4 x ¾-14 NPT THREADED HOLE
Plug should be flush to 1.33mm max
Apply thread sealant on plug before inserting
Wall rough-in opening = 7.00" diameter
SAMPLE NUMBER: 1237L-RD - M - MH20T4 - 120 - CS - LBB
MODEL
WALL TYPE
1237-RD
7" round, open fascia
C
Concrete
1237C-RD
7" round, cross fascia
pour
1237E-RD
7" round, eyelid fascia
D
Drywall
1237L-RD
7" round, louver fascia
M
Masonry
Fixture includes integral electronic gear.
Lamp not included except for LED sources.
4 x ¾-14 NPT THREADED HOLE
Plug should be flush to 1.33mm max
Apply thread sealant on plug before inserting
Wall rough-in opening = 7.00" diameter
SAMPLE NUMBER: 1237L-SQ - C - CF13 - 120 - BZ - LBB
MODEL
WALL TYPE
1237-SQ
7" square, open fascia
C
Concrete
1237C-SQ
7" square, cross fascia
pour
1237E-SQ
7" square, eyelid fascia
D
Drywall
1237L-SQ
7" square, louver fascia
M
Masonry
Fixture includes integral electronic gear.
Lamp not included except for LED sources.
4.5"
(114mm)
3.5"
(90mm)
3.5"
(90mm)
1237-RD
SOURCE
VOLTS
12V Halogen
12V Halogen
20T3
20W / T3 / G4
120/12
277/12
LED
LED
12LED
12W/LED
120/12
Compact Fluorescent
Compact Fluorescent
CF13
13W/TTT/GX24q-1
120
277
Metal Halide
Metal Halide
20T3
20W/T4.5/G8.5
120
277
4.5"
(114mm)
3.5"
(90mm)
3.5"
(90mm)
1237-SQ
SOURCE
VOLTS
12V Halogen
12V Halogen
20T3
20W / T3 / G4
120/12
277/12
LED
LED
12LED
12W/LED
120/12
Compact Fluorescent
Compact Fluorescent
CF13
13W/TTT/GX24q-1
120
277
Metal Halide
Metal Halide
MH20T4
20W/T4.5/G8.5
120
277
.85" (max.)
ø 7.75"
(197mm)
ø 5.5"
(140mm)
FINISH
OPTIONS
Painted
Advance Ship Back Box
BK
Black
(select LBB option and order
BZ
Bronze
back box separately)
CS
City silver
LBB
Less back box
VE
Verde
WT
White
Natural Metal
NBR
Brass
NSS
Stainless
steel
1237-BB-C Back Box & cover
for poured concrete
1237-BB-D Back Box & cover
for drywall
1237-BB-M Back Box & cover
for masonry
7.75"
(197mm)
7.75
(197mm)
ø 5.5"
(140mm)
FINISH
OPTIONS
Painted
Advance Ship Back Box
BK
Black
(select LBB option and order
BZ
Bronze
back box separately)
CS
City silver
LBB
Less back box
VE
Verde
WT
White
Natural Metal
NBR
Brass
NSS
Stainless
steel
1237-BB-C Back Box & cover
for poured concrete
1237-BB-D Back Box & cover
for drywall
1237-BB-M Back Box & cover
for masonry
LUMIERE
(22mm)
RIO™ 1237-RD
20W (max.) T3 Halogen
12W (max.) LED
Low Voltage (12V)
13W (max.) Compact Fluorescent
20W T4.5 (max.) Metal Halide
FEATURES
• Integral electronic gear
• Factory assembled Power-Tray™
• Fascia adjusts 20° for proper alignment
• ADA compliant
• IP68 rated outdoor protection
• UL/cUL listed
• Three (3) year warranty
NOTE: See 'Accessories' section for Lamps
.85 (max.)
(22mm)
RIO™ 1237-SQ
20W (max.) T3 Halogen
12W (max.) LED
Low Voltage (12V)
13W (max.) Compact Fluorescent
20W T4.5 (max.) Metal Halide
FEATURES
• Integral electronic gear
• Factory assembled Power-Tray™
• Fascia adjusts 20° for proper alignment
• ADA compliant
• IP68 rated outdoor protection
• UL/cUL listed
• Three (3) year warranty
NOTE: See 'Accessories' section for Lamps
COOPER LIGHTING
`
®
Line Voltage
Line Voltage
1049
