- Page 1 OWNER’S MANUAL 3D Blu-ray™ / DVD Home Cinema System Please read this manual carefully before operating your set and retain it for future reference. BH7220BW (BH7220BW, S72B1-F/S/C/W, W2, T2) BH7520TW (BH7520TW, S72T1-S/W, S72B1-C, W2, T2)
- Page 2 Getting Started Safety Information CAUTION CAUTION : CLASS 1M VISIBLE AND INVISIBLE LASER RISK OF ELECTRIC SHOCK RADIATION WHEN OPEN. DO NOT VIEW DIRECTLY DO NOT OPEN WITH OPTICAL INSTRUMENTS CAUTION: TO REDUCE THE RISK OF ELECTRIC Use of controls, adjustments or the performance of SHOCK DO NOT REMOVE COVER (OR BACK) NO procedures other than those specified herein may USER-SERVICEABLE PARTS INSIDE REFER SERVICING...
- Page 3 Getting Started Disposal of waste batteries/accumulators This device is equipped with a portable battery or accumulator. 1. When this crossed-out wheeled Safety way to remove the battery or the bin symbol is attached to batteries/ battery from the equipment: Remove the accumulators of Your product it means old battery or battery pack, follow the steps they are covered by European Directive...
- Page 4 Because AACS (Advanced Access Content System) is approved as content protection system for Blu-ray Disc format, similar to use of LG Electronics hereby declares that this/these CSS (Content Scramble System) for DVD format, product(s) is/are in compliance with the essential...
- Page 5 Getting Started Important Notice for TV colour system The colour system of this player differs according to currently playing discs. For example, when the player plays the disc recorded in the NTSC colour system, the image is output as an NTSC signal. Only the multi system colour TV can receive all signals output from the player.
-
Page 6: Table Of Contents
Table of Contents Table of Contents – Playback content in the USB device System Setting Settings Getting Started – Initial Setup Safety Information – Adjust the Setup Settings Introduction – [DISPLAY] Menu – Playable Discs and symbols used in – [LANGUAGE] Menu this manual –... - Page 7 – Deleting a saved station – Deleting all the saved stations – Improving poor FM reception – See information about a radio station Using the Premium Using the LG Apps – Signing in – Managing my Apps Troubleshooting Troubleshooting – General –...
-
Page 8: Getting Started
Getting Started Introduction Playable Discs and symbols used in this manual Media/Term Logo Symbol Description y Discs such as movies that can be purchased or rented. y “Blu-ray 3D” discs and “Blu-ray 3D ONLY” discs. y BD-R/RE discs that are recorded in BDAV format. Blu-Ray y BD-R/RE discs that contain Movie, Music or Photo files. -
Page 9: About The "7" Symbol Display
[Mastered] in order to make the discs compatible with the LG players when formatting rewritable discs. When setting the option to Live System, you cannot use it on LG player. (Mastered/Live File System : Disc format system for windows Vista) -
Page 10: File Requirement
Getting Started File requirement Movie files File File Codec Format Audio Format Subtitle Location Extension “.avi”, “.divx”, DIVX3.xx, DIVX4.xx, Dolby Digital, SubRip (.srt / .txt), SAMI (.smi), “.mpg”, “.mpeg”, DIVX5.xx, DIVX6.xx DTS, MP3, SubStation Alpha (.ssa/.txt), “.mkv”, “.mp4”, (Standard playback WMA, AAC, MicroDVD (.sub/.txt), VobSub Disc,... -
Page 11: Avchd (Advanced Video Codec High Definition)
Getting Started Note Note y The file name is limited to 180 characters. y A “avi” file which is encoded “WMV 9 codec” is not supported. y Maximum files/folder: Less than 2 000 (total number of files and folders) y This player supports UTF-8 files even it contains Unicode subtitle contents. -
Page 12: About Dlna
Getting Started About DLNA Regional Code This Player is a DLNA Certified digital media player This unit has a regional code printed on the rear of that can display and play movie, photo and music the unit. This unit can play only BD-ROM or DVD content from your DLNA-compatible digital media discs labeled same as the rear of the unit or “ALL”. -
Page 13: Remote Control
(SCAN): Searches They are also used for [MOVIE], backward or forward. [PHOTO], [MUSIC], [Premium] and [LG Apps] menu. C/V (SKIP): Goes to the - B button: Selects mono/ stereo next or previous chapter / track / in FM mode. -
Page 14: Front Panel
Getting Started Front panel > Caution a Disc Slot Precautions in using the touch buttons b Display Window y Use the touch buttons with clean and dry c Remote Sensor hands. d PORT. IN - In a humid environment, wipe out any e iPod/ iPhone/ iPad/ USB Port moisture on the touch buttons before f Operation buttons... -
Page 15: Rear Panel
Getting Started Rear panel a AC power cord g LAN port b Speakers connectors h HDMI IN 1/2 c Cooling Fan i HDMI OUT TO TV d OPTICAL IN j VIDEO OUT e Antenna Connector k WIRELESS connector f AUX (L/R) INPUT... -
Page 16: Connecting
Connecting > Caution Positioning the system y Be careful to make sure children not to put their hands or any objects into the *speaker The following illustration shows an example of duct. positioning the system. Note that the illustrations *Speaker duct: A hole for plentiful bass in these instructions differ from the actual unit for sound on speaker cabinet (enclosure). -
Page 17: Speaker Connection
Connecting Speaker Connection Attaching the speakers to the player 1. Connect speaker wires to the player. Each speaker wire is color-coded. Use matching color wires for corresponding speakers. Color Speaker Position Green Center Center Orange Any front position woofer Front Front right White Front... -
Page 18: Wireless Speakers Connection
Connecting Wireless speakers connection 4. Turn on the main unit: The main unit and wireless receiver will be automatically connected. LED indicator of wireless receiver > Caution y Insert the Wireless TX with the marked LED Color Operation “Wireless TX" facing upwards to rear on the Blue or yellow The wireless receiver is receiving unit. - Page 19 Connecting Connecting Note About Ferrite Core (for EMI only) About Ferrite Core (for EMI only) y If there is a strong electromagnetic wave Be sure to attach the ferrite core to the power cord product nearby, interference may occur. Put (for connecting to this unit and wireless receiver).
-
Page 20: Connecting To Your Tv
Connecting Connecting to Your TV HDMI Connection If you have a HDMI TV or monitor, you can connect it to this player using a HDMI cable (Type A, High Make one of the following connections, depending speed HDMI™ cable with Ethernet). Connect the on the capabilities of your existing equipment. -
Page 21: What Is Simplink
4.5 m(15 ft.)). What is SIMPLINK? Some functions of this unit are controlled by the TV’s remote control when this unit and LG TV’s with SIMPLINK are connected through HDMI connection. Controllable functions by LG TV’s remote control;... -
Page 22: Video Connection
Connecting Video Connection Resolution Setting Connect the VIDEO OUT jack on the player to the The player provides several output resolutions for video in jack on the TV using a video cable. You can HDMI OUT jack. You can change the resolution hear the sound through the system’s speakers. -
Page 23: Antenna Connection
Connecting Note Antenna connection y If your TV does not accept the resolution you have set on the player, you can set Connect the supplied antenna for listening to the resolution to 576p as follows: radio. 1. Press HOME ( ) to disappear the HOME menu. -
Page 24: Connections With External Device
Connecting Connections with PORT. IN connection external device You can enjoy the sound from your portable audio player through the speakers of this system. Connect the headphones (or line out ) jack of the portable audio player into the PORT. IN socket of AUX Connection this unit. -
Page 25: Optical In Connection
Connecting OPTICAL IN connection HDMI IN 1/2 connection You can enjoy the sound from your component You can enjoy the pictures and sound from your with a digital optical connection through the component through this connection. speakers of this system. Connect the HDMI OUT jack of your component Connect the optical output jack of your component into the HDMI IN 1 or 2 jack on this unit. -
Page 26: Connecting To Your Home Network
Connecting Connecting to your Home Network Broadband service This player can be connected to a local area network (LAN) via the LAN port on the rear panel or the internal wireless module. By connecting the unit to a broadband home network, you have access to services such as software updates, BD-LIVE interactivity and on-line content services. -
Page 27: Wired Network Setup
Connecting Wired Network Setup Advanced Setting If you want to set the network settings manually, If there is a DHCP server on the local area network use W/S to select [Advanced Setting] on the (LAN) via wired connection, this player will [Network Setting] menu and press ENTER (b). -
Page 28: Wireless Network Connection
Connecting Wireless Network Connection Wireless Network Setup Another connection option is to use an Access Point For the wireless network connection, the player or a wireless router. The network configuration and needs to be set up for network communication. connection method may vary depending on the This adjustment can be done from the [Setup] equipment in use and the network environment. - Page 29 Connecting Advanced Setting If you want to set the network settings manually, use W/S to select [Advanced Setting] on the [Network Setting] menu and press ENTER (b). 1. Use W/S to select [Wireless] and press ENTER (b). Note y WEP security mode generally have 4 keys available on an access point setting.
- Page 30 Connecting Notes on Network Connection: y A DSL modem is required to use DSL service and a cable modem is required to use cable modem y Many network connection problems during service. Depending on the access method of and set up can often be fixed by re-setting the subscriber agreement with your ISP, you may not router or modem.
-
Page 31: Usb Device Connection
Connecting Note USB device connection y This player supports USB flash drive/external HDD formatted in FAT16, FAT32 and NTFS This player can play movie, music and photo files when accessing files (music, photo, movie). contained in the USB device. However, for BD-Live, only FAT16 and FAT32 formats are supported. -
Page 32: System Setting
System Setting Settings 5. Use W/S/A/D to select the IP mode between [Dynamic] and [Static]. Normally, select [Dynamic] to allocate an IP address automatically. Initial Setup When you turn on the unit for the first time, the initial setup wizard appears on the screen. Set the display language, network settings and speaker setup on the initial setup wizard. -
Page 33: Adjust The Setup Settings
System Setting Adjust the Setup Settings 8. Select [Next] and press ENTER (b). 9. Press ENTER (b) to verify the test tone signals of You can change the settings of the player in the the speakers. [Setup] menu. 1. Press HOME ( ). After verifying the test tone signals, press ENTER (b) while [Stop] is highlighted. -
Page 34: [Display] Menu
System Setting [DISPLAY] Menu Resolution Sets the output resolution of the HDMI video signal. TV Aspect Ratio Refer to page 22 for details about the resolution setting. Select a TV aspect ratio option according to your TV type. [Auto] [4:3 Letter Box] If the HDMI OUT jack is connected to TVs providing display information (EDID), Select when a standard 4:3 TV is connected. -
Page 35: [Language] Menu
System Setting HDMI Color Setting [LANGUAGE] Menu Select the type of output from the HDMI OUT jack. Display Menu For this setting, please refer to the manuals of your display device. Select a language for the [Setup] menu and on- screen display. -
Page 36: [Audio] Menu
System Setting [AUDIO] Menu Speaker Setup To obtain the best possible sound, use the speaker Each disc has a variety of audio output options. Set setup display to specify the volume of the speakers the player’s Audio options according to the type of you have connected and their distance from your audio system you use. - Page 37 System Setting HD AV Sync Sometimes Digital TV encounters a delay between picture and sound. If this happens you can compensate by setting a delay on the sound so that it effectively ‘waits’ for the picture to arrive: this is called HD AV Sync. Use W S to scroll up and down through the delay amount, which you can set at anything between 0 and 300 ms.
-
Page 38: [Lock] Menu
System Setting [LOCK] Menu DVD Rating Blocks playback of rated DVD based on their The [LOCK] settings affect only BD-ROM and DVD content. (Not all discs are rated.) playback. To access the any features in [LOCK] settings, you [Rating 1-8] must enter the 4-digit security code you have Rating one (1) has the most restrictions and created. -
Page 39: [Network] Menu
The [NETWORK] settings are needed to use the [Country Setting] software update, BD Live and on-line content Select your area for displaying proper services services. and contents on the [Premium] and [LG Apps] feature. Connection Setting If your home network environment is ready to Device Name... - Page 40 System Setting Network Play Initialize This function allows you to control the playback [Factory Set] of media streamed from DLNA media server by a You can reset the player to its original factory DLNA certified smartphone. Most DLNA certified settings. smartphone has a function to control the playback media on your home network.
-
Page 41: 3D Sound Effect
System Setting Sound Effect Setting the [User EQ] You can select a suitable sound mode. Press SOUND EFFECT repeatedly until the desired mode appears on the front panel display or the TV screen. The displayed items for the equalizer maybe different depending on sound sources and effects. -
Page 42: Operating
This player can play movie, music and photo files screen. contained in the disc or USB device. e [LG Apps] - Displays the [LG Apps] screen. 1. Insert a data disc in the disc slot or connect a f [Input] - Changes input mode. -
Page 43: Playing Blu-Ray 3D Disc
Operating Playing Blu-ray 3D disc Enjoying BD-Live™ This player can play the Blu-ray 3D discs which BD-ROM supporting BD-Live that has a network contains separate views for the left and right eyes. extension function allows you to enjoy more functions such as downloading new movie trailers by connecting this unit to the internet. -
Page 44: Playing A File On A Network Server
Operating Playing a file on a network Wi-Fi Direct™ Connection server Connecting to a Wi-Fi Direct™ certified device This player can play video, audio and photo files located in a DLNA server through your home This player can play movie, music and photo files network. - Page 45 Operating Note Connecting to a Wi-Fi available When you connect this unit from other Wi-Fi devices Direct™ devices, PIN connection method is not available. This player can connect to a general Wi-Fi device 6. Select a server that shared from the connected using Wi-Fi Direct™...
-
Page 46: Basic Operations For Video And Audio Content
Operating Basic operations for video and 8. Select a server that shared from the connected Wi-Fi device using W/S, and press ENTER (b) audio content to navigate the server. To stop playback Press Z (STOP) while playback. To pause playback Press M (PAUSE) while playback. -
Page 47: Basic Operations For Photo Content
Operating Basic operations for photo Resume playback content eroyt To play a slide show The unit records the point where you pressed the Press d (PLAY) to start slide show. Z (STOP) depending on the disc. If “MZ (Resume Stop)” appears on the screen briefly, To stop a slide show press d (PLAY) to resume playback (from the scene Press Z (STOP) while slide show. -
Page 48: Advanced Playback
Operating Advanced Playback Repeating a specific portion eroty This player can repeat a portion you have selected. Repeat Playback 1. While playback, press REPEAT (h) to select erotu [A-] at the beginning of the portion you wish to repeat. 2. Press ENTER (b) at the end of the portion. Your During playback, press REPEAT (h) repeatedly to selected portion will be repeated continually. -
Page 49: Changing Content List View
Operating Changing content list view Selecting a subtitle file On the [Movie], [Music] or [Photo] menu, you can If the subtitle file name is different from the movie change the content list view. file name, you need to select the subtitle file on the [Movie] menu before playing the movie. -
Page 50: Options While Viewing A Photo
Operating Options while viewing a photo Listening to music while slide show You can use various options during viewing a photo in full screen. You can display photo files while listening to music 1. While viewing a photo in full screen, press INFO/ files. -
Page 51: On-Screen Display
To use the [Movie Information] option, the player must be connected to the broadband internet for accessing the Gracenote Media Database. y LG is a licensee of Gracenote technology and is not responsible or liable for information from the Gracenote Media Database. -
Page 52: Playing From Selected Time
Operating Playing from selected time Hearing a different audio eroy eroy 1. Press INFO/MENU (m) during playback. The 1. During playback, press INFO/MENU (m) to time search box shows the elapsed playing display the On-Screen display. time. 2. Use W/S to select the [Audio] option. 2. -
Page 53: Changing The Tv Aspect Ratio
Operating Changing the TV Aspect Ratio Changing the Picture Mode eroy You can change the TV aspect ratio setting while You can change the [Picture mode] option while playback. playback. 1. During playback, press INFO/MENU (m) to 1. During playback, press INFO/MENU (m) to display the On-Screen display. -
Page 54: Viewing Information From Gracenote Media Database
Gracenote Media Database. content and content in DLNA servers. If there is no music information from the database, y LG is a licensee of Gracenote technology music titles will not appear on the screen. and is not responsible or liable for... -
Page 55: Playing The Ipod
Operating Playing the iPod You can enjoy the sound with your iPod. For details about iPod, refer to the iPod’s User Guide. Preparation Press REPEAT (h) to select a desired repeat Before connecting the iPod, turn this unit off and mode :Track (;), All (:), Shuffle All (l :), reduce the volume of this unit to its minimum. - Page 56 Operating Note y An error message “CHECK” or “Connected iPod model is not supported. ” appears when: - your iPod is not available for the function to be operated. y An error message “CHECK” or “Please update your iPod’s software. ” appears when: - your iPod has an old software version.
-
Page 57: Radio Operations
Operating Radio Operations Deleting a saved station 1. Press PRESET (- / +) to select a preset number you want to delete. Be sure that the antennas are connected. (Refer to the page 23) 2. Press CLEAR, the preset number will blink in the display window. -
Page 58: Using The Premium
1. Check the network connection and settings (page 26). 2. Press HOME ( ). 3. Select the [LG Apps] using A/D, and press ENTER (b). 4. Select an on-line service using W/S/A/D, and press ENTER (b). -
Page 59: Signing In
Operating Signing in Managing my Apps To use the [LG Apps] feature, you need to sign in You can move or delete an installed application in with your account. the [My Apps] menu. 1. On the [LG Apps] or [My Apps] screen, press red Move an application (R) colored button. -
Page 60: Troubleshooting
Troubleshooting Troubleshooting General Symptom Cause & Solution The Power does not turned on. y Plug the power cord into the wall outlet securely. The unit does not start y Insert a playable disc. (Check the disc type, color system, and regional playback. -
Page 61: Network
Troubleshooting Network Symptom Cause & Solution BD-Live feature does not work. y The connected USB storage may not have enough space. Connect the USB storage with at least 1GB free space. y Ensure that the unit is correctly connected to the local area network and can access the internet (see page 26). -
Page 62: Picture
You can update the Player using the latest software to enhance the products operation and/or add new features. To obtain the latest software for this player (if updates have been made), please visit http://www.lg.com/global/support or contact LG Electronics customer care centre. Open source software notice To obtain the corresponding source code under GPL, LGPL, MPL and other open source licenses, please visit http://opensource.lge.com. -
Page 63: Appendix
Appendix Controlling a TV with Setting up the remote to control your TV the Supplied Remote You can operate your TV with the supplied remote Control control. If your TV is listed in the table below, set the appropriate manufacturer code. You can control your TV using the buttons below. -
Page 64: Network Software Update
Appendix Network Software Software Update Update You can update the player using the latest software to enhance the products operation and/or add new features. You can update the software by connecting the unit directly to the software update Network update notification server. - Page 65 Note The Software Update function may not work properly depending on your internet environment. In this case, you can obtain the latest software from the authorized LG Electronics Service Centre then update your player. Refer to “Customer Support” on page...
-
Page 66: About Nero Mediahome 4 Essentials
Appendix About Nero System Requirements MediaHome 4 Windows PC Essentials y Windows® XP (Service Pack 2 or higher), Windows Vista® (no Service Pack required), Windows® 7 (no Service Pack required), Windows® XP Media Nero MediaHome 4 Essentials is a software for Center Edition 2005 (Service Pack 2 or higher), sharing movie, music and photo files stored on your Windows Server®... -
Page 67: Installing Nero Mediahome 4
Appendix Installing Nero MediaHome 4 Mac OS X Essentials 1. Start up your computer, and insert the supplied CD-ROM disc into your computer’s CD-ROM drive. Windows 2. Browse the CD-ROM drive and open the Start up your computer, and insert the supplied CD- “MediaHome_4_Essentials_MAC”... -
Page 68: Area Code List
Appendix Area Code List Choose an area code from this list. Area Code Area Code Area Code Area Code Afghanistan Fiji Monaco Singapore Argentina Finland Mongolia Slovak Republic Australia France Morocco Slovenia Austria Germany Nepal South Africa Belgium Great Britain Netherlands South Korea Bhutan... -
Page 69: Language Code List
Appendix Language code List Use this list to input your desired language for the following initial settings: [Disc Audio], [Disc Subtitle] and [Disc Menu]. Language Code Language Code Language Code Language Code Afar 6565 French 7082 Lithuanian 7684 Sindhi 8368 Afrikaans 6570 Frisian... -
Page 70: Trademarks And Licenses
Appendix Trademarks and Licenses Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,226,616; 6,487,535; 7,392,195; 7,272,567; 7,333,929; 7,212,872 & other U.S. and worldwide patents issued & pending. Blu-ray Disc™, Blu-ray™, Blu-ray 3D™, BD-Live™, DTS-HD, the Symbol, & DTS-HD and the Symbol BONUSVIEW™... - Page 71 Appendix You agree that your non-exclusive license to use the Gracenote Data, the Gracenote Software, and Gracenote Servers will terminate if you violate these restrictions. If your license terminates, you agree to cease any and all use of the Gracenote DivX®, DivX Certified®...
- Page 72 Appendix Cinavia Notice This product uses Cinavia technology to limit the use of unauthorized copies of some commercially- produced film and videos and their soundtracks. When a prohibited use of an unauthorized copy is detected, a message will be displayed and playback or copying will be interrupted.
-
Page 73: Audio Output Specifications
Appendix Audio Output Specifications Jack/Setting HDMI OUT Source BitStream PCM Stereo PCM Multi-Ch DTS Re-encode Dolby Digital PCM 2ch PCM 5.1ch Dolby Digital Dolby Digital Plus PCM 2ch PCM 5.1ch Dolby Digital Plus Dolby TrueHD PCM 2ch PCM 5.1ch Dolby TrueHD PCM 2ch PCM 5.1ch DTS-HD... -
Page 74: Specifications
Appendix Specifications General Power requirements Refer to main label on the rear panel. Power consumption Refer to main label on the rear panel. Dimensions (W x H x D) Approx. 440 X 65 X 297 mm Net Weight (Approx.) 3.3 kg Operating temperature 5 °C to 35 °C (41 °F to 95 °F) Operating humidity... - Page 75 Integrated IEEE 802.11n (2.4 GHz band) wireless networking access, Wireless LAN (internal antenna) compatible with 802.11b/g Wi-Fi networks. Bus Power Supply (USB) DC 5 V 0 2.1 A Speakers (BH7220BW) Front speaker (Left/ Right) Type 2 Way 2 speaker Max. Input power...
- Page 76 Appendix Speakers (BH7520TW) Front speaker (Left/ Right) Type 2 Way 3 speaker Max. Input power 360 W Net Dimensions Impedance Rated 4 Ω 250 x 1200 x 250 mm (W x H x D) Input Power 180 W Net Weight 4.1 kg Rear speaker (Left/ Right) Type...
-
Page 77: Maintenance
Appendix Maintenance Notes on Discs Handling Discs Handling the Unit Do not touch the playback side of the disc. Hold the disc by the edges so that fingerprints do not get on the surface. Never stick paper or tape on the When shipping the unit disc. -
Page 78: Important Information Relating To Network Services
Appendix Important Information Relating to Network Services All information, data, documents, communications, downloads, files, text, images, photographs, graphics, videos, webcasts, publications, tools, resources, software, code, programs, applets, widgets, applications, products and other content (“Content”) and all services and offerings (“Services”) provided or made available by or through any third party (each a “Service Provider”) is the sole responsibility of the Service Provider from whom it...
