- Page 1 A860 Manual.qxd 11/21/05 10:34 AM Page 1 A860 Agile Modulator Installation and Operation Manual Operation www.picomacom.com Ph: 800-421-6511 Manual Rev. 11/05...
- Page 2 The simple push button tuning interface allows the A860 to be con- figured for CATV standard, HRC, and IRC or North American broadcast channels with an RF output of 60 dBmV.
-
Page 3: Specifications
A860 Manual.qxd 11/21/05 10:34 AM Specifications RF OUTPUT Frequency Range: 54-860 MHz Level: 60 dBmV min Level Adjustment: 20 dB Impedance: 75 ohms Frequency Stability: ±3 kHz Audio/Video Ratio: -10 to -20 dB Adjustable Output Return Loss: -18 dB In Band Spurious:... -
Page 4: Product Inspection
To ensure proper installation and operation, take a moment to read this guide before proceeding with the installation. If you have any questions or comments about the A860 Agile Modulator, please contact your dealer or have him contact the PICO MACOM Service Center at the phone number on the bottom of the page. -
Page 5: Connections And Controls
I.F. input. 21. 4.5 MHz Input: Input for BTSC stereo encoder operation. 22. MPX Out: Used to provide MPX output to additional modulators when internal stereo encoder is present, thus eliminating need for additional encoders. -
Page 6: Installation
The Federal Communications Commission requires that cable system modulators, which operate in the aircraft communications and navigation bands, are offset in frequency by 12.5 kHz. The A860 PLL oscillator is factory set to comply with FCC requirements for frequency accuracy (±5 kHz) in the aeronautical communication and navigation bands. - Page 7 Signal Combining Methods The output levels of the modulator should be the same as the output of the off-air strip amplifiers. The A860 modulators are usually combined with either the DSP806 channel processors, or XBS series strip amplifiers. Three methods are suggested to combine strip amplifier, modulator and processor outputs.
-
Page 8: Five-Year Limited Warranty
2. The date of purchase 3. A specific identification of the problem Deliver the products to Pico Macom, Inc. or ship the products in the original packing material to the address below. Include satisfactory evidence of the date of purchase.
