- Page 1 DVD-VCR CHT-1010 Instruction Manual www.samsungvcr.com PAL/NTSC...
-
Page 2: Table Of Contents
Contents OREWORD Safety Instructions ... Disc Type and Characteristics... N DVD-VCR O VERVIEWS Front View of the DVD-VCR ... Rear View of the DVD-VCR... Infrared Remote Control ... Display Indicators ... Accessories ... DVD-VCR ONNECTING Deciding How to Connect DVD-VCR... Connecting DVD-VCR to the TV using the Coaxial Cable ... - Page 3 Contents (cont.) N Appendix A - Advanced Connections Connecting the FM and AM antennas ... Connecting the Speakers ... LINE3 AUDIO Setting ... Speaker Volume Control ... Speaker setup ... Dolby Pro Logic II decoder ... SOUND mode/effect function ... Listening to radio broadcasts...
-
Page 4: Disc Type And Characteristics
Disc Type and Characteristics This DVD player is capable of playing the following types of discs with the corresponding logos : Max. Disc Types Recording Disc Size Playing (Logos) Types Time Single-sided 240 min. 12 Cm Double-sided Audio 480 min. Single-sided Video 80 min. -
Page 5: Infrared Remote Control
32 PLAY/PAUSE 33 CLEAR 34 DISC MENU 35 RIGHT You have just purchased a SAMSUNG Video Cassette Recorder (DVD-VCR). 36 DOWN 37 RETURN, A.DUB Together with your DVD-VCR, you will find the following accessories in the box. 38 SUBTITLE, TIMER... -
Page 6: Your Dvd-Vcr
Deciding How to Connect DVD-VCR You must take into account various factors when connecting audio or video systems: N Types of connectors available on your systems N Systems connected permanently to the DVD-VCR (satellite receiver for example) or temporarily (camcorder for example) Your DVD-VCR is equipped with the following connectors. -
Page 7: Connecting Other Equipment To Your Dvd-Vcr
Connecting Other Equipment to Your DVD-VCR You can connect other audio and/or video equipment to your DVD-VCR in different ways. The following illustrations give a few examples of the connection possibilities. ➢ The RCA input/output connectors on the rear of the DVD-VCR are used for equipment, such as camcorders, VCRs or sound systems. -
Page 8: Tuning Your Television For The Dvd-Vcr
Tuning Your Television for the DVD-VCR You must tune your television for the DVD-VCR only if you are not using a RCA cable ➢ To view pictures from your DVD-VCR when a RCA cable is used, the television must be set to the audio/video mode (AV). -
Page 9: Copying From Dvd To Vcr
Copying from DVD to VCR The DVD-VCR allows you to copy the contents of a DVD to a VHS tape with a press of the COPY button. If the DVD you are attempting to copy is copy protected, you will not be able to copy the disc. It is not permitted to copy Macrovision®... -
Page 10: Menu Language
Menu Language Open “MAIN MENU” With the DVD in stop mode, press the SETUP button. Set “Language” and ➛, ❿ buttons, move the selection arrow to Using the œ ❷ Language set then press ENTER button. Set menu Language Move the selection bar to your desired Language, then press ENTER button. -
Page 11: Presetting The Stations Automatically
Presetting the Stations Automatically ☛ You do not need to preset the stations if you have already set them automatically (see Plug & Auto Set Up on page 13). Your DVD-VCR contains a built-in tuner used to receive television broadcasts. You must preset the stations received through the tuner. -
Page 12: Presetting The Stations Manually
Presetting the Stations Manually ☛ You do not need to preset the stations manually if you have already set them automatically. MAIN MENU Press the SETUP button on the remote control. Result: The MAIN MENU is displayed. Press the corresponding INSTALLATION option. -
Page 13: Changing The Preset Station Table
Changing the Preset Station Table You can rearrange the Station Table and give different programme numbers to the stations listed according to your own preferences. MAIN MENU Press the SETUP button on the remote control. Press the corresponding INSTALLATION option. INSTALLATION ➛¤¤¤❿... -
Page 14: Selecting The Colour Mode
Selecting the Colour Mode Before recording or playing back a cassette, you can select the required system standard. Otherwise, the system automatically selects the reception standard when you select AUTO. MAIN MENU ➢ When playing back a cassette, the standard is automatically selected by the DVD-VCR. -
Page 15: Auto Power Off
Auto Power Off The Auto Power Off feature automatically turns off your DVD-VCR if no signal is received and you do not press any button for the selected time. MAIN MENU Press SETUP on the remote control. Result: The MAIN MENU is displayed. Press the corresponding USER SET USER SET... -
Page 16: Displaying/Hiding On-Screen Information
Displaying/Hiding On-Screen Information Your DVD-VCR displays most information both on the DVD-VCR and the television. You can choose to display or hide this information on the television screen (except for the Index, MAIN MENU and MAIN MENU Timer functions, which cannot be hidden). Press SETUP on the remote control. -
Page 17: Recording A Programme With Automatic Stop
Recording a Programme with Automatic Stop This function enables you to record up to nine hours (LP) of programmes. Your DVD-VCR stops automatically after the requested length of time. Switch on the television. To monitor the programme being recorded, select the television channel reserved for use with your DVD-VCR (or the AV input if used). -
Page 18: Checking A Preset Recording
Checking a Preset Recording You can check your preset recordings: N When you have finished presetting the DVD-VCR N If you have forgotten which programmes will be recorded 1/JAN TUE 12:09 PR DAY START STOP Press TIMER on the remote control. 1 SA 9 12:00 12:50SP -- ---- --:-- --:---- Result:... -
Page 19: Selecting The Audio Output Mode
Selecting the Audio Output Mode You can select the mode in which the sound is reproduced on the loudspeakers and AV outputs. The following options are available. Option Used to listen to the sound on the left Hi-Fi channel. Used to listen to the sound on the right Hi-Fi channel. Used to listen to the mixed sound of the Hi-Fi and normal channels. -
Page 20: Picture Search, Fast Forward/Rewind
Picture Search, Fast Forward/Rewind Picture Search enables you to Fast Forward or Rewind and look for a particular part of a tape. Press PLAY, the VCR will enter normal play mode. While in play, press and release the times the normal playback speed. To return to normal playback mode, press the If you press and HOLD down the search at 9 times the normal speed. -
Page 21: Connecting An Rca Audio/Video Input Cable
Connecting an RCA Audio/Video Input Cable You can connect other audio/video equipment to your DVD-VCR using audio/video cables if the appropriate outputs are available on the equipment chosen. Examples: N You wish to copy a video cassette with the help of a second VCR (see page 39). -
Page 22: Audio Dubbing A Pre-Recorded Cassette
Audio button on the remote control until the MIX option is displayed (see page 34). Using the TV Buttons on the Remote Control Your DVD-VCR remote control will work with Samsung televisions and compatible brands. To determine whether your television is compatible, follow the instructions below. -
Page 23: Sqpb (Super Vhs Quasi Playback)
SQPB (Super VHS Quasi Playback) This function is for playback of Super VHS format tapes only, not for recording. Inset the SVHS format tape that you want to see. ❿ Press PLAY ( ll ) to start playing the cassette. Press SVHS button to start SQPB. -
Page 24: Using The Setup Menu
Using the Setup Menu The Setup menu lets you customize your DVD-VCR by allowing you to select various language preferences, set up a parental level, even adjust the player to the type of television screen you have. MAIN MENU With the unit in Stop mode, press the SETUP button on the remote. Result: The MAIN MENU is displayed. -
Page 25: Setting Up The Audio Language Features
Setting Up the Audio Language Features MAIN MENU Using the Audio Language: With the unit in Stop mode, press the SETUP button on the remote. Result: The MAIN MENU is displayed. DVD SETUP RETURN ➛¤¤¤❿ ENTER œ❷¤¤ Press the corresponding option. -
Page 26: Setting Up The Audio Options
Setting Up the Audio Options With the unit in Stop mode, press the SETUP button on the remote. Result: The MAIN MENU is displayed. MAIN MENU Press the corresponding option. Press the ENTER button to select this option. Result: The DVD SETUP menu is displayed. DVD SETUP Use the buttons to select Audio Options. -
Page 27: S-Video Connections (For Dvd)
S-Video Connections (for DVD) The S-Video is only for the DVD player. The tuner and VCR will still be viewed through the RF or line inputs. You must follow the “DVD Out” instructions on page 49 to activate your alternative (S-Video) video selection. If your television is equipped with S-Video input, you can enjoy superior video quality when watching DVDs with your DVD-VCR. -
Page 28: Using The Display Function (Dvd/Vcd/Cd)
Using the Display Function (DVD/VCD/CD) When Playing a DVD During play, press the DISPLAY button on the remote. - Current title, chapter number, elapsed time, audio and subtitle will be displayed. ➛❿ • Use the NUMBER buttons to enter a different title, then press the ENTER button. -
Page 29: Repeat Play
Repeat Play Repeat the current track, chapter, title, a chosen section (A-B), or all of the disc. Press the REPEAT button on the remote. Repeat screen appears. Select Chapter, Title or A-B using the ➛ or ❿ buttons. - Repeat A-B •... -
Page 30: Program Play (Cd)
Program Play (CD) Press the MODE button. Use the ➛ or ❿ buttons to select PROGRAM. Press the ENTER button. Use the ➛ or ❿ buttons to select the first chapter (or track) to add to the program. Press the ENTER button. The selection numbers appear in the Program Order box. -
Page 31: Selecting The Audio Language (Using The Audio Button)
Selecting the Audio Language (Using the Audio button) You can select a desired language quickly and easily with the AUDIO button. Press the AUDIO button. Use the œ ❷ buttons to select the desired language on a DVD. - The audio languages are represented by abbreviations. ➢... -
Page 32: Using The Bookmark Function (Dvd/Vcd)
Using the Bookmark Function (DVD/VCD) The Bookmark function lets you select parts of a DVD or VCD (MENU OFF mode) so that you can quickly find the section at a later time. During play, press the MARK button on the remote. The Bookmark icons will be displayed. - Page 33 MP3 Play When an MP3 Disc is inserted into the DVD-VCR, the first song file of the first folder plays. Total : 3 Press STOP to stop playback of the first song file, then press 1 music c1 music c1 RETURN to display the music folder menu on the right side of the 2 music c2 3 music c3...
- Page 34 Connecting the FM and AM antennas FM antenna connections • Connect the FM antenna to the FM 75 COAXIAL terminal. • Unwind the antenna wire and then fasten it to a wall in an area where reception is best. - If reception is poor, connect the outdoor antenna. Remove the existing FM antenna before connecting the 75 coaxial cable.
- Page 35 LINE 3 AUDIO Setting Open “MAIN MENU” MAIN MENU With the DVD in stop mode, press the SETUP button. Select “Option” Using the up/down and left/right buttons, move the selection cursor to “USER SET”, then press ENTER to select. USER SET ➛¤¤¤❿...
- Page 36 Speaker setup To adjust the speaker balance Press the SPEAKER button. • Each time you press the button, the speaker is selected in the order of FL➝ C ➝ FR ➝ SR ➝ SL ➝ SW ➝ VOL. You will see this on the unit's display. Use the + and - buttons to adjust the volume on the desired speaker.
- Page 37 SOUND mode/effect function This feature simulates the sound of different acoustic spaces. Press the SOUND MODE button. • Each time you press the button, the sound mode changes as follows. • The SOUND mode adds a coustic surround effect during playback of stereo analog or linear PCM digital signals.
- Page 38 Technical Specifications Rated voltage AC 220 - 240V, 50Hz Operating ambient temperature +5°C ~ +35°C General Installation conditions Operation position : Horizontal, Relative humidity : Below 75% Video input (Rear) RCA jack : 1.0Vp-p (unbalanced) 75 Input Audio input (Rear) RCA jack : -8dBm, 47Kohm unbalanced RF out UHF 21-69 (Initial CH36)
- Page 39 Problems and Solutions (VCR) Before contacting the Samsung after-sales service, perform the following simple checks. Problem No power Check that the power plug is connected to a wall outlet. Have you pressed the STANDBY/ON button? You cannot insert a video cassette A video cassette can only be inserted with the window side up and the safety tab facing you.
