Summary of Contents for Pico Macom VSM-3/4S
- Page 1 VSM-3/4S Audio-Video with Super Video RF Modulator Installation and Operation Manual Operation Ph:800-421-6511 www.picomacom.com Manual Rev. 05/03...
-
Page 2: Product Inspection
To insure proper installation and operation, take a moment to read this guide before proceeding with the installation. If you have any questions or comments about the VSM-3/4S RF Modulator, please contact your dealer or have him contact the PICO MACOM Service Center at these phone numbers: 800-421-6511, 818-493-4300. - Page 3 21. Outdoor Antenna Grounding: Before attempting to install this product, be sure the antenna or cable system is grounded so as to VSM-3/4S provide some protection against voltage surges and built-up static charges.
- Page 4 VSM-3/4S Audio-Video with Super Video RF Modulator The VSM-3/4S VIDEO RF MODULATOR WITH S-VHS INPUT is a single channel audio/video signal modulator that is designed to convert the separate audio and video signals from various video components such as video cameras, VCRs, DVD Players, or game consoles into a single VHF signal appropriate for viewing on most television sets.
-
Page 5: Specifications
Output Channels: 3 or 4 Output Impedance: 75 Ohms Audio Audio Input Impedance: 13±3k Ohms Ordering Information VSM-3/4S Audio-Video with Super Video RF Modulator Specifications VSM-3/4S Audio-Video with Super Video RF Modulator Video Input Impedance: TV to ANT Insertion Loss:... -
Page 6: Operation And Controls
Operation and Controls VSM-3/4S Operation Turn the power on to both your television and your video component. Turn both your TV and the RF Modulator to the same channel (3 or 4, whichever gives you the clearest pic- ture) using the switch in the back of the modulator. -
Page 7: Installation Procedure
*Transformer RF Modulator Coaxial Cable Coaxial Cable *Transformer *Not Included Note: Accessories nec- Installation Procedure VSM-3/4S RF Modulator Video Patch Cord essary for proper Your Video Component installation may be obtained from your retailer. Ph:800-421-6511 RF Modulator... -
Page 8: Warranty
We will issue an invoice for the List Price of the loaner unit plus shipping costs. When you receive the loaner unit, pack the failed unit in the loaner unit’s box and ship it freight prepaid to Pico Macom for repair. When you receive the repaired unit, a new RMA number will be provided in the box. Carefully pack the loaner unit and affix the new RMA number on the box and ship it back to us for full credit excluding shipping costs.
