- Page 1 Exeter Installation Manual Model: 59161 Brushed Nickel 59594 Fresh White Fan weight ±2 lbs: 17.9 lbs (8.1 kg) ©2018 Hunter Fan Co. PG3690 r071718...
- Page 2 - All wiring must be in accordance with national and local electrical codes ANSI/NFPA 70. If you are unfamiliar with wiring, use a qualified electrician. c.2 - Use only Hunter replacement parts. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 3 We recommend that you pull everything out of the box and lay it out. We have grouped the drawn components below with the hardware you’ll need for those Hunter Pro Tip: parts. The screws below are drawn to scale to make it easier to identify what piece of hardware is needed to install each component.
-
Page 4: Choosing The Right Installation Location
A little more information on Angled Mounting: For optimum performance and appearance, a longer downrod should be used with your Hunter ceiling fan when installing on high or angled ceiling. If your ceiling is angled greater than 34° you will also need an Angled Mounting Kit. -
Page 5: Installing The Ceiling Bracket
You have two options for installation. Pick which one works best for your location. Remove any existing Hunter Pro Tip: bracket prior to installation. Only use the provided Hunter ceiling bracket that came in your fan’s box. The machine screws are the ones that came with your outlet box. -
Page 6: Hanging The Fan
1886 Hanging the Fan NOTICE To prevent damage to fan, ALWAYS lift holding either the fan housing or the downrod. Place the downrod ball into the slot in the ceiling bracket. Progress Check: Your fan should look like this. Ceiling Bracket Hanging Fan Wiring Blades... -
Page 7: Wiring The Fan
Here is how to connect the wires: Push the bare metal ends of the wires together and slide a wire The Exeter ceiling fan is designed to be operated by nut over them. Then, twist the wire nut clockwise until tight. -
Page 8: Installing The Canopy
1886 Installing the Canopy Insert the two canopy screws found in the hardware bag. Canopy Screw Lift the canopy into place so that the screw holes are aligned. Installing the Blades: Attach each blade to a blade iron using three blade washers, found in the hardware bag, and three blade assembly screws, found in the hardware bag. -
Page 9: Assembling The Light Kit
1886 Assembling the Light Kit 1 of 5 2 of 5 Light Kit Screw Light Kit Screw Insert the third screw, Feed the wire plug through the found in the hardware center hole of the upper switch bag, into place and then Partially install two light kit housing, then wrap keyhole tighten all three screws. -
Page 10: Preparing The Remote Control
1886 Preparing the Remote Control The remote control is already paired for use. NOTICE Battery Door • Always purchase the correct size and grade of battery most suitable for the intended use. • Replace all batteries of a set at the same time. •... -
Page 11: Troubleshooting
• Check to see if any of the blades are cracked. If so, replace all of the blades. Hunter Pro Tip: Cleaning the Fan Use soft brushes or cloths to prevent scratching. Cleaning products may damage the finishes. -
Page 12: Limited Lifetime Warranty
Please do not ship your fan or any fan parts to Hunter. Delivery will be refused. provide maintenance to the fan, or acts of God (e.g. flood).
