LG DH7520TW Owner's Manual

Wireless
Hide thumbs
Table of Contents

Advertisement

Quick Links

OWNER'S MANUAL
DVD Wireless Home
Theater System
Please read this manual carefully before operating
your set and retain it for future reference.
DH7520TW (DH7520TW, S72T1-S/ W, S72B1-C, W2)
PRINTED IN CHINA
DH7520TW-PB.DSAUNL1_ENG_4634.indd 1
2012-05-10
2:31:17

Advertisement

Table of Contents
loading

Related Manuals for LG DH7520TW

Summary of Contents for LG DH7520TW

  • Page 1 OWNER’S MANUAL DVD Wireless Home Theater System Please read this manual carefully before operating your set and retain it for future reference. DH7520TW (DH7520TW, S72T1-S/ W, S72B1-C, W2) PRINTED IN CHINA DH7520TW-PB.DSAUNL1_ENG_4634.indd 1 2012-05-10 2:31:17...
  • Page 2 This product shall not be placed in a built- in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instruction has been adhered to. DH7520TW-PB.DSAUNL1_ENG_4634.indd 2 2012-05-10 2:31:18...
  • Page 3 This device is equipped with a portable battery or You have to set the disc format option to [Mastered] accumulator. in order to make the discs compatible with the LG players when formatting rewritable discs. When Safety way to remove the battery or the...

  • Page 4: Table Of Contents

    Advanced Operations – USB Connection – Recording to USB – OPTICAL In connection Using a Bluetooth wireless technology – Home theater speaker ez setup – Listening to music of a Bluetooth Antenna Connection device DH7520TW-PB.DSAUNL1_ENG_4634.indd 4 2012-05-10 2:31:18...
  • Page 5 – Preparation – Enjoying iPod on the screen – Enjoying the iPod IN mode Troubleshooting Troubleshooting Appendix Maintenance – Handling the Unit – Notes on Discs Area Code List Language code List Trademarks and Licenses Specifications DH7520TW-PB.DSAUNL1_ENG_4634.indd 5 2012-05-10 2:31:18...

  • Page 6: Getting Started

    Listens to sounds from TV, DVD and Digital device with vivid 5.1 (2.1 or 2.0) ch mode. Made for iPod Enjoys music form IPod with simple connection. AM antenna (1) Video cable (1) HDMI Cable (1) iPod Cradle (1) Wireless TX (1) DH7520TW-PB.DSAUNL1_ENG_4634.indd 6 2012-05-10 2:31:19...

  • Page 7: Introduction

    “&” may appear on your TV display during code from your unit, the message “Check operation and indicates that the function explained Regional Code” appears on the TV screen. in this owner’s manual is not available on that specific media. DH7520TW-PB.DSAUNL1_ENG_4634.indd 7 2012-05-10 2:31:20...

  • Page 8: Playable File Requirement

    If the name of movie file is different from that of the subtitle file, during playback of a DivX file, subtitle may not be display. y If you play a DivX file differ from DivXspec, it may not operate normally. DH7520TW-PB.DSAUNL1_ENG_4634.indd 8 2012-05-10 2:31:20...

  • Page 9: Remote Control

    - You can control the sound in the menu or exits the setup level, input source, and power menu. switching of LG TVs as well. Hold POWER (TV) and press PR/ TITLE: If the current DVD title has CH (W/S) button repeatedly a menu, the title menu appears until the TV turns on or off.

  • Page 10: Front Panel

    USB Port Connects a USB device. e R (OPEN/CLOSE) Ejects or insert the disc from slot loader. f T (PLAY/PAUSE) Starts playback. Pauses playback temporarily, press again to exit pause mode. g I (STOP) Stops playback. DH7520TW-PB.DSAUNL1_ENG_4634.indd 10 2012-05-10 2:31:20...

  • Page 11: Rear Panel

    AM- Connects the AM loop antenna k AUX (L/R) INPUT e iPod (24 pin) Connects to an external source with 2 channel f WIRELESS audio outputs. g VIDEO OUT Connects to a TV with video inputs. DH7520TW-PB.DSAUNL1_ENG_4634.indd 11 2012-05-10 2:31:21...

  • Page 12: Connecting

    3. Attach the speaker to the pole, then secure the connection with a supplied screw. Speaker Speaker cables 1. Attach the base to the pole. Be careful with the orientation of the pole and base, as in the illustration. DH7520TW-PB.DSAUNL1_ENG_4634.indd 12 2012-05-10 2:31:21...
  • Page 13 Be careful that the speaker does not fall down. Otherwise it may result in the speaker malfunctioning and causing personal injury and/ or property damage. Bottom of base 5. Connect the speaker wire to the connector on the speaker. DH7520TW-PB.DSAUNL1_ENG_4634.indd 13 2012-05-10 2:31:21...

  • Page 14: Attaching The Speakers To The Unit

    2. Connect the wires to the speakers. Connect the other end of each wire to the correct speaker according to the color coding: Color Speaker Position Green Center Center Orange Sub woofer Any front position Front Front right White Front Front left DH7520TW-PB.DSAUNL1_ENG_4634.indd 14 2012-05-10 2:31:22...

  • Page 15: Positioning The System

    But it is better to place the subwoofer near the front speakers. Turn it slightly toward the center of the room to reduce the wall reflections. Unit DH7520TW-PB.DSAUNL1_ENG_4634.indd 15 2012-05-10 2:31:22...

  • Page 16: Wireless Speakers Connection

    Step 1 - Step 3. 2. Connect the power cord of the Wireless Receiver to the outlet. 3. Turn off the unit and insert the Wireless TX into the WIRELESS connector on the rear of the unit. Line DH7520TW-PB.DSAUNL1_ENG_4634.indd 16 2012-05-10 2:31:23...
  • Page 17 It takes a few seconds (and may take longer) for the Wireless TX and Wireless Receiver to communicate with each other. y Use the rear speaker at least 30 cm (11 inch) away from either TV screen or PC monitor. DH7520TW-PB.DSAUNL1_ENG_4634.indd 17 2012-05-10 2:31:23...

  • Page 18: Connections To Your Tv

    Make sure the unit is connected directly to the TV. Tune the TV to the correct video input channel. y Do not connect your player via your VCR. The image could be distorted by the copy protection system. Green Blue DH7520TW-PB.DSAUNL1_ENG_4634.indd 18 2012-05-10 2:31:23...

  • Page 19: Hdmi Out Connection

    When the HDMI connection with HDCP is not verified, TV screen is changed to black or green screen or the snow noise may occur on the screen. In this case, check the the HDMI connection, or disconnect the HDMI cable. DH7520TW-PB.DSAUNL1_ENG_4634.indd 19 2012-05-10 2:31:24...

  • Page 20: Video Connection

    Connecting Video Connection Connect the VIDEO OUT jack on the unit to the video in jack on the TV using a video cable. You can hear the sound through the system’s speakers. Unit Yellow DH7520TW-PB.DSAUNL1_ENG_4634.indd 20 2012-05-10 2:31:24...

  • Page 21: Resolution Setting

    ENTER to confirm your selection. Note If your TV does not accept the resolution you have set on the player, you can set resolution to 480p (or 576p) as follows: Press Z STOP for more than 5 seconds. DH7520TW-PB.DSAUNL1_ENG_4634.indd 21 2012-05-10 2:31:24...

  • Page 22: Optional Equipment Connection

    P RADIO&INPUT. If your TV has only one output for audio (mono), connect it to the left (white) audio jack 4. Turn on the portable player or external device on the unit. and start it playing. DH7520TW-PB.DSAUNL1_ENG_4634.indd 22 2012-05-10 2:31:24...

  • Page 23: Usb Connection

    External HDD, Card readers, Locked devices, or hard type usb devices are not supported. y USB port of the unit cannot be connected to PC. The unit can not be used as a storage device. DH7520TW-PB.DSAUNL1_ENG_4634.indd 23 2012-05-10 2:31:24...

  • Page 24: Optical In Connection

    To select the AUX OPT directly. 3. Listen sound with 5.1(2.1 or 2)ch speaker. 4. To escape from AUX OPT by using the OPTICAL. Function is retuned to previous one. To the digital optical output jack of your component DH7520TW-PB.DSAUNL1_ENG_4634.indd 24 2012-05-10 2:31:24...

  • Page 25: Antenna Connection

    To prevent noise pickup, keep the AM Loop antenna away from the unit and other components. y Be sure to fully extend the FM wire antenna. After connecting the FM wire antenna, keep it as horizontal as possible. DH7520TW-PB.DSAUNL1_ENG_4634.indd 25 2012-05-10 2:31:25...

  • Page 26: System Setting

    2. Use WSAD to select a language then press b ENTER. b ENTER To confirm menu. The confirm menu will appear. Select 3. Use AD to select the [Enter] then press b ENTER to finish the language setup. DH7520TW-PB.DSAUNL1_ENG_4634.indd 26 2012-05-10 2:31:25...

  • Page 27: Language

    Select when a 16:9 wide TV is connected. Display Mode The Display Mode setting works only when the TV Aspect mode is set to 4:3. [Letterbox] Displays a wide picture with bands on the upper and lower portions of the screen. DH7520TW-PB.DSAUNL1_ENG_4634.indd 27 2012-05-10 2:31:25...

  • Page 28: Audio

    4. Adjust options using WSAD buttons. and press b ENTER. Press b ENTER again to 5. Returns to the previous menu by pressing x stop. Adjust the volume to match the volume RETURN. of test signals memorized in the system. DH7520TW-PB.DSAUNL1_ENG_4634.indd 28 2012-05-10 2:31:25...

  • Page 29: Lock (Parental Control)

    Rating one (1) has the most restrictions and rating eight (8) is the least restrictive. [Unlock] If you select unlock, parental control is not active and the disc plays in full. 4. Press b ENTER to confirm your rating selection. DH7520TW-PB.DSAUNL1_ENG_4634.indd 29 2012-05-10 2:31:25...

  • Page 30: Others

    2. Input a password and press b ENTER. 3. Select the first character using WS buttons. 4. Press b ENTER and select the second character using WS buttons. 5. Press b ENTER to confirm your Area code selection. DH7520TW-PB.DSAUNL1_ENG_4634.indd 30 2012-05-10 2:31:25...

  • Page 31: Operating

    You can not select the [Music], [Movie] or y The unit plays only music file contained in [Photo] option when the USB device is not the USB storage device or disc automatically. connected and a disc is not inserted. DH7520TW-PB.DSAUNL1_ENG_4634.indd 31 2012-05-10 2:31:25...

  • Page 32: Other Operations

    - Audio CD/ MP3/ WMA : Track/ All/ Random/ Off In the pause mode, press Slowing down SLOW (c or v) to select the playing the required speed. (DVD, DivX speed only) The DivX file cannot be slow down reverse playback. DH7520TW-PB.DSAUNL1_ENG_4634.indd 32 2012-05-10 2:31:25...

  • Page 33: To Display The Dvd Menu

    2. Press WS to select the time clock icon and “--:--:--” appears. 3. Input the required start time in hours, minutes, and seconds from left to right. If you enter the wrong numbers, press CLEAR to remove the DH7520TW-PB.DSAUNL1_ENG_4634.indd 33 2012-05-10 2:31:25...

  • Page 34: Marked Playback

    4. Select the play mode by using the and press ENTER. [Mark Play] Marked playback. [Current Play] Normal playback. Note If you want to select all files on the list, select [Select All] and press b ENTER. DH7520TW-PB.DSAUNL1_ENG_4634.indd 34 2012-05-10 2:31:26...

  • Page 35: Viewing A Photo File

    Viewing a particular show. b ENTER Select file. d Rotate – Press ENTER to rotate the photo.  Returning to the x RETURN Close [Home Menu]. e Go to list – Press  ENTER to return [Photo] menu. DH7520TW-PB.DSAUNL1_ENG_4634.indd 35 2012-05-10 2:31:26...

  • Page 36: Sleep Timer Setting

    The last scene remains in memory even if you remove the disc from the unit or switch off the unit. If you load a disc that has the scene memorized, the scene is automatically recalled. DH7520TW-PB.DSAUNL1_ENG_4634.indd 36 2012-05-10 2:31:26...

  • Page 37: Radio Operations

    6. Repeat the steps 2 to 5 to store other stations. Deleting all the saved stations 1. Press and hold CLEAR for two seconds. “ERASE ALL” will flash up on the unit display. 2. Press CLEAR to erase all saved of the radio stations. DH7520TW-PB.DSAUNL1_ENG_4634.indd 37 2012-05-10 2:31:26...

  • Page 38: Sound Adjustment

    It depends on the mode of surround and the source of audio, it is not defective. y You may need to reset the surround mode, after switching the input, sometimes even after the sound track changed. DH7520TW-PB.DSAUNL1_ENG_4634.indd 38 2012-05-10 2:31:26...

  • Page 39: Advanced Operations

    The making of unauthorized copies of copy- protected material, including computer programs, files, broadcasts and sound recordings, may be an infringement of copyrights and constitute a criminal offense. This equipment should not be used for such purposes. Be responsible Respect copyrights. DH7520TW-PB.DSAUNL1_ENG_4634.indd 39 2012-05-10 2:31:26...

  • Page 40: Using A Bluetooth Wireless Technology

    Cascade if the connection was made via display depending on the type of Bluetooth Bluetooth® wireless technology. device.Your unit appears as “LG Audio”. Available Devices : Mobile phone, MP3, Laptop, 3. Enter the PIN code. PDA (This units be supported the Stereo Headset.) PIN code : 0000 4.

  • Page 41: Listening To Music On This Unit Using Bluetooth Device

    Sound output from the speakers is stopped. Press and hold m INFO/DISPLAY repeatedly. Note Bluetooth information is changed as follows. y You cannot use VOL (volume), SOUND EFFECT, SPEAKER LEVEL in this mode. Local Bluetooth Device Address Device Name None DH7520TW-PB.DSAUNL1_ENG_4634.indd 41 2012-05-10 2:31:26...
  • Page 42 Bluetooth and the unit gets out of the operating range of Bluetooth. y The device with Bluetooth wireless technology is disconnected, if you turn off the main unit or put the device away from the main unit more than 10m. DH7520TW-PB.DSAUNL1_ENG_4634.indd 42 2012-05-10 2:31:26...

  • Page 43: Playing The Ipod

    TV. For details about a slide show, refer to the iPod User Guide. y Before connecting the iPod, turn this unit off and reduce the volume of this unit to its minimum. DH7520TW-PB.DSAUNL1_ENG_4634.indd 43 2012-05-10 2:31:27...

  • Page 44: Enjoying Ipod On The Screen

    Refer to basic operation section. Note y If the iPod’s OSD language is selected to simple chinese, the power scroll function is not operated correctly. y The controls on your iPod are not operational in this mode. DH7520TW-PB.DSAUNL1_ENG_4634.indd 44 2012-05-10 2:31:27...
  • Page 45 (e.g. “slide to unlock”) y If you use an application, make a call, or send and receive SMS text message, etc. on iPod touch or iPhone, disconnect it from iPod dock of this unit and then use it. DH7520TW-PB.DSAUNL1_ENG_4634.indd 45 2012-05-10 2:31:27...

  • Page 46: Troubleshooting

    Remove the obstacle. The battery in the remote control are flat. Replace the battery with new ones. Check whether the player is connected to the unit correctly. iPod does not work. Connect it to the unit correctly. DH7520TW-PB.DSAUNL1_ENG_4634.indd 46 2012-05-10 2:31:27...

  • Page 47: Appendix

    Maintaining the Unit The unit is a high-tech, precision device. If the optical pick-up lens and disc drive parts are dirty or worn, the picture quality could be diminished. For details, please contact your nearest authorized service center. DH7520TW-PB.DSAUNL1_ENG_4634.indd 47 2012-05-10 2:31:27...

  • Page 48: Area Code List

    Jamaica Philippines Ukraine Costa Rica Japan Poland United States Croatia Kenya Portugal Uruguay Czech Republic Kuwait Romania Uzbekistan Denmark Libya Russian Vietnam Federation Ecuador Luxembourg Zimbabwe Saudi Arabia Egypt Malaysia Senegal El Salvador Maldives Ethiopia Mexico DH7520TW-PB.DSAUNL1_ENG_4634.indd 48 2012-05-10 2:31:27...

  • Page 49: Language Code List

    Kurdish 7585 Scots Gaelic 7168 Xhosa 8872 Estonian 6984 Laothian 7679 Serbian 8382 Yiddish 7473 Faroese 7079 Latin 7665 Serbo-Croatian 8372 Yoruba 8979 Fiji 7074 Latvian, Lettish 7686 Shona 8378 Zulu 9085 Finnish 7073 Lingala 7678 DH7520TW-PB.DSAUNL1_ENG_4634.indd 49 2012-05-10 2:31:27...

  • Page 50: Trademarks And Licenses

    The Bluetooth® word mark and logos are owned by the Bluetooth® SIG, Inc. and any use of such marks by LG Electronics is under license. Other trademarks and trade names are those of their respective owners. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI licensing LLC.
  • Page 51 Play, Pause, Scan, Skip, Stop, Power Off, etc. y Refer to the TV owner’s manual for the details of SIMPLINK function. y LG TV with SIMPLINK function has the logo as shown above. y Use a higher version cable than High Speed HDMI™ Cable.

  • Page 52: Specifications

    522 to 1 620 kHz, 520 to 1 710 kHz or 522 to 1 710 kHz Wireless receiver Power requirements Refer to main label on the wireless receiver Power consumption Refer to main label on the wireless receiver External dimensions (WxHxD) 60 X 220 X 175 mm Net Weight 0.9 kg DH7520TW-PB.DSAUNL1_ENG_4634.indd 52 2012-05-10 2:31:28...
  • Page 53 3 Ω Input Power 200 W Max. Input Power 400 W Net Dimensions (W x H x D) 251 x 336 x 347 mm Net Weight 6.3 kg Design and specifications are subject to change without notice. DH7520TW-PB.DSAUNL1_ENG_4634.indd 53 2012-05-10 2:31:28...
  • Page 54 • DH7520TW-PB.DSAUNL1_ENG_4634.indd 54 2012-05-10 2:31:28...
  • Page 55 DH7520TW-PB.DSAUNL1_ENG_4634.indd 55 2012-05-10 2:31:28...
