Cooper Lighting HALO L1816 Specification Sheet

6 1/2"
2 1/2"
[165mm]
[64mm]
Max. Extension:
9 1/2" [239mm]
8 3/4"
3 5/16"
(222mm)
(84mm)
Max Extension:
12" [302mm]
11 3/4"
(298mm) 5 1/2"
(138mm)
Max. Extension:
15 1/4" [384mm]
5 1/2"
2 1/4"
[140mm]
[57mm]
Max. Extension:
6" [152mm]
Lampholder/Track Compatibility
L1806
Halo Single and 2-Circuit Halo 4-Circuit
L1807
L650, L651, L652, L653 L963 Converter required for
L1808
L641, L642, L643 use with Halo 4-Circuit:
L611, L612, L613 L621, L622, L623
L1631, L1632
L 1 8 0 6 PA R 2 0 S t u d i o C l a s s i c
Finish: Black (MB), Polished Aluminum (PAL)
Lamp: 50W PAR20, 75W PAR16
Accessories: L1978MB Black Barn Door Shutters
L1978PAL Polished Aluminum Barn Door
Shutters
ACCEPTS
HINGED BACK
FOR
BARN DOORS THEATRICAL
RELAMPING
AVAILABLE GELS
L1807 PAR30 Studio Classic
Finish: Black (MB), Polished Aluminum (PAL)
Lamp: 75W PAR30
Notes: Supplied with gel holder
Accessories: L1979MB Black Barn Door Shutters
L1979PAL Polished Aluminum
Barn Door Shutters
HINGED BACK ACCEPTS
FOR BARN DOORS
THEATRICAL
RELAMPING
AVAILABLE
GELS
L1808 PAR38 Studio Classic
Finish: Black (MB), Polished Aluminum (PAL)
Lamp: 250W PAR38
Notes: Supplied with gel holder
Accessories: L1980MB Black Barn Door Shutters
L1980PAL Polished Aluminum Barn
Door Shutters
ACCEPTS
HINGED BACK
FOR
BARN DOORS THEATRICAL
RELAMPING
AVAILABLE
GELS
L 1 8 1 6 L o w Vo l t a g e S t u d i o C l a s s i c
Finish: Black (MB), Polished Aluminum (PAL)
Lamp: 75W 12V MR16
Notes: Supplied with media holder
Accessories: L100 Filters/Lenses
L1984MB Black Barn Door Shutters
L1984PAL Polished Aluminum Barn Door Shutters
L1984P White Barn Door Shutters
12V
INTEGRAL
HINGED BACK
ELECTRONIC FOR BARN DOORS
RELAMPING
AVAILABLE
TRANSFORMER
Halo "LA" Architectural
LA1L Converter required
for use with Halo "LA"
Linear Architectural Track:
LA631, LA632, LA633
50W PAR20
75W PAR16
75W MAX
PAR30
250W MAX
PAR38
75W MAX
ACCEPTS FILTERS
12V MR16
LENSES & LOUVER
Lampholder/Track Compatibility
L1816
Lazer Track
LZR102, LZR104,
LZR106, LZR108
HALO
M B
M B
M B
M B
(Shown with optional accessories)
Halo Single and 2-Circuit Lazer Track
L650, L651, L652, L653 LZR102, LZR104,
L641, L642, L643 LZR106, LZR108
L611, L612, L613
L1631, L1632
COOPER LIGHTING
®
PA L
PA L
PA L
PA L
289
