SPECIFICATIONS.

1 2 3 4 5 6 7
1 2 3 4 5 6 7
1 2 3 4 5 6 7
1 2 3 4 5 6 7
1 2 3 4 5 6 7
Projection type .............. Rear projection, console
Projection system .......... 3 lens and 3 CRTs in-line
Scanning frequency ....... XG135RP
H 15 to 135 kHz/V 40 to 160Hz
XG85RP/XG85RPW
H 15 to 85 kHz/V 40 to 160Hz
Retrace time .................. H 6.0 µS (fH 15 to 30kHz)
H 2.6 µS (fH 30 to 77kHz)
H 2.0 µS (fH 77 to 120kHz)
H 1.4 µS (fH 120 to 135kHz)
V 270 µS
Video bandwidth ............ 150MHz (-3dB) XG135RP
110MHz (-3dB) XG85RP/XG85RPW
CRT ............................... 8 inch liquid cooled
Deflection angle 90 degrees
Lens .............................. Hybrid lens with ECP and ARC
(ECP: Enhanced Color Purity, except B-lens,
(ARC: Anti-Reflective Coating)
HD-70(RGB)(XG85RP/XG85RPW)
Picture size .................... 72 inches diagonal (4:3)/66 inches diaginal (16:9)
Resolution ..................... 1100TV lines at center (HDTV)
Pixel resolution .............. 2500 2000 dots (Addressable)
(XG85RP/XG85RPW: 1600 1200 dots )
Light output ................... 850 cd/m
High voltage .................. 32kV
Input .............................. RGB signal 0.7Vp-p 75 ohm positive (BNC)
H/V sync 0.7 to 4.0Vp-p 75 ohm/1K ohm negative
or positive (BNC)
COMP sync 0.7 to 4.0Vp-p 75 ohm/1K ohm
negative or positive (BNC)
Sync on G 0.3 to 0.6Vp-p 75 ohm negative (BNC)
Y, Cr, Cb: Y1.0Vp-p 75Ω Sync negative (BNC)
COMP Video 1.0Vp-p 75 ohm positive (BNC)
S-video: Y 1.0Vp-p 75 ohm positive
Video system NTSC, PAL, SECAM and NTSC4.43
Audio:
Convergence .................. Digital convergence (Pre-set 100 positions)
Quick copy convergence
Static and wave convergence
Point convergence, Zone convergence
Convergence limits ........ Less than 0.2% of V-height
Audio output amplifer .... 20W+20W, 6 ohm
Warm up time ................ 20 minutes
1) This works only for VIDEO and COMPONENT signals.
2) This works only for NTSC video and COMPONENTsignals.
Specifications are subject to change without notice.
The dimensions given for the projector do not include protruding parts.
2
(White peak)
Cr, Cb 0.7Vp-p 75Ω (BNC)(same asY,Pb,Pr)
C 0.28Vp-p 75 ohm (burst level)
0.5 Vrms, 47kΩ, L, R (RCA)
RGB, VIDEO, S-Video
Setup signal ................... Cross hairs, Cross hatch, Dot, Window Pattern, H
test pattern
Power supply ................. AC 120V 60Hz
Input current ................. 7.4A (AC 120V)
Safety and regulation ..... Meets FCC class A requirements
UL Approved (UL 1950, CSA 950)
DHHS Approved
Meets DOC (Canada)
Meets RED ACT
Cabinet dimensions
XG85RP/XG135RP ........ 57 11/16 (W) 32(D) 78 7/16(H) inch
(42 1/4(D) : mirror at the maximum out position)
XG85RPW ..................... 57 11/16 (W) 32(D) 72 15/16(H) inch
(42 1/4(D) : mirror at the maximum out position)
Weight ........................... 217.5 kg/479 lbs
Upper ............... 92.6 kg/204 lbs
Lower ............... 124.9 kg/275 lbs with chassis projector installed
61.3 kg/135 lbs without projector
Remote control .............. Wired application
Wireless (operating distance 7m/23ft.)
Remote control functions ..... User remote (RC-6320); Power ON/OFF, Input
signal select, Picture mute, Bright, Contrast, Color
1)
Source information, Static convergence, Normal-
ize, Enter, End, Closed Caption
Full function remote (RC-6321); Test, Display, Help,
Information, Input list, Static focus, Edge focus, H/
V position, White balance select, Static conver-
gence, Wave convergence, Point convergence, H/V
amplitude, H/V linearity, H/V key-stone, H/V pin-
cushion, H/V blanking, Tilt, Skew, H/V bow, Store,
Normalize, Enter, End
Main control function .... Power ON/OFF, Input signal select,
External control ............. Power ON/OFF, Input signal select, Picture mute,
Sound mute, Remote control data input
PC control ..................... Acceptable (Optional)
Supplied accessories ..... Full function remote control unit (RC-6321), User
remote control unit (RC-6320), Remote cable
16m/52ft., AC line cable, Operation manual, Set-
Up manual
Environment .................. Temperature 0 to 40 degrees C
Humidity 0 to 90% non-condensing
Storage -10 to 50 degrees C
Sound emission ............. Less than 45dB (A). Complies with ISO 3744 or
ISO 7779
40
1) 2)
, Sharpness , Tint , Volume, Sound mute,
