- Page 1 Operation manual Daikin Altherma 3 H HT F+W ETVH16S18DA6V(G) ETVH16S23DA6V(G) ETVH16S18DA9W(G) ETVH16S23DA9W(G) ETVX16S18DA6V(G) ETVX16S23DA6V(G) ETVX16S18DA9W(G) ETVX16S23DA9W(G) ETBH16DA6V ETBH16DA9W Operation manual ETBX16DA6V English Daikin Altherma 3 H HT F+W ETBX16DA9W...
-
Page 2: Table Of Contents
Thermostat type [2.A] Symptom: The system is making gurgling noises after Additional zone (if applicable) commissioning................19 Thermostat type [3.A] 8 Disposal Information 9 Glossary Dealer information [8.3] Operation manual ETVH/X16S18+23DA6V+9W(G) + ETBH/X16DA6V+9W Daikin Altherma 3 H HT F+W 4P586455-1 – 2019.07... -
Page 3: Quick Actions
To turn room temperature control ON or OFF 1 Go to [C.1]: Operation > Room. Operation Room Space heating/cooling 2 Set operation to On or Off. ETVH/X16S18+23DA6V+9W(G) + ETBH/X16DA6V+9W Operation manual Daikin Altherma 3 H HT F+W 4P586455-1 – 2019.07... - Page 4 Increase or decrease the slope/offset. When slope is selected: set slope and go to offset. When offset is selected: set offset. Confirm changes and return to the submenu. Operation manual ETVH/X16S18+23DA6V+9W(G) + ETBH/X16DA6V+9W Daikin Altherma 3 H HT F+W 4P586455-1 – 2019.07...
-
Page 5: Domestic Hot Water
X1 is unequally higher than the X1 is equally higher as the preferred temperature at X2. preferred temperature at X2. ETVH/X16S18+23DA6V+9W(G) + ETBH/X16DA6V+9W Operation manual Daikin Altherma 3 H HT F+W 4P586455-1 – 2019.07... -
Page 6: General Information
3 General information Daikin Online Control Heating app General information If set up by your installer, you can use the Daikin Online Control Heating app to control and About this document monitor the status of your Daikin Altherma heat pump system. For more information, see: Thank you for purchasing this product. -
Page 7: Components In A Typical System Layout
The unit is in operation. Blinking red Malfunction A malfunction occurred. "7.1 To display the help text malfunction" [ 4 18] in case of a for more information. ETVH/X16S18+23DA6V+9W(G) + ETBH/X16DA6V+9W Operation manual Daikin Altherma 3 H HT F+W 4P586455-1 – 2019.07... -
Page 8: Menu Structure: Overview User Settings
User profile Operation Room Space heating/cooling Tank Setpoint screen Only accessible by installer INFORMATION Depending on the selected installer settings and unit type, settings will be visible/invisible. Operation manual ETVH/X16S18+23DA6V+9W(G) + ETBH/X16DA6V+9W Daikin Altherma 3 H HT F+W 4P586455-1 – 2019.07... -
Page 9: Possible Screens: Overview
Leaving water temperature setpoint Go to the main menu screen. Holiday mode Enable/disable breadcrumbs. Holiday mode active Item Description a Domestic hot water Domestic hot water Measured tank temperature ETVH/X16S18+23DA6V+9W(G) + ETBH/X16DA6V+9W Operation manual Daikin Altherma 3 H HT F+W 4P586455-1 – 2019.07... -
Page 10: Main Menu Screen
Fixed by the unit Set the leaving water temperature for b2 Restricted by the installer the additional zone (if present). Current temperature Measured by the unit Operation manual ETVH/X16S18+23DA6V+9W(G) + ETBH/X16DA6V+9W Daikin Altherma 3 H HT F+W 4P586455-1 – 2019.07... -
Page 11: Detailed Screen With Values
Space heating/cooling operation ON In menu… You can read out… Space heating/cooling operation OFF [8.1] Energy data Produced energy, consumed electricity, and consumed gas [8.2] Malfunction history Malfunction history ETVH/X16S18+23DA6V+9W(G) + ETBH/X16DA6V+9W Operation manual Daikin Altherma 3 H HT F+W 4P586455-1 – 2019.07... -
Page 12: Space Heating/Cooling Control
To restrict automatic changeover according to a schedule Conditions: You set the space operation mode to Automatic. 1 Go to [4.2]: Space heating/cooling > Operation mode schedule. 2 Select a month. Operation manual ETVH/X16S18+23DA6V+9W(G) + ETBH/X16DA6V+9W Daikin Altherma 3 H HT F+W 4P586455-1 – 2019.07... -
Page 13: Domestic Hot Water Control
Powerful operation allows the domestic hot water to be heated by the backup heater or booster heater. Use this mode on days when there is more hot water usage than usual. ETVH/X16S18+23DA6V+9W(G) + ETBH/X16DA6V+9W Operation manual Daikin Altherma 3 H HT F+W 4P586455-1 – 2019.07... -
Page 14: Schedule Screen: Example
In this example, Monday is the first day you programmed. Thus, the last programmed action is valid up to the first action of next Monday. Operation manual ETVH/X16S18+23DA6V+9W(G) + ETBH/X16DA6V+9W Daikin Altherma 3 H HT F+W 4P586455-1 – 2019.07... -
Page 15: Weather-Dependent Curve
5 Select Saturday. the curve can be adjusted by an installer or user. 6 Select Copy. ETVH/X16S18+23DA6V+9W(G) + ETBH/X16DA6V+9W Operation manual Daikin Altherma 3 H HT F+W 4P586455-1 – 2019.07... -
Page 16: 2-Points Curve
Possible actions on this screen X1, X2 Examples of outdoor ambient temperature Go through the temperatures. Change the temperature. Go to the next temperature. Confirm changes and proceed. Operation manual ETVH/X16S18+23DA6V+9W(G) + ETBH/X16DA6V+9W Daikin Altherma 3 H HT F+W 4P586455-1 – 2019.07... -
Page 17: Using Weather-Dependent Curves
[5.C] Tank > WD curve you have a party, or when you are leaving for a couple of hours. ▪ For longer periods: You can use the holiday mode. ETVH/X16S18+23DA6V+9W(G) + ETBH/X16DA6V+9W Operation manual Daikin Altherma 3 H HT F+W 4P586455-1 – 2019.07... -
Page 18: Maintenance And Service
▪ Do NOT use cleaning materials or means to accelerate the defrosting process other than those recommended by the manufacturer. ▪ Be aware that the refrigerant inside the system is odourless. Operation manual ETVH/X16S18+23DA6V+9W(G) + ETBH/X16DA6V+9W Daikin Altherma 3 H HT F+W 4P586455-1 – 2019.07... -
Page 19: Symptom: You Are Feeling Too Cold (Hot) In Your Living Room
▪ For ETBH/X: The backup heater automatically takes over the heat load, and the booster heater in the optional tank takes over the domestic hot water production. ETVH/X16S18+23DA6V+9W(G) + ETBH/X16DA6V+9W Operation manual Daikin Altherma 3 H HT F+W 4P586455-1 – 2019.07... -
Page 20: Disposal
DHW = Domestic hot water Hot water used, in any type of building, for domestic purposes. LWT = Leaving water temperature Water temperature at the water outlet of the heat pump. Operation manual ETVH/X16S18+23DA6V+9W(G) + ETBH/X16DA6V+9W Daikin Altherma 3 H HT F+W 4P586455-1 – 2019.07... - Page 24 4P586455-1 0000000V 4P586455-1 2019.07...
