IMPORTANT MANUAL
OPERATOR'S MANUAL
MODEL:
PB14538LT
LAWN TRACTOR
ALWAYS WEAR EYE PROTECTION DURING OPERATION
Visit our website: www.poulanpro.com
Gasoline containing up to 10% ethanol (E10) is acceptable for use in this machine.
The use of any gasoline exceeding 10% ethanol (E10) will void the product warranty.
581 50 51-27
DO NOT THROW AWAY
WARNING:
Read this Man u al and follow all Warnings
and Safety Instructions. Fail ure to do so
can re sult in serious in ju ry.
09.28.12 JM
Printed in the U.S.A.
Advertisement
Table of Contents
Related Manuals for Poulan Pro PB14538LT
Summary of Contents for Poulan Pro PB14538LT
- Page 1 WARNING: MODEL: Read this Man u al and follow all Warnings and Safety Instructions. Fail ure to do so PB14538LT can re sult in serious in ju ry. LAWN TRACTOR ALWAYS WEAR EYE PROTECTION DURING OPERATION Visit our website: www.poulanpro.com Gasoline containing up to 10% ethanol (E10) is acceptable for use in this machine.
-
Page 2: Safety Rules
SAFETY RULES Safe Operation Practices for Ride-On Mowers DANGER: THIS CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROW ING OBJECTS. FAILURE TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH. • Never leave a running machine unattended. Always turn WARNING: In order to prevent ac ci den tal off blades, set parking brake, stop engine, and remove starting when setting up, trans port ing,... - Page 3 SAFETY RULES Safe Operation Practices for Ride-On Mowers III. CHILDREN • If fuel is spilled on clothing, change clothing immediately. • Never overfill fuel tank. Replace gas cap and tighten securely. WARNING. CHILDREN CAN BE INJURED BY THIS EQUIPMENT. The American Academy GENERAL SERVICE of Pediatrics recommends that children be a •...
-
Page 4: Table Of Contents
PRODUCT SPECIFICATIONS CONGRATULATIONS on your purchase of a new tractor. It has been designed, engineered and manu fac tured to Gasoline Capacity 1.50 Gallons (5,67 L) give you the best possible dependability and performance. and Type: Unleaded Regular Should you experience any problem you cannot easily Oil Type (API: SG-SL): SAE 30 (above 32°F/0°C) remedy, please contact your nearest authorized service... - Page 5 UNASSEMBLED PARTS Steering Wheel (1) Hex Bolt Steering Wheel Insert Steering Wheel (1) Large Steering Flat Washer Extension Shaft Steering Wheel Steering Boot (1) Lock Washer Adapter Seat (1) Knob (1) Washer (1) Seat Keys Oil Drain Extension Slope Sheet Key(s)
-
Page 6: Assembly
ASSEMBLY Your new tractor has been assembled at the factory with exception of those parts left unassembled for shipping purposes. To ensure safe and proper operation of your tractor all parts and hardware you assemble must be tightened securely. Use the correct tools as necessary to insure proper tightness. - Page 7 ASSEMBLY CHECK TIRE PRESSURE INSTALL SEAT (See Fig. 3) The tires on your tractor were overinflated at the factory Adjust seat before tightening adjustment knob. for shipping purposes. Correct tire pressure is important • Remove adjustment knob and flat washer securing for best cutting performance.
-
Page 8: Operation
OPERATION These symbols may appear on your tractor or in literature supplied with the product. Learn and understand their mean- ing. HIGH FAST SLOW REVERSE NEUTRAL CHOKE IGNITION SWITCH ENGINE START ENGINE ON PARKING BRAKE ENGINE OFF REVERSE PARKING BRAKE PARKING BRAKE OPERATION LOCKED... - Page 9 OPERATION KNOW YOUR TRACTOR READ THIS OPERATOR'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR TRACTOR Compare the illustrations with your tractor to familiarize yourself with the locations of various controls and ad just ments. Save this manual for future reference. ATTACHMENT ROS "ON"...
- Page 10 OPERATION The operation of any tractor can result in foreign objects thrown into the eyes, which can result in severe eye dam age. Always wear safety glass es or eye shields while operating your tractor or per form ing any ad just ments or repairs. We rec om mend standard safety glasses or a wide vision safety mask worn over spectacles.
- Page 11 OPERATION REVERSE OPERATION SYSTEM (ROS) "ENGAGED" POSITION Your tractor is equipped with a Reverse Operation System ATTACHMENT (ROS). Any attempt by the operator to travel in the reverse LIFT LEVER direction with the attachment clutch engaged will shut off HIGH PO SI TION the engine unless ignition key is placed in the ROS "ON"...
- Page 12 OPERATION TO START ENGINE (See Fig. 4) BEFORE STARTING THE ENGINE When starting the engine for the first time or if the engine CHECK ENGINE OIL LEVEL has run out of fuel, it will take extra cranking time to move fuel from the tank to the engine.
- Page 13 OPERATION MOWING TIPS • Tire chains cannot be used when the mower hous ing is attached to tractor. • Mower should be properly leveled for best mowing performance. See “TO LEVEL MOWER HOUSING” in the Service and Adjustments section of this manual. •...
-
Page 14: Maintenance Schedule
MAINTENANCE BEFORE EVERY EVERY EVERY EVERY EVERY BEFORE MAINTENANCE EACH SEASON STORAGE SCHEDULE HOURS HOURS HOURS HOURS Check Brake Operation Check Tire Pressure Check Operator Presence & ROS Systems Check for Loose Fasteners Check/Replace Mower Blades Lubrication Chart Check Battery Level Clean Battery and Terminals Check Transaxle Cooling Check Mower Levelness... -
Page 15: Maintenance
MAINTENANCE TRACTOR BLADE CARE For best results mower blades must be kept sharp. Re place Always observe safety rules when per form ing any bent or damaged blades. main te nance. CAUTION: Use only a replacement blade ap- BRAKE OPERATION proved by the manufacturer of your tractor. - Page 16 MAINTENANCE V-BELTS TO CHANGE ENGINE OIL (See Fig. 12) Check V-belts for deterioration and wear after 100 hours Determine temperature range expected before oil change. of operation and replace if necessary. The belts are not All oil must meet API service classification SG-SL. ad just able.
- Page 17 MAINTENANCE CLEAN AIR SCREEN IN-LINE FUEL FILTER (See Fig. 14) Air screen must be kept free of dirt and chaff to prevent The fuel filter should be replaced once each season. If fuel engine dam age from overheating. Clean with a wire brush filter becomes clogged, ob struct ing fuel flow to car bu re tor, re place ment is re quired.
-
Page 18: Service And Adjustments
SERVICE AND ADJUSTMENTS WARNING: TO AVOID SE RI OUS IN JU RY, BEFORE PERFORMING ANY SERVICE OR ADJUSTMENTS: • Depress clutch/brake pedal fully and set parking brake. • Place gearshift lever in neutral position. • Place attachment clutch in “DISENGAGED” position. •... - Page 19 SERVICE AND ADJUSTMENTS TO LEVEL MOWER HOUSING FRONT-TO-BACK ADJUSTMENT (See Figs. 18 and 19) Adjust the mower while tractor is parked on level ground IMPORTANT: DECK MUST BE LEVEL SIDE-TO-SIDE. IF THE FOLLOWING FRONT-TO-BACK ADJUSTMENT IS NECESSARY, or driveway. Make sure tires are properly inflated If tires BE SURE TO AD JUST BOTH FRONT LINKS EQUAL LY SO are over or underinflated, you will not properly adjust your MOWER WILL STAY LEVEL SIDE-TO-SIDE.
- Page 20 SERVICE AND ADJUSTMENTS TO REPLACE MOTION DRIVE BELT TO REPLACE MOWER BLADE DRIVE BELT (See Fig. 21) (See Fig. 20) Park the tractor on level surface. En gage parking brake. The mower blade drive belt may be replaced without tools. For as sis tance, there is a belt installation guide decal on Park the tractor on level surface.
- Page 21 SERVICE AND ADJUSTMENTS TRANSAXLE GEAR SHIFT LEVER NEU TRAL ADJUSTMENT (See Fig. 22) WASH ERS The transaxle should be in neutral when the gear shift lever is RE TAIN ING RING in neutral (lock gate) position. The adjustment is preset at the factory;...
- Page 22 SERVICE AND ADJUSTMENTS REPLACING BATTERY (See Fig. 25) TO REPLACE FUSE Replace with 20 amp automotive-type plug-in fuse. The WARNING: Do not short battery fuse holder is located behind the dash. ter mi nals by allowing a wrench or any other object to contact both terminals TO REMOVE HOOD AND GRILL ASSEMBLY at the same time.
-
Page 23: Storage
STORAGE ENGINE Immediately prepare your tractor for storage at the end of the season or if the tractor will not be used for 30 days or more. FUEL SYSTEM IMPORTANT: IT IS IMPORTANT TO PREVENT GUM DEPOSITS WARNING: Never store the trac tor with FROM FORMING IN ES SEN TIAL FUEL SYSTEM PARTS SUCH gas o line in the tank inside a building AS CARBURETOR, FUEL FIL TER, FUEL HOSE, OR TANK... -
Page 24: Trou Ble Shoot Ing
TROUBLESHOOTING POINTS PROBLEM CAUSE CORRECTION 1. Out of fuel. 1. Fill fuel tank. Will not start 2. Engine not “CHOKED” properly. 2. See “TO START ENGINE” in Operation section. 3. Engine flooded. 3. Wait several minutes before attempting to start. 4. - Page 25 TROUBLESHOOTING POINTS PROBLEM CAUSE CORRECTION 1. Worn, bent or loose blade. 1. Replace blade. Tighten blade bolt. Excessive 2. Bent blade mandrel. 2. Replace blade mandrel. vibration 3. Loose/damaged part(s). 3. Tighten loose part(s). Replace damaged parts. 1. Faulty operator-safety presence control 1.
- Page 26 SERVICE NOTES...
-
Page 28: Warranty
LIMITED WARRANTY The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from defects in mate- rials and work man ship. For a period of two (2) years from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we find to be defective due to materials or workmanship.
