Manual Brel Bi-Directional Rollerblind motor
BLE 20
Read the manual before you begin the
installation. If these instructions are not
followed, this may lead to defects and
injury in which warranty can't be claimed.
www.brel-home.com
Visit our website for more manuals and information
BLE 20-05
Scan the QR code here for the manual to
download & view instructional videos
M O T O R S
EN NL DE FR
Advertisement
Table of Contents
Related Manuals for brel-motors BLE 20
Summary of Contents for brel-motors BLE 20
- Page 1 M O T O R S INSTALLATION MANUAL Manual Brel Bi-Directional Rollerblind motor BLE 20 Read the manual before you begin the installation. If these instructions are not followed, this may lead to defects and injury in which warranty can’t be claimed.
- Page 2 Wiring/Installing the motor/Compatible with hub Technical data of the motor/Reach/Charging the motor Functions remote control Warning Do not operate the motor BREL-Motors declares that this in humid surroundings. motor has been manufactured according to the guidelines of the CE standard 1999/5/EC...
-
Page 3: Installing The Motor
Page 3 Wiring Antenna USB-C BLE 20 LED Light LED Light BLE 20 USB-C Antenna Magnet Plug Installing the Motor These assemblies are usually already done in the factory Attach the crown and wheel to the motor and place the clip on the shaft of the motor so that the wheel is fixed to the motor. - Page 4 = 20 meter Charging the motor If charging the BLE 20 only use a charger with USB-C plug (5V) The battery is empty when the motor light flashes red. The light flashes green while charging. The battery is fully charged when the light stops blinking and lights-up continuously.
-
Page 5: Establishing Connection
Page 5 Functions Remote Control Current Channel Stop Down Programm Channel- C- Button P2 Channel+ C+ There are 2x P2 buttons, no matter which one you press. Scan the QR code here for the manual to download & view instructional videos BLE20-05 Step 1 Setting up the first remote/channel... - Page 6 Page 6 Step 3 Adjusting the direction of rotation (Only if the direction of rotation is not correct) Only possible if no end positions are set. until Press UP and DOWN button The direction of rotation of simultaneously, until the product moves. the motor is OK.
-
Page 7: Additional Settings
Learn Extra transmitter/channel Only possible when end limits are set. = Already existing transmitter/channel = New transmitter/channel NOTE It is not possible to connect the DD116 or DD118 to a BLE 20 motor Method 1 P2 a P2 a P2 b Press P2 of a. -
Page 8: Speed Control
Page 8 Option D Speed Control 1x P2 The motor speed Press 1x up. Press 1x up. has been increased Press P2. The product Press 1x down. Press 1x down. The motor speed moves 1x up and down has been reduced. If the motor does NOT react after this action, it is already at the highest or lowest speed.
