaton-Fuller Petroleum oil: SAE 50: above — Engine oil 10°F (–12°C) API-SL or API-CF SAE 40: below — (MIL-L-2104E or 10°F (–12°C)
Page 223 Maintenance and Specifications Viscosity / Equivalent Lubrication Ambient Component Ford part type temperature / name / number Notes Spicer (non- Petroleum oil: SAE 50: above — synchronized) Engine oil 0°F (–18°C) (lubricants are API-SL or listed in order of API-CF SAE 40: below —...
Page 224 Maintenance and Specifications Viscosity / Equivalent Lubrication Ambient Component Ford part type temperature / name / number Notes Spicer Petroleum oil: SAE 50: above — (synchronized) Engine oil 10°F (–12°C) (lubricants are API-SL or listed in order of API-CF SAE 40: below —...
Page 225 Maintenance and Specifications Viscosity / Equivalent Lubrication Ambient Component Ford part type temperature / name / number Notes Meritor Petroleum oil: SAE 50: above — Heavy Duty 10°F (–12°C) Engine Oil SAE 40: above — MIL-L-2104E or 10°F (–12°C) API-SL or...
Page 226 Maintenance and Specifications Viscosity / Equivalent Lubrication Ambient Component Ford part type temperature / name / number Notes Rear axle Eaton-Spicer - RHEOLUBE 362 — — two-speed axle (or equivalent) (Eaton part number 113741) Eaton - Generic SAE 75W: –40°F...
Page 227 Maintenance and Specifications Viscosity / Equivalent Lubrication Ambient Component Ford part type temperature / name / number Notes Spicer - Multipurpose EP SAE 75W: –40°F Motorcraft SAE single-speed gear lube of API to 32°F (–40°C 75W-90 Fuel axle GL-5 quality to 0°C)
Page 228 Maintenance and Specifications Viscosity / Equivalent Lubrication Ambient Component Ford part type temperature / name / number Notes Meritor - Fill at the — — single-speed factory with axle Synthetic SAE 75W-90, will have a tag attached to fill plug that reads as follows: “Filled with...
Page 229 Maintenance and Specifications Viscosity / Equivalent Lubrication Ambient Component Ford part type temperature / name / number Notes Cab components Hydraulic lift Dexron III — Motorcraft pump fluid Mercon Multi-Purpose (ATF) Transmission Fluid / XT-2-QDX Cab latch and Mobile SHC 32 —...
Page 230 Maintenance and Specifications Viscosity / Equivalent Lubrication Ambient Component Ford part type temperature / name / number Notes Door window NGLI #2 — Motorcraft regulators multipurpose Multi-Purpose lithium complez Grease Spray / grease XL-5 or Motorcraft Multi-Purpose Grease / XG-4 Weatherstripping Silicone —...
Page 231: Refill Capacities
Maintenance and Specifications REFILL CAPACITIES Rear axle Weight Fluid capacity Axle capacity - lb. Description - pints code (kg) (liters) S135–S 13500 (6123) Single rear axle, single 24.5 (11.6) reduction 4S150–S 15500 (7031) Single rear axle, single 24.5 (11.6) reduction 17060S 17500 (7938) Single rear axle, single...
Page 232 Maintenance and Specifications Engine coolant and oil Engine coolant Engine oil Engine type (approximate (approximate capacity) capacity) 54.4 pints 19.0 quarts 6.0L Power Stroke (25.7L) (18.0L) 60.0 pints Refer to the Caterpillar (28.4L) engine operator manual for 48.8 pints engine oil refill Cummins B (23.1L) capacities.
Page 233 Maintenance and Specifications Air conditioner refrigerant - r134a Lb. (Kg) 1.87 (.85) Note: This system uses PAG-type refrigerant oil. Refrigerant fitting torque Captured washer nut: 170–190 inch lb. (19–21 N•m) Note: This system uses mineral based refrigerant oil to lubricate o-rings and fittings.
Page 234 The VIN is printed on the Vehicle Rating Decal attached to the vehicle. The VIN also serves as the warranty number. If you ever find it necessary to communicate with Ford Motor Company about your vehicle, always include the VIN in your communication.
Page 235: Scheduled Maintenance Guide
Your authorized dealer specializes in knowing all about Ford Motor Company vehicles rather than knowing a little about all makes. There are Ford or Ford of Canada dealer service shops ready to serve you wherever you drive in the U.S. or Canada. They stock Ford and Motorcraft parts, and Ford Chemicals and lubricants.
Page 236 Scheduled Maintenance Guide OWNER MAINTENANCE You can do much of the maintenance your vehicle requires yourself, if you have the time and a reasonable amount of mechanical ability. If you prefer to have this work done professionally, your authorized dealer stands ready to help you.
Page 237 Scheduled Maintenance Guide Emissions control system(s) laws Federal law prohibits vehicle manufacturers, dealers and other persons engaged in the business of repairing, servicing, selling, leasing or trading motor vehicles, as well as fleet operators from knowingly removing or rendering an emissions control device or system inoperative. Further, modifications of the emissions control system(s) could create liability on the part of individual owners under the laws of some states.
Page 238 Required Maintenance Services and in the General Maintenance Checklist. To further help minimize noise emissions degradation throughout the life of the vehicle, Ford Motor Company recommends that this vehicle should be operated in the manner described within this Owner Guide.
Page 239 Failure to maintain proper air brake adjustment can result in reduction or loss of braking ability. Air brake inspection and adjustment should be performed by a qualified service technician in accordance with the instructions in the Ford Truck Service Manual. Cam brakes - automatic slack adjusters...
Page 240 Scheduled Maintenance Guide SCHEDULED MAINTENANCE GUIDE 2006 F-650/750 (f67) Supplement USA (fus)
Page 241 Scheduled Maintenance Guide Daily owner checks Engine Check the air filter restriction gauge. Check the engine oil. Inspect the coolant level (6.0L Power Stroke engine; Caterpillar and Cummins engines, refer to the Owner’s Manual). Brake system Check the air brake system reservoir automatic drain valve operation.
Page 242 Scheduled Maintenance Guide Check every oil change (Oil change interval for the 6.0L Power Stroke engine is 10,000 miles [16,000 km]; (refer to the Caterpillar and Cummins service manuals for instructions and information) Engine system Check the engine cooling system - hoses, clamps and protection*.
Page 243 Use only permanent type coolant that meets Ford specifications WSS-M97B51-A1. See the engine manufacturer’s operating guide for supplemental corrosion inhibitor specifications.
Page 244 Scheduled Maintenance Guide Maintenance Operation Frequency - Observation Inspect the automatic slack Insufficient power shown in loaded adjuster function practice stop. Check the operation of the Vehicle handling qualities not up to brakes, the clutch, and the par. (1),(2) steering Inspect the vehicle for missing, Excessive noise emanates from under damaged, or mislocated noise...
Page 245 Scheduled Maintenance Guide Maintenance Operation Frequency - Observation Check fuel pump pressure Insufficient full-throttle power or backfiring. Clean radiator cap seal. Clean When the cap does not hold pressure. and inspect the cap surface on the radiator Check the battery terminals for Whenever electrical power supply has corrosion diminished.
Page 246 Scheduled Maintenance Guide On-Highway (60,000 miles [96,000 km] or more annually) - Miles, kilometers or months - whichever occurs first Miles (x 1000) 15 30 45 60 75 90 105 120 135 150 Component Kilometers (x 1000) 24 48 72 96 120 144 168 192 216 240 Months 12 15 18 21 24 27 30 Non-driving front axle...
Page 247 Scheduled Maintenance Guide On-Highway (60,000 miles [96,000 km] or more annually) - Miles, kilometers or months - whichever occurs first Miles (x 1000) 15 30 45 60 75 90 105 120 135 150 Component Kilometers (x 1000) 24 48 72 96 120 144 168 192 216 240 Months 12 15 18 21 24 27 30 Cooling system...
Page 248 Scheduled Maintenance Guide On-Highway (60,000 Miles [96,000 km] or more annually) - Miles, kilometers or months - whichever occurs first Component Miles (x 1000) 165 180 195 210 225 240 255 270 285 300 Kilometers (x 1000) 264 288 312 336 360 384 408 432 456 480 Months 33 36 39 42 45 48 51 54 57 60 Non-driving front axle...
Page 249 Scheduled Maintenance Guide On-Highway (60,000 Miles [96,000 km] or more annually) - Miles, kilometers or months - whichever occurs first Component Miles (x 1000) 165 180 195 210 225 240 255 270 285 300 Kilometers (x 1000) 264 288 312 336 360 384 408 432 456 480 Months 33 36 39 42 45 48 51 54 57 60 •...
Page 250 Scheduled Maintenance Guide City (60,000 Miles [96,000 km] or less annually) - Miles, kilometers or months - whichever occurs first Component Miles (x 1000) 10 20 30 40 50 60 70 80 90 100 Kilometers (x 1000) 16 32 48 64 80 96 112 128 144 160 Months 12 15 18 21 24 27 30 Non-driving front axle...
Page 251 Scheduled Maintenance Guide City (60,000 Miles [96,000 km] or less annually) - Miles, kilometers or months - whichever occurs first Component Miles (x 1000) 10 20 30 40 50 60 70 80 90 100 Kilometers (x 1000) 16 32 48 64 80 96 112 128 144 160 Months 12 15 18 21 24 27 30 Cooling system...
Page 252 Scheduled Maintenance Guide City (60,000 Miles [96,000 km] or less annually) - Miles, kilometers or months - whichever occurs first Component Miles (x 1000) 110 120 130 140 150 160 170 180 190 200 Kilometers (x 1000) 176 192 208 224 240 256 272 288 304 320 Months 33 36 39 42 45 48 51 54 57 60 Non-driving front axle...
Page 253 Scheduled Maintenance Guide City (60,000 Miles [96,000 km] or less annually) - Miles, kilometers or months - whichever occurs first Component Miles (x 1000) 110 120 130 140 150 160 170 180 190 200 Kilometers (x 1000) 176 192 208 224 240 256 272 288 304 320 Months 33 36 39 42 45 48 51 54 57 60 Cooling system...
Page 254 Scheduled Maintenance Guide Severe Service (On/Off Road in dirty conditions or 20,000 miles [32,000 km] or less annually) - Miles, kilometers or months - whichever occurs first Component Miles (x 1000) 10 15 20 25 30 35 40 45 50 Kilometers (x 1000) 16 24 32 40 48 56 64 72 80 Months...
Page 255 Scheduled Maintenance Guide Severe Service (On/Off Road in dirty conditions or 20,000 miles [32,000 km] or less annually) - Miles, kilometers or months - whichever occurs first Component Miles (x 1000) 10 15 20 25 30 35 40 45 50 Kilometers (x 1000) 16 24 32 40 48 56 64 72 80 Months...
Page 256 Scheduled Maintenance Guide Severe Service (On/Off Road in Dirty Conditions or 20,000 miles [32,0000 km] or less annually) - Miles, kilometers or months - whichever occurs first Component Miles (x 1000) 55 60 65 70 75 80 85 90 95 100 Kilometers (x 1000) 88 96 104 112 120 128 136 144 152 160 Months...
Page 257 Scheduled Maintenance Guide Severe Service (On/Off Road in Dirty Conditions or 20,000 miles [32,0000 km] or less annually) - Miles, kilometers or months - whichever occurs first Component Miles (x 1000) 55 60 65 70 75 80 85 90 95 100 Kilometers (x 1000) 88 96 104 112 120 128 136 144 152 160 Months...
Page 258 Scheduled Maintenance Guide Date: Dealer’s Stamp: Odometer reading: R.O.# Date: Dealer’s Stamp: Odometer reading: R.O.# Date: Dealer’s Stamp: Odometer reading: R.O.# Date: Dealer’s Stamp: Odometer reading: R.O.# Date: Dealer’s Stamp: Odometer reading: R.O.# Date: Dealer’s Stamp: Odometer reading: R.O.# 2006 F-650/750 (f67) Supplement USA (fus)
Page 259 Scheduled Maintenance Guide Date: Dealer’s Stamp: Odometer reading: R.O.# Date: Dealer’s Stamp: Odometer reading: R.O.# Date: Dealer’s Stamp: Odometer reading: R.O.# Date: Dealer’s Stamp: Odometer reading: R.O.# Date: Dealer’s Stamp: Odometer reading: R.O.# Date: Dealer’s Stamp: Odometer reading: R.O.# 2006 F-650/750 (f67) Supplement USA (fus)
Page 260 Scheduled Maintenance Guide Date: Dealer’s Stamp: Odometer reading: R.O.# Date: Dealer’s Stamp: Odometer reading: R.O.# Date: Dealer’s Stamp: Odometer reading: R.O.# Date: Dealer’s Stamp: Odometer reading: R.O.# Date: Dealer’s Stamp: Odometer reading: R.O.# Date: Dealer’s Stamp: Odometer reading: R.O.# 2006 F-650/750 (f67) Supplement USA (fus)
Page 261 Scheduled Maintenance Guide Date: Dealer’s Stamp: Odometer reading: R.O.# Date: Dealer’s Stamp: Odometer reading: R.O.# 2006 F-650/750 (f67) Supplement USA (fus)
Page 262 Scheduled Maintenance Guide 2006 F-650/750 (f67) Supplement USA (fus)
Page 263 Scheduled Maintenance Guide 2006 F-650/750 (f67) Supplement USA (fus)
Page 264 Scheduled Maintenance Guide SPECIAL OPERATING CONDITIONS If your driving habits frequently include one or more the following conditions: • Short trips of less than 10 miles (16 km) when outside temperatures remain below freezing. • Operating during hot weather in stop-and-go “rush hour” traffic. •...
Page 265: Motorcraft Premium Gold Coolant Change Record
Scheduled Maintenance Guide Date: Dealer’s Stamp: Odometer reading: R.O.# See corresponding mileage in maintenance schedule for services performed. Date: Dealer’s Stamp: Odometer reading: R.O.# See corresponding mileage in maintenance schedule for services performed. Date: Dealer’s Stamp: Odometer reading: R.O.# See corresponding mileage in maintenance schedule for services performed. Date: Dealer’s Stamp: Odometer reading:...
Page 266 Scheduled Maintenance Guide Current mileage goes here => Dealer Stamp Add 45,000 miles to the current miles + 45,000 Next change due at this mileage => Today’s date goes here => Add 3 years + 00 / 00 / 03 Date of next change =>...
Page 267: Index
Index Air conditioning ......51 Catalytic converter manual heating and air (see Emission control) .....174 conditioning system ....51 CD-single premium .....33 Air suspension ......119 Cell phone use ......7 Anti-lock brake system Child safety restraints ....83 (see Brakes) ......117 child safety belts ......83 Audio system Child safety seats ......86 (see Radio) ....33–34, 39, 44...
Page 268 Cruise control Engine oil ........177 (see Speed control) ....63 checking and adding ....177 Customer Assistance ..143, 159 oil pressure gauge ....28 Ford accessories for your recommendations ....178 vehicle ........166 refill capacities ......232 specifications ......218 Getting assistance outside the U.S. and Canada .....159, 161 Getting roadside assistance ...143...
Page 269 Index Headlamps ........53 instrument panel, dimming ..54 interior lamps ......55 aiming ........54 replacing bulbs ....55–57 daytime running lights .....53 high beam .........53 Lane change indicator warning chime ......23 (see Turn signal) ......54 Heating ........50–51 Lights, warning and indicator ..23 heater only system ....50 air suspension ......23 manual heating and air anti-lock brakes (ABS) ..23, 117...
Page 270 Index fluid, refill capacity ....232 heated ........73 fluid, specifications ....218 Special notice ........6 Power Take-Off (PTO) Specification chart, operation .........131 lubricants ........218 Power Windows ......59 Speed control ......63 Speedometer .......28 Starting your vehicle ....91 Radio ......33–34, 39, 44 jump starting ......151 preparing to start your Relays ........145 vehicle ........91...
Page 271 Index Waxing your vehicle ....163 Wheels ........208 Vehicle loading ....136–137 Windows Voltmeter (see Battery voltage power .........59 gauge) ..........28 Windshield defrosting ......50–51 Warning chimes ......23 Windshield washer fluid and wipers ..........58 Warning lights (see Lights) ..23 checking and cleaning ....165 Warranty coverage ......6 operation ........58 Washer fluid ......185...
