12-1/8" - 12-3/8"
[308mm - 314mm]
TIE WIRE
11-1/4" [286mm]
(NOT BY NEORAY)
HOUSING WIDTH
(4 TWISTS MINIMUM)
9" [229mm]
FIXTURE OPENING
Construction
20-gauge steel housing.
Electrical
120, 277, 347 or Universal Voltage electronic ballast.
Fixtures and electrical components certified to UL
and CUL standards.
Finish
Durable, low gloss, white, powder coated acrylic
finish.
Mounting
Recessed.
R U N S A N D PAT T E R N S
PATTERNS ARE PROVIDED WITH
CORNER SECTIONS.
FIELD DIMENSIONS ARE REQUIRED.
FILLER SECTIONS ARE CUT TO LENGTH IN THE FIELD.
NOTES: For complete product data, refer to the Neo-Ray Specification Binder. Specifications and dimensions subject to change without notice. Products may be
modified for use in international markets. Please contact your Cooper Lighting Sales Representative for availability and ordering information.
ORDERING INFORMATION:
Sample number: 79OS-1T8-4-1EB-SI
Series
79OS
Number of Lamps
9"
1=1 Lamp
[229mm]
OVERALL
HEIGHT
Lamp Type
T8
Run Length
Overall Nominal Run Length__ft. (Any combination of 8', 6', 4' and 3'
sections)
Voltage
1
1=120V
Ballast
EB=Electronic Ballast (Standard)
Switching
SI=Single Switching
Emergency
EM=Emergency Pack (Consult Factory)
Fusing
GLR
1 Due to various constraints, some options may not be combined with others.
11-3/8"
90˚ Inside Corner
90˚ Inside Corner
(not included)
T5
2=277V
3=347V
U=Universal
DB=Dimming Ballast
GMF
12-1/8"
2"
8" Filler Section
NEO-RAY
™
79-OS
I N D I R E C T
• Direct wall wash light
distribution.
• T5 and T8 lamping.
• Softly graduated wall
illumination without lamp
socket shadows.
• Factory prepared inside and
outside mitered corners,
create a refined finished
detail at the ceiling line.
• Lamps shielded from all
viewing angles.
• Die formed steel housing.
• Runs are field adjustable.
• Illuminated wall continues
above the ceiling line to
create floating ceiling effect.
• 90 degree mitered corners.
• Contractor friendly
installation.
COOPER LIGHTING
767
