Cooper Lighting Shaper 664 Series Specification Sheet

D E S C R I P T I O N
664 Direct/Indirect Luminous or Solid Shade with an arm mount
bracket.
S P E C I F I C AT I O N F E AT U R E S
M a te ri a l
Aluminum arm and wall canopy.
Metal shade is solid brass, solid
copper or solid aluminum. Matte
white polyethylene two piece
cone. Optional Decorative Baffle
(BL).
F i n i s h
Standard: Natural Aluminum
(NA). [Sustainable Design]
Premium: Matte White (MW),
Lacquered Satin Aluminum
(SAL), Satin Brass (SB), Satin
Copper (SCP), Polished Copper
(PCP) or Custom Color (CC).
O p t i c s
Refer to
www.shaperlighting.com for
complete photometrics.
B a l l a s t
Integral electronic HPF , multi-volt
120/277V (347V Canada),
thermally protected with end-of-
life circuitry to accommodate the
specified lamp wattage.
O R D E R I N G I N F O R M AT I O N
Sample Number: 664-CFL/1-277V-PCP
Series Lamp
664 Solid Shade = CFL/1
w/ Arm Mount (18/26/32W
Bracket -Triple)
INC/1/60
Notes:
1
Available with CFL only.
2
Consult the factory for available options.
3
Supplied by others.
L a m p / S o cke t
One (1) 18W (GX24q-2), 26W or
32W (GX24q-3) 4-pin triple CFL
lamp or one (1) 60W A-19 lamp.
CFL socket injection molded
plastic. INC socket fired ceramic
rated for 660W-250V. Lamps
furnished by others.
I n s t a l l a t i o n
Supplied with a universal
circular strap for a standard 4"
J-box or plaster ring.
O p t i o n s
Dimming Ballast - Contact the
factory for ballast options (DM),
Decorative Baffle (BL), Remote
Energy Battery - Supplied by
others (REM), Damp Location
(DL): All Painted Finishes only.
Energy Star Rating - Consult
factory. MRI Applications (INC
only) - Contact Factory.
Voltage Finish
120V
Standard
1
NA Natural Aluminum =
277V
1
347V
Premium
CC Custom Color =
MW Matte White =
PCP Polished Copper =
SAL Lacquered Satin Aluminum =
SB Satin Brass =
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
Catalog #
Project
Comments
Prepared by
L a b e l s
U.L. and C.U.L approved for
indoor and damp location. See
options for damp location
finishing requirements.
M o d i f i c a t i o n s
Shaper's skilled craftspeople
with their depth of experience
offer the designer the flexibility
to modify standard wall
luminaires for project specific
solutions. Contact the factory
regarding scale options, unique
finishes, mounting, additional
materials/colors, or decorative
detailing.
Options
BL Decorative Baffle =
DL Damp Location =
2
DM CFL Dimming Ballast =
3
REM Remote Emergency Battery =
shaperlighting.com
Type
Date
664 SERIES
I n t e r i o r W a l l L u m i n a i r e
S t a r t e r C o l l e c t i o n
D i r e c t / I n d i r e c t
S o l i d S h a d e w i t h a n
A r m M o u n t B r a c k e t
STARTER
COLLECTION
Shaper's exclusive Starter Collection fixtures
are featured throughout the Shaper product
line. The concept of offering highly styled,
affordable fixtures was introduced over
fourteen years ago and has become one of
our fastest growing lines. The design
premise, basic construction, clean lines
and unadorned shapes are highly desirable
in modern architectural environments.
SUSTAINABLE
DESIGN
Shaper has a long-standing history of
offering environmentally-friendly fixtures.
The copper and bronze alloys used in our
exterior luminaires feature up to 98% re-
cycled content, contribute less undesirable
air emissions compared to painted alumi-
num and are easy to recycle.
MAGNETIC
RESONANCE
IMAGING (MRI)
Lighting fixtures for MRI facilities are
specialized and unique, requiring non-
ferrous construction. Fluorescent fixtures
cannot be used due to the ferrous parts in
ballasts and lampholders. Modified incan-
descent fixtures meet the requirements.
ENERGY
STAR
Shaper now offers a wide variety
of fixtures that can be provided
with an Energy Star Rating.
Refer to the Icon Legend
Link on shaperlighting.com.
