Technical Information- Dishwasher
MDBH950AWB
MDBH970AWB
Due to possibility of personal injury or property damage, always contact an authorized technician for servicing or
repair of this unit. Refer to Service Manual 16021814.
All safety information must be followed as provided in Service Manual 16021814.
To avoid risk of electrical shock, personal injury, or death, disconnect power to dishwasher before servicing, unless
testing requires power.
Specifications
MDBH950AW*
Power Source
Voltage AC
120 VAC
Amperage
(Single Unit)
Frequency
Motor
horsepower
Receptacle
Plug
Dimensions
33 ½" to 35 ¼"
Height−overall
Width
Depth
Weight
Un-crated
*On selected models only
May 2004
©2004 Maytag Services
MDBH950AWQ
MDBH970AWQ
!
!
MDBH970AW*
120 VAC
15 A
15 A
60 Hz
60 Hz
1/3
1/3
N/A
N/A
N/A
N/A
33 ½" to 35 ¼"
23 7/8"
23 7/8"
23 1/2"
23 1/2"
65 lbs.
65 lbs.
MDBH950AWS
MDBH970AWS
CAUTION
WARNING
Benefits
Wash cycles
Heavy Wash
Normal Wash
Light Wash
Rinse Only
Auto Clean
Drying System
Features
Control Lock
*Sanitizer
*ToughScrub
Plus™
*Extra Rinse
QuietSeries
100™
QuietSeries
300™
2/4/6 Hour Delay
Start
1-9 Hour Delay
Start
Energy Star
Remaining Time
Countdown
Display
Active Vent Dry
Finer Filtration
Hard Food
Disposer
9 Touch Pad
Controls
11 Touch Pad
Controls
1
MDBH950AWW
MDBH970AWW
MDBH950AW*
MDBH970AW*
4
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
5
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
16023222

Advertisement

Table of Contents
loading

Related Manuals for Maytag MDBH950AWB

Summary of Contents for Maytag MDBH950AWB

  • Page 1 2/4/6 Hour Delay Start 1-9 Hour Delay Start Energy Star Remaining Time Countdown Display Active Vent Dry Finer Filtration Hard Food Disposer 9 Touch Pad Controls 11 Touch Pad Controls *On selected models only May 2004 16023222 ©2004 Maytag Services...

  • Page 2: Component Specifications

    120V with 1/4" actuation stroke within 60 seconds Dispenser wax motor Measure resistance from J6 Pin 3 Tan (Dispenser) to ST4 Black 2 k Ω 120V with 1/4" (Common) .......... actuation stroke within 60 seconds 16023222 May 2004 ©2004 Maytag Services...
  • Page 3 ± 5% in air, 830 watts thermostat is closed). ± 5% in coldwater Drain Motor Measure resistance from ST6 Gray (Drain) to ST4 Black 120v/60hz (Common). See section “Motor Connections and 25 Ω Diagram” for wiring contacts ....May 2004 16023222 ©2004 Maytag Services...
  • Page 4 J5 Pin 1 (Temp) - J5 Pin 4 (Neutral) See Component Info Notes: 1. This value assumes the high limit thermostat is closed. 2. This value assumes the float switch is closed. 3. Results are approximate values. 16023222 May 2004 ©2004 Maytag Services...

  • Page 5: Electrical Diagnostics

    Electrical Diagnostics WARNING To avoid risk of electrical shock, personal injury, or death, disconnect power to dishwasher before servicing, unless testing requires power. May 2004 16023222 ©2004 Maytag Services...
  • Page 6 To avoid risk of electrical shock, personal injury, or death, disconnect power to dishwasher before servicing, unless testing requires power. Wire harness Connection plug Blue (Common) Yellow (Main) Green (Ground) Red (Start) 1/3HP 120V/60hz, 3.2 amps, 3250 RPM 16023222 May 2004 ©2004 Maytag Services...

  • Page 7: Wiring Diagram

    90 seconds Detergent & Rinse Aid - 120V incremental duty with ¼” actuation stroke within 90 seconds Capacitor 300V / 50 - 60hz 185°F(85°C), 15µf + 10% / -5% Drain Motor 45 watts May 2004 16023222 ©2004 Maytag Services...

  • Page 8: Cycle Chart

    Cycle Chart WARNING To avoid risk of electrical shock, personal injury, or death, disconnect power to dishwasher before servicing, unless testing requires power. 16023222 May 2004 ©2004 Maytag Services...
