TECHNICAL SPECIFICATIONS
STANDARDS
• IEEE 802.11G, 802.11B
INTERFACE
• 32-BIT CARDBUS WITH PCMCIA TYPE II
DATA RATES
• 1, 2, 5.5, 6, 9, 11,12, 18, 24, 36, 48, 54MBPS
WITH AUTO FALLBACK
• SMC 108G
OPERATING RANGE
• OUTDOORS: UP TO 1,155 FEET / 350 METERS
• INDOORS: UP TO 260 FEET / 80 METERS
NETWORK CONFIGURATION
• AD-HOC (PEER TO PEER)
• INFRASTRUCTURE
MODULATION
• OFDM WITH BPSK, QPSK, 16QAM, 64QAM
(11G) DBPSK, DQPSK, CCK (11B)
SECURITY
• 64-/128-BIT WIRED EQUIVALENT
PRIVACY (WEP)
• WPA/WPA2
RF FREQUENCY
• 2400MHZ – 2497 MHZ – JAPAN BAND
• 2400MHZ – 2483.5MHZ – NORTH
AMERICA, EUROPE
• 2455MHZ – 2475MHZ – SPAIN
• 2446.5MHZ – 2483.5MHZ – FRANCE
OPERATING CHANNEL
• 11 CHANNELS (US, CANADA)
• 13 CHANNELS (EUROPE)
• 14 CHANNELS (JAPAN)
RF OUTPUT POWER
• 64 DBM QAM - 11 DBM
• 16 DBM QAM - 14 DBM
• QPSK - 16 DBM
• BPSK - 17 DBM
• DBPSK, DQPSK, CCK 17
SENSITIVITY
• 802.11G; PER < 10%
• 54 MBPS –65 DBM
• 48 MBPS –66 DBM
• 36 MBPS –70 DBM
• 24 MBPS –72 DBM
• 18 MBPS –77 DBM
• 12 MBPS –79 DBM
• 9 MBPS –81 DBM
• 6 MBPS –82 DBM
• 802.11B: PER < 8%
• 11 MBPS –80 DBM
www.smc.com
SMCWCBT-G
• 5.5 MBPS –83 DBM
• 2 MBPS –86 DBM
• 1 MBPS –89 DBM
OPERATING SYSTEMS
• WINDOWS 98SE/ME/2000/XP
ANTENNA GAIN
• 1.5 DBM
ANTENNA TYPE
• BUILT IN DIVERSITY PATCH ANTENNA
LED INDICATOR
• ACTIVITY
• LINK
POWER VOLTAGE
• 3.3+/- 5%
POWER CONSUMPTION
• TX (480MA) ; RX (380MA)
DIMENSION
• 115 X 54 mm
• 4.5 X 2.125 in
WEIGHT
• 45 g
• 0.10 lbs
COMPLIANCE
• USA: FCC PART 15 CLASS B AND C
• EUROPE: ETSI EN 300 328-2 AND ETSI EN 301
489-1, -17, EN60950, CE-MARK
• CANADA: ISC RSS139
• JAPAN: RCR STD 33, T66; JETA
TEMPERATURE RANGE
• OPERATING: -0Oº C - +60Oº C
• STORAGE: -20OºC - +65Oº C
HUMIDITY
• 20% TO 80% NON-CONDENSING
