- Page 1 Grass Trimmer/Brush Cutter Operator's Manual MODEL SRM - 261U WARNING DANGER Read rules for safe operation and instructions carefully. ECHO provides an Operator's Manual and a Safety Manual. Both must be read and understood for proper and safe operation. X753001281 X7532093201 11/05...
-
Page 2: Table Of Contents
NTRODUCTION Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-job dependability. Read and understand this manual and the SAFETY MANUAL you found in the same package. You will find both easy to use and full of helpful operating tips and SAFETY messages. -
Page 3: Safety
RASS RIMMER RUSH UTTER PERATOR ANUAL AFETY MANUAL SAFETY SYMBOLS AND IMPORTANT INFORMATION Throughout this manual and on the product itself, you will find safety alerts and helpful, informational messages preceded by symbols or key words. The following is an explanation of those symbols and key words and what they mean to you. - Page 4 Wear no-slip, heavy-duty work gloves to improve your grip on the handle. Gloves also reduce the transmission of machine vibration to your hands. Hearing Protection ECHO recommends wearing hearing protection whenever unit is used. Proper Clothing Wear snug fitting, durable clothing;...
- Page 5 RASS RIMMER RUSH UTTER PERATOR ANUAL Repetitive Stress Injuries It is believed that overusing the muscles and tendons of the fingers, hands, arms, and shoulders may cause soreness, swelling, numbness, weakness, and extreme pain in those areas. Certain repetitive hand activities may put you at a high risk for developing a Repetitive Stress Injury (RSI).
-
Page 6: Equipment
Use only ECHO approved attachments. Serious injury may result from the use of a non-approved attachment combination. ECHO, INC. will not be responsible for the failure of cutting devices, attachments or accessories which have not been tested and approved by ECHO. Read and comply with all safety instructions listed in this manual and safety manual. -
Page 7: Description
Locate these safety decals on your unit. Make sure the decals are legible and that you understand and follow the instructions on them. If a decal cannot be read, a new one can be ordered from your ECHO dealer. See PARTS ORDER- ING instructions for specific information. - Page 8 POWER HEAD - Includes the Engine, Clutch, Fuel System, Ignition System and Recoil Starter. THROTTLE TRIGGER LOCKOUT - This lever must be held during starting. Operation of the throttle trigger is prevented unless throttle trigger lockout lever is engaged. STOP SWITCH - "SLIDE SWITCH" mounted on top of the Throttle Trigger Housing. Move switch FORWARD to RUN, BACK to STOP.
-
Page 9: Contents
The ECHO product you purchased has been factory pre-assembled for your convenience. Due to packaging restrictions, shield installation and other assembly may be necessary. After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing parts. Use the contents list to check for missing parts. -
Page 10: Assembly
SSEMBLY PLASTIC SHIELD INSTALLATION (Nylon line operation) Tools Required: Screwdriver, Locking Tool Parts Required: Plastic Debris Shield, Shield Plate, three (3) 5 x 16 mm screws. WARNING DANGER The plastic shield is for use with the Nylon Line Head only. Install Metal Shield when using plastic or metal blades, or serious injury may result. -
Page 11: Nylon Line Head Removal
You must install the U-Handle and all Blade Conversion parts shown in the following instructions before operating this unit with a metal blade, otherwise serious injury may result. NOTE Model SRM-261U includes U-Handle, and necessary blade conversion parts. Blades are not provided with trimmer/ brushcutters and must be selected for type of cutting being performed. -
Page 12: U-Handle Installation
Install Blade Tools Required: Locking Tool, 17x19 mm Wrench. Parts Required: Upper Plate w/ 20 mm pilot, Lower Plate, 10 mm Nut w/ L.H. threads, 2 x 25 mm Cotter Pin, Blade. Install upper plate (D) on splined PTO shaft, pilot side down. Blade installation requires Upper Plate (D) with 20 mm pilot. -
Page 13: Throttle Linkage And Ignition Leads
Check throttle for freedom of movement and that wide open throttle / low idle extremes are adjusted properly. If adjustment cannot be achieved with adjusting nuts (B), consult with your Echo Dealer for correct adjustment procedure. Tighten nuts (B). Connect ignition stop leads (C) and (D). - Page 14 Plastic/Nylon Grass/Weed Blades may be used where ever the nylon line head is used. DO NOT use this blade for heavy weeds or brush! 8 Tooth Weed/Grass Blade (P/N 69600120331) is designed for grass, garden debris and thick weeds. DO NOT use this blade for brush or heavy woody growth, 19 mm (3/4 in.) diameter or larger.
-
Page 15: Fuel
Echo premium Power Blend Universal 2-Stroke Oil may be mixed shut-off containers to reduce fuel at 50:1 ratio for application in all Echo engines sold in the past spillage. regardless of ratio specified in those manuals. After use •... -
Page 16: Starting Cold Engine
STARTING COLD ENGINE WARNING DANGER The attachment will operate immediately when the engine starts and could result in loss of control and possible serious injury. Keep movable parts of the attachment off the ground and away from objects that could become entangled or thrown. Stop Switch Move stop switch button (A) forward away from the STOP position. -
Page 17: Starting Warm Engine
The attachment should not move at idle, otherwise serious personal injury may result. NOTE If attachment moves, readjust carburetor according to “Carburetor Adjustment” instructions in this manual or see your ECHO Dealer. Stop Switch Move stop switch button (A) forward away from the STOP position. -
Page 18: Stopping Engine
ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOURSELF or have the ECHO Dealer do it, each maintenance task has been graded. If the task is not listed, see your ECHO Dealer for repairs. -
Page 19: Maintenance Intervals
RASS RIMMER RUSH UTTER PERATOR ANUAL MAINTENANCE INTERVALS n i l t I - t l i t l i n i l l f f ) s l l i o s t l t n i ® ® . -
Page 20: Air Filter
AIR FILTER Level 1. Tools required: Cleaning brush, 25 or 50 mm (1 or 2 in.) medium bristle paint brush. Parts required: 90030 REPOWER AIR & FUEL FILTER KIT. Close choke (Cold Start Position ( ). This prevents dirt from entering the carburetor throat when the air filter is removed. -
Page 21: Spark Plug
RASS RIMMER RUSH UTTER PERATOR ANUAL SPARK PLUG Level 2. Tools Required: T-Wrench, Feeler gauge, Soft Metal Brush. Parts Required: REPOWER Tune-Up Kit P/N 90075 IMPORTANT Use only NGK BPM-8Y spark plug (BPMR-8Y in Canada) otherwise severe engine damage may occur. Remove spark plug and check for fouling, worn and rounded center electrode. -
Page 22: Exhaust System
Remove spark plug lead. Remove two (2) muffler cover screws and muffler cover (A). Remove screw and arm rest (B). Remove engine cover (C). IMPORTANT DO NOT use a metal scraper to remove dirt from the cylinder fins. Use brush to remove dirt from the cylinder fins. Remove grass and leaves from the grid between the recoil starter and fuel tank. -
Page 23: Carburetor Adjustment
The cylinder exhaust port must be inspected and cleaned of excess carbon every 3 months or 90 hours of operation in order to maintain this engine within the emissions durability period. ECHO strongly recommends that you return your unit to your ECHO dealer for this important maintenance service. CARBURETOR ADJUSTMENT... -
Page 24: Lubrication
Loosen two (2) screws (B) and remove center locating screw (C). Pull gear box and shield from drive shaft housing. Pull flexible cable from the drive shaft housing, wipe clean and recoat with a thin coating[15 ml (1/2 oz.)] of ECHO LUBE ®... -
Page 25: Nylon Line Replacement
PERATOR ANUAL NYLON LINE REPLACEMENT Level 1. Parts Required: ECHO 2.4mm (0.095 in.) Nylon Trimmer Line 12m (40 feet [two 20 ft. sections]) Echomatic Pro Trimmer Head Do not push spool in. Hold drum and turn spool clockwise until peg clicks and disappears from hole. Pull spool out of drum. -
Page 26: Sharpening Metal Blades
SHARPENING METAL BLADES Three styles of metal blades are approved for use on the ECHO Brush Cutter. The 8-tooth blade can be sharpened during normal maintenance. The clearing blade and 80 tooth blade require professional service. Before sharpening, CLOSELY inspect blade for cracks (look at the bottom of each tooth and the center mounting hole closely), missing teeth and bending. -
Page 27: Troubleshooting
RASS RIMMER RUSH UTTER PERATOR ANUAL ROUBLESHOOTING t l i l f f t l i t l i t l i t l i t r i t r i WARNING DANGER Fuel vapors are extremely flammable and may cause fire and/or explosion. Never test for ignition spark by ground- ing spark plug near cylinder plug hole, otherwise serious personal injury may result. -
Page 28: Storage
TORAGE WARNING DANGER During operation the muffler or catalytic muffler and surrounding cover become hot. Always keep exhaust area clear of flammable debris during transportation or when storing, otherwise serious property damage or personal injury may result. Long Term Storage (over 30 days) Do not store your unit for a prolonged period of time (30 days or longer) without performing protective storage mainte- nance which includes the following: Store unit in a dry, dust free place, out of the reach... -
Page 29: Specifications
RUSH UTTER PERATOR ANUAL PECIFICATIONS MODEL ----------------------------------------------------- SRM-261U Length ------------------------------------------------------- 1795 mm (70.7 in.) Width -------------------------------------------------------- 711 mm (28.0 in.) Height ------------------------------------------------------- 478.5 mm (18.84 in.) Weight (dry) w/Cutter Head ------------------------------ 6.3 kg (13.8 lb.) Engine Type ------------------------------------------------ Air cooled, two-stroke, single cylinder gasoline engine Bore ---------------------------------------------------------- 34.0 mm (1.34 in.) - Page 30 NOTES...
- Page 31 RASS RIMMER RUSH UTTER PERATOR ANUAL NOTES...
-
Page 32: Servicing Information
• Purchasing from your Echo Dealer. • Manuals are available by sending a written request stating the model number and serial number of your Echo unit, part number of the manual, your name and address, and mail to the address below.
