Table of contents
Before Using the Machine for the first time
1.Installation
1.Names and functions of respective parts.
2.Applicable engine
3.Parts to be assembled
(1) Unpacking
(2) list of parts to be assembled
(3) assembling procedure
4.Installation and movement
(1)Installation
(2)movement
(3)threading the twine
2.Inspection before operation
1.Inspection before operation
(1)Inspection of respective parts of engine
(2)Inspection of machine proper
2.Inspecting at start of engine
3.list of oiling and greasing points
3.How to operate
1.purpose of machine
2.adjustment for operation
(1) Film loading
(2) Adjustment of side roller
3.working procedure
(1) Number of turns of film
(2)Method for starting the machine
(3)Rotating speed of turn table
(4)working method
4.After completion of operation
1.Care after completion of operation
2.For storing the machine for a long period of time
1
Advertisement
Table of Contents
Related Manuals for Range Road RRF940
Summary of Contents for Range Road RRF940
- Page 1 Table of contents Before Using the Machine for the first time 1.Installation 1.Names and functions of respective parts. 2.Applicable engine 3.Parts to be assembled (1) Unpacking (2) list of parts to be assembled (3) assembling procedure 4.Installation and movement (1)Installation (2)movement (3)threading the twine 2.Inspection before operation...
-
Page 2: Inspection And Maintenance
5.Inspection and maintenance 1.Inspection and maintenance table 2.Adjustment relating to start lever 6.Trouble corrections 1.trouble corrections... -
Page 3: Before Using The Machine For The First Time
Before Using the Machine for the first time Before using the machine for the first time,carry out the following. 1.check the engine oil Check whether or not a specified quantity of engine oil exists.if it is too small,replenish the oil up filler port without screwing it,and measure. Add oil to the top graduation line of the oil gauge. - Page 4 2. Check the quantity of fuel Use lead-free gasoline for motor vehicles as the fuel The tank capacity is about 1.5 liters. Precaution For refueling, don’t fill up to the entrance of the fuel filler port,and keep the fuel level under the ...
-
Page 5: Installation
1. Installation Correctly install for safe operation 1.Names and functions of respective parts 1.Main frame The main frame supports the engine,drive unit,automatic stopping device,turn table and stretching device 2.Handle and wheels The handle and wheels support the machine and can be used to work 3.Drive unit The drive unit decelerates the rotation from engine,and the belt clutch tension is used to transmit the retation to or to isolate the ratation from the turn table. - Page 6 2.Applicable engine The machine is designed to exhibit its performance when an adequate engine is mounted on it.the engine of the machine has the following specification. Engine horse power Continuous rating 3600rpm 3.Part to be assembled 1.Unpacking Remove the parts fixed to the packing frame 2.list of parts to be assembled Confirm whether or not all the necessary parts are provided based on the packing list contained in the package...
- Page 7 (3)Assembling of start lever After assembling the stretching device as described in the above 3-3-(2),insert a lever B into the bush portion at the top of the stretching device,and insert the bush into a bottom lever A,fixing using a bolt and a flange nylon nut Precaution It should be noted that if the bolt and the flange nylon nut are tightened extremely,the pipes of the ...
- Page 8 CAUTION If the inspection before start of operation is neglected,it can happen that the machine is poorly adjusted and broken or that any person working nearby is injured accidentally. Before starting operation,inspect the machine based on the instruction manual ...
- Page 9 explanation of “2-3 List of oiling and greasing points.” 2.Inspection at start of engine WARNING Before starting the engine,confirm that the start lever is set at “OFF position.” If the engine is started with the start lever at “ON position,” the turn table will rotate to injure any person working nearby. If the engine is started indoors as in a house, the exhaust gas may cause poisoning.Open windows ...
-
Page 10: How To Operate
Gear (turn table) Greasing coating Every 30 working hours ② Drive chain(turn table) After use ③ Drive chain(automatic After use ④ stopping device) Slide arm screw(automatic After use ⑤ stopping device) Side arm shaft face After use ⑥ (automatic stopping device Gear (stretching device) Grease coating Every 30 working hours... - Page 11 silage from damage caused by birds,rodents,inserts,etc. It is ideal to stack the wrapped bales vertically in two or three stages,for maintaining the sealing accuracy and saving the preserving space. The number of stages must be such that the stacked bales do not fall but remain stable and safe.
- Page 12 2.Adjust of side roller (1) Place the bale to be wrapped,on the turn table alongside the side plate on the drive side (drive chain side) (2)Adjust the side roller for adaptation to the width of the bale,and fix using a bolt and nut. Precaution When adjusting the side roller,keep a spacing of about 30 to about 50mm between the end face of ...
- Page 13 If you open any cover during operation or rotation,you may be caught by the rotating portion and injured.Do not open any cover during operation or rotation. If you touch the film or stretch roller while the film is wound,you may be caught and injured.Don’t ...
