Cooper Lighting HALO L1525 Specification Sheet

L 1 5 2 5
Finish:
Lamp:
5 3/4"
5 1/4"
(146mm)
m)
Max. Extension:
50W R20
7 1/4"[184mm]
L 1 5 5 0
Finish:
Lamp:
6 15/16"
5 1/8"
(176mm)
(130mm)
Max. Extension:
8 1/2" [216mm]
L 1 5 5 1
Finish:
Lamp:
5 7/16"
3 7/8"
(138mm)
(98mm)
Max. Extension:
7" [178mm]
L 1 5 5 2
Finish:
Lamp:
6 9/16"
5 1/8"
(167mm)
(130mm)
Max. Extension:
9 1/4" [235mm]
Lampholder/Track Compatibility
L1525
Halo Single and 2-Circuit Halo 4-Circuit
L1550
L650, L651, L652, L653 L963 Converter required for
L1551
L641, L642, L643 use with Halo 4-Circuit:
L1552
L611, L612, L613 L621, L622, L623
L1631, L1632
D e c o R o u n d b a c k C y l i n d e r
White (P), Black (MB)
50W R20, 50W PAR20, 75W PAR16
50W PAR20 75W PAR16
R o u n d b a c k C y l i n d e r w i t h V i e n t i S t e m a n d B l a c k B a f f l e
White with Brass Trim (P/B)
75W BR30, 75W R30, 75W PAR30, 100W A19
or 100W BR25 (Halo Z10)
75W BR30
75W R30
BAFFLE
75W PAR30
100W BR25
R o u n d b a c k C y l i n d e r w i t h V i e n t i S t e m a n d B l a c k B a f f l e
White with Brass Trim (P/B)
50W R20, 50W PAR20, 75W A19, 60W PAR16
BAFFLE
60W PAR16 50W R20
R o u n d b a c k C y l i n d e r w i t h Yo k e a n d B l a c k B a f f l e
White with Brass Trim (P/B)
75W BR30, 75W R30, 75W PAR30, 100W A19,
100W BR25 (Halo Z10)
75W BR30
75W R30
BAFFLE
75W PAR30
100W BR25
Halo "LA" Architectural
LA1L Converter required
for use with Halo "LA"
Linear Architectural Track:
LA631, LA632, LA633
100W A19
50 PAR20 75W A19
100W A19
Lazer Track
LZR102, LZR104,
LZR106, LZR108
HALO
M B
COOPER LIGHTING
®
P
P / B
P / B
P
P / B
293
