Cooper Lighting Shaper 642 Specification Sheet

D E S C R I P T I O N
The 642 Quarter Sphere Wall Sconce features indirect illumination
and is offered in two profiles. The 642/4 is ADA compliant.
S P E C I F I C AT I O N F E AT U R E S
M a te ri a l
Painted or plated cold-rolled
steel base metal. Hexcel louver,
painted black or white aluminum.
F i n i s h
Standard: Matte White (MW) or
Matte Black (MB).
Premium: Satin Chrome (SC),
Polished Chrome (PC), Satin
Brass (SB), Laquered Satin
Aluminum (SAL), Oxidized Brass
(OBRS), (NA) Natural Aluminum,
(SAL) Laquered Satin Aluminum,
Polished Brass (PB), Lacquered
Satin Chrome (SCL) and
Lacquered Satin Nickel (SNL)
finishes only.
O p t i c s
Refer to
www.shaperlighting.com for
complete photometrics.
B a l l a s t
Integral electronic HPF , multi-volt
120/277V (347V Canada),
thermally protected with end-of-
life circuitry to accommodate the
specified lamp wattage.
O R D E R I N G I N F O R M AT I O N
Sample Number: 642-CFL/1/26-277V-PC
Series Lamp
= CFL/1/13
642 Wall Sconce
CFL/1/26
=
642/4
ADA Compliant
Wall Sconce CFL/1/32
INC/1/100
Notes:
1
Available with 642/4 Series.
2
Available with CFL only.
3
Supplied by others.
4
Available with 642 Series.
L a m p / S o cke t
642: One (1) 26W or 32W
(GX24q-3) 4-pin triple CFL lamp
or one (1) 100W A-19 lamp.
642/4: One (1) 13W (2GX7) 4-pin
low wattage CFL lamp, one (1)
26W (G24q-3) quad CFL lamp or
one 100W A-19 lamp CFL socket
injection molded plastic. INC
socket fired ceramic rated for
660W-250V. Lamps furnished by
others.
I n s t a l l a t i o n
Supplied with a universal
circular strap for a standard 4"
J-box or plaster ring.
O p t i o n s
White Hexcel Louver (WHL),
Black Hexcel Louver (BHL),
Accent Balls (ACB), Decorative
Finial (DF), Trim Ring (TR),
Remote Emergency Battery (642
only) - Supplied by others (REM),
MRI Applications (INC only) -
Contact factory, Damp Location
(DL): All Painted Finishes,
Lacquered Satin Chrome (SCL)
and Lacquered Satin Nickel (SNL)
finishes only. Energy Star Rating
Voltage Finish
1
120V Standard
2 =
MB Matte Black
277V
2 =
MW Matte White
347V
Premium
=
CC Custom Color
=
OBRS Oxidized Brass
=
PB Polished Brass
=
PC Polished Chrome
=
SAL Lacquered Satin
Aluminum
=
SB Satin Brass
=
SC Satin Chrome
=
SCL Lacquered Satin Chrome
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
Catalog #
Project
Comments
Prepared by
- Consult factory. MRI
Applications (INC only) - Contact
Factory.
L a b e l s
U.L. and C.U.L approved for
indoor and damp location. See
options for damp location
finishing requirements. 642/4 is
ADA compliant.
M o d i f i c a t i o n s
Shaper's skilled craftspeople
with their depth of experience
offer the designer the flexibility
to modify standard wall
luminaires for project specific
solutions. Contact the factory
regarding scale options, unique
finishes, mounting, additional
materials/colors, or decorative
detailing.
Options
=
TR Trim Ring
=
ACB Accent Balls
=
DL Damp Location
=
REM Remote
3, 4
Emergency Battery
=
DF Decorative Finial
=
BHL Black Hexcel
Top Louver
=
WHL White Hexcel
Top Louver
shaperlighting.com
Type
Date
642 SERIES
642/4 SERIES
I n t e r i o r W a l l L u m i n a i r e
I n d i r e c t
Q u a r t e r S p h e r e
AMERICAN DISABILITIES
ACT (ADA)
Shaper offers a large selection of ADA
interior and exterior wall luminaires.
ADA requires all fixtures below 68" to
have a maximum projection of 4".
SUSTAINABLE
DESIGN
Shaper has a long-standing history of
offering environmentally-friendly fixtures.
The copper and bronze alloys used in our
exterior luminaires feature up to 98% re-
cycled content, contribute less undesirable
air emissions compared to painted alumi-
num and are easy to recycle.
MAGNETIC
RESONANCE
IMAGING (MRI)
Lighting fixtures for MRI facilities are
specialized and unique, requiring non-
ferrous construction. Fluorescent fixtures
cannot be used due to the ferrous parts in
ballasts and lampholders. Modified incan-
descent fixtures meet the requirements.
ENERGY
STAR
Shaper now offers a wide variety
of fixtures that can be provided
with an Energy Star Rating.
QUICK SHIP (QS)
Shaper's Quick Ship program
features over thirty-four fixtures
with finish options such as Satin
Chrome, Natural Aluminum and
Satin Brass and a wide variety of
lamp selections. All products ship
in five days from receipt of order.
Refer to the Icon Legend
Link on shaperlighting.com.
