Video camcorder
Hide thumbs Also See for SC-L901:
Table of Contents

Advertisement

Quick Links

ENGLISH

Video Camcorder

8mm

COLOR LCD

SCL901/L906/L907
Hi
SCL901/L906/L907
Owner's Instruction Book
Before operating the unit, please read
this instruction book thoroughly, and retain it for future
reference.
Videocámara
8mm
PANTALLA LCD DE COLOR
SCL901/L906/L907
Hi
ELECTRONICS
Manual de instrucciones del usuario
Antes de utilizar la videocámara, lea completamente el
presente manual de instrucciones, y consérvelo para futuras
consultas.
ESPAÑOL
SCL901/L906/L907
AD68-00732C

Advertisement

Table of Contents
loading

Related Manuals for Samsung SC-L901

Summary of Contents for Samsung SC-L901

  • Page 1: Video Camcorder

    ENGLISH Video Camcorder COLOR LCD SCL901/L906/L907 SCL901/L906/L907 Owner’s Instruction Book Before operating the unit, please read this instruction book thoroughly, and retain it for future reference. Videocámara PANTALLA LCD DE COLOR SCL901/L906/L907 SCL901/L906/L907 ELECTRONICS Manual de instrucciones del usuario Antes de utilizar la videocámara, lea completamente el presente manual de instrucciones, y consérvelo para futuras consultas.
  • Page 2 ENGLISH Notices and Safety Instructions Safety Instructions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER(OR BACK). NO USER SERVICEABLE PARTS INSIDE, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. To prevent electric shock, match wide blade of plug to wide slot and fully insert.
  • Page 3 ENGLISH Notices and Safety Instructions 9. VENTILATION: Slots and openings in the cabinet are provided for ventilation to ensure reliable operation of the CAMCORDER and to protect it from overheating. These openings must not be blocked or covered. Never place your CAMCORDER on a bed, sofa, rug, or other similar surface: on or near a radiator or heat register.
  • Page 4 ENGLISH Notices and Safety Instructions 14. LIGHTNING: For added protection of this CAMCORDER during a lightning storm when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the CAMCORDER due to lightning and power-line surges.
  • Page 5 ENGLISH Notices and Safety Instructions 22. To prevent damage which may result in fire or shock hazard, do not expose this appliance to rain or moisture. 23. If this power supply is used at 240V ac, a suitable plug adapter should be use. NOTE TO CATV SYSTEM INSTALLER: This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines...

  • Page 6: Table Of Contents

    ENGLISH Contents Notices and Safety Instructions Getting to Know Your Camcorder Features ...8 Descriptions Front View/Side View/Rear View...9, 10, 11 OSD (On Screen Display) ...12 Accessories Supplied with the Camcorder...14 Remote Control (SCL906/L907 only) ...15 Self Timer Recording...15 Preparing Adjusting the Hand Strap and Shoulder Strap ...16 Attaching the Lens Cover ...17 Lithium Battery Installation ...17 Connecting the Power Source...18...
  • Page 7 ENGLISH Contents (continued) Program AE (Automatic Exposure) ...38 DSE (Digital Special Effects) in CAMERA mode...40 Setting and Recording DATE/TIME...42 Selecting and Recording a Title ...44 Fade In and Out ...46 Snap Shot (SCL906/L907 only)...47 White Balance ...48 SELECT LANGUAGE...49 Demonstration ...50 Setting the Date/Title Color ...51 Lighting Techniques...52 Playing back a Tape...

  • Page 8: Notices And Safety Instructions

    ENGLISH Notices and Safety Instructions Notices regarding rotation of LCD screen Please rotate the LCD screen carefully as illustrated. Unintended rotation may cause damage to the inside of the hinge that connects the LCD screen to the Camcorder. 1) LCD screen closed. 2) Standard recording by using the LCD screen.
  • Page 9 ENGLISH Notices and Safety Instructions Notices regarding electronic viewfinder 1) Do not place the camcorder so that the viewfinder is pointing towards the sun. Direct sunlight can damage the inside of the viewfinder. Be careful when placing the camcorder under sunlight or by a window.
  • Page 10 ENGLISH Notices and Safety Instructions Notices regarding the battery pack Make sure that the battery pack is charged before recording outdoors. To preserve battery power, keep your camcorder turned off when you are not operating it. When your camcorder is in CAMERA mode, if it is left in STANDBY for more than 5 minutes without operation, it will automatically turn off to protect against unexpected battery discharge.
  • Page 11 ENGLISH Notices and Safety Instructions Notices with Recording or Playback by using LCD 1) The LCD Screen is manufactured by using high precision technology. However, there may be some tiny specks (red, blue or green in color) that appear on the LCD Screen.

  • Page 12: Getting To Know Your Camcorder

    ENGLISH Getting to Know Your Camcorder Features Your camcorder has many features for recording and playing back. MULTI OSD LANGUAGE You can select the appropriate OSD Language among English, French, Spanish. Snap Shot (SCL906/L907 only) The Snap Shot function lets you record an object at a standstill for a limited time in Camera mode.

  • Page 13: Front View/Side View/Rear View

    ENGLISH Getting to Know Your Camcorder Front View 2. REC SEARCH (REW) 3. LIGHT (PLAY/STILL) 6. TAPE EJECT 13. VIDEO LIGHT 1. LENS 9. Remote Sensor 8. MIC 1. Lens (see page 68) 6. TAPE EJECT (see page 22) 2. REC SEARCH (REW) Use when ejecting the tape.

  • Page 14: Vista Frontal/Vista Lateral/Vista Trasera

    ENGLISH Getting to Know Your Camcorder Side View 24. BLC 23. FADE 20. SPEAKER 22. LCD Open 14. MENU ON/OFF (see page 26) 19. DSE (see page 40) MENU ON/OFF works in DSE works in CAMERA and CAMERA and PLAYER mode. PLAYER mode.
  • Page 15 ENGLISH Getting to Know Your Camcorder Rear View 36. BATTERY EJECT 27. Hooks for shoulder strap 37. SNAP SHOT/D.ZOOM 28. AUDIO/VIDEO Out 32. START/STOP 35. Battery Pack Compartment 38. Recharging Indicator 34. DC Jack 25. ZOOM (see page 30) 33. External MIC (see page 68) 26.

  • Page 16: Osd (On Screen Display)

    ENGLISH Getting to Know Your Camcorder OSD (On Screen Display) You can turn the OSD on/off by setting the Display menu on/off. The TITLE, DATE/TIME, EASY and CUSTOM functions can be operated even after the OSD is turned off. The OSD is displayed in the viewfinder and the LCD Screen. a.
  • Page 17 ENGLISH Getting to Know Your Camcorder OSD (On Screen Display) j. Time (see page 42) Indicates the time you are recording. k. Title (see page 44) Indicates the recorded title you have set. It is superimposed on the scene. l. Self diagnosis (see page 64) (TAPE!, TAPE END!, PROTECTION!) Checks the operation of the Camcorder.

  • Page 18: Accessories Supplied With The Camcorder

    ENGLISH Getting to Know Your Camcorder Accessories Supplied with Camcorder Make sure that the following basic accessories are supplied with your camcorder. Basic Accessories 1. AC Power Adapter 1. AC Power Adapter. (AA-E8 TYPE) (see page 18) 2. AC cord. (see page 18) 3.

  • Page 19: Remote Control (Scl906/L907 Only)

    ENGLISH Getting to Know Your Camcorder Remote Control (SCL906/L907 only) Description of Buttons 1. Start/Stop (see page 23) 2. Self Timer 3. Still (see page 55) 4. WIDE (see page 30) 5. TELE (see page 30) 6. Display (see page 12) (Play) (see page 54) (FF) (see page 55) (REW) (see page 55)

  • Page 20: Preparing

    ENGLISH Preparing 1. Set power switch to CAMERA mode. 2. Press Self Timer button until the appropriate indicator is displayed on the LCD: WAIT-10S/SELF-30S WAIT-10S/SELF-END 3. Press START/STOP button to start the timer. : After waiting for 10 seconds, recording starts. : If you have selected SELF-30S, recording stops automatically after 30 seconds.

  • Page 21: Attaching The Lens Cover

    ENGLISH Preparing Attaching the Lens Cover Lithium Battery Installation The lithium battery maintains the clock function, title and preset contents of the memory; even if the battery pack or AC power adapter is removed. The lithium battery for the camcorder lasts about 8~10 months under normal operation from the time of installation.

  • Page 22: Connecting The Power Source

    ENGLISH Preparing Connecting the Power Source There are two ways to connect power source. Using the AC Power Adapter : used for indoor recording. Using the Battery Pack: used for outdoor recording. To use the AC Power Adapter 1. Connect the AC Power Adapter to the AC cord.

  • Page 23: To Use The Battery Pack

    ENGLISH Preparing To use the Battery Pack How long will the battery last for recording? Depends on how often you are likely to use the zoom feature during recording. Recharging the Battery Pack 1. Attach the battery pack to the camcorder.

  • Page 24: Using The Battery Pack

    ENGLISH Preparing Using the Battery Pack Continuous recording time table based on model and battery type. LCD ON, Battery Type EVF OFF Approx-imately SB-L110A 90 minutes Approx-imately SB-L160 130 minutes Approx-imately SB-L320 270 minutes The continuous recording times given in the table are approximate.

  • Page 25: Battery Level Display

    ENGLISH Preparing Battery Level Display The battery level display indicates the amount of power remaining in the battery pack. 1. Fully charged 2. 10~40% consumed 3. 40~60% consumed 4. 60~80% consumed (prepare a charged one) 5. 80~95% consumed (change the battery) 6.

  • Page 26: Inserting And Ejecting A Cassette

    ENGLISH Preparing Inserting and Ejecting a Cassette There are several cassette types, depending on: Color system used Recording/playback time. Inserting and Ejecting a Cassette Check to see if the battery pack is in place or AC adapter is connected. 1. Press the EJECT button. The compartment opens automatically.

  • Page 27: Basic Recording

    ENGLISH Basic Recording Making Your First Recording Please make these preparations before recording. Did you connect a power source? (Battery Pack or AC Power Adapter) Did you set the power switch to CAMERA position? Did you insert a cassette? (see page 22) Open the LCD Screen and make sure that STBY is displayed on the LCD (if the red tab of the cassette is opened, STBY will not be displayed)
  • Page 28 ENGLISH Basic Recording b. To stop recording, press the red START/STOP button again. When Recording stops, STBY should be displayed on the LCD. When a cassette is loaded and the camcorder is left in STANDBY mode for over 5 minutes without being used, it will turn off automatically.

  • Page 29: Hints For Stable Image Recording

    ENGLISH Basic Recording Hints for Stable Image Recording While recording, it is very important to hold the camcorder correctly. For stable recording, fix the LENS COVER firmly by clipping it on the hand strap. (refer to figure) Recording with the LCD Screen 1.

  • Page 30: Adjusting The Lcd

    ENGLISH Basic Recording Adjusting the LCD Your camcorder is equipped with a 2.5 inch color Liquid Crystal Display (LCD) screen, which allows you to view recording or playback directly. Depending on the conditions in which you are using the camcorder (indoors or outdoors for example), you can adjust: Brightness Color 1.

  • Page 31: Adjusting Focus Of The Viewfinder

    ENGLISH Basic Recording 9. Turn the UP/DOWN dial to adjust the LCD color setting. 10. Press ENTER. For further adjustment, repeat steps 7, 8, 9. 11. Press the MENU ON/OFF button to end the setting. Note: If you do not press a button within 30 seconds, the setting will disappear.

  • Page 32: Playing Back A Tape On The Lcd

    ENGLISH Basic Recording Playing back a tape on the LCD You can monitor the playback picture on the LCD Screen. Make sure that the battery pack is in place. 1. Hold down the tab of the power switch and push the switch to PLAYER mode. 2.

  • Page 33: Adjusting The Lcd During Play

    ENGLISH Basic Recording Adjusting the LCD during PLAY The LCD adjustment method in PLAYER mode is identical to step number 4 of page 26, except the power switch must be set to PLAYER. Controlling the Sound from the Speaker When you use the LCD Screen while playing back, you can hear sound from the Speaker.

  • Page 34: Advanced Recording

    ENGLISH Advanced Recording Zooming In and Out Zoom works in CAMERA mode only. Zooming is a recording technique that lets you change the size of the subject in the picture. For more professional looking recordings, do not use the zoom function too often. You can also choose from two zoom speeds to suit different needs : Gradual zoom (9~12 seconds from TELE/WIDE to...

  • Page 35: Digital Zoom

    ENGLISH Advanced Recording Digital Zoom Digital Zoom works in CAMERA mode only. Zooms more than 22x are performed digitally. The picture quality deteriorates as you go towards the “T” side. We recommend that you use the DIS (SCL906/L907) feature with the DIGITAL ZOOM for picture stability. (see page 35) 1.
  • Page 36 ENGLISH Advanced Recording Setting the DIGITAL ZOOM ON/OFF (SCL906/L907 only) The DIGITAL ZOOM feature is explained on page 31. 1. Set the power switch to CAMERA mode. (see page 18) 2. Press the MENU ON/OFF button. The MENU list will appear. 3.

  • Page 37: Easy Mode (For Beginners)

    ENGLISH Advanced Recording EASY Mode (for Beginners) Even a beginner can easily make a recording using the EASY mode. The EASY mode only operates in CAMERA mode. 1. Set the power switch to CAMERA mode (see page 18). 2. By pressing the EASY button, all the functions of the camera will be set to off and the recording settings will be set to the following basic mode.

  • Page 38: Custom-Creating Your Own Customized Recording Settings

    ENGLISH Advanced Recording CUSTOM - Creating your own customized recording settings You can customize the settings and save them for future use. The CUSTOM function only operates in CAMERA mode. 1. Set the power switch to CAMERA mode. (see page 18) 2.

  • Page 39: Dis (Digital Image Stabilizer, Scl906/L907 Only)

    ENGLISH Advanced Recording DIS (Digital Image Stabilizer, SCL906/L907 only) The DIS function works in CAMERA mode only. DIS (Digital Image Stabilizer) is a handshake compensation function that compensates for any shaking or moving of the hand holding the camcorder (within reasonable limits). It provides more stable pictures when: Recording in the Zoom In mode Recording a small object close-up...

  • Page 40: Mf/Af (Manual Focus/Auto Focus)

    Auto Focusing The AF (Auto Focus) mode is set automatically when you switch on the Power switch. If you are inexperienced with camcorders, we recommend that you use the Auto Focus mode. Manual Focusing In the following situations, you should obtain better results by adjusting the focus manually.

  • Page 41: Blc

    ENGLISH Advanced Recording 4. Turn the UP/DOWN dial up or down until the object is focused. 5. You will obtain a sharp picture after zooming out. 6. To return to AF(Auto Focus), press the MF button again. Note: The MF function will not operate in EASY mode.

  • Page 42: Program Ae (Automatic Exposure)

    ENGLISH Advanced Recording PROGRAM AE (Automatic Exposure) The PROGRAM AE function works in the CAMERA mode only. The PROGRAM AE modes allow you to adjust shutter speeds and aperture to suit different recording conditions. They give you creative control over the depth of the field. There are 6 automatic exposure modes.
  • Page 43 ENGLISH Advanced Recording Setting the PROGRAM AE(Automatic Exposure) mode 1. Set the power switch to CAMERA mode. (see page 18) 2. Press the P.AE button, the ( symbol will be displayed. 3. Press the P.AE button until the appropriate symbol is displayed. No Display : Auto mode.

  • Page 44: Dse (Digital Special Effects) In Camera Mode

    ENGLISH Advanced Recording DSE (Digital Special Effects) in CAMERA mode The digital effects enable you to give a creative look to your recording by adding various special effects. Select the appropriate digital effect for the type of picture that you wish to record. There are several DSE modes.
  • Page 45 ENGLISH Advanced Recording Selecting and recording DSE effects 1. Set the power switch to CAMERA mode. (see page 18) 2. Press the DSE button, STROBE or SEPIA will be displayed. 3. Keep pressing the DSE button, until the desired mode is displayed. 4.

  • Page 46: Setting And Recording Date/Time

    ENGLISH Advanced Recording Setting and Recording the DATE/TIME Setting and recording the date/time feature works in the CAMERA mode only. You can record the date/time on your tapes, so you will know when it was made. The date and time are recorded whenever they are displayed on the viewfinder or LCD.
  • Page 47 ENGLISH Advanced Recording 7. Press ENTER. The month to be reset will blink. 8. Turn the UP/DOWN dial to set the desired month. 9. Press ENTER. The day to be reset will blink. 10. You can set the day, hour and minute following the same procedure used for setting the year and month.

  • Page 48: Selecting And Recording A Title

    ENGLISH Advanced Recording Selecting and Recording a Title Selecting and recording a TITLE is possible in the CAMERA mode only. The TITLE feature allows you to select a preset title stored in the camcorder’s memory. You can also select the language of the titles. Selecting a Language and Setting a Title Selecting a language is possible in STANDBY in CAMERA mode only.
  • Page 49 ENGLISH Advanced Recording 6. Turn the UP/DOWN dial to select the appropriate language. You may select languages among ENGLISH/FRENCH/GERMAN/ ITALIAN/SPANISH/RUSSIAN. 7. Press ENTER. Then, the title list in the language you chose will appear. 8. Turn UP/DOWN dial to whichever TITLE you desire. 9.

  • Page 50: Fade In And Out

    ENGLISH Advanced Recording Fade In and Out The FADE function works in CAMERA mode only. You can give your films a professional look by using special effects such as fading in and out at the beginning or end of a sequence.

  • Page 51: Snap Shot (Scl906/L907 Only)

    ENGLISH Advanced Recording Snap Shot (SCL906/L907 only) With the SNAP SHOT feature, your camcorder functions like a regular film camera, allowing you to take single still pictures. The SNAP SHOT function operates in the CAMERA mode. 1. Set the power switch to CAMERA mode. 2.

  • Page 52: White Balance

    ENGLISH Advanced Recording White Balance WHITE BALANCE is a recording function that preserves the unique color of the object in any recording condition. You may select the appropriate WHITE BALANCE mode to obtain good color quality of the image. AUTO: This mode is generally used to control the WHITE BALANCE automatically.

  • Page 53: Select Language

    ENGLISH Advanced Recording SELECT LANGUAGE 1. Press the MENU ON/OFF button. The MENU list will appear. 2. Turn the UP/DOWN dial to LANGUAGE and Press the ENTER button. 3. Turn the UP/DOWN dial to select the appropriate language. 4. Press the ENTER button. 5.

  • Page 54: Demonstration

    TITLE...OFF D/TITLE COLOR ..WHITE C.RESET ...0:00:00 DEMO ...OFF EXIT: MENU 4. Pulse ENTER para seleccionar ON. SAMSUNG Comenzara la demostración 5. Ponga el POWER switch en OFF para acabar la Demonstration. DEMONSTRATION Nota: La funcion MENU ON/OFF no funcionara en EASY o REC.

  • Page 55: Setting The Date/Title Color

    ENGLISH Advanced Recording Setting the Date/Title Color 1. Set the power switch to CAMERA mode. (see page 18) 2. Press the MENU ON/OFF button. The MENU list will appear. 3. Turn the UP/DOWN dial to D/TITLE COLOR...WHITE. 4. Press ENTER. A list of available colors will appear.

  • Page 56: Lighting Techniques

    ENGLISH Advanced Recording Lighting Techniques When you use your camcorder, there are only two possible recording environments. You will be recording outdoors (Normal recording or through an ND(Neutral Density) filter). You will be recording indoors (Video light recommended or required). The single greatest influence on picture quality is the level of brightness, measured in lux.

  • Page 57: Playing Back A Tape

    ENGLISH Playing back a Tape To view a tape that you have recorded. Playback function works in PLAYER mode only. There are two ways to see a tape; To watch with LCD: recommended for outdoor use. To watch with TV monitor: recommended for indoor use. To watch with LCD It is practical to view a tape using the LCD Screen in a car or the outdoors.
  • Page 58 ENGLISH Playing back a Tape Notes: SCL901/L906/L907 feature a monaural audio system. If your TV or VCR features a stereo audio system, connect the audio cable to input “L” of your TV or VCR. You can use an S-VIDEO cable to obtain better quality of pictures if you have the S-VIDEO connector on your TV.

  • Page 59: Various Functions In Player Mode

    ENGLISH Playing back a Tape Various Functions in PLAYER mode To view a STILL picture (Playback pause) Press (PLAY/STILL) button during playback. To resume playback, press (PLAY/STILL) button again. Note: Your camcorder will automatically stop if it is left for more than 5 minutes in STILL mode without operation in order to prevent tape and head-drum wear.

  • Page 60: Adjusting The Lcd

    ENGLISH Playing back a Tape Adjusting the LCD The LCD control in PLAYER mode is identical to step 3 of the page 26, except the power switch must be set to PLAYER mode. Setting the Speaker ON/OFF The speaker is turned ON/OFF by opening/closing the LCD. The speaker ON/OFF setting operates when the LCD is opened.

  • Page 61: Multi Playback (Using A Pal60 System)

    ENGLISH Playing back a Tape Multi Playback (using a PAL60 System) This Camcorder can convert an NTSC tape recorded in the SP mode to the “PAL60” format, allowing you to view it on a PAL TV which has Vertical sync adjustment circuitry for 60Hz. “PAL60”...

  • Page 62: Usb Interface (Scl907 Only)

    ENGLISH USB interface (SCL907 only) Transferring a Digital Image through a USB Connection You can easily transfer a still image from a camera, tape, memory to a PC without additional add-on cards via a USB connection. If you transfer data to a PC, you need to install the software (Driver, Editing software) supplied with the camcorder.

  • Page 63: Installing Usb Media 2.0 Program

    ENGLISH USB interface (SCL907 only) Installing USB Media 2.0 Program Do not connect the camcorder to PC before installing the program. If another camera or scanner is connected, please disconnect it in advance. This explanation is based on Windows How to install the program 1.
  • Page 64 4. La ventana que aparece a continuación muestra la carpeta de instalación del programa. El programa se instala por defecto en la siguiente carpeta: C:\Archivos de programa\ Samsung\USB Media 2.0 Haga clic en para cambiar de carpeta. 5. Conecte la videocámara al ordenador.
  • Page 65 ENGLISH USB interface (SCL907 only) Connecting to a PC 1. Connect a USB cable to the USB port on the PC. 2. Connect the other end of the USB cable into the proper terminal on the camcorder. (USB jack) 3. Connect the audio cable to the Line input jack of the PC. If the PC has no Line input jack, connect the audio cable to the MIC input jack.

  • Page 66: Maintenance

    ENGLISH Maintenance Cleaning and Taking care of the Camcorder Cleaning the Viewfinder Releasing the Eyecap 1. Pull the VIEWFINDER up and then turn the screw counter-clockwise. 2. Pull the EYECAP out. 3. Clean the EYECAP and the VIEWFINDER screen with a soft cloth and cotton swab or a blower.

  • Page 67: Using Your Camcorder Abroad

    ENGLISH Using Your Camcorder Abroad Using Your Camcorder Abroad Each country or area has its own electric and TV color system. Before using your camcorder abroad, check the following: Power sources You can use your camcorder in any country or area that uses 100V to 240V, 50/60 Hz.

  • Page 68: Troubleshooting

    ENGLISH Troubleshooting Troubleshooting Before contacting a service center, perform the following simple checks. They might save you the time and expense of an unnecessary call. Self Diagnosis Display Display Blinking Inform that... the battery pack is slow almost discharged the battery pack is fast fully discharged.

  • Page 69: Checking

    ENGLISH Troubleshooting Checking If you run into any problem using the camcorder, use the following table to troubleshoot the problem. If these instructions do not allow you to solve the problem, take a note of: The model and serial number marked on the bottom of the camcorder.
  • Page 70 ENGLISH Troubleshooting Symptom Explanation/Solution A vertical stripe appears The contrast between the subject when you record a bright and the background is too great for subject against a dark the camcorder to operate normally. background (candle flame, Make the background bright to for example).

  • Page 71: Moisture Condensation

    ENGLISH Troubleshooting Moisture Condensation If the camcorder is brought directly from a cold place to a warm place, moisture may condense inside the camcorder, on the surface of the tape, or on the lens. In this condition, the tape may stick to the head drum and be damaged or the unit may not operate correctly.

  • Page 72: Specifications

    ENGLISH Specifications The design and technical specifications may be changed without notice. System SCL901/L906/L907 Recording system Video: 2 rotary heads Helical scanning FM Audio: FM monaural system Video signal NTSC color, EIA standard Usable cassette Hi8 or 8mm Tape speed SP: 14.345 mm/sec Speed mode Record: SP only Playback: SP only...

  • Page 73: Index

    ENGLISH Index - A - ABROAD ...63 EASY ...33 AC POWER ADAPTER...18 EJECT ...22 ADJUSTING...26 ENTER ...26 AF ...36 EXTERNAL MIC ...68 AUDIO ...53 AUTO FOCUSING...36 AUTO MODE ...38 FADE IN ...46 AUTO POWER OFF ...24 FADE OUT ...46 FAR ...36 - B - FF (FAST FORWARD) ...55 BATTERY ...19...
  • Page 74 ENGLISH Index - O - STANDBY...18 START/STOP ...23 OPERATION MODE...13 STILL...55 OSD ...12 STOP ...54 STROBE...40 - P - SYSTEM...68 S-VIDEO ...54 PLAY ...54 PLAYER...54 PORTRAIT MODE...38 POWER CONSUMPTION ..68 TAPE COUNTER...13 POWER REQUIREMENT...68 TAPE EJECT...22 POWER SWITCH...18 TAPE END...64 PROGRAM AE...38 TIME...42 TITLE ...44...

  • Page 75: Warranty(Sea Users Only)

    Warranty (SEA Users Only) SAMSUNG LIMITED WARRANTY SAMSUNG Electronics America Inc. (SEA), warrants that this product is free from defective material and workmanship. SEA further warrants that if product fails to operate properly within the specified warranty period and the failure is due to improper workmanship or defective material, SEA will repair or replace the product at it’s option.
