Preparation before setting

(1) Supply pressure to the product. (100 to 200 kPa)
(2) Insert a acceptable clearance gauge between the detection surface and the workpiece.
Alternatively, place a sample workpiece (non-defective workpiece) on the detection nozzle.
■

Setting

(1) Press the button while in measurement mode. The display value will be displayed in the main
screen and the switch point in the sub screen.
(2) Press the or
∗: Pressing the and
switch point value disappears, will make the switch point the same as the current display value. (Snap shot function)
Then, it is possible to adjust the switch point value by pressing the
(3) Press the button to complete the switch point setting. The product will return to measurement mode.
buttons to adjust the switch point value.
buttons simultaneously for a minimum of 1 second, then releasing the buttons when the displayed
or buttons.
-45-
4 How to use
