Cooper Lighting LUMIERE DBY Specification Sheet

`
LUMIERE
D E S C R I P T I O N
Lumière offers junction boxes to meet virtually any landscape lighting application.
*Replace xx with corresponding finish.
O R D E R I N G I N F O R M AT I O N
SAMPLE NUMBER: MB1-BK
Order junction boxes as separate line items. Specify quantities and (if applicable) finish.
1082
COOPER LIGHTING
®
DBY
2" x 2-5/8" (51mm x 67mm)
Use with low voltage fixtures only
MB1-xx*
4-7/8" x 2" (124mm x 51mm)
Use with line voltage or low voltage fixtures
MB2-xx*
6-1/2" x 2-7/8" (165mm x 73mm)
Use with line voltage or low voltage fixtures
MBR1-xx*
4-1/8" x 1-5/8" (105mm x 41mm)
Use with line voltage or low voltage fixtures
DESCRIPTION
Direct burial, watertight wiring kit. For
through wiring of low voltage cable.
Constructed from injection-molded
plastic.
DESCRIPTION
Rectangular, above ground junction box
for surface or recessed mounting. It
accepts Lumière's FS1 or FS2 fixture
mounting covers (not included).
Constructed from die-cast aluminum.
Specify finish (BK, BZ, CS, VE, WT).
DESCRIPTION
Round, below grade junction box and
cover for inground installation.
Constructed from cast iron.
Specify finish (BK, BZ, CS, VE, WT).
DESCRIPTION
Round, above ground junction box for
surface or recessed mounting. It accepts
Lumière's RS1 or RS2 fixture mounting
covers (not included). Constructed
from die-cast aluminum.
Specify finish (BK, BZ, CS, VE, WT).
