8mm CAMCORDER
SCL700/710/750/770
SERVICE
For mechanical disassembly and adjustment, refer to the "Mechanical Manual"
(DE-10
AD68-00420H).
8mm CAMCORDER
8
Manual
CONTENTS
2. Product Specifications and
Comparison Chart
8. Wiring Diagram

Advertisement

Table of Contents
loading

Related Manuals for Samsung SCL700

Summary of Contents for Samsung SCL700

  • Page 1 2. Product Specifications and Comparison Chart 3. Disassembly and Reassembly 4. Alignment and Adjustment 5. Exploded View and Parts List 6. Electrical Parts List 7. PCB Diagrams 8. Wiring Diagram 9. Schematic Diagrams © Samsung Electronics Co.,Ltd. JAN. 2002 Printed in Korea AD68-00420R...
  • Page 2 Alternatively, wear a dis- tion, replace the picture tube only with one that is the same type as the original. charging Wrist-strap device. (Be sure to remove it prior to applying power--this is an electric shock precaution.) Samsung Electronics...
  • Page 3 17. Observe the original lead dress, especially near the following areas : Antenna wiring, sharp edges, and especially the AC and high voltage power supplies. Always inspect for pinched, out-of-place, or frayed wiring. Do not change the spacing between components and the Samsung Electronics...
  • Page 4 External mic Monaural ø3.5 (SCL750/L770) General Power requirements DC 8.4 V (1.5 A) Power consumption SCL700/L710 : 5.4 W, SCL750/L770: 5.9 W *Recording, LCD ON Built-in mic Condenser mic, omni-directional Built-in speaker Dynamic, 0.5 W standard Operating temperature 0°C to 40°C (32°F to 104°F) Dimension (W 174 mm (3.98...
  • Page 5 Products Specifications and Comparison Chart 2-2 Comparison Chart 2-2-1. NTSC Models NTSC Model Features SCL700 SCL710 SCL750 SCL770 Format Video Light Remote Control Mono Mono Mono Mono Audio SNAP/SHOT 270K 270K 270K 270K 880X 880X 880X 880X Digital Zoom Ratio...
  • Page 6 3. Disassembly and Reassembly 3-1. Cabinet and PCB 3-1-1 Ass’y Cover Housing Removal REMOVE 2 SCREWS. Remove the ass’y cover housing in the direction of arrow. Fig. 3-1 Ass’y Cover Housing Removal Samsung Electronics...
  • Page 7 REMOVE ASS’Y CASE TOP BY GENTLY RELEASING 1 LOCKING TAB WITH A SMALL SCREW DRIVER. (SEE DETAIL "A") REASSEMBLY : PUT THE 5 TABS INTO THE SLOTS, WHILE SLIDING IT AS SHOWN IN DETAIL "B". Fig. 4-2 Ass’y Case Top Removal Samsung Electronics...
  • Page 8 Disassembly and Reassembly 3-1-3 Ass’y Front Removal REMOVE THE ASS’Y FRONT IN THE DIRECTION OF ARROW. REMOVE 1 SCREWS. DISCONNECT THE HARNESS FROM THE CN701 OF ASS’Y MAIN PCB. Fig.3-3 Ass’y Front Removal Samsung Electronics...
  • Page 9 Disassembly and Reassembly 3-1-4 Ass’y Case Left Removal REMOVE THE ASS’Y-CASE LEFT REMOVE 2 SCREWS. IN THE DIRECTION OF ARROW. REMOVE 3 SCREWS. REMOVE 1 SCREW. Fig. 3-4 Ass’y Case Left Removal Samsung Electronics...
  • Page 10 Disassembly and Reassembly 3-1-5 Ass’y Case Right Removal REMOVE THE CASE RIGHT ASSEMBLY IN THE DIRECTION OF ARROW. REMOVE 1 SCREW. REMOVE 1 SCREW. REMOVE 2 SCREWS. Fig. 3-5 Ass’y Case Right Removal Samsung Electronics...
  • Page 11 Disassembly and Reassembly 3-1-6 Ass’y LCD Removal REMOVE 5 SCREWS. REMOVE THE LCD ASS’Y IN TEH DIRECTION OF ARROW. REMOVE 2 SCREWS. REMOVE THE COVER BOTTOM ASS’Y IN THE DIRECTION OF ARROW. Fig. 3-6 Ass’y LCD Removal Samsung Electronics...
  • Page 12 Disassembly and Reassembly 3-1-7 Ass’y EVF/CVF Removal REMOVE 3 SCREWS. REMOVE THE EVF/CVF ASS’Y IN THE DIRECTION OF ARROW. Fig. 3-7 Ass’y EVF/CVF Removal Samsung Electronics...
  • Page 13 Disassembly and Reassembly 3-1-8 Ass’y Rear Board Removal REMOVE THE REAR ASS’Y IN THE DIRECTION OF ARROW. REMOVE 2 SCREWS. Fig. 3-8 Ass’y Rear Board Removal Samsung Electronics...
  • Page 14 PULL OUT THE MAIN PCB FROM THE ASS’Y DECK IN THE DIRECTION OF ARROW DISCONNECT THE FPC FROM THE MAIN PCB. DISCONNECT CONNECTOR FROM THE HEAD-DRUM. REMOVE THE 2 SCREWS. Fig. 3-9 Ass’y Deck and Main PCB Removal Samsung Electronics...
  • Page 15 Disassembly and Reassembly 3-1-10 Ass’y Camera Removal REMOVE 2 SCREWS. REMOVE SOLDER WITH DISCONNECT CONNECTOR AND PULL OUT THE AN IRON TO ISOLATE ASS’Y LENS IN THE DIRECTION OF ARROW SHIELD-CASE AND LENS. Fig. 3-10 Ass’y Camera Removal 3-10 Samsung Electronics...

  • Page 16: Circuit Boards Location

    Disassembly and Reassembly 3-2. Circuit Boards Location ASS’Y MAIN BOARD ASS’Y FRONT BOARD ASS’Y EVF BOARD ASS’Y CCD BOARD ASS’Y REAR BOARD ASS’Y LCD BOARD ASS’Y FUNCTION BOARD Fig. 3-11 Circuit Boards Location Samsung Electronics 3-11...
  • Page 17 MAIN PCB ASS’Y CVF CNV01 CNL102 LCD PCB B/L FPC B/L FPC LCD PCB HINGE FPC HINGE FPC CNL101 CN604(CN606) MAIN PCB HINGE FPC HINGE FPC CNL201 LCD PCB LCD FPC LCD FPC Fig. 3-12 Connector Diagrams 3-12 Samsung Electronics...
  • Page 18 Head Switching Trigger - Pin 9 of CN452 CN452 J453 CN452 CN452 SW478 SW477 PB RF SW471 J451 DC-JACK J452 D451 SUPER-JACK ONLY Hi8 MODEL Head Switching - Trigger Fig. 1 Test point Fig. 2 Test location of test point (Rear Board) Samsung Electronics...
  • Page 19 COMMON GROUND IC601 157PIN IC601 158PIN IC601 159PIN LOADING EJECT UNLOADING PLAY LOADING STOP STOP IC601 IC601 IC601 POSITION ACTION MODE 157PIN 158PIN 159PIN EJECT EJECT UNLOADING STOP UNLOADING STOP LOADING STOP LOADING STOP PLAY, FF, REW, STILL..Samsung Electronics...

  • Page 20: Camera Section Adjustment

    BLC (MODE UP) FADE (MODE DOWN) Mode change.(One step or 100 step) MENU ON/OFF (MODE UP ‘100’) MANUAL FOCUS RING (NEAR/FAR) Manual focus adjustment. ZOOM TELE 1) Move the zoom position of lens. ZOOM WIDE 2) Semi-Auto lens adjustment. Samsung Electronics...
  • Page 21 3. Eject the tape if it is in the unit. 4. Set the power switch of the camcorder to “CAMERA” position. STEP 3 0DF. ERR : A0 EVR : A0 Note : When “XX XX” is shown in service adjustment procedures, this indicates variable values. Samsung Electronics...
  • Page 22 ; AGC =#022 VALUE :#237- V ENHANCER MIN ; AGC MAX % (E5=90%) FOR H,V ENHANCER MIN (#021,022) ; IRIS CONTROL GAIN ‘80’=CENTER ; SHUTTER START POINT OF IRIS CONTROL PERCENT(FF=100% IRIS OPEN) ; AGC AETRGET PERCENT( =AETARGET*(#026/100hex) Samsung Electronics...
  • Page 23 ; AWB_hall_shutter HALL VALUE= INPUT HALL -(shutter/(80*#056)) ; PKOUD_IRIS ; PKOUD_FAR: ZOOM TELE & FOCUS FAR(5.9M) (#057+#058) LESS THEN ,SRTAT DECREASE RANGE ; PKSHUT_RAT ; PKOUD_AMIN ; Mg DIRECTION CONTROL LIMIT ; mAWB_Pkoud_step: ]UPPER 4BIT(INCREASE SPEED),LOWER 4BIT (DECREASE SPEED) Samsung Electronics...
  • Page 24 ; D6=’0’ MIDDLE ZOOM TRACK COMPENSATION ON=’00’ OFF=’40’) ; DSP AF HGSTART HIGH (AT ALL AREA) ; DSP AF HGSTART LOW (AT ALL AREA) ; DSP AF HGSTOP HIGH (AT ALL AREA) ; DSP AF HGSTOP LOW (AT ALL AREA) Samsung Electronics...
  • Page 25 ; FLEXZONE AF/AE WINDOW V OFFSET DIS ; V_YUKO(HIGH) VERTICAL EFFECTIVE H LINE NUMBER HIGH ; V_YUKO(HIGH) VERTICAL EFFECTIVE H LINE NUMBER LOW ; H_YUKO(HIGH) HORIZENTALL EFFECTIVE PIXEL NUMBER HIGH ; H_YUKO(HIGH) HORIZENTALL EFFECTIVE PIXEL NUMBER LOW ; H_HOSEI HORIZENTAL START/STOP OFFSET Samsung Electronics...
  • Page 26 ;Y M_F PEDESTAL LEVEL CHANGE ;OFFSET BINARY CODE (NTSC TPY:0E HEX) ;Y M_F PEDESTAL LEVEL CHANGE; 1=ADD, 0=SUB. ;FADE_LEV (FADE LEVEL) ;BLACK FADE TYP=C0 hex ;Y_WB NEGA = ‘1’ , POSI=’0’ ;HLENH_LM (HILIGHT ENHANCER LIMIT LEVEL) ; TEST MODE ;NEGA/POSI Samsung Electronics...
  • Page 27 AWB INITIALIZED BLOCK FIXED ;OFSMG_N (OFFSET Mg-G) ;OFSRB_N (OFFSET R-B) ;CW_LEV_G0 (aMGL : G WHITE DETECTIONAREA) ;CW_LEV_M0 (aMGH : Mg WHITE DETECTIONAREA) ;CW_LEV_B0 (aRBL : B WHITE DETECTIONAREA) ;CW_LEV_R0 (aRBH : R WHITE DETECTIONAREA) ;CB_LEV_G0 (bMGL : G WHITE DETECTIONAREA) 4-10 Samsung Electronics...
  • Page 28 ;OSDHD tr ;OSDHDSTARTPHASE(SCBLKSTARTPHASE; OSD) ;OSDHD rf ;OSDHDENDPHASE( OSD)-HIGH ;LOW ;CBLK tr (CBLK blanking STARTPHASE) ;CBLK tf (CBLK blanking ENDPHASE)-HIGH ;LOW ;CAMERA MODE(REC); LCDHD tf ,LCDHD STARTPHASE, LCD ;CAMERA MODE(REC); LCDHD tr, LCDHD END PHASE, LCD -HIGH ;LOW Samsung Electronics 4-11...
  • Page 29 CVF ADJUST LTG1( VCK1=LCD) TIMIMG DATA: FIXED LTG2( VCK2=LCD) TIMIMG DATA: FIXED LTG3( LCD) TIMIMG DATA: FIXED LTG4( LCD) TIMIMG DATA: FIXED LTG5( CLK=LCD) TIMIMG DATA: FIXED LTG6( ENABLE=LCD) TIMIMG DATA: FIXED LTG7( H.START=LCD) TIMIMG DATA: FIXED 4-12 Samsung Electronics...
  • Page 30 #438 CASIO-LCD ;VERTICAL/HORIZENTAL DIRECTION CONVERT #439 CASIO-LCD #43A CASIO-LCD VTR-PB SEARCH MODE LCD TIMING SETTING DATA FIXED CASIO-LCD ;SEARCH/STILL, HV COUNTER TEST DATA-LOW #3FD CASIO-LCD ofe2 #3FE CASIO-LCD ;SEARCH/STILL, SRT SIGNAL SHIFT -LOW #409 CASIO-LCD #40A CASIO-LCD Samsung Electronics 4-13...
  • Page 31 #3CA K g-y/b-y -HIGH ,gain 4TIMES(0~1023/64) #3CC #4F0 PB MODE #4F6 PB MODE #4FC PB MODE #502 PB MODE DIS REGISTER DIS_ON ZOOM_ON LSSC_ON MIRR_ON PIP_ON POWER PIP_MIRR BYPASS FRAME STILL1 STILL2 CEDGE_ON APT_ON OSD_ON TRA_ON GAMA_ON 4-14 Samsung Electronics...
  • Page 32 SCK CNT“SCK MASK(NTSC1820fH/3,PAL1824fH/3) ; PB MODE TG HCYCLE TG: H CYCLE SETTING (T=1/fs) : D11 ~ D9 TG HCYCLE TG: H CYCLE SETTING (T=1/fs) : D8 ~ D1 ;BACKUP_EMG_L VCR EEPROM DATA(LITHIUM BACKUP AREA) ;BACKUP_EMG_H ;BACKUP_TTLSELDATA ;BACKUP_TITLEDSPCUSSTATE(DISP_OFF)//SAMSUNG ;BACKUP_TITLEDSPSTATE(DISP_OFF)//CANON Samsung Electronics 4-15...
  • Page 33 ;NORMALLYPB PB/EDIT-PB : D33~D40 ;NORMALLYPB PB/EDIT-PB : D41~D48 ;NORMALLYPB PB/EDIT-PB : D49~D56 ;NORMALLYPB PB/EDIT-PB : D57~D64 ;NORMALLYPB PB/EDIT-PB : D65~D72 ;NORMALLYPB PB/EDIT-PB : D73~D80 ;NORMALLYPB PB/EDIT-PB : D81~D88 ;NORMALLYPB PB/EDIT-PB : D89~D96 ;NORMALLYPB PB/EDIT-PB : D97~D104 ;NORMALLYPB PB/EDIT-PB : D105~D112 4-16 Samsung Electronics...
  • Page 34 CAMERA R-Y BURST LEVEL ;CAM R-Y BURST LEVEL ;PB TBC OFF:PEDESTAL LEVEL ;PB TBC OFF:PB SYNC LEVEL ;SYNC SEP&AF ZONE ADD LEVEL ;Y AND CAM Y CLIP LEVEL ;CAM SYNC CUT LEVEL ;C RF OUTPUT A/D SETTING Samsung Electronics 4-17...
  • Page 35 CHANGED DATA BY MODEL ADDR MODEL/DATA CONTENT APPLY MODELS NTSC OPTION(DIS MODEL) VP-L750/VP-L770/SCL750/SCL770 OPTION(NON-DIS MODEL) VP-L710/SCL700 AGC ON H ENHANCER VP-L750/VP-L770/SCL750/SCL770 AGC ON H ENHANCER VP-L710/SCL700 AGC ON H CORE LEVEL VP-L750/VP-L770/SCL750/SCL770 AGC ON H CORE LEVEL VP-L710/SCL700 AGC ON V CORE LEVEL...
  • Page 36 NOTE: NTSC NORMAL ADDR.3CD~552 :CVF MODEL (CVF ONLY:HI8/NORMAL) DATA NTSC HI8 MODEL INITIAL DATA (000~7FF) NTSC HI8 ; 0 PAGE DATA(000~0FF) // 0 NTSC HI8 ; 1 PAGE DATA(100~1FF) // 0 NTSC HI8 ; 2 PAGE DATA(200~2FF) // 0 Samsung Electronics 4-19...
  • Page 37 Alignment and Adjustment NTSC HI8 ; 3 PAGE DATA(300~3FF) // 0 NOTE: NTSC HI8 ADDR.3CD~552 :NON-CVF MODEL (LCD/EVF:HI8/NORMAL) NTSC HI8 ; 4 PAGE DATA(400~4FF) // 0 NTSC HI8 ; 5 PAGE DATA(500~5FF) // 0 4-20 Samsung Electronics...
  • Page 38 Alignment and Adjustment NTSC HI8 ; 6 PAGE DATA(600~6FF) // 0 NTSC HI8 ; 7 PAGE DATA(700~7FF) // 0 NTSC NORMAL MODEL INITIAL DATA (000~7FF) NTSC NORMAL ; 0 PAGE DATA(000~0FF) // 0 Samsung Electronics 4-21...
  • Page 39 Alignment and Adjustment NTSC NORMAL ; 1 PAGE DATA(100~1FF) // 0 NTSC NORMAL ; 2 PAGE DATA(200~2FF) // 0 NTSC NORMAL ; 3 PAGE DATA(300~3FF) // 0 4-22 Samsung Electronics...
  • Page 40 Alignment and Adjustment NOTE: NTSC NORMAL ADDR.3CD~552 :CVF MODEL (CVF ONLY:HI8/NORMAL) NTSC NORMAL ; 4 PAGE DATA(400~4FF) // 0 NTSC NORMAL ; 5 PAGE DATA(500~5FF) // 0 NTSC NORMAL ; 6 PAGE DATA(600~6FF) // 0 Samsung Electronics 4-23...
  • Page 41 Alignment and Adjustment NTSC NORMAL ; 7 PAGE DATA(700~7FF) // 0 4-24 Samsung Electronics...
  • Page 42 NOTE: PAL NORMAL ADDR.3CD~552 :CVF MODEL (CVF ONLY:HI8/NORMAL) DATA PAL HI8 MODEL INITIAL DATA (000~7FF) PAL HI8 ; 0 PAGE DATA(000~0FF) // 0 PAL HI8 ; 1 PAGE DATA(100~1FF) // 0 PAL HI8 ; 2 PAGE DATA(200~2FF) // 0 Samsung Electronics 4-25...
  • Page 43 Alignment and Adjustment PAL HI8 ; 3 PAGE DATA(300~3FF) // 0 NOTE: PAL HI8 ADDR.3CD~552 :NON-CVF MODEL (LCD/EVF:HI8/NORMAL) PAL HI8 ; 4 PAGE DATA(400~4FF) // 0 PAL HI8 ; 5 PAGE DATA(500~5FF) // 0 4-26 Samsung Electronics...
  • Page 44 PAL HI8 ; 7 PAGE DATA(700~7FF) // 0 NOTE: PAL NORMAL ADDR.3CD~552 :NON-CVF MODEL (LCD/EVF:NORMAL/NORMAL) DATA NOTE: PAL NORMAL ADDR.3CD~552 :CVF MODEL (CVF ONLY:NORMAL/NORMAL) DATA PAL NORMAL MODEL INITIAL DATA (000~7FF) PAL NORMAL ; 0 PAGE DATA(000~0FF) // 0 Samsung Electronics 4-27...
  • Page 45 Alignment and Adjustment PAL NORMAL ; 1 PAGE DATA(100~1FF) // 0 PAL NORMAL ; 2 PAGE DATA(200~2FF) // 0 PAL NORMAL ; 3 PAGE DATA(300~3FF) // 0 4-28 Samsung Electronics...
  • Page 46 Alignment and Adjustment NOTE: PAL NORMAL ADDR.3CD~552 :NON-CVF MODEL (LCD/EVF:NORMAL/NORMAL) PAL NORMAL ; 4 PAGE DATA(400~4FF) // 0 PAL NORMAL ; 5 PAGE DATA(500~5FF) // 0 PAL NORMAL ; 6 PAGE DATA(600~6FF) // 0 Samsung Electronics 4-29...
  • Page 47 Alignment and Adjustment PAL NORMAL ; 7 PAGE DATA(700~7FF) // 0 4-30 Samsung Electronics...
  • Page 48 The camera will move both zoom and focus lens. The adjustment is finished when the O.K! message appears on the TV screen. Store the data to mode 099, 09A, 0AA, 0AB, 0AD, 0C9, 0CA, 0CB and 0CC. (3M±1cm) (Be sure to maintain the distance.) LENS Samsung Electronics 4-31...
  • Page 49 Store the data to mode 0A6, 0A7, 0A8, 0A9 a-4. The OSD shows “OK!”. b. W/B Outdoor b-1. Aim the camera at a 5100°K gray-scale (3100°K+CCB12) chart illuminated at 1500 to 2000 lx. (40us) 4-32 Samsung Electronics...
  • Page 50 6) Adjust the “ P.AE(DATA UP)/DSE(DATA DOWN)” button so that the white vector moves to the R-Y axial on screen of the vectorscope. Note : Bright dot shifts after the confirm button is pressed. 70 IRE (NTSC) 500mV (PAL) Samsung Electronics 4-33...
  • Page 51 DOWN)” button so that theRed vector is 105. 7) Be sure to press the “ENTER (CONFIRM)” but- CYAN VECTOR ton to memorize setting. 284 DEG. Note : Bright dot shifts after the confirm button is pressed. (outdoor : 038, 039) 4-34 Samsung Electronics...
  • Page 52 346 DEG. Note : Outdoor(5100°K) color Gain & Hue adjust. - 5100°K color bar (or 3100°K color bar with CCB12 Filter) - Restart step 7. prewhite balance(I) ~ step 14. Ye-G Hue. - The outdoor(5100°K) mode in 034~03F. Samsung Electronics 4-35...
  • Page 53 Then unit goes into service mode. EPR : XX EVR : XX DATA DOWN MODE DOWN MODE ‘100’ UP CONFIRM MODE UP DATA UP Note : When XX XX is shown in service adjustment procedures, this indicates variable values. 4-36 Samsung Electronics...
  • Page 54 2) Adjust ADDRESS that a data of 5E9 is equal to 15(default). If you want, you can adjust other data in range “00~35” (Adjustment of 5EA, 5EB is in the same way.) 3) Adjust ADDRESS that a data of 5EA is equal to 15(default). 4) Adjust ADDRESS that a data of 5EB is equal to 1A(default). Samsung Electronics 4-37...
  • Page 55 2) Adjust VRE02 and check that A level is 2.5Vp-p. if not, adjust A level to be 2.5Vp-p. 6PIN CONNECTOR A LEVEL 20us <Position of TP-V on EVF PCB> <TP-V Wave form> Notes : When XX XX is shown in service adjustment procedures, this indicates variable values. 4-38 Samsung Electronics...
  • Page 56 Address of the adjustment mode. Name of the adjustment mode. : there are 061h to 1 ch.(refer xxxx) : every address have a name like this (refer xxx) Present data New data : be adjusted before. : be adjusted newly. Samsung Electronics 4-39...
  • Page 57 5. If you want to finish the adjustment mode, you have to do “Battery Reset”. The “Battery Reset” means that you pull out the power source and pull in it again. Then, the adjustment is ended and the camcorder works normally. 4-40 Samsung Electronics...
  • Page 58 FRONT PCB MAIN PCB AUDIO GND VIDEO OUT CN452 PB RF AUDIO OUT HD SW VCR UNREG JIG CS VCR UNREG JIG SCK SS GND JIG SO REAR PCB JIG DETECT JIG SI Fig. 1 Video Signal Connection Samsung Electronics 4-41...
  • Page 59 Connect a power source. c. Get into the VCR adjustment mode. MODEL NAME ADDRESSED CODE d. Press the “BLC(MODE UP)” or “FADE(MODE SCL700 DOWN)” button of Camcorder so as to select SCL710 NTSC the address 061. SCL750 e. Insert the Standard Color Bar Tape and press SCL770 the “PLAY”...
  • Page 60 6.5H(NTSC)/7.0H(PAL) automatically. EPR : XX EVR : XX<6.5H> g. Be sure to press the “ENTER(CONFIRM)” but- ton on Camcorder to memorize setting. h. Reset the power source so as to fix the new data to the Camcorder’s EEPROM. Samsung Electronics 4-43...
  • Page 61 Alignment and Adjustment MEMO MEMO 4-44 Samsung Electronics...
  • Page 62 5-9 Ass’y Camera/Deck - - - - - - - - - - - - - - - - - - - - - - 5-18 5-10 Ass’y Rear - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-20 Samsung Electronics...
  • Page 63 Exploded View and Parts List 5-1 Mechanical Parts (1) Samsung Electronics...
  • Page 64 Exploded View and Parts List Loc. No New Part No Description and Specification Remark 6009-001287 SCREW-SPECIAL;SM45C,2,TH,+,M1.4,L3.9(3.2) 6001-001575 SCREW-MACHINE;PH,+,M1.4,L3.5,ZPC(BLK),SW 6001-001417 SCREW-MACHINE AD97-04500A ASSY-COVER-REEL;SUS+ETC,DE-10,ASSY AD97-04498A ASSY-IDLER;POM+ETC,DE-10,ASSY AD97-04757A HOUSING-ASSY;-,-,-,-,-,-,-,DE-6 AD97-04440A ASSY-DRUM PAL;-,DE-10,PAL AD97-04625A ASSY-SEMI DECK;DE-10 Samsung Electronics...
  • Page 65 Exploded View and Parts List 5-2 Mechanical Parts (2) Samsung Electronics...
  • Page 66 Loc. No New Part No Description and Specification Remark AD97-04497A ASSY-SUB-CHASSIS;SECC+ETC,DE-10,ASSY AC66-12041A REEL-S(ASSY);-,-,-,DE-6 AC66-12042A REEL-T(ASSY);-,-,-,DE-6 AC66-30120A LEVER-BRAKE SOFT T (ASSY);-,-,-,-,DE-6,- AD97-04490A ASSY-ARM-PINCH;-,DE-10,SUS+ETC AD97-04491A ASSY-POLE-BASE T;-,DE-10,PPS+ETC AD97-04493A ASSY-ARM-TENSION;-,DE-10,ASSY AD97-04494A ASSY-ARM-REVIEW;SUS+ETC,DE-10,ASSY AD97-04499A ASSY-BRAKE-SUB S;DURACON+ETC,DE-10,ASSY AD97-04522A ASSY-POLE-BASE S;PPS+ETC,DE-10,- AD61-00922A SPRING ETC-TENSION;DE-10,SWPB,-,-,-,-,-, AC61-62022A SPRING ETC-SOFT BRAKE(S);-,-,-,-,-,-,-,- Samsung Electronics...
  • Page 67 Exploded View and Parts List 5-3 Mechanical Parts (3) Samsung Electronics...
  • Page 68 WASHER-SLIT;ID 1,OD 2.6,T 0.4,POLYSLIDER AD66-00141A GEAR-CAPSTAN;DE-10,PA(1724K),-,-,-,-,-,- AD66-00142A GEAR-PULLEY;DE-10,DURACON M90-44,-,-,-,- AC66-62001A BELT-TIMMING;-,L137 T0.4,-,-,-,-,-,- AD66-00130A LEVER-CAM;DE-10,SUS430 CP,0.6,-,-,-,-,- AD66-00140A GEAR-CAM MAIN;DE-10,ZYTEL 70G-43L,-,-,-, AD97-04496A ASSY-SLIDE-MAIN;SECC+ETC,DE-10,ASSY AD66-00131A LEVER-EJECT;DE-10,DURANEX #3300,-,-,-,-, AD66-00139A GEAR-LOADING;DE-10,DURACON M90-44,-,-,-, AD97-04504A ASSY-LOADING-MOTOR;MOTOR+TEC,DE-10,ASSY AD97-04554A ASSY-CAPSTAN-MOTOR;-,DE-10,ASSY AD97-04555A ASSY-CAPSTAN MOTOR;-,DE-10,ASSY AD61-00950A HOLDER-FPC SUB;DE-10,POM,-,-,-,NATURAL,- AD97-04495A ASSY-MAIN CHASSIS;DE-10 Samsung Electronics...
  • Page 69 Exploded View and Parts List 5-4 Ass’y EVF Samsung Electronics...
  • Page 70 PLATE-NUT;SPTE T0.8 AD97-02441A ASSY-EVF LENS AD97-04665A ASSY-CASE EVF R AD73-00040A RUBBER-EYE CUP;SILICON D/GRAY AD66-00105A LINK-EVF;POM BLK AD66-00106A LINK-LOCK;ABS 94HB BLK AD64-00458A LOCKER-EVF;POM BLK AD61-00104A GUIDE-PLATE;SPTE T0.8 AD61-00297A SHAFT-EVF;SUS303 AD97-04455A ASSY-UNIT EVF;0.24”,NTSC AC60-10055A SCREW-TAPPING;M2X4 FZB AC60-10054A SCREW-TAPPING;M2X6,FZB AC60-10043A SCREW-TAPPING;1.7X6,FZB Samsung Electronics...
  • Page 71 Exploded View and Parts List 5-5 Ass’y Right 5-10 Samsung Electronics...
  • Page 72 AD64-00694A CASE-RIGHT;ABS94HB HF0660I G3532 AD64-00424A BUTTON-REC/STOP;ABS94HB RED AD61-00905A HOLDER-POWER;POM BLK AD64-00695A KNOB-POWER;ABS94HB HF0660I G3532 AD64-00696A LOCKER-POWER;ABS94HB GREEN AD61-00214A BRACKET-GRIP BACK;SUS304 T0.8 AD59-00044A UNIT-BELT GRIP;LEATHER, BLK AD97-03191A ASSY-CAP HOOD;ASS'Y AD61-00906A PLATE-SPRING POWER AD61-00915A SPRING-LOCK POWER AD60-10509A SCREW-TAP PWH Samsung Electronics 5-11...
  • Page 73 Exploded View and Parts List 5-6 Ass’y LCD 5-12 Samsung Electronics...
  • Page 74 BUTTON-LCD LOCK;PC/ABS AD64-00446A BUTTON-LCD REVERSE;ABS 94HB AD61-00585A GUIDE-LCD LOCK;POM BLK AD61-12033A BRKT-NUT;SECC T0.8 AD61-00344A SPRING-LCD LOCK;SWPB AD61-00627A SPRING-LCD REVERSE;SUS304 WPB AD97-02487A ASSY-HINGE;ASSY AC60-10019A SCREW-MACHINE;M2X4 FZB AC60-10028A SCREW-MACHINE;M1.7X3 FZB AC60-10043A SCREW-TAPPING;TAP1.7X6 FZB AC60-12128A SCREW-TAPPING;TAP1.7X4 FEB 6001-001291 SCREW-MACHIN;M1.7X4 FZB Samsung Electronics 5-13...
  • Page 75 Exploded View and Parts List 5-7 Ass’y Left 5-14 Samsung Electronics...
  • Page 76 Exploded View and Parts List Loc. No New Part No Description and Specification Remark AD63-00065C COVER-LI BATTERY AD63-00315A COVER-LEFT(W4);ABS94HB HG0760 G6238,TITAN SCL700 AD63-00315B COVER-LEFT(W4);ABS94HB HG0760 G6238,TITAN SCL710 AD63-00315C COVER-LEFT(W4);ABS94HB HG0760 G6238,TITAN SCL750 AD63-00315D COVER-LEFT(W4);ABS94HB HG0760 G6238,TITAN SCL770 AD64-70085A BADGE-SAMSUNG(30);AL (30mm) AD64-00753A BUTTON-EASY(W4);ABS94HB NTR...
  • Page 77 Exploded View and Parts List 5-9 Ass’y Front 5-16 Samsung Electronics...
  • Page 78 Exploded View and Parts List Loc. No New Part No Description and Specification Remark AD64-00693G CASE-FRONT;880X,MIC(X),USB(X),TITAN SCL700/SCL710 AD64-00693H CASE-FRONT;880X,MIC(O),USB(X),TITAN SCL750 AD64-00693J CASE-FRONT;880X,MIC(O),USB(O),TITAN SCL770 AD67-00157A LENS-HOOD(AL);AL AD67-00038C LENS-HOOD(22X);ABS 94HB BLK AD64-00697A MASK-LAMP;PC CLR SCL700/SCL750/SCL770 AD63-00299A COVER-DUMMY LAMP SCL710 AD67-00156A MIRROR-LAMP;NYLON66(5232G) SCL700/SCL750/SCL770 AD64-00698A WINDOW-REMOCON;PMMA TITANE...
  • Page 79 Exploded View and Parts List 5-10 Ass’y Camera/Deck 5-18 Samsung Electronics...
  • Page 80 Description and Specification Remark AD97-02879A ASSY-ZOOM LENS;22X AD97-04856A ASSY-CCD AD61-00576A BRACKET-LENS(22X)-180;SUS304 T0.5(22X) AD63-62008A SPACER-CCD;SILICON (Hi8) AD29-92001F FILTER-OLP;OG-BF455 AD61-00222A CHASSIS-TOP AD61-00904A CHASSIS-BOTTOM AD92-00005A ASSY-PCB DECK FPC AD97-04462A ASSY-ROTARY FPC AD64-00422A CASE-TOP;W-PJ,ABS94HB AD97-04370A ASSY-DECK;DE-10 NTSC AC60-10054A SCREW-TAPTITE(2X6);BLK AC60-10024A SCREW-MACHINE(2X3);YEL Samsung Electronics 5-19...
  • Page 81 Exploded View and Parts List 5-11 Ass’y Rear 5-20 Samsung Electronics...
  • Page 82 Exploded View and Parts List Loc. No New Part No Description and Specification Remark AD63-00064D COVER-JIG;W-PJ/D/GRAY,ABS94HB AD97-03188A ASSY-CASE REAR;ASS'Y:Hi8 (D.ZOOM)- SCL700/SCL710 AD97-02604A ASSY-CASE REAR;ASS'Y:Hi8 (S.SHOT) SCL750/SCL770 AD64-00418E CASE-REAR;Hi8 (D.ZOOM) SCL700/SCL710 AD64-00418C CASE-REAR;Hi8 (S.SHOT) SCL750/SCL770 AD61-00578A BRACKET-REAR(W2);SUS304 T0.8 1/2H AD64-00423A BUTTON-SNAP SHOT;ABS94HB HF0660I G3532 AD61-00573A HOLDER-BATTERY EJECT;ABS94HB HF0660I G3532 ALL...
  • Page 83 Exploded View and Parts List MEMO MEMO 5-22 Samsung Electronics...

  • Page 84: Electrical Parts List

    2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, C163 2203-001408 C-CERAMIC,CHIP;0.27nF,5%,50V,NP0,TP,1608 C512 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608 C167 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C513 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608 C171 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C514 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608 C172 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 C516 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP C173 2203-002605 C-CERAMIC,CHIP;0.008nF,0.25pF,50V,NP0,TP C517 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608, C174 2203-000236 C-CERAMIC,CHIP;0.1nF,5%,50V,NP0,TP,1608 C518 2203-000888 C-CERAMIC,CHIP;4.7nF,10%,50V,X7R,TP,1608 Samsung Electronics...
  • Page 85 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP C702 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608, C918 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP C703 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, C919 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP C704 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, C920 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP C705 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608, C921 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP C706 2404-001131 C-TA,CHIP;22UF,10%,10V,GP,TP,3528 C922 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2 C707 2404-000232 C-TA,CHIP;4.7uF,20%,10V,-,TP,3216,- C923 2203-005644 C-CERAMIC,CHIP;10000nF,10%,6.3V,X5R,TP,3 Samsung Electronics...
  • Page 86 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 CL05 2203-000799 C-CERAMIC,CHIP;33nF,10%,16V,X7R,TP,1608 CP18 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, CL06 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, CP19 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 CL07 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, CP20 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 CL08 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, CP21 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, CL09 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, CP22 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, CL10 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2 CP23 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 Samsung Electronics...
  • Page 87 2703-000375 INDUCTOR-SMD;82uH,5%,2.5x2x1.8mm CV20 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, L187 2703-000376 INDUCTOR-SMD;8.2uH,5%,2.5x2x1.8mm CV21 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 L201 2703-000409 INDUCTOR-SMD;47uH,10%,3.2x2.5x2.2mm CV22 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 L401 2703-000396 INDUCTOR-SMD;10uH,10%,2.5x2x1.8mm CV23 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 L701 2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm CV26 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 L702 2703-000002 INDUCTOR-SMD;100uH,10%,2.5x3.2x2mm D601 0401-001054 DIODE-SWITCHING;KDS160,85V,300mA,SOD-323 L902 2703-001871 INDUCTOR-SMD;10UH,20%,6X6X2.8MM Samsung Electronics...
  • Page 88 Q453 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT- R110 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608 Q454 0504-001035 TR-DIGITAL;KRA301,PNP,100MW,4.7K/4.7K,SO R111 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608 Q455 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT- R112 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608 Q501 0501-002312 TR-SMALL SIGNAL;HN2C01FU,NPN,200mW,UMD6, R114 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608 Q502 0501-002312 TR-SMALL SIGNAL;HN2C01FU,NPN,200mW,UMD6, R115 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608 Q601 0504-001040 TR-DIGITAL;KRC403,NPN,100MW,22K/22K,SOT- R116 2007-000129 R-CHIP;27Kohm,5%,1/16W,DA,TP,1608 Samsung Electronics...
  • Page 89 2007-000503 R-CHIP;2.2ohm,5%,1/16W,DA,TP,1608 R174 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 R519 2007-000503 R-CHIP;2.2ohm,5%,1/16W,DA,TP,1608 R175 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 R520 2007-000503 R-CHIP;2.2ohm,5%,1/16W,DA,TP,1608 R176 2007-000122 R-CHIP;1.2Kohm,5%,1/16W,DA,TP,1608 R521 2007-000483 R-CHIP;1OHM,5%,1/10W,DA,TP,2012 R177 2007-000081 R-CHIP;2.7Kohm,5%,1/16W,DA,TP,1608 R522 2007-000483 R-CHIP;1OHM,5%,1/10W,DA,TP,2012 R178 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608 R523 2007-000483 R-CHIP;1OHM,5%,1/10W,DA,TP,2012 R179 2007-000122 R-CHIP;1.2Kohm,5%,1/16W,DA,TP,1608 R524 2007-000483 R-CHIP;1OHM,5%,1/10W,DA,TP,2012 Samsung Electronics...
  • Page 90 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608 R589 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608 R650 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608 R590 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608 R651 2007-000106 R-CHIP;220Kohm,5%,1/16W,DA,TP,1608 R591 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608 R652 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608 R593 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 R653 2007-000106 R-CHIP;220Kohm,5%,1/16W,DA,TP,1608 R594 2007-000691 R-CHIP;3.3Mohm,5%,1/16W,DA,TP,1608 R655 2007-000863 R-CHIP;4.3OHM,5%,1/10W,DA,TP,2012 R595 2007-000691 R-CHIP;3.3Mohm,5%,1/16W,DA,TP,1608 R656 2007-000060 R-CHIP;100Kohm,1%,1/16W,DA,TP,1608 Samsung Electronics...
  • Page 91 2007-001694 R-CHIP;12Kohm,0.5%,1/16W,DA,TP,1608 R703 2007-000134 R-CHIP;33Kohm,5%,1/16W,DA,TP,1608 R925 2007-000458 R-CHIP;18Kohm,5%,1/16W,DA,TP,1608 R704 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608 R926 2007-001644 R-CHIP;10Kohm,0.5%,1/16W,DA,TP,1608 R705 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608 R927 2007-000043 R-CHIP;1Kohm,1%,1/16W,DA,TP,1608 R706 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 R928 2007-000086 R-CHIP;5.6Kohm,5%,1/16W,DA,TP,1608 R708 2007-000134 R-CHIP;33Kohm,5%,1/16W,DA,TP,1608 R929 2007-001649 R-CHIP;4.7Kohm,0.5%,1/16W,DA,TP,1608 R709 2007-000462 R-CHIP;18OHM,5%,1/10W,DA,TP,2012 R930 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608 Samsung Electronics...
  • Page 92 2007-000134 R-CHIP;33Kohm,5%,1/16W,DA,TP,1608 RP28 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 RL16 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608 RP29 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608 RL17 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608 RP30 2007-000763 R-CHIP;330ohm,1%,1/16W,DA,TP,1608 RL18 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608 RP300 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608 RL19 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608 RP301 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608 RL20 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 RP31 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 RL21 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608 Samsung Electronics...
  • Page 93 2301-001092 C-FILM,MPEF;100nF,20%,275V,BK,18x6x12,15 RV21 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012 2401-003302 C-AL;47uF,20%,400V,GP,TP,18X31.5,7. RV24 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608 2401-003046 C-AL;47uF,20%,50V,WT,TP,6.3x11,2.5 SW601 3404-001034 SWITCH-TACT;12V,50mA,160gf,4x7.4x1.8mm,S 2203-000716 C-CERAMIC,CHIP;3.3nF,10%,50V,X7R,TP,2012 SW602 3404-001034 SWITCH-TACT;12V,50mA,160gf,4x7.4x1.8mm,S 2203-000716 C-CERAMIC,CHIP;3.3nF,10%,50V,X7R,TP,2012 SW603 3404-001034 SWITCH-TACT;12V,50mA,160gf,4x7.4x1.8mm,S 2203-000716 C-CERAMIC,CHIP;3.3nF,10%,50V,X7R,TP,2012 SW606 3404-001034 SWITCH-TACT;12V,50mA,160gf,4x7.4x1.8mm,S 2201-000828 C-CERAMIC,DISC;3.3nF,20%,400V,Y5U,TP,15x SW607 3404-001034 SWITCH-TACT;12V,50mA,160gf,4x7.4x1.8mm,S 2401-000133 C-AL;1000uF,20%,16V,GP,TP,10x20,5 6-10 Samsung Electronics...
  • Page 94 2203-000239 C-CERAMIC,CHIP;0.1nF,5%,50V,NP0,TP,2012 0501-000457 TR-SMALL SIGNAL;MMBT2222A,NPN,350MW,SOT- CT04 2203-000199 C-CERAMIC,CHIP;100nF,+80-20%,50V,Z5U,TP, 2007-000477 R-CHIP;1MOHM,5%,1/10W,DA,TP,2012 ICT01 AD09-00005A IC-MCU;KS51850-H9D,-,REEL,-,-,SOP,- 2007-000481 R-CHIP;1MOHM,5%,1/8W,DA,TP,3216 LDT01 0601-000519 LED-IR;ROUND,5mm,170mW,4V,940nm,- 2007-000481 R-CHIP;1MOHM,5%,1/8W,DA,TP,3216 RT01 2007-000483 R-CHIP;1OHM,5%,1/10W,DA,TP,2012 2003-000771 R-METAL OXIDE(S);68Kohm,5%,2W,AA,TP,4x12 XT01 2802-000148 RESONATOR-CERAMIC;455KHz,0.4%,BK,7.0x3.5 2007-000598 R-CHIP;22OHM,5%,1/8W,DA,TP,3216 2007-000768 R-CHIP;330OHM,5%,1/8W,DA,TP,3216 ASSY-FRONT BOARD;USB,W4-PJ,RMT O,LIGHT O Samsung Electronics 6-11...
  • Page 95 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2 R473 2007-000071 R-CHIP;22ohm,5%,1/16W,DA,TP,1608 CU65 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2 SW471 3409-001035 SWITCH-DETECTOR;3~5V,50uA~10mA,2,30gf,LE CU66 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, SW473 3404-001117 SWITCH-TACT;12V,50mA,130gf,8.0x3.7x2.5mm ICU01 0904-001638 IC-USC;ARK-8601,16BIT,BGA,96P,13X13MM SW474 3404-001119 SWITCH-TACT;12V,50mA,130gf,6.2x6.2x2.6mm ICU02 1204-001573 IC-VIDEO PROCESS;SAA7113H,QFP,44P,393MIL SW477 3409-001035 SWITCH-DETECTOR;3~5V,50uA~10mA,2,30gf,LE ICU03 1203-002013 IC-VOLTAGE REGULATOR;62FP3302,SOT-23,3P, SW478 3409-001036 SWITCH-DETECTOR;3~5V,50uA~10mA,2,30gf,LE 6-12 Samsung Electronics...
  • Page 96 SW472 3404-001118 SWITCH-TACT;12V DC,50mA,130gf,5x6x4.3mm, RE21 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608 SW475 3404-001118 SWITCH-TACT;12V DC,50mA,130gf,5x6x4.3mm, RE22 2007-000342 R-CHIP;120OHM,1%,1/10W,DA,TP,2012 SW476 3404-001118 SWITCH-TACT;12V DC,50mA,130gf,5x6x4.3mm, RE24 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608 SW477 3404-001118 SWITCH-TACT;12V DC,50mA,130gf,5x6x4.3mm, RE25 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608 SW478 3404-001118 SWITCH-TACT;12V DC,50mA,130gf,5x6x4.3mm, RE26 2007-000125 R-CHIP;3.9Kohm,5%,1/16W,DA,TP,1608 CN471 3708-001564 CONNECTOR-FPC/FFC/PIC;19P,1mm,ANGLE,SN Samsung Electronics 6-13...
  • Page 97 ICL201 0801-002732 IC-CMOS LOGIC;TC7WT126FU,INVERTER,SSOP,8 ICL202 0801-002733 IC-CMOS LOGIC;TC7WT125FU,BUFFER,SSOP,8P, ICL203 0801-000301 IC-CMOS LOGIC;7W04,INVERTER,SSOP,8P,110M LL101 2703-000396 INDUCTOR-SMD;10uH,10%,2.5x2x1.8mm LL102 2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm LL103 2703-001196 INDUCTOR-SMD;150uH,20%,7x7x3.2mm LL201 2703-001883 INDUCTOR-SMD;22uH,10%,2.5x2x1.8mm LL202 2703-000396 INDUCTOR-SMD;10uH,10%,2.5x2x1.8mm LL203 2703-001883 INDUCTOR-SMD;22uH,10%,2.5x2x1.8mm LL204 2703-001883 INDUCTOR-SMD;22uH,10%,2.5x2x1.8mm QL101 0501-002310 TR-SMALL SIGNAL;HN1B04FU,PNP/NPN,200mW,U 6-14 Samsung Electronics...
  • Page 98 7-8 CCD PCB - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-9 7-9 USB PCB - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-10 Samsung Electronics...
  • Page 99 PCB Diagrams 7-1 Main PCB (Component Side) Samsung Electronics...
  • Page 100 PCB Diagrams Samsung Electronics...
  • Page 101 PCB Diagrams 7-2 Main PCB (Conductor Side) Samsung Electronics...
  • Page 102 PCB Diagrams Samsung Electronics...
  • Page 103 PCB Diagrams 7-3 Rear PCB (Component Side) (Conductor Side) Samsung Electronics...
  • Page 104 PCB Diagrams 7-4 EVF PCB (Component Side) (Conductor Side) Samsung Electronics...
  • Page 105 PCB Diagrams 7-5 Function PCB 7-6 Front PCB 7-7 LCD PCB Samsung Electronics...
  • Page 106 PCB Diagrams 7-8 CCD PCB (Component Side) (Conductor Side) Samsung Electronics...
  • Page 107 PCB Diagrams 7-9 USB PCB (Component Side) (Conductor Side) 7-10 Samsung Electronics...
  • Page 108 8. Wiring Diagram Samsung Electronics...
  • Page 109 Wiring Diagram MEMO MEMO Samsung Electronics...

  • Page 110: Schematic Diagrams

    9-10 CAMERA (Main) - - - - - - - - - - - - - - - - - - - - - - - - 9-11 9-11 USB - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9-12 Samsung Electronics...
  • Page 111 Schematic Diagrams 9-1 DC/DC Converter (Main) Samsung Electronics...
  • Page 112 Schematic Diagrams 9-2 System Control (Main) Samsung Electronics...
  • Page 113 Schematic Diagrams 9-3 Audio (Main) Samsung Electronics...
  • Page 114 Schematic Diagrams 9-4 Pre-Amp (Main) Samsung Electronics...
  • Page 115 Schematic Diagrams 9-5 Front Samsung Electronics...
  • Page 116 Schematic Diagrams 9-6 Function Samsung Electronics...
  • Page 117 Schematic Diagrams 9-7 EVF Samsung Electronics...
  • Page 118 Schematic Diagrams 9-8 LCD Samsung Electronics...
  • Page 119 Schematic Diagrams 9-9 CCD 9-10 Samsung Electronics...
  • Page 120 Schematic Diagrams 9-10 CAMERA (Main) Samsung Electronics 9-11...
  • Page 121 C819 680nF R808 VDDA Y(0:7) AGND VIN1 AVSS AVDD AGND XTAL1 IC802 PVSS VICLK PIXCLK VDDD VDDD XTAL2 PVDD VPX3226E VDDD X802 AGND 20.250MHZ RES* UV(0:7) CN802 SCLK J801 CN801 MIC_JACK VIDEO_IN SNDGND AGND LIGHT_VCC LIGHT_GND LIGHT 9-12 Samsung Electronics...
  • Page 122 COVER 2/26/02 8:30 AM Page 1 8mm CAMCORDER DE-10 MECHANICAL Manual File with the SERVICE MANUAL. CAMCORDER CONTENTS 1. Operation 2. Adjustment 3. Disassembly and Reassembly © Samsung Electronics Co., Ltd. JAN. 2002 Printed in Korea AD68-00420H...
  • Page 123 3 SWITCH MODE 9 DRUM E GEAR IDLER 4 ARM TENSION 0 MOTOR CAPSTAN F REEL T 5 POLE BASE S A GEAR CAPSTAN G HOLDER FPC SUB 6 BRAKE SUB S ASS'Y B ARM REVIEW H BRAKE SOFT T Samsung Electronics...
  • Page 124 1 MOTOR LOADING 8 GEAR CAPSTAN 2 GEAR LOADING 9 SLIDER MAIN 3 SWITCH MODE 0 BELT TIMING 4 GEAR CAM MAIN A LEVER EJECT 5 LEVER CAM B GEAR PULLEY 6 DRUM C HOLDER FPC SUB 7 MOTOR CAPSTAN Samsung Electronics...
  • Page 125 Chassis Sub loading BL 4 STOP 202° ~ 208° Stopped BL 5 PLAY 262.5° ~ (287°) In REC/CUE/REV/FF/REW/PAUSE NOTE : 0 : Opened 1 : Connected with COMMON REFERENCE LINE OF SWITCH MODE AND GEAR CAM MAIN Fig. 1-3 Samsung Electronics...
  • Page 126 Gear Loading 4 rotates. ↓ Switch Mode 5 rotates. ↓ Gear Cam Main 6 rotates. 2 GEAR WHEEL MOTOR MOTOR LOADING 1 GEAR WORM LOADING 3 GEAR LOADING 4 SWITCH MODE 5 GEAR CAM MAIN 6 Fig. 1-4 Samsung Electronics...
  • Page 127 Gear Cam Main 4 rotates. ↓ SUB LOAD Lever Cam 5 turns. ↓ Chassis Sub 6 slides. STOP PLAY MOTOR LOADING 1 GEAR LOADING 2 SWITCH MODE 3 GEAR CAM MAIN 4 LEVER CAM 5 CHASSIS SUB 6 Fig. 1-5 Samsung Electronics...
  • Page 128 Slider Main 3 slides in direction of arrow. ↓ Lever Brake S 5 released by Slider Main 3 . STOP PLAY MOTOR LOADING 1 SLIDER MAIN 3 LEVER BRAKE S 5 LEVER SUB S 4 CHASSIS SUB 2 REEL S 6 Fig. 1-6 Samsung Electronics...
  • Page 129 SUB LOAD Brake Soft T 5 ; Reel T rotates clockwise. (One-way effect) ; Reel T rotates counterclockwise. STOP PLAY MOTOR 1 LOADING 2 CHASSIS SUB 3 SLIDER MAIN 4 REEL T 5 BRAKE SOFT T Fig. 1-7 Samsung Electronics...
  • Page 130 After loading is complete, Arm Tension 3 moves by S/W Mode Cam SUB LOAD Curve 5 . STOP PLAY CHASSIS MAIN 7 MOTOR LOADING 1 ARM TENSION 3 SPRING TENSION 6 S/W MODE CAM CURVE 5 CAM CURVE 4 2 CHASSIS Fig. 1-8 Samsung Electronics...
  • Page 131 ↓ Pinch Roller 6 released from shaft of Motor Capstan 5 . ; Return to STOP PLAY MOTOR LOADING 1 5 MOTOR CAPSTAN 6 PINCH ROLLER 4 SLIDER MAIN 3 ARM PINCH ROLLER 2 CHASSIS SUB Fig. 1-9 Samsung Electronics...
  • Page 132 Pole Base S 6 , T 7 attaches to “V” groove of Main Chassis 8 . STOP PLAY MAIN CHASSIS 8 MOTOR LOADING 1 POLE BASE S 6 7 POLE BASE T 3 SLIDER MAIN ARM LOADING S 4 5 ARM LOADING T 2 CHASSIS SUB Fig. 1-10 1-10 Samsung Electronics...
  • Page 133 Arm Review 5 simulaneously rotates and translates by Cam Curve 4 of UNLOAD Chassis Main 3 . SUB LOAD STOP PLAY MOTOR LOADING 1 3 CHASSIS MAIN 5 ARM REVIEW 4 CAM CURVE 2 CHASSIS SUB Fig. 1-11 Samsung Electronics 1-11...
  • Page 134 Gear Idler 5 engages Reel T 6 or Reel S 7 . ↓ Reel T 6 or Reel S 7 rotates. DRUM 1 MOTOR CAPSTAN 2 GEAR CAPSTAN 3 BELT TIMING 6 REEL T REEL S 7 5 GEAR IDLER 4 GEAR PULLEY Fig. 1-12 1-12 Samsung Electronics...
  • Page 135 Lever Locker 4 hooks on Chassis Sub Key release 3 of Chassis Sub releases reel lock of cassette tape. Catch 5 , and Housing is locked. Lever Locker’s Front Edge 6 turns on S/W Push 7 . Fig. 1-13 Samsung Electronics 1-13...
  • Page 136 Arm Tension rotates in direc- reverse and then stops. by Slider Main, and Pinch tion of arrow slightly, and Roller detaches from Lever Brake S, Brake Main T Capstan Shaft. contact Reel for braking. ARM TENSION Fig. 1-14 1-14 Samsung Electronics...
  • Page 137 GEAR LOADING GEAR CAPSTAN SWITCH MODE SLIDER MAIN GEAR CAM MAIN BELT TIMING LEVER CAM GEAR PULLEY DRUM CAPSTAN SHAFT PINCH ROLLER LEVER BRAKE S REEL T REEL S BRAKE SOFT T BRAKE SUB S Fig. 1-15 Samsung Electronics 1-15...
  • Page 138 Shaft. Motor Loading stops. Motor Capstan rotates forward. Gear Capstan and Belt Timing, Gear Pulley, Gear Idler rotate. Reel S rotates. Reel T rotates. * The tape fed from the Motor Capstan is wound by this operation. 1-16 Samsung Electronics...
  • Page 139 DRUM PINCH ROLLER ARM TENSION LEVER BRAKE S REEL T BRAKE SUB S BRAKE SOFT T GEAR IDLER MOTOR LOADING CAPSTAN SHAFT GEAR LOADING GEAR CAPSTAN SWITCH MODE GEAR CAM MAIN SLIDER MAIN GEAR PULLEY Fig. 1-16 Samsung Electronics 1-17...
  • Page 140 Gear Capstan and Belt Timing, Gear Pulley, Gear Idler rotate. Reel T rotates 19 times faster Pinch Roller rotates 19 times faster than PLAY mode. than PLAY mode. * This operation feeds tape 19 times faster than PLAY mode. 1-18 Samsung Electronics...
  • Page 141 LEVER BRAKE S REEL T BRAKE SUB S BRAKE SOFT T GEAR IDLER MOTOR LOADING CAPSTAN SHAFT GEAR LOADING GEAR CAPSTAN SWITCH MODE GEAR CAM MAIN SLIDER MAIN GEAR PULLEY PINCH ROLLER SLIDER MAIN TENSION Fig. 1-17 Samsung Electronics 1-19...
  • Page 142 Brake Soft T contacts Reel T by reverse rotation of Reel T. Reel S rotates 19 times faster than Pinch Roller rotates 19 times faster PLAY mode. than PLAY mode. * This operation feeds tape backward 19 times faster than PLAY mode. 1-20 Samsung Electronics...
  • Page 143 REEL T BRAKE SUB S BRAKE SOFT T GEAR IDLER MOTOR LOADING CAPSTAN SHAFT GEAR LOADING GEAR CAPSTAN SWITCH MODE GEAR CAM MAIN SLIDER MAIN GEAR PULLEY PINCH ROLLER SLIDER MAIN TENSION * ONE-WAY EFFECT Fig. 1-18 Samsung Electronics 1-21...
  • Page 144 Reel T stops. Reel S stops. * Drum is still rotating during REC/PAUSE . Push START/STOP key. * Tape is wound to Reel T Motor Capstan rotates. Pinch Roller rotates. by this operation. Reel T rotates. Reel S rotates. 1-22 Samsung Electronics...
  • Page 145 LEVER BRAKE S REEL T BRAKE SUB S BRAKE SOFT T GEAR IDLER MOTOR LOADING CAPSTAN SHAFT GEAR LOADING GEAR CAPSTAN SWITCH MODE GEAR CAM MAIN SLIDER MAIN GEAR PULLEY PINCH ROLLER SLIDER MAIN TENSION Fig. 1-19 Samsung Electronics 1-23...
  • Page 146 * S/W Push is turned off. Lever Locker to release lock of Housing. Motor Loading stops. Housing raised. (Eject completed.) Motor Capstan stops. Motor Loading rotates. Lever Eject moves back by Slider Main to lock Housing. Motor Loading stops. 1-24 Samsung Electronics...
  • Page 147 ARM PINCH ROLLER GEAR IDLER LEVER BRAKE S REEL T BRAKE SUB S BRAKE SOFT T REEL S MOTOR CAPSTAN GEAR LOADING GEAR CAPSTAN SWITCH MODE SLIDER MAIN GEAR CAM MAIN LEVER CAM GEAR PULLEY CHASSIS SUB Fig. 1-20 Samsung Electronics 1-25...
  • Page 148 Gear Capstan and Belt Timing, Gear Pulley, Gear Idler rotate. Reel S rotates approx. 9 times faster. Reel T rotates approx. 9 times faster. * Tape which is fed by Motor Capstan is wound up to Reel T. 1-26 Samsung Electronics...
  • Page 149 Operation DRUM MOTOR CAPSTAN GEAR CAPSTAN BELT TIMING REEL S REEL T GEAR IDLER GEAR PULLEY Fig. 1-21 Samsung Electronics 1-27...
  • Page 150 Gear Idler contacts Reel S. Reel T rotates in reverse approx. 7 times Reel S rotates in reverse approx. 7 times faster. faster. * Tape which is fed by Motor Capstan is wound up to Reel S. 1-28 Samsung Electronics...
  • Page 151 DRUM PINCH ROLLER ARM TENSION LEVER BRAKE S REEL T BRAKE SUB S BRAKE SOFT T GEAR IDLER MOTOR LOADING CAPSTAN SHAFT GEAR LOADING GEAR CAPSTAN SWITCH MODE GEAR CAM MAIN SLIDER MAIN GEAR PULLEY Fig. 1-22 Samsung Electronics 1-29...
  • Page 152 Operation MEMO MEMO 1-30 Samsung Electronics...
  • Page 153 Table 2-1 2. Choose the polarity (depending on whether Drum side Opposite side Movement of Chassis loading or unloading). 3. Supply the voltage to the Motor Loading, and set – Loading to the desired mode. – Unloading Fig. 2-2 Samsung Electronics...
  • Page 154 Upper Drum assembly clockwise. Also, the Head tip will be damaged if the lens tissue is moved in a perpendicular direction. Be sure to follow these instructions when cleaning the Drum Ass’y. PINCH ROLLER Fig. 2-3 Samsung Electronics...
  • Page 155 (Oil contaminated with dust might cause the bearings to wear out or seize.) A “drop” of oil is defined as the amount attached to the tip of a ø 2mm stick as shown in Fig. 2-4. ø 2mm Fig. 2-4 Samsung Electronics...
  • Page 156 Note : Check if the arm tension can be moved toward arrow C in PB mode. Use the tape which is fed to the end. 0~1mm Hole of Holder Loading ARM TENSION 1 BAND ADJUST TENSION 2 Fig. 2-5 Samsung Electronics...
  • Page 157 * Remarks : If the cassette torque tape is recorded both in the LP/SP modes by mistake, the torque at the switching point between SP/LP modes becomes unstable. In that case, do the torque adjustment in REC mode. Fig. 2-6 Samsung Electronics...
  • Page 158 The upper surface of the P.C.B Reel to the Reel S table resting surface and the Reel T table resting surface should each be 5.7 ± 0.2mm. REEL S TABLE REEL T TABLE RESTING SURFACE RESTING SURFACE SUB CHASSIS Fig. 2-7 Samsung Electronics...

  • Page 159: Tape Path Adjustment

    (Fig. 2-8 A). B DEFECT AT INLET If not flat (B or C in Fig. 2-8), do adjustments 2-5-2 through 2-5-5. C DEFECT AT OUTLET Fig. 2-8 REEL S REEL T Fig. 2-9 Samsung Electronics...
  • Page 160 2. Set to REV mode and observe the outlet waveform of PB RF signal. (Fig. 2-12) P7 CAPSTAN GUIDE ROLLER T (P5) GUIDE ROLLER S (P2) TAPE SHOULD NOT BE LOOSENED HERE Fig. 2-10 Fig. 2-11 (NG) (GOOD) Fig. 2-12 Samsung Electronics...
  • Page 161 3. Confirm that no large fluctuations occur on the Confirm that the waveform peaks still have a waveform. (Fig. 2-14) uniform pitch. (Fig. 2-15 a = b = c a b c a b c > 65(%) Fig. 2-13 Fig. 2-15 < Fig. 2-14 Samsung Electronics...
  • Page 162 Also confirm that the tape is not loosened or curled around the Pinch Roller. 4. Repeat steps 2. and 3. CAPSTAN GUIDE ROLLER TAPE SHOULD NOT BE LOOSENED OR CURLED HERE Fig. 2-16 FROM THE REEL S TO THE REEL T Fig. 2-17 2-10 Samsung Electronics...
  • Page 163 2. Choose the polarity depending on whether loading or unloading. (See Table 3-1) 3. Supply the voltage to the Motor Loading. Table 3-1 Drum side Opposite side Movement of chassis – Loading – Unloading Fig. 3-1 Loading and Unloading Samsung Electronics...
  • Page 164 Pin Arm 6 and lift the Housing Ass’y. 1 LEVER LOCK < Fig . A > 5 ARM R 3 LEVER 2 ROLLER SUB 4 ARM L 6 PIN ARM < Fig . B > 6 PIN ARM Fig. 3-2 Housing Samsung Electronics...
  • Page 165 Drum 3 . Do not touch the Head tip 4 during servicing. 1. Remove 3 screws 2 , then lift the Drum Ass’y 3 . 3 DRUM ASS'Y 4 HEAD TIP 1 MAIN CHASSIS 2 3 SCREWS Fig. 3-3 Drum Samsung Electronics...
  • Page 166 3. Secure with 2 screws 1 . 4. Mount the Holder FPC 6 and then secure with 1 screw. 1 2 SCREW 2 COVER REEL ASS'Y 5 1 SCREW 6 HOLDER 3 IDLER ASS'Y 4 PIN Fig. 3-4 Idler & Holder FPC Samsung Electronics...
  • Page 167 A SUB DECK CAM 2 SUB DECK ASS'Y 7 ARM TENSION ASS'Y 4 2 BOSS 6 PIN 5 2 RAILS Fig . B LEVER CAM Fig . A 3 MAIN DECK ASS'Y 9 GUIDE PIN Fig. 3-5 Sub Deck Samsung Electronics...
  • Page 168 2. Push the Pole Base T Ass’y 2 (arrow “D”). then remove it from Link Loading T 4 . 1 POLE BASE S ASS'Y 2 POLE BASE T ASS'Y 3 SUB DECK ASS'Y 4 LINK LOADING T 5 LINK LOADING S Fig. 3-6 Pole Base S, T Samsung Electronics...
  • Page 169 1 ARM REVIEW ASS'Y 2 ARM PINCH ROLLER ASS'Y 7 GUIDE PIN 4 BUSH 3 SUB DECK HOLE 5 BUSH ARM PINCH REVIEW ASS'Y ROLLER ASS'Y Fig . A Fig . B Fig. 3-7 Arm Pinch Roller and Arm Review Samsung Electronics...
  • Page 170 3. Insert the Spring Tension 1 into the Spring Hook 2 ARM TENSION ASS'Y 5 PIN ARM TENSION 3 SPRING HOOK 1 SPRING TENSION 6 SUB DECK GUIDE HOLE 7 BUSH 4 SPRING HOOK Fig. 3-8 Arm Tension Samsung Electronics...
  • Page 171 6 BRAKE SOFT T 4 REEL S ASS'Y 7 REEL T ASS'Y 1 SPRING BRAKE SUB S 5 BRAKE SUB S ASS'Y 2 SPRING HOOK 3 SPRING HOOK Fig. 3-9 Reel (S, T), Brake Sub S Ass’y, Brake Soft T Samsung Electronics...
  • Page 172 Ass’y 3 are inserted into the Main Base. 3. Secure 2 screw 1 . 1 2 SCREW 3 MOTOR LOADING ASS'Y 6 GEAR LOADING 2 2 HOOKS 4 BOSS 5 S/W MODE ASS'Y Fig. 3-10 Motor Loading, Gear Loading 3-10 Samsung Electronics...
  • Page 173 4. Remove the Slider Main Ass’y 4 . (arrow “C”) 4 SLIDER MAIN ASS'Y 3 LEVER EJECT TIMING POINT 1 2 SCREWS 2 MOTOR CAPSTAN Fig . A 5 GEAR CAM MAIN Fig. 3-11 Motor Capstan, Lever Eject, Slider Main Samsung Electronics 3-11...
  • Page 174 1 WASHER SLIT 2 GEAR CAPSTAN 3 BELT TIMING 5 GEAR CAM MAIN TIMING (B) (HOLE) 6 LEVER CAM TIMING (A) (HOLE) 7 PIN Fig. 3-12 Gear Capstan, Gear Pulley Ass’y, Belt Timing, Gear Cam Main, Lever Cam 3-12 Samsung Electronics...

This manual is also suitable for:

Scl750Scl770Scl710

Table of Contents
