- Page 1 IGITAL IDEO RANSPORT YSTEM BCI reserves the right to make changes to the products described herein without prior notice or consent. No liability is assumed as a result of their use or application. All rights reserved. ©2005 Broadata Communications, Inc.
- Page 2 This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lightning strikes, etc. Use of surge protection systems is highly recommended in order to protect and extend the life of your equipment. Broadata Technical Support, CustomerService@Broadatacom.com...
-
Page 3: Table Of Contents
4.0 MAINTENANCE AND TROUBLESHOOTING....13 4.1 MAINTENANCE ............. 13 4.2 TROUBLESHOOTING ..........14 5.0 SPECIFICATIONS ............16 6.0 SERVICE PROCEDURE ..........17 6.1 REPLACEMENT POLICY ..........17 6.2 RETURN AND REPAIR SERVICE ......... 17 7.0 LIMITED WARRANTY ............ 18 Broadata Technical Support, (800) 214-0222... -
Page 4: Product Description
Fiber Optic HD-SDI Digital Video Transport System 1.0 PRODUCT DESCRIPTION The 1100E Series is a high performance, yet affordable, Fiber Optic HD-SDI Digital Video Transport System. The standard 1100E system is designed to transport one (1) channel SMPTE-292M HD or SMPTE-259M serial digital video signal over long distance through either singlemode or multimode fiber. - Page 5 BCI 1100E User’s Manual Fiber Optic HD-SDI Digital Video Transport System 1100E-TRX DIGITAL DIGITAL VIDEO VIDEO OUT1 OUT2 12VDC Figure 1-1 1100E Front/Rear Panels Broadata Technical Support, (800) 214-0222...
-
Page 6: Setup
Fiber Optic HD-SDI Digital Video Transport System 2.0 SETUP The BCI 1100E Series units are used in pairs. For unidirectional systems, one 1100E transmitter unit is located at the near end and connected to the 1100E receiver located at the far end of the link, connected through one optical fiber. -
Page 7: Mounting
Serial Digital Video signal are sent over a 75-ohm coax cable terminated in a BNC connector (e.g., Belden 1694A or better). The data rate is 1.485 Gbps. Use the following steps for connecting the video. Broadata Technical Support, (800) 214-0222... - Page 8 IN connector on the 1100E transmitter unit. 2. Connect the digital video OUT or/and BNC connectors on the 1100E receiver unit to the user’s digital video monitor. 1100E-TRX DIGITAL DIGITAL VIDEO VIDEO OUT1 OUT2 Figure 2-2 Electrical Connection Broadata Technical Support, CustomerService@Broadatacom.com...
-
Page 9: Optical Fiber Connection
Table 1, and following the instructions and guidelines. 1100E-TRX DIGITAL DIGITAL VIDEO VIDEO OUT1 OUT2 1100E-TRX DIGITAL DIGITAL VIDEO VIDEO OUT1 OUT2 Figure 2-3 Fiber Optic Connection Broadata Technical Support, (800) 214-0222... -
Page 10: Dc Power Connection
The 1100E derives power from an external 12VDC power supply. This power supply is a wall-mounted AC/DC adapter, 95-240 VAC, 47 Hz to 63 Hz, at 1A. This power supply comes standard for the 1100 unless otherwise specified. Broadata Technical Support, CustomerService@Broadatacom.com... -
Page 11: Operation
After the installation procedure is completed, the units are ready for operation. To operate the BCI 1100E units, simply apply power as indicated in the previous step. Note that the following front panel link status indicator, shown in Table 2 will be activated. Broadata Technical Support, (800) 214-0222... -
Page 12: Maintenance And Troubleshooting
. l a t i n d i l c i t . l a t i n c i t d i l c i t i l l s i l Table 2 Status Indicators Broadata Technical Support, CustomerService@Broadatacom.com... -
Page 13: Troubleshooting
For each unit, the transmit (TX) fiber is connected to the other unit’s receiver (RX). 3. If the POWER indicator and Optical Link indicator are ON, but the audio/video channels are not operating, then: Broadata Technical Support, (800) 214-0222... - Page 14 Turn the power off, then back on to reset the link. d. Output levels of the user’s video and audio sources are not above the allowed input levels of the 1100E units (see Section 5.0 Specifications). Broadata Technical Support, CustomerService@Broadatacom.com...
-
Page 15: Specifications
0 to 95% RH, non-condensing Status Indicators Power, Optical Link, Signal Detect, Reclocking Optical Fiber Type Multimode and Singlemode Number of Fibers 2 or 1 Wavelength 1310 and/or 1550 nm Fiber Optic Connector ST (Multimode) FC (Singlemode) Broadata Technical Support, (800) 214-0222... -
Page 16: Service Procedure
The 1100E System contains no user serviceable components. If you have a problem with your unit, please contact the Customer Service Department. To facilitate our return/repair processing please contact Broadata Communications, Inc. to obtain a Return Material Authorization (RMA). Please include the following information: •... -
Page 17: Limited Warranty
Fiber Optic HD-SDI Digital Video Transport System 7.0 LIMITED WARRANTY Broadata Communications, Inc. (BCI) warrants, for a period of one year from date of shipment, each product sold shall be free from defects in material and workmanship. BCI will correct, either by repair, or at BCI’s... - Page 18 Broadata Communications, Inc. 2545 West 237th Street, Suite K Torrance, CA 90505 1-800-214-0222 (310) 530-1416 (310) 530-5958 (Facsimile) e-mail: CustomerService@Broadatacom.com Website: www.broadatacom.com 6000E-1100-B...
