PREMIUM PRESSURE WASHER
INSTRUCTION
MANUAL
MANUEL
D'UTILISATION
MANUAL DE
INSTRUCCIONES
MODEL
MODÈLE
MODELO
MS60799
If your pressure washer is not working properly or if there are parts missing or broken,
please DO NOT RETURN IT TO THE PLACE OF PURCHASE. Contact our Customer
Service Department at 1-877-362-4271 or www.simpsoncleaning.com
Si votre rondelle de pression ne travaille pas convenablement ou s'il y a des
parties manquant ou cassé, s'il vous plaît le PAS LE RETOURNE AU LIEU
D'ACHAT. Contacter notre département de service clients à
www.simpsoncleaning.com
Si su lavadora a presión no trabaja correctamente ó encuentra partes rotas
ófaltantes, por favor NO LA REGRECE AL LUGAR DONDE LA COMPRO.
Contáctese con nuestro Departamento de Servicio al Cliente llamando al
1-877-362-4271 ou www.simpsoncleaning.com
IMPORTANT: Please make certain that the person who is to use this equipment carefully
reads and understands these instructions before operating.
IMPORTANT  : Assurez-vous que toute personne qui utilisera cet équipement lise
attentivement ces instructions avant de l'utiliser.
IMPORTANTE: Aségurese por favor de que la persona que vaya a utilizar este equipo lea
con cuidado y comprenda estas instrucciones antes de operar.
VEA EL ESPAÑOL EN LA CONTRAPORTADA. INSTRUCTIVO DE OPERACIÓN,
CENTROS DE SERVICIO Y PÓLIZA DE GARANTÍA. ADVERTENCIA:
LÉASE ESTE INSTRUCTIVO ANTES DE USAR EL PRODUCTO.
SAVE THIS MANUAL FOR FUTURE REFERENCE
LISEZ ET CONSERVEZ CES INSTRUCTIONS
CONSERVE ESTAS INSTRUCCIONES PARA FUTURAS CONSULTAS
Part No. 7108423 Rev. 0
Please contact us for further information at www.allpartsinc.com
AUG 2015
2600
PSI
2.3
GPM
1-877-362-4271 o

Advertisement

Table of Contents
loading

Related Manuals for Simpson MS60799

Summary of Contents for Simpson MS60799

  • Page 1 INSTRUCCIONES MODEL MODÈLE MODELO MS60799 If your pressure washer is not working properly or if there are parts missing or broken, please DO NOT RETURN IT TO THE PLACE OF PURCHASE. Contact our Customer Service Department at 1-877-362-4271 or www.simpsoncleaning.com Si votre rondelle de pression ne travaille pas convenablement ou s'il y a des parties manquant ou cassé, s'il vous plaît le PAS LE RETOURNE AU LIEU...

  • Page 2: Safety Guidelines - Definitions

    SAFETY GUIDELINES - DEFINITIONS This manual contains information that is important for you to know and understand. This information relates to protecting YOUR SAFETY and PREVENTING EQUIPMENT PROBLEMS. To help you recognize this information, we use the symbols below. Please read the manual and pay attention to these symbols. DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
  • Page 3 WARNING: This product may not be equipped with a spark-arresting muffler. If the product is not equipped and will be used around flam ma ble ma teri als or on land covered with materials such as agricultural crops, forest, brush, grass or other similar items, then an ap proved spark arrester must be installed and is legally required in the state of California.
  • Page 4 DANGER: RISK TO BREATHING (ASPHYXIATION) WHAT CAN HAPPEN HOW TO PREVENT IT • Breathing ex haust fumes will cause • Operate pressure washer in a well- se ri ous injury or death! En gine ventilated area. Avoid en closed areas exhaust contains carbon mon ox ide, such as ga rages, base ments, etc.
  • Page 5 DANGER: RISK OF INJURY FROM SPRAY WHAT CAN HAPPEN HOW TO PREVENT IT • High-velocity fluid spray can cause • Always wear ANSI-approved Z87.1 objects to break, projecting particles safety glasses. Wear protective clothing at high speed. to protect against accidental spraying. •...
  • Page 6 DANGER: RISK OF INJURY OR PROP ER TY DAMAGE WHEN TRANSPORTING OR STORING WHAT CAN HAPPEN HOW TO PREVENT IT • Fuel or oil can leak or spill and could • If pressure washer is equipped with a fuel result in fire or breathing hazard. shut-off valve, turn the valve to the OFF Se rious in ju ry or death can re sult.
  • Page 7 WARNING: RISK OF BURSTING WHAT CAN HAPPEN HOW TO PREVENT IT • Over inflation of tires could result in • Use a tire pressure gauge to check the serious injury and property damage. tires pressure before each use and while inflating tires;...
  • Page 8 QUICK SETUP GUIDE WARNING: To reduce the risk of injury, read the pressure washer instruction manual and the engine instruction manual before operating pressure washer. Add Gasoline Add/Check Oil Install the Handle Place handle onto In a well ventilated The engine is frame, depress outdoor area shipped without...
  • Page 9 Connect Spray Connect QC Turn Water Wand to Spray Nozzles to Spray Faucet Wand Completely On Thread the spray wand into Pull quick connect Do not run the unit the end of the spray gun. coupler back and insert without water supply nozzle.
  • Page 10 GET TO KNOW THE PRESSURE WASHER NOTE: Photographs and line drawings used in this manual are for reference only and do not represent a specific model. Compare the illustrations with your unit to familiarize yourself with the location of various controls and adjustments. Save this manual for future reference. BASIC ELEMENTS OF A PRESSURE WASHER (FIG.

  • Page 11: Operation

    Pump Inlet K. Quick Connect Nozzles BASIC ELEMENTS OF AN ENGINE Refer to the Engine Owner's Manual for location and operation of engine controls. Choke Control: Opens and closes carburetor choke valve. Starter Grip: Pulling starter grip operates recoil starter to crank engine. Engine Switch: Enables and disables ignition system.

  • Page 12: Pressure Washer Operating Features

    Bypass Mode: Allows water to re-circulate within the pump when the gun trigger is not pulled. This feature allows the operator to release the trigger gun and reposition themselves without having to turn the engine off in between cleaning actions. WARNING: Do not allow the unit to run for more than two minutes without the gun trigger being pulled.
  • Page 13 NOZZLE COLOR SPRAY PATTERN USES SURFACES* 15˚ intense cleaning grills, driveways, concrete of unpainted or brick walkways, Yellow hard surfaces unpainted brick or stucco 25˚ intense cleaning of metal, concrete or wood larger areas Green low pressure applies cleaning Low pressure solutions spray is safe on all Black...
  • Page 14 • Your washer operates at fluid pressures and velocities high enough to penetrate human and animal flesh, which could result in amputation or other serious injury. Leaks caused by loose fittings or worn or damaged hoses can result in injection injuries.
  • Page 15 Verify the filter screen (M) is in water inlet of pump. NOTE: Convex side faces out. Connect water source (N) to pump inlet (J). NOTE: Water source must provide a minimum of 5 gallons per minute at 20 PSI. Connect high pressure hose (C) to pump outlet (I). WARNING: To reduce the possibility of contamination always protect against backflow when connected to a potable water system.

  • Page 16: Shutting Down

    SHUTTING DOWN After each use, if you have applied chemicals, place detergent siphon hose into container of clean water and draw clean water through chemical injection system to rinse system thoroughly. NOTICE: Risk of property damage. Failure to do so could cause damage to the pump.
  • Page 17 ® is environmentally friendly. NOTE: Using pump guard helps provide proper lubrication to the internal seals of the pump regardless of temperature or environment. NOTICE: Risk of property damage. Use only SIMPSON / POWERWASHER ® ® Pump Guard or equivalent. Other products could be corrosive and/or contain alco- hol which may cause pump damage.

  • Page 18: Specifications

    NOTICE: The use of any other accessory not recommended for use with this tool could be hazardous. Use only accessories rated equal to or greater than the rating of the pressure washer. SPECIFICATIONS MS60799 MODEL PSI Max* 2600 PSI GPM Max* 2.3 gpm...
  • Page 19 ONE YEAR LIMITED WARRANTY ON PUMP AND FRAME SIMPSON SIMPSON warrants to the original purchaser that the pump of the ® ® pressure washer covered under this warranty is free from manufacturer’s defects in material and workmanship for one year from the date of purchase. The one year limited warranty applies to the pump only.

  • Page 20: Troubleshooting Guide

    IMPLIED WARRANTIES, INCLUDING THOSE OF MERCHANTABILITY OR • FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR FROM THE DATE OF ORIGINAL PURCHASE. Some states do not allow limitations on how long an implied warranty lasts, so the above limitations may not apply to you. TROUBLE SHOOTING GUIDE OPERATIONAL POSSIBLE CAUSE...
  • Page 21 OPERATIONAL POSSIBLE CAUSE SOLUTION ISSUE No or low Choke in the “Choke” position Move choke to the “No pressure Choke”po si tion (initial use) High pressure hose is too long Use high pressure hose under 100 feet (30 m) See How to Use Spray Will not draw Spray wand not in Wand paragraph in the...
  • Page 22 FNA Group, Inc. 7152 99th Street Pleasant Prairie, WI 53158 www.simpsoncleaning.com Internet Address: Warranty Registration via Internet www.simpsoncleaning.com Adresse Internet : Enregistrement de la garantie par Internet www.simpsoncleaning.com Sitio Address: Registro Garantía mediante Internet Copyright. All Rights Reserved Copyright. Todos los derechos reservados Copyright.
