Cooper Lighting Shaper 640 Specification Sheet

D E S C R I P T I O N
640 Tapered Square Wall Sconce features indirect illumination.
S P E C I F I C AT I O N F E AT U R E S
M a te ri a l
Brass, aluminum or cold-rolled
steel base and trim. Matte white
formed acrylic diffuser.
F i n i s h
Standard: Matte White (MW).
Premium: Natural Aluminum
(NA) [Sustainable Design],
Lacquered Natural Aluminum
(SAL), Satin Chrome (SC),
Polished Chrome (PC), Satin
Brass (SB), Polished Brass (PB),
Satin Copper (SCP), Polished
Copper (PCP), Satin Nickel (SN),
Polished Nickel (PN), Oxidized
Brass (OBRS), Oxidized Copper
(OCP), Gun Metal (GNM),
Lacquered Satin Chrome (SCL),
Lacquered Satin Nickel (SNL) or
Custom Color (CC).
O p t i c s
Refer to
www.shaperlighting.com for
complete photometrics.
B a l l a s t
Integral electronic HPF , multi-volt
120/277V (347V Canada),
thermally protected with end-of-
O R D E R I N G I N F O R M AT I O N
Sample Number: 640-CFL/1/18-120V-CC
Series Lamp Voltage
640 Wall = CFL/1/18
Indirect
INC/1/60
Tapered
Square
Notes:
1
Interior applications only.
2
CFL only.
3 Supplied by others.
life circuitry to accommodate the
specified CFL lamp wattage.
L a m p / S o cke t
One (1) 18W (2G11) 4-pin high
lumen CFL lamp or one (1) 60W
Frosted T-10 incandescent lamp.
CFL socket injection molded
plastic top. INC socket fired
ceramic rated for 660W-250V.
Lamps furnished by others.
I n s t a l l a t i o n
Supplied with a universal
circular strap for a standard 4"
J-box or plaster ring.
O p t i o n s
Hand Painted Faux Alabaster
Diffuser (FD), Hand Painted Faux
Linen Diffuser (LND), Damp
Location (DL): All painted
finishes, Lacquered Satin
Chrome (SCL) and Lacquered
Satin Nickel (SNL) finishes only.
Remote Emergency Battery -
Supplied by others (REM).
Energy Star Rating - Contact
factory. MRI Applications (INC
only) - Contact factory.
Finish
120V
Standard
2 MW Matte White =
277V
2
347V
Premium
CC Custom Color =
GNM Gun Metal =
NA Natural Aluminum =
OCP Oxidized Copper =
OBRS Oxidized Brass =
PB Polished Brass =
PC Polished Chrome =
PCP Polished Copper =
PN Polished Nickel =
SB Satin Brass =
SC Satin Chrome =
SCL Lacquered Natural Aluminum =
SCL Lacquered Satin Chrome =
SCP Satin Copper =
SN Satin Nickel =
SNL Lacquered Satin Nickel =
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
Catalog #
Project
Comments
Prepared by
L a b e l s
U.L. and C.U.L approved for
indoor and damp location. See
options for damp location
finishing requirements.
M o d i f i c a t i o n s
Shaper's skilled craftspeople
with their depth of experience
offer the designer the flexibility
to modify standard wall
luminaires for project specific
solutions. Contact the factory
regarding scale options, unique
finishes, mounting, additional
materials/colors, or decorative
detailing.
Options
1
DL Damp Location =
FD Hand Painted Faux =
Alabaster Diffuser
LND Hand Painted Faux =
Linen Diffuser
REM Remote Emergency Battery = 3
shaperlighting.com
Type
Date
640 SERIES
I n t e r i o r W a l l L u m i n a i r e
I n d i r e c t " C r a f t s m a n "
Ta p e r e d S q u a r e
SUSTAINABLE
DESIGN
Shaper has a long-standing history
of offering environmentally-friendly
fixtures. The copper and bronze alloys
used in our exterior luminaires feature
up to 98% recycled content, contribute
less undesirable air emissions compared
to painted aluminum and are easy to
recycle.
MAGNETIC
RESONANCE
IMAGING (MRI)
Lighting fixtures for MRI facilities are
specialized and unique, requiring non-
ferrous construction. Fluorescent fixtures
cannot be used due to the ferrous parts in
ballasts and lampholders. Modified incan-
descent fixtures meet the requirements.
ENERGY
STAR
Shaper now offers a wide variety of
fixtures that can be provided with an
Energy Star Rating.
Refer to the Icon Legend
Link on shaperlighting.com.
