ARRI Claypaky XTYLOS AQUA User Information

Page Contents
2 1. Safety information
4 2. Unpacking and preparation
7 3. Installation and start-up
7 3.1 Installing the fixture
7 3.2 Connecting to mains supply
8 3.3 Connecting the control signal line: DMX / Art-Net
8 3.4 Switching on the fixture and basic SetUp
9 4. Dimensions
XTYLOS AQUA
USER INFORMATION
INDEX
Congratulations on choosing a Claypaky product!
We thank you for your custom.
Please note that this product, as all the others in the rich
Claypaky range, has been designed and made with total quality
to ensure excellent performance and best meet your
expectations and requirements.
The Xtylos Aqua is a compact beam moving light with unique
optical and chromatic characteristics, making use of a tailor-made
laser source (Patent Application filed). This laser source, lasting for
10,000 hours, is enclosed in a reliable, safe and fully sealed module
and it is the powerful engine of an incredible array of colors.
The beam aperture is less than 2° and it can be decreased
further to 0.5°. The Xtylos Aqua uses laser technology with RGB
additive color mixing. In contrast to the subtractive mixing used
with discharge lamps, colored light beams are as bright as a
white light beam! The range of effects features two gobo wheels
- with 7 rotating gobos and 12 fixed gobos (including 7 beam
diameter reducers) - a wheel with 3 prisms, and a sixteen facet
prism on a dedicated channel which can be overlapped with the
prism wheel.
The Xtylos Aqua is definitely the most dynamic light on the
market. It is the first moving head light with a laser light source,
and this opens up new, surprising prospects for the development
of the entire entertainment lighting world.
CJ3001
