SMART Hi-Fi AUDIO
Wireless Multi-room Sound Bar
SERVICE MANUAL
MODEL: MUSIC flow HS6 (LAS650M)
CAUTION
BEFORE SERVICING THE UNIT, READ THE "SAFETY PRECAUTIONS"
IN THIS MANUAL.
P/NO : AFN76793374
OCTOBER, 2014
