- Page 1 Dryer User Manual DU 8112 PA0 2960311639_EN/131117.1559...
-
Page 2: Please Read This User Manual First
Please read this user manual first! Dear Customer, Thank you for prefering a Beko product. We hope that your product which has been manufactured with high quality and technology will give you the best results. We advise you to read through this manual and the other accompanying documentation carefully before using your product and keep it for future reference. -
Page 3: Important Instructions For Safety And Environment
Important instructions for safety and environment This section contains safety instructions that will help protect from risk of personal injury or property damage. Failure to follow these instructions shall void any warranty. 1.1 General safety • The dryer can be used by children at and above 8 years old and by persons whose physical, sensory or mental capabilities were not fully developed or who lack experience and knowledge provided that they are... - Page 4 Important instructions for safety and environment • Before putting laundry in a steam program, stains on it should be removed. • You may only put laundry that is not dirty or stained but permeated with unpleasant odour in steam (odour removal) program.
-
Page 5: Product Safety
Important instructions for safety and environment • Power cable plug must be easily accessible after installation. Damaged mains cable should be changed notifying the Authorized Service. If the dryer is faulty, it must not be operated unless it is repaired by an authorized service agent! There is the risk of electric shock! 1.1.2 Product safety Superheating of the clothes inside of the dryer can... - Page 6 Important instructions for safety and environment Below specified laundry or items must not be dried in the dryer due to the fire hazard: • Garments or pillows bolstered with rubber foam (latex foam), shower bonnets, water resistant textiles, materials with rubber reinforcement and rubber foam pads.
- Page 7 Important instructions for safety and environment If it is unavoidable that fabrics that contain vegetable or cooking oil or have been contaminated by hair care products be placed in a tumble dryer they should first be washed in hot water with extra detergent - this will reduce, but not eliminate, the hazard.
-
Page 8: Mounting Over A Washing Machine
Important instructions for safety and environment • Do not lean on the loading door of your dryer when it is open, otherwise it may fall over. • The lint must not be allowed to accumulate around the tumble dryer • The tumble dryer is not to be used if industrial chemicals have been used for cleaning. -
Page 9: Intended Use
Important instructions for safety and environment Installation Table for Washing Machine and Dryer Washing Machine Depth Dryer Depth 62 cm 60 cm 54 cm 50 cm 49 cm 45 cm 40 cm Can be 54 cm Can be installed installed Cannot be installed Cannot be... -
Page 10: Compliance With The Weee Regulation And Disposing Of The Waste Product
Important instructions for safety and environment 1.5 Compliance with the WEEE regulation and disposing of the waste product This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waste electrical and electronic equipment (WEEE). This product has been manufactured with high quality parts and materials which can be reused and are suitable for recycling. - Page 11 Height (Min. / Max.) 84,6 cm / 86,6 cm* Width 59,7 cm Depth 56,8 cm Capacity (max.) 8 kg** Net weight (± 4 kg) 34 kg Width Voltage See type label*** Rated power input the product. match the product exactly. may vary.
-
Page 12: Your Dryer
Your Dryer 2.1 Overview 1. Top panel 2. Control panel 3. Loading door 4. Kick plate opening button 5. Ventilation grids 6. Adjustable legs 7. Kick plate 8. Type label 9. Lint filter 10. Water tank drawer 11. Power cord 2.2 Package Contents 1. -
Page 13: Appropriate Installation Location
Installation Before the calling the nearest Authorized Do not place the dryer on the Service for the installation of the dryer, power cable. ensure that electrical installation and water drain is appropriate referring to the user’s 3.2 Removing the manual. If they are not suitable, contact a transportation safety qualified electrician and technician to make assembly... -
Page 14: Adjusting The Feet
Installation 3.6 Changing the illumination lamp In case an illumination lamp is used in your laundry dryer.To change the Bulb/LED used for illumination of your tumble dryer, call your Authorized Service.The lamp(s) used in this appliance is not suitable for household room illumination. -
Page 15: Laundry Not Suitable For Drying In The Dryer
Preparation 4.1 Laundry suitable for drying • Do not add wet laundry while the dryer is in operation in the dryer • For models with a condenser unit: clean Always obey the instructions given on the the condenser once in a month or after garment tags. - Page 16 Preparation Following weights are given as examples. Approximate Laundry weights (g)* Cotton quilt covers 1500 (double) Cotton quilt covers 1000 (single) Bed sheets (double) Bed sheets (single) Large tablecloths Small tablecloths Tea napkins Bath towels Hand towels Blouses Cotton shirts Shirts Cotton dresses Dresses...
-
Page 17: Control Panel
Operating the product 5.1 Control Panel On/Off/Program selection button Start/Stand-by button End Time button 4. Drying Level Button Buzzer volume/Time programs selection button 5.2 Symbols Filter Cleaning the Child-proof Mute Tank Volume up Delicates Express Shirts Sport Daily Freshen Up Cottons lter drawer / lock... -
Page 18: Program Selection And Consumption Chart
5.4 Program selection and consumption chart Programmes Programme Description You may dry your cotton laundry to be ironed in Cotton Iron Dry this programme to have them slightly damp for 1000 ease o roning. (Shirt, T-shirt, tablecloth, etc.) You may dry all your cotton laundry in this programme. - Page 19 Operating the product Use this programme to dry non-pigmenting 1000 synthetic and cotton laundry items together. Program used for baby clothing with can be Babyprotect 1200 dried approval on the label. You may dry denim pants, skirts, shirts or jackets Jeans 1200 in this programme.
-
Page 20: Auxiliary Functions
Operating the product 5.5 Auxiliary functions Changing the end time If you want to change the duration during Buzzer / time the countdown: Drying machine makes an audible warning Cancel the program by turning the On/Off/ when the program is completed. If you Program selection knob. -
Page 21: Child Lock
Operating the product 5.8 Child Lock Adding and removing clothes during stand-by The drying machine has a child lock which If you want to add or remove clothes to/from prevents the program flow from being the drying machine after the drying program interrupted when the buttons are pressed starts: during a program. -
Page 22: Cancelling The Program
Operating the product 5.10 Cancelling the program If you want to cancel the program and terminate the drying operation for any reason after the drying machine starts running, turn the On/Off/Cancel knob, the program will be cancelled. The inside of the drying machine shall be extremely hot when you cancel the program during machine operation, so run the... -
Page 23: Maintenance And Cleaning
Maintenance and cleaning Service life of the product extends and frequently faced problems decrease if cleaned at regular intervals. 6.1 Lint Filter / Loading Door Inner Surface Lint and fiber released from the laundry to the air during the drying cycle are collected in the Lint Filter. -
Page 24: Draining The Water Tank
Maintenance and cleaning To drain the water tank: Clean metal surfaces of the Remove the water tank in the drawer or sensors 4 times a year. container carefully. Do not use metal tools when cleaning metal surfaces of the sensors. CAUTION: Never use solvents, cleaning agents or similar substances for cleaning due to... - Page 25 Maintenance and cleaning Pull out the condenser. 4. Clean the condenser by applying pressurized water with a shower armature and wait until the water drains. Place the condenser in its housing. Fasten the 2 locks and make sure that they are seated securely. Close the kick plate cover.
-
Page 26: Troubleshooting
Troubleshooting Drying operation takes too long. • Fibre filter pores might be clogged. >>> Wash the filter with warm water. • Filter drawer might be clogged. >>> Clean the sponge and filter cloth (if any) in the filter drawer. (for the products with a heat pump) •... - Page 27 Troubleshooting The lighting inside the drying machine does not turn on. (For models with a lamp) • Drying machine might not be turned on with the On/Off button or program might not be selected for machines without an On/Off button. >>> Make sure that the drying machine is turned on.
- Page 28 PRODUCT FICHE Complying Commission Delegated Regulation (EU) No 392/2012 BEKO Supplier name or trademark DU 8112 PA0 Model name Rated capacity (kg) Air Vented Type of Tumble Dryer Condenser Energy efficiency class Annual Energy Consumption (kWh) Automatic Type of Control...
