DESCRIPTION
Miniature cylindrical recessed housing and round trim with smooth
regressed splay and 45º cut-off. Includes enclosure with integral electronic
metal halide ballast and wiring compartment.
For new construction or remodel applications. Insulation must be kept 3"
from all sides and at least 1" above the housing.
SPECIFICATION FEATURES
A ...Housing
All aluminum construction with 18" of
flexible conduit attached to a cylindrical
transformer/wiring enclosure. Swing
out mounting clips form pressure fit for
mounting in 1/2" - 3/4" drywall.
B ...Trim:
3.5" o.d. round trim with smooth re-
gressed splay and 45º cut-off. Finished
in white, black, industrial silver, stainless
steel (painted), and custom colors.
C ...System Protection:
Thermal protection inside housing.
Vent holes in housing provide cooler
operation. All aluminum construction
provides overall reduced temperatures.
2.00"
ORDERING INFORMATION
LX3004MH
__
Fixture
Finish
LX3004MH
WH = White
Regressed Lynx Trim with
BK = Black
Smooth Regressed Splay, 45º
S = Industrial Silver
Cut-Off & Housing & Ballast
SS = Stainless Steel (painted)
Enclosure
PM = Primer
www.cooperlighting.com
D ...Electrical
Electronic metal halide ballast housed
in a separate metal enclosure.
Enclosure includes a separated wiring
compartment and entry for primary
leads.
E ...Lamp
ES16 or CMHMR16 Metal Halide in
20 watts.
. GX10 twist-lock
(not included)
lamp socket for firm, mechanical lamp
connection. Can accept up to two (2)
optical accessories.
Ceiling Cut-Out: 3.19" dia.
8.90"
Flexible Conduit
D
20
Lamp/Ballast Wattage
20 = 20 watts
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX 818-349- 3031
Catalog #
Project
Comments
Prepared by
18.00"
A
3.50" dia.
__
Voltage
120 = 120 volts
277 = 277 volts
Type
Date
LX3004MH
Miniature Round
Trim w/ Smooth
Regressed Splay
45º Cut-Off
C
Cylindrical Housing
Ballast/Wiring
6.75"
Enclosure
E
ES16 Metal Halide 20 watts
CMHMR16 Metal Halide 20 watts
B
2.31" dia.
U.L. Listed. Suitable for use in
combustible ceilings.
LYNX
rev. 011007
