INSTALLATION AND
OPERATION MANUAL
WHIRLPOOL, AIR BATHS AND SOAKING TUBS
MODEL NUMBERS:
015-0005
015-0015
015-0026
015-0066
015-0076
015-0077
015-0140
015-0141
015-0142R
015-0142L
015-0143
015-0144
015-0145
015-0146
015-0150
015-0156
015-0305
015-0309
015-2500
015-4800
015-5400
THANK YOU...
for selecting an Eljer bathing product. Your new bath is shipped to you after careful inspection. The whirlpool
version is completely assembled with pump and circulatory system piping. All you need to finish the installation
are your selected fittings, electrical connections and support bedding material.
To ensure maximum performance and pleasure from this product, please follow the instructions and cautions.
For questions or service issues, please call Technical Support 1-(800)-442-1902.
Please do not contact or return product to the store.
© Eljer 2015
All product names listed herein are trademarks of Eljer unless otherwise noted.
025-0005
025-0140
025-0141
025-0142R
025-0142L
025-0143
025-0144
025-0145
025-0146
025-0155
025-0159
025-2505
025-4805
025-5405
1
035-0140
035-0141
035-0142R
035-0142L
035-0143
035-0144
035-0145
035-0146
035-0151
035-0158
035-2501
035-5401
045-0140
045-0141
045-0142R
045-0142L
045-0143
045-0145
045-0146
045-0154
045-0157
045-2504
045-4804
045-5404
754764-100 Rev. D
Advertisement
Table of Contents
Related Manuals for American Standard ELJER 015-0005
Summary of Contents for American Standard ELJER 015-0005
-
Page 1: Cover
INSTALLATION AND OPERATION MANUAL WHIRLPOOL, AIR BATHS AND SOAKING TUBS MODEL NUMBERS: 015-0005 025-0005 035-0140 045-0140 015-0015 025-0140 035-0141 045-0141 015-0026 025-0141 035-0142R 045-0142R 015-0066 025-0142R 035-0142L 045-0142L 015-0076 025-0142L 035-0143 045-0143 015-0077 025-0143 035-0144 045-0145 015-0140 025-0144 035-0145 045-0146 015-0141 025-0145 035-0146... -
Page 2: Table Of Contents
TABLE OF CONTENTS: Cover....................Page 1 Table of Contents................Page 2 Safety Instructions Notice..............Page 3 Installation, Framing and Post Installation Clean-Up Instructions...............Page 4 - 5 Typical Flange & Under Deck Mounting Instructions......Page 5 - 6 General Specifications for Whirlpools..........Page 7 - 8 Roughing-in References for All Model Series........Pages 9 - 17 Electrical Installation Instructions.............Page 18 - 19 Whirlpool and Air Massage... -
Page 3: Safety Instructions Notice
Use this unit only for its intended use as described in this manual. Do not use any attachments not recommended by American Standard. The unit must be connected only to a supply circuit that is properly protected by a ground-fault circuit-interrupter (GFCI). -
Page 4: Installation, Framing And Post Installation Clean-Up Instructions
Installation and Framing Instructions Each bath arrives ready for installation, completely equipped with the pump and plumbing necessary for operation. However, a drain/overflow kit is required for each bath and it is not included. The variety of installations for this bath may require framing procedures other than those shown. Locate studs as required. -
Page 5: Typical Flange & Under Deck Mounting Instructions
INSTALLATION AND FRAMING INSTRUCTIONS The variety of installations possible for this whirlpool may require framing procedures other than those shown. Locate studs as needed. Ensure roughing-in dimensions are proper, plumb and square. Provisions must be made in all installations for an access opening for servicing the pump and controls. - Page 6 TYPICAL FLANGE MOUNTING DETAIL SUGGESTED WHIRLPOOL / BATH INSTALLATION METHOD WOOD STUD STUDS WATERPROOF DRYWALL OR CEMENT BOARD TILE ROOFING NAIL SEALANT 1 x 3 (25 x 76mm) WOOD STRINGER FULL LENGTH STEEL STEEL STUD STUDS WASHER WATERPROOF DRYWALL OR CEMENT BOARD TILE SEALANT 4"...
-
Page 7: General Specifications For Whirlpools
SPECIFICATIONS: SIDE VIEW END VIEW DRAIN / OVERFLOW GENERAL SPECIFICATIONS FOR ELJER WHIRLPOOLS AND BATH TUBS Description Dimensions Drain / Height to Cut Out Rough-In Tub Edge to Weight with Product Gallon to L-W-H Overflow Underside Pier Recess Centerline Water / Floor Weight Overflow of Deck: C... - Page 8 SPECIFICATIONS: SIDE VIEW END VIEW DRAIN / OVERFLOW GENERAL SPECIFICATIONS FOR ELJER WHIRLPOOLS AND BATH TUBS Description Dimensions Drain / Height to Cut Out Rough-In Tub Edge to Weight with Product Gallon to L-W-H Overflow Underside Pier Recess Centerline Water / Floor Weight Overflow of Deck: C...
-
Page 9: Roughing-In References For All Model Series
ROUGH-IN REFERENCES CYPRESS MODEL 015-0005 60" (1524mm) 16" (406mm) 40-1/2" (1029mm) 32" 19-1/2" (813mm) (495mm) 9" x 14" (229 x 356mm) FLOOR CUTOUT PROVIDE ACCESS TO PUMP 10-1/4" (260mm) 60" 32" (1524mm) (813mm) 1-1/2" (38mm) 17-1/2" 19" (445mm) (483mm) MADISON MODEL 015-0015 60"... - Page 10 ROUGH-IN REFERENCES CANTERBURY MODEL 015-0026 60" (1524mm) 18" (457mm) 44-1/2" (1130mm) 36" (914mm) 24-1/2" (622mm) 9" x 14" (229 x 356mm) FLOOR CUTOUT PROVIDE ACCESS TO PUMP 8-1/4" (209mm) 60" 36" (1524mm) (914mm) 1-1/2" (38mm) 19-1/2" 17-1/2" (495mm) (444mm) TRIANGLE MODEL 015-0066 35-1/2"...
- Page 11 ROUGH-IN REFERENCES EMBLEM MODEL 015-0076 EMBLEM TOTAL MASSAGE MODEL 015-0077 72" (1829mm) 18" (457mm) 51-1/2" (1308mm) 36" 21-1/2" (914mm) (546mm) 9" x 14" (229 x 356mm) PROVIDE ACCESS FLOOR CUTOUT TO PUMP 10-1/2" (267mm) 72" 36" (1829mm) (914mm) 1-1/2" (38mm) 17-1/2"...
- Page 12 ROUGH-IN REFERENCES CABRILLO MODEL 025-0142R/L 38-1/2" (978mm) 16" (406mm) 19" (483mm) 32" (813mm) 9-1/2" (241mm) 32" 60" (813mm) (1524mm) 20-1/2" (521mm) CASCADA MODEL 025-0005 60" (1524mm) 16" (406mm) 40-1/2" (1029mm) 32" 19-1/2" (813mm) (495mm) 9" x 14" (229 x 356mm) PROVIDE ACCESS FLOOR CUTOUT TO PUMP...
- Page 13 ROUGH-IN REFERENCES LASALLE MODEL 025-0140 38-1/2" (978mm) 16" (406mm) 20" (508mm) 32" (813mm) 9-1/2" (241mm) 32" 60" (813mm) (1524mm) 1-1/2" (38mm) 20" (508mm) LASALLE XL MODEL 025-0141 50-1/2" (1283mm) 18" (406mm) 23" (584mm) 36" (914mm) 9-1/2" (241mm) 36" 72" (914mm) (1829mm) 1-1/2"...
- Page 14 ROUGH-IN REFERENCES MERRICK MODEL 025-0144 7-3/4" 3" (197mm) (76mm) 2-3/4" 44-1/2" (69mm) (1130mm) 21-1/2" 26" 32" (546mm) (659mm) (813mm) 16" 53-3/4" (406mm) (1365mm) 3-1/4" 59-3/4" (83mm) (1518mm) 1-1/2" 32" 59-3/4" (38mm) (813mm) (1518mm) 19-1/4" 17-1/4" (489mm) (438mm) MERRICK XL MODEL 025-0145 8-1/4"...
- Page 15 ROUGH-IN REFERENCES GEMINI MODEL 025-0143 60" 60" (1524mm) (1524mm) 35-1/2" (902mm) 25-7/8" 10-1/2" (657mm) (267mm) 48-1/4" (1226mm) 1-1/2" 3" (38mm) (76mm) C/L OF OVERFLOW 21-1/2" (546mm) 18" 20" (508mm) (457mm) RIDGEFIELD MODEL 025-0146 7-3/8" 4" (187mm) (102mm) 4" (102mm) 42-1/2" (1079mm) 24"...
- Page 16 ROUGH-IN REFERENCES VENICE MODEL 025-2505 21" (533mm) 45" 42" (1143mm) 25-1/2" (1067mm) (648mm) Pump Location 10-3/4" (273mm) 36" = Control Panel (914mm) 1-1/2" 72" 42" (38mm) (1829mm) (1067mm) 21-1/2" 23" (546mm) (584mm) GENESIS MODEL 025-5405 47" (1194mm) 42" 24" (1067mm) (610mm) Pump Location...
- Page 17 ROUGH-IN REFERENCES PATRIOT MODEL 025-0155 / 025-0159 18" (457mm) 42" (1067mm) 18" 36" (457mm) (914mm) PUMP LOCATION C = CONTROL PANEL 60" 36" (1524mm) (914mm) 1" (25mm) 21" (533mm) 18-3/4" 16-1/4" 19-3/4" (476mm) (413mm) (502mm) 1/2" (13mm) CASANOVA MODEL 025-4805 36"...
-
Page 18: Electrical Installation Instructions
ELECTRICAL INSTALLATION INSTRUCTIONS All wiring must be performed by a licensed electrician in accordance with the national electrical code and all other applicable codes. WARNING: When using electrical products, basic precautions should always be observed, including the following: 1. DANGER: RISK OF ELECTRIC SHOCK Connect only to a circuit protected by a ground-fault circuit interrupter. -
Page 19: Whirlpool And Air Massage Combination Models
ELECTRICAL INSTALLATION INSTRUCTIONS (continued) WHIRLPOOL PLUS AIR BATH COMBINATIONS The whirlpool pump and blower should be installed on a 120 vac, 20 amp dedicated circuit. The circuit should be hard-wired from the electrical power supply panel. The circuit must be a three (3) wire circuit from the electrical supply panel. -
Page 20: Operating Instructions
OPERATING INSTRUCTIONS 1. Fill the bath to at least 3 inches above the jets before activating the pump. 2. The pump is activated by an on/off switch. Each depression of the button switches the power either on or off. Do not repeatedly depress the switch in rapid order if you do not see the whirlpool function right away, as it may take a few seconds before you can see it fully operating. -
Page 21: Cleaning And Maintenance
Your Eljer whirlpool is designed to give you many years of pleasure with reasonable care and maintenance. Your new acrylic bathtub is tough, durable and easy to care for. The colors have been formulated to match other Eljer fixtures and enhance your choice of bathroom decorations. The high gloss surface will retain its lasting luster with proper care and maintenance. -
Page 22: Warranty
AS America, Inc. (“American Standard”) warrants to the original consumer purchaser that it will, at its option, repair or replace this tub or any of its parts that are found by American Standard, in its sole judgment, to be defective under normal residential use and maintenance so long as it is owned by the original consumer purchaser.
