Instruction Manual
coMMercIal electrIc water heaters
Models ej*006 through ej*020 series 102
es*030 through es*050 series 110
& et*030 through et*120 series 110
InstallatIon - operatIon - serVIce
300 Maddox Simpson Parkway
- MaIntenance - lIMIted warranty
Lebanon, TN 37090
Phone: 615-889-8900 • Fax: 615-547-1000
Technical Service email: 2tech@lochinvar.com
www.lochinvar.com
Thank you for buying this energy efficient water heater.
We appreciate your confidence in our products.
place these InstructIons adjacent to heater and notIfy owner to keep for future reference.
PRINTED 1011
322884-000
1
