Instructions For Use - Original Instructions / Instrucciones de uso / Mode d' emploi
Active Models: 05370A (28 BOOST), 05380A (32 BOOST), 05390A (26 Disc), 05400A (28 Disc), 05410A (34 Disc),
05420A (28 Cyl), 56383304 (28 Disc), 56383986 (26 Disc NYCTA)
Obsolete Models: 05420C(28 Cyl), 56380651(28 BOOST), 56380657(26 Disc), 56380658(28 Disc), 56380659(34 Disc),
05370C(28 BOOST), 05380C(32 BOOST), 05390C(26 Disc), 05400C(28 Disc), 05410C (34 Disc)
This manual is only for machines manufactured after June 2014
U.S. Patent No. 6,105,192; No. 6,760,947; and Patent Pending
Patents Pending
READ THIS BOOK
LEA ESTE MANUAL
LISEZ CE MANUEL
This book has important information for the use and safe operation of this machine. Failure to read this
book prior to operating or attempting any service or maintenance procedure to your Clarke machine
could result in injury to you or to other personnel; damage to the machine or to other property could
occur as well. You must have training in the operation of this machine before using it. If your operator(s)
cannot read this manual, have it explained fully before attempting to operate this machine.
All directions given in this book are as seen from the operator's position at the rear of the machine.
Form No. 56091125
5/2014 revised 9/2017 REV C
AUTOSCRUBBER
Disc 26 / Disc 28 / Disc 34
Cylindrical 28
MID-SIZE
®
/
EN
English (2 - 24)
ES
Español (26 - 48)
FR
Français (50 - 72)
Advertisement
Table of Contents
Related Manuals for Clarke FOCUS II Disc 26
Summary of Contents for Clarke FOCUS II Disc 26
- Page 1 This book has important information for the use and safe operation of this machine. Failure to read this book prior to operating or attempting any service or maintenance procedure to your Clarke machine could result in injury to you or to other personnel; damage to the machine or to other property could occur as well.
-
Page 2: Table Of Contents
Modifi cations and additions to the cleaning machine which affect capacity and safe operation shall not be performed by the customer or user without prior written approval from Nilfi sk-Advance Inc. Unapproved modifi cations will void the machine warranty and make the customer liable for any resulting accidents. Clarke ® -2- FORM NO. 56091125 Operator’s Manual (EN) - FOCUS II MID-SIZE AUTOSCRUBBER... -
Page 3: Operator Safety Instructions
Failure to read the Owner’s Manual prior to operating or attempting any service or maintenance procedure to your Clarke machine could result in injury to you or to other personnel; damage to the machine or to other property could occur as well. You must have training in the operation of this machine before using it. If your operator(s) cannot read English, have this manual explained fully before attempting to operate this machine. -
Page 4: Introduction
The Focus II Disc 34 uses two brushes or pads to scrub a path 34 inches wide. The Focus II Disc 28 uses two brushes or pads to scrub a path 28 inches wide. The Focus II Disc 26 uses two brushes or pads to scrub a path 26 inches wide. The Focus II BOOST 32 uses one pad or brush to scrub a path 32 inches wide. -
Page 5: Machine Specifi Cations
18 months pro-rate on batteries (90 days full unconditional) Vibration @ handle <2.5m/s Sound test @ operator’s ear 71 dBA 63 dBA 63 dBA revised 9/2014 Clarke ® Operator’s Manual (EN) - FOCUS II MID-SIZE AUTOSCRUBBER ® FORM NO. 56091125 - 5 -... -
Page 6: Procedures For Transporting
Replace squeegee assembly and other removed components, after the machine is unloaded and ready to use. revised 9/2014 Clarke ® -6- FORM NO. 56091125 Operator’s Manual (EN) - FOCUS II MID-SIZE AUTOSCRUBBER... -
Page 7: Symbols Used On Focus Ii Midsize
Battery Meter Vacuum On/Off Chemical Mixing Control (Optional) Solution Control On/Off Main Switch Battery Charge (Only on model 56383986) Status LED revised 9/2014 Clarke ® Operator’s Manual (EN) - FOCUS II MID-SIZE AUTOSCRUBBER ® FORM NO. 56091125 - 7 -... -
Page 8: Machine Control Panel
Emergency Stop (Model 56383986 only) (See Figure 1, Item “P”) Press this switch to disconnect power to all machine functions. To reset the Emergency Stop switch, rotate the red knob clockwise. revised 9/2014 Clarke ® -8- FORM NO. 56091125 Operator’s Manual (EN) - FOCUS II MID-SIZE AUTOSCRUBBER... - Page 9 ENGLISH MACHINE CONTROL PANEL DISK & BOOST MODELS MODEL 56383986 only CYLINDRICAL MODELS Figure 1 revised 9/2014 Clarke ® Operator’s Manual (EN) - FOCUS II MID-SIZE AUTOSCRUBBER ® FORM NO. 56091125 - 9 -...
-
Page 10: Machine Controls And Features
Never charge any battery with an unsuitable battery charger. Carefully follow the instruc- tions by the manufacturer of the batteries and battery charger. Figure 5 Clarke ® -10- FORM NO. 56091125 Operator’s Manual (EN) - FOCUS II MID-SIZE AUTOSCRUBBER ®... - Page 11 Locate drain hose behind the transaxle. d. Place hand behind fl ange and open valve. e. When empty, close valve. f. Neutralize any acid spills with ammonia or bicarbonate of soda. Clarke ® Operator’s Manual (EN) - FOCUS II MID-SIZE AUTOSCRUBBER ®...
- Page 12 NOTE: To prevent permanent damage to the batteries, avoid their complete discharge. Never leave the batteries completely dis- charged, even if the machine is not being used. When recharging the batteries, keep the recovery tank open. Check the level of the electrolyte and if necessary top off with distilled water. Clarke ® -12- FORM NO. 56091125 Operator’s Manual (EN) - FOCUS II MID-SIZE AUTOSCRUBBER...
- Page 13 4. Go to the front of the machine and pull downward on the brush or pad until it releases from the fl ex plates. See fi gure 11. Figure 11 Clarke ® Operator’s Manual (EN) - FOCUS II MID-SIZE AUTOSCRUBBER ®...
- Page 14 4. Unlatch right and left brush housings and remove them. See fi gure 12. 5. Push down on two sides of the brush or pad driver until the gim- bals release. Clarke ® -14- FORM NO. 56091125 Operator’s Manual (EN) - FOCUS II MID-SIZE AUTOSCRUBBER...
- Page 15 Do not oper- ate this machine unless it is completely assembled. Inspect the machine care- fully before operation. Clarke ® Operator’s Manual (EN) - FOCUS II MID-SIZE AUTOSCRUBBER ® FORM NO. 56091125 - 15 -...
-
Page 16: How To Operate The Machine
Do not use with or near fl ammables such as gasoline, grain dust, solvents, and thinners. Only use a cleaning concentration recommended by the chemi- cal manufacturer. WARNING: Clarke recommends a maximum water Figure 17 temperature of 120°F(49°C) Clarke ® -16- FORM NO. 56091125 Operator’s Manual (EN) - FOCUS II MID-SIZE AUTOSCRUBBER... - Page 17 6. Slowly close the recovery tank. NOTE: With the knob turned fully counterclockwise, only water will be delivered to the fl oor. GREEN BLUE YELLOW Figure 19 Clarke ® Operator’s Manual (EN) - FOCUS II MID-SIZE AUTOSCRUBBER ® FORM NO. 56091125 - 17 -...
- Page 18 Do not use with or near fl ammables such as gasoline, grain dust, solvents and thinners. Only use a cleaning concentration recommended by the chemical manufacturer. WARNING: Clarke recommends a maximum water tem- perature of 120 F (49 Figure 20 Operating The Machine NOTE: Put the machine in the lowest traverse speed setting.
- Page 19 Lower the brush or pad and scrub the fl oor. Scrub the fl oor again with additional solution and lower the squeegee and turn vacuum motor “ON”. Pick up all the solution with the squeegee. Clarke ® Operator’s Manual (EN) - FOCUS II MID-SIZE AUTOSCRUBBER ®...
-
Page 20: Maintenance
6. Check the installation of the squeegee and squeegee hose. 7. Make sure the solution drain/level indicator hose is secure on upper fi tting. Clarke ® -20- FORM NO. 56091125 Operator’s Manual (EN) - FOCUS II MID-SIZE AUTOSCRUBBER ®...
