Page 10: For Your Information
Also, remodeling like this will have an effect on advanced safety equipment such as Toyota Safety Sense and there is a danger that it will not work prop- erly or the danger that it may work in situations where it should not be work-...
Page 11 SRS airbag system ● Seat belt pretensioner system Be sure to check with your Toyota dealer for precautionary measures or spe- cial instructions regarding installation of an RF-transmitter system. Further information regarding frequency bands, power levels, antenna posi- tions and installation provisions for the installation of RF-transmitters, is avail- able on request at your Toyota dealer.
Page 12 Usage of data collected through Toyota Connected Services If your Toyota has Toyota Connected Services and if you have subscribed to those services, please refer to the Toyota Connected Services usage contract...
Page 13 EDR. ● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehi- cle) is obtained •...
Page 14 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
Page 16: Reading This Manual
Reading this manual WARNING: Explains something that, if not obeyed, could cause death or serious injury to people. NOTICE: Explains something that, if not obeyed, could cause damage to or a malfunction in the vehicle or its equipment. 1 2 3 Indicates operating or working procedures.
Page 17: How To Search
How to search ■ Searching by name • Alphabetical index ..P. 500 ■ Searching installation position • Pictorial index....P. 16 ■ Searching by symptom or sound • What to do if... (Troubleshooting) ..P. 496 ■ Searching by title •...
Page 18: Pictorial Index
Pictorial index Pictorial index ■ Exterior Doors ......... . . P. 142 Locking/unlocking .
Page 19 Pictorial index Windshield wipers ....... . . P. 233 Precautions for winter season ......P. 338 Precautions for car wash (vehicles with rain-sensing windshield wipers) .
Page 20 Pictorial index ■ Instrument panel Power switch ........P. 203 Starting the hybrid system/changing the modes .
Page 21 Pictorial index Turn signal lever ........P. 218 Headlight switch .
Page 22 Pictorial index ■ Switches Fuel filler door opener switch ..... . . P. 242 Trunk opener switch ....... P. 149 1, 2 Camera switch VSC OFF switch.
Page 23 Pictorial index Meter control switches ......P. 96, 108 Paddle shift switches ......P. 212 Vehicle-to-vehicle distance switch .
Page 24 Pictorial index Seat ventilator switches ......P. 349 Seat heater switches ......P. 349 Parking brake.
Page 25 Pictorial index ■ Interior SRS airbags ........P. 35 Floor mats .
Page 26 Pictorial index Interior lights/personal lights ..... . P. 351 Panoramic moon roof switches ....P. 180 “SOS”...
Page 27 Seat belts......30 SRS airbags......35 Exhaust gas precautions ..45 1-2. Child safety Riding with children....46 Child restraint systems ..47 1-3. Emergency assistance Toyota Connected Services......66 1-4. Hybrid system Hybrid system features ..71 Hybrid system precautions ......75 1-5. Theft deterrent system Immobilizer system ....81...
Page 28: 1-1. For Safe Use
1-1. For safe use Before driving Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eyelets. Turn the upper knob of each retaining hook (clip) to secure the floor mats in place.
Page 29 When installing the driver’s floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. ●...
Page 30: For Safe Driving
1-1. For safe use For safe driving For safe driving, adjust the seat and mirror to an appropriate position before driving. Correct driving posture Adjust angle seatback so that you are sitting straight up and so that you do not have to lean forward to steer.
Page 31 1-1. For safe use Adjusting the mirrors Make sure that you can see backward clearly by adjusting the inside and outside rear view mirrors properly. (P. 171, 173) WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ●...
Page 32: Seat Belts
1-1. For safe use Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
Page 33 1-1. For safe use Adjusting the seat belt shoulder anchor height (front seats) Push the seat belt shoulder Release button anchor down while pressing the release button. Push the seat belt shoulder anchor up. Move the height adjuster up and down as needed until you hear a click.
Page 34 ■ Seat belt regulations If seat belt regulations exist in the country where you reside, please contact your Toyota dealer for seat belt replacement or installation. ■ Rear seat belt guide Use the seat belt after passing it through the guide if the seat belt comes free from the guide.
Page 35 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
Page 36 ● Ensure that the belt and plate are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
Page 37: Srs Airbags
1-1. For safe use SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. ◆...
Page 38 1-1. For safe use SRS airbag system components Front impact sensors Front passenger airbag Driver’s knee airbag Side impact sensors (rear) Seat belt pretensioners and Side impact sensors (front) force limiters SRS warning light Airbag sensor assembly Driver airbag Side impact sensors (front Front side airbags doors) Curtain shield airbags...
Page 39 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are...
Page 40 1-1. For safe use WARNING ■ SRS airbag precautions ● Do not sit on the edge of the seat or lean against the dashboard. ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger.
Page 41 Wash off any residue as soon as possible to prevent skin irritation. ● If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer.
Page 42 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 43 The interior lights will turn on automatically. (P. 353) ● The emergency flashers will turn on automatically. (P. 424) Vehicles with Toyota Connected Services: If any of the following situations occur, the system is designed to send an emergency call to the Toyota Con- nected Services control center, notifying them of the vehicle’s location (with-...
Page 44 1-1. For safe use ■ SRS airbag deployment conditions (SRS side and curtain shield airbags) ● The SRS side and curtain shield airbags will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to the impact force produced by an approximately 1500 kg [3300 lb.] vehicle colliding with the vehicle cabin from a direction perpendicular to the vehicle orientation at an approximate speed of 20 - 30 km/h [12 - 18 mph]).
Page 45 1-1. For safe use ■ Types of collisions that may not deploy the SRS airbags (SRS side and curtain shield airbags) The SRS side and curtain shield airbags may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.
Page 46 1-1. For safe use ■ When to contact your Toyota dealer In the following cases, the vehicle will require inspection and/or repair. Con- tact your Toyota dealer as soon as possible. ● Any of the SRS airbags have been inflated. ●...
Page 47: Exhaust Gas Precautions
Keep the trunk lid closed. ● If you smell exhaust gases in the vehicle even when the trunk lid is closed, open the windows and have the vehicle inspected at your Toyota dealer as soon as possible. ■ When parking ●...
Page 48: 1-2. Child Safety
1-2. Child safety Riding with children Observe the following precautions when children are in the vehi- cle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt. ● It is recommended that children sit in the rear seats to avoid acci- dental contact with the shift lever, wiper switch etc.
Page 49: Child Restraint Systems
1-2. Child safety Child restraint systems Before installing a child restraint system in the vehicle, there are precautions that need to be observed, different types of child restraint systems, as well as installation methods, etc., written in this manual. Use a child restraint system when riding with a small child that can- not properly use a seat belt.
Page 50 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the weight and size of the child, installed on the rear seat. Accord- ing to accident statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 51: When Using A Child Restraint System
1-2. Child safety When using a child restraint system ■ When installing a child restraint system to a front passenger seat For the safety of a child, install a child restraint system to a rear seat. When installing a child restraint system to a front passenger seat is unavoidable, adjust the seat as follows and install the child restraint system.
Page 52 1-2. Child safety WARNING ■ When using a child restraint system Observe the following precautions. Failure to do so may result in death or serious injury. ● Extreme Hazard! Do not use a rearward facing child restraint on a seat protected by an airbag in front of it! This is because the force of the rapid inflation of the front passenger airbag can cause...
Page 53 1-2. Child safety WARNING ■ When using a child restraint system ● Do not allow the child to lean his/her head or any part of his/her body against the door or the area of the seat, front or rear pillars, or roof side rails from which the SRS side airbags or SRS curtain shield airbags deploy even if the child is seated in the child restraint system.
Page 54: Child Restraint System Compatibility For Each Seating Position
1-2. Child safety Child restraint system compatibility for each seating position ■ Child restraint system compatibility for each seating position Compatibility of each seating position with child restraint systems (P. 54) displays the type of child restraint systems that can be used and possible seating positions for installation using symbols.
Page 55 1-2. Child safety : UN(ECE) R44 and UN(ECE) R129 are U.N. regulations for child restraint systems. : The child restraint systems mentioned in the table may not be avail- able outside of the EU area. : The displayed mark may differ depending on the product. Checking the category of the child restraint system.
Page 56 1-2. Child safety ■ Compatibility of each seating position with child restraint sys- tems 1, 2, 3 Suitable for “universal” category child restraint system fixed with the seat belt. Suitable for i-Size and ISOFIX child restraint system. Includes a top tether anchorage point. Never use a rear-facing child restraint system on the front passenger seat.
Page 57 1-2. Child safety : Move the front seat fully rearward. If the passenger seat height can be adjusted, move it to the upper most position. : Adjust the seatback angle to the most upright position. When installing a forward-facing child seat, if there is a gap between the child seat and the seatback, adjust the seatback angle...
Page 58 1-2. Child safety ■ Detail information for child restraint systems installation Seating position Seat position number Seating position suitable Forward for universal belted facing (Yes/No) only i-Size seating position (Yes/No) Seating position suitable for lateral fixture (L1/L2/No) Suitable rearward facing R2X,R2, R2X,R2, fixture (R1/R2X/R2/R3/No)
Page 59 1-2. Child safety Fixture Description Full-height, forward-facing child restraint systems Reduced-height forward-facing child restraint systems Reduced-height forward-facing child restraint systems Full-size, rearward-facing child restraint systems Reduced-size, rearward-facing child restraint systems Reduced-size, rearward-facing child restraint systems Rearward-facing infant seat Left lateral-facing (carrycot) infant seat Right lateral-facing (carrycot) infant seat Junior seat Junior seat...
Page 60 1-2. Child safety When securing some types of child restraint systems in rear seat, it may not be possible to properly use the seat belts in positions next to the child restraint without interfering with it or affecting seat belt effectiveness.
Page 61: Child Restraint System Installation Method
1-2. Child safety Child restraint system installation method Confirm with the operation manual enclosed with the child restraint system about the installation of the child restraint system. Installation method Page Seat belt attachment P. 60 ISOFIX rigid anchor P. 62 attachment Child restraint anchor P.
Page 62: Fixed With A Seat Belt
1-2. Child safety Child restraint system fixed with a seat belt ■ Installing child restraint system using a seat belt Install the child restraint system in accordance to the operation manual enclosed with the child restraint system. If the child restraint system on hand is not within the “universal” cat- egory (or the necessary information is not in the table), refer to the “Vehicle List”...
Page 63 You may need a locking clip to install the child restraint system. Follow the instructions provided by the manufacturer of the system. If your child restraint system does not provide a locking clip, you can purchase the following item from your Toyota dealer: Locking clip for child restraint system (Part No. 73119-22010) WARNING ■...
Page 64: Fixed With An Isofix Rigid Anchor
1-2. Child safety Child restraint system fixed with an ISOFIX rigid anchor ■ ISOFIX rigid anchors (ISOFIX child restraint system) Lower anchors are provided for the rear outboard seats. (Marks displaying the location of the anchors are attached to the seats.) ■...
Page 65 1-2. Child safety Check the positions of the exclusive fixing bars, and install the child restraint sys- tem to the seat. The bars are installed behind the covers. After installing the child restraint system, rock it back and forth to ensure that it is installed securely.
Page 66: Using A Child Restraint Anchor Fitting
1-2. Child safety Using a child restraint anchor fitting ■ Child restraint anchor fittings Anchor fittings are provided for each rear seat. Use anchor fittings when fixing the strap. Anchor fittings Upper anchorage strap ■ Fixing the strap to the child restraint anchor fitting Install the child restraint system in accordance to the operation manual enclosed with the child restraint system.
Page 67 1-2. Child safety WARNING ■ When installing a child restraint system Observe the following precautions. Failure to do so may result in death or serious injury. ● Firmly attach the upper anchorage strap and make sure that the belt is not twisted.
Page 68: 1-3. Emergency Assistance
1-3. Emergency assistance 1, 2 Toyota Connected Services Toyota Connected Services are telematics services that use Global Positioning System (GPS) data and embedded cellular technology to enable the following emergency calls to be made: ACN (Automatic Collision Notification) and SOS Emergency Call (Manual emergency service notification) (by pressing the “SOS”...
Page 69 1-3. Emergency assistance Toyota Connected Services ■ ACN (Automatic Collision Notification) If any airbag deploys, the system is designed to automatically call the Emergency Call Centre. The Call Centre Agent will determine your vehicle’s location, the time of the incident and the vehicle VIN, and attempt to speak with the vehicle occupants to assess the situation.
Page 70 Contact your Toyota dealer. Enabled Toyota vehicles collect and transmit vehicle data to provide connected services. SOS and Automatic Collision Notification may be disabled if green LED under SOS button is not illuminated. For more info including re-activation, visit https://www.toyota.com.au/privacy...
Page 71 1-3. Emergency assistance WARNING ■ When the ACN/SOS may not be made ● It may not be possible to make ACN/SOS in any of the following situations. In such cases, report to emergency services provider (000 system etc.) by other means such as nearby public phones. •...
Page 72 ● Using the system while there is smoke or an unusual smell may cause a fire. Stop using the system immediately and consult your Toyota dealer. NOTICE ■...
Page 73: Hybrid System
1-4. Hybrid system Hybrid system features Your vehicle is a hybrid vehicle. It has characteristics different from conventional vehicles. Be sure you are closely familiar with the characteristics of your vehicle, and operate it with care. The hybrid system combines the use of a gasoline engine and an electric motor (traction motor) according to driving condi- tions, improving fuel efficiency and reducing exhaust emis- sions.
Page 74 1-4. Hybrid system ◆ When stopped/during start off The gasoline engine stops when the vehicle is stopped. During start off, the electric motor (traction motor) drives the vehicle. At slow speeds or when traveling down a gentle slope, the engine is stopped and the electric motor (traction motor) is used.
Page 75 30 minutes or 16 km (10 miles). If the hybrid battery (traction battery) becomes fully discharged and you are unable to start the hybrid system, contact your Toyota dealer. ■ Charging the 12-volt battery...
Page 76 Vibration may be felt when the gasoline engine starts or stops. ● Cooling fan sounds may be heard from the air intake vent. (P. 76) ■ Maintenance, repair, recycling, and disposal Contact your Toyota dealer regarding maintenance, repair, recycling and dis- posal. Do not dispose of the vehicle yourself.
Page 77: Hybrid System Precautions
1-4. Hybrid system Hybrid system precautions Take care when handling the hybrid system, as it is a high volt- age system (about 650 V at maximum) as well as contains parts that become extremely hot when the hybrid system is operating. Obey the warning labels attached to the vehicle.
Page 78 If the emergency shut off system activates, your vehicle will not restart. To restart the hybrid system, contact your Toyota dealer. Hybrid warning message A message is automatically displayed when a malfunction occurs in the hybrid system or an improper operation is attempted.
Page 79 If a warning light comes on, a warning message is displayed, or the 12- volt battery is disconnected The hybrid system may not start. In this case, try to start the system again. If the “READY” indicator does not come on, contact your Toyota dealer. ■ Running out of fuel...
Page 80 1-4. Hybrid system WARNING ■ High voltage precautions This vehicle has high voltage DC and AC systems as well as a 12-volt sys- tem. DC and AC high voltage is very dangerous and can cause severe burns and electric shock that may result in death or serious injury. ●...
Page 81 1-4. Hybrid system WARNING ■ Road accident cautions Observe the following precautions to reduce the risk of death or serious injury: ● Pull your vehicle off the road, apply the parking brake, shift the shift lever to P, and turn the hybrid system off. ●...
Page 82 Toyota dealer or a qualified service shop. If the hybrid battery is not dis- posed of properly, it may cause electric shock that can result in death or serious injury.
Page 83: Theft Deterrent System
1-5. Theft deterrent system Immobilizer system The vehicle’s keys have built-in transponder chips that prevent the hybrid system from starting if a key has not been previously registered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehi- cle.
Page 84: Alarm
1-5. Theft deterrent system Alarm The alarm The alarm uses light and sound to give an alert when an intrusion is detected. The alarm is triggered in the following situations when the alarm is set: ● A locked door is unlocked or opened in any way other than using the entry function, wireless remote control or mechanical key.
Page 85 1-5. Theft deterrent system ■ System maintenance The vehicle has a maintenance-free type alarm system. ■ Items to check before locking the vehicle To prevent unexpected triggering of the alarm and vehicle theft, make sure of the following: ● Nobody is in the vehicle. ●...
Page 86 1-5. Theft deterrent system ■ Alarm-operated door lock In the following cases, depending on the situation, the door may automatically lock to prevent improper entry into the vehicle: ● When a person remaining in the vehicle unlocks the door and the alarm is activated.
Page 87: Instrument Cluster
Instrument cluster Instrument cluster Warning lights and indicators ......86 Gauges and meters .....91 Multi-information display (4.2-inch display) ....95 Multi-information display (7-inch display) ....106 Head-up display....126 Energy monitor/ consumption screen ..132...
Page 88: Instrument Cluster Warning Lights And Indicators
2. Instrument cluster Warning lights and indicators The warning lights and indicators on the instrument cluster, cen- ter panel and outside rear view mirrors inform the driver of the status of the vehicle’s various systems. For the purpose of explanation, the following illustrations dis- play all warning lights and indicators illuminated.
Page 89 Warning lights inform the driver of malfunctions in any of the vehicle’s systems. (Lane Tracing Brake system warning Assist) indicator light (P. 434) (P. 436) (Yellow) (Red) Toyota parking assist- Brake system warning sensor indicator light (P. 434) (P. 436) (if equipped) (Yellow) Malfunction indicator RCD OFF indicator lamp (P.
Page 90 There may be a malfunction in a system if a light does not come on, or turn off. Have the vehicle inspected by your Toyota dealer. : This light illuminates on the multi-information display with a message.
Page 91 EV indicator (P. 73) mirror indicators (P. 308) (if equipped) Security indicator EV drive mode indicator (P. 81, 82) (P. 209) Toyota parking assist- Low outside tempera- sensor indicator ture indicator (P. 91) (P. 315) (if equipped) RCD OFF indicator (P.
Page 92 Have the vehicle inspected by your Toyota dealer immediately if this occurs.
Page 93: Gauges And Meters
2. Instrument cluster Gauges and meters 4.2-inch display  7-inch display ...
Page 94 2. Instrument cluster Hybrid System Indicator Displays hybrid system output or regeneration level (P. 93) Shift position (P. 212) Outside temperature Displays the outside temperature within the range of -40°C (-40°F) to 50°C (122°F). Low outside temperature indicator comes on when the ambient temperature is 3°C (37°F) or lower.
Page 95 2. Instrument cluster ■ The meters and display illuminate when The power switch is in ON mode. ■ Brightness of the meters (day mode and night mode) ● The brightness of the meters is changed between day mode and night mode.
Page 96 ● When “” or “E” is displayed, the system may be malfunctioning. Take your vehicle to your Toyota dealer. ■ Fuel gauge and driving range display The fuel gauge and driving range display are linked. If the fuel gauge and...
Page 97: Multi-Information Display (4.2-Inch Display)
2. Instrument cluster Multi-information display (4.2-inch display) Summary of functions The multi-information display presents the driver with a variety of driv- ing-related data, such as the current outside temperature. The multi- information display can also be used to change the display settings and other settings.
Page 98 2. Instrument cluster “ODO/TRIP” switch (P. 96) Meter control switches (P. 96) Using the multi-information display ◆ Using the content display area The content display area is operated using the meter control switches. Scroll screens , change the displayed content and move the cursor Press: Enter/Set...
Page 99 2. Instrument cluster Menu icons Select a menu icon to display its content. Drive information (P. 98) Select to display various drive data. Audio system-linked display Select to enable selection of an audio source or track on the meter using the meter control switches. Driving assist system information Select to display the operational status of the following systems: •...
Page 100 2. Instrument cluster Drive information ( ■ Trip (after start) Average fuel economy Displays the average fuel con- sumption since hybrid system start. Average vehicle speed Displays the average vehicle speed since hybrid system start. Elapsed time Displays the time elapsed since hybrid system start.
Page 101 2. Instrument cluster ■ Tank (after refuel) 1, 2 Driving range Displays the driving range with remaining fuel. 1, 3 Average fuel economy Displays the average fuel con- sumption since the vehicle was refueled. : When only a small amount of fuel is added to the tank, the display may not be updated.
Page 102 2. Instrument cluster Settings display ( ◆ Changing settings Use the meter control switches on the steering wheel to change settings. Press to select Operate the switches to select a desired item. Change the setting by referring to the message displayed on the screen.
Page 103 2. Instrument cluster ■ PCS (Pre-Collision System) (P. 250) The following pre-collision system settings can be changed: Item Settings Details Select to enable/disable the pre- collision system. Early Select to change the warning Warning sensitivity Middle timing. Late ■ DRCC (Dynamic radar cruise control) (P. 284) Item Settings Details...
Page 104 2. Instrument cluster Item Settings Details 5km/h(3mph) Select a speed threshold over which the excess speed notifica- Excess speed noti- 3km/h(2mph) tion will start to operate when a fication level speed limit sign is displayed on the multi-information display. 1km/h(1mph) ■...
Page 105 2. Instrument cluster Odometer/trip meter ■ Odometer Displays the total distance the vehicle has been driven. ■ Trip meter A/trip meter B Displays the distance the vehicle has been driven since the meter was last reset. Trip meters A and B can be used to record and dis- play different distances independently.
Page 106 2. Instrument cluster ■ Suggestion to close the power windows (linked to vehicle speed) If the vehicle is driven at high speeds for a certain amount of time with a power window open, a suggestion message will be displayed asking if you wish to close the power windows. To close all of the power windows, select “Yes”.
Page 107 2. Instrument cluster WARNING ■ Caution for use while driving ● When operating the multi-information display while driving, pay extra attention to the safety of the area around the vehicle. ● Do not look continuously at the multi-information display while driving as you may fail to see pedestrians, objects on the road, etc.
Page 108: Multi-Information Display (7-Inch Display)
2. Instrument cluster Multi-information display (7-inch display) Summary of functions The multi-information display presents the driver with a variety of driv- ing-related data, such as the current outside temperature. The multi- information display can also be used to change the display settings and other settings.
Page 109 2. Instrument cluster Content display area A variety of information can be displayed by selecting a menu icon. Addi- tionally, warning or suggestion/advice pop-up displays will be displayed in some situations. • Menu icon content (P. 109) • Suggestion function (P. 123) •...
Page 110 2. Instrument cluster Using the multi-information display ◆ Using the content display area The content display area is operated using the meter control switches. Scroll screens , change the displayed content and move the cursor Press: Enter/Set Press and hold: Reset/Dis- play the next screen Return previous...
Page 111 Display the following information: • Energy monitor (P. 132) Enable/Disable the following systems: • Parking assist (Toyota parking assist-sensor) (P. 315) • BSM (Blind Spot Monitor) function (P. 308) • RCTA (Rear Cross Traffic Alert) function (P. 323) This function can also be enabled/disabled on Settings display (P.
Page 112 2. Instrument cluster Eco-friendly driving information ( ■ Fuel consumption Current fuel consumption Displays the instantaneous cur- rent fuel consumption. Average fuel economy (after start) Displays the average fuel con- sumption since hybrid system start. Driving range 2, 3 Displays the driving range with remaining fuel. Gadget The following items can be displayed by changing the settings for gad- get content and fuel economy type on...
Page 113 2. Instrument cluster Average fuel economy Displayed item (listed below) can be changed on the fuel economy type screen of . (P. 115) ● Total (after reset) 1, 5 Displays the average fuel consumption since the display was reset. ● Tank (after refuel) Displays the average fuel consumption since the vehicle was 1, 2 refueled.
Page 114 2. Instrument cluster ■ Eco guide The Eco guide displays a guide for eco-friendly acceleration and scores which represent an evaluation of how the vehicle has been driven ecologically in different states. ECO Accelerator Guidance Eco score ● ECO Accelerator Guidance Eco area Indicates that the vehicle is being driven in an Eco-friendly...
Page 115 2. Instrument cluster ● Eco score The following 3 Eco driving methods are evaluated in 5 levels: Smooth start-off acceleration, driving without sudden acceleration, and smooth stopping. When the vehicle is stopped, an Eco score out of 100 points will be displayed. Eco start status Eco cruise status Eco stop status...
Page 116 2. Instrument cluster ■ Speedometer display/Driving range Speedometer display Displays the vehicle speed. Driving range Displays the driving range with remaining fuel. When only a small amount of fuel is added to the tank, the dis- play may not be updated. When refueling, turn the power switch off.
Page 117 2. Instrument cluster Settings display ( ◆ Changing settings Use the meter control switches on the steering wheel to change settings. Press to select Operate the switches to select a desired item. Press or press and hold The available settings will differ depending on if is pressed or pressed and held.
Page 118 2. Instrument cluster ■ PCS (Pre-Collision System) (P. 250) Press and hold to change the settings of the following items: Item Settings Details Select to enable/disable the pre- collision system. Early Select to change the warning Warning sensitivity Middle timing. Late ■...
Page 119 2. Instrument cluster ■ BSM (Blind Spot Monitor) (P. 308) Press to enable/disable the Blind Spot Monitor function. Item Settings Details Select enable/disable Blind Spot Monitor function. Press and hold to change the settings of the following item: Item Settings Details Outside rear view Select to change the brightness...
Page 120 Details 1 (Low) RCTA buzzer vol- Select to change the volume of 2 (Medium) the RCTA buzzer. 3 (Loud) ■ Parking assist (Toyota parking assist-sensor) (P. 315) Press to enable/disable the Toyota parking assist-sensor. Item Settings Details Toyota parking Select...
Page 121 2. Instrument cluster ■ HUD (Head-up display) (if equipped) (P. 126) Press to enable/disable the head-up display. Item Settings Details Select enable/disable head-up display. Press and hold to change the settings of the following items: Item Settings Details Select to adjust the brightness/ position of the head-up display.
Page 122 2. Instrument cluster ■ RSA (Road Sign Assist) (P. 280) Press and hold to change the settings of the following items: Item Settings Details Select enable/disable RSA. Select a notification method used to warn the driver if the vehicle speed exceeds the speed dis- played on the speed limit sign on Excess speed...
Page 123 2. Instrument cluster ■ Meter settings Press and hold to change the settings of the following items: Item Settings Details Select to change the language Language displayed. Select to change the units of Units measure displayed. Select to enable/disable the EV (EV indicator) indicator.
Page 124 2. Instrument cluster Item Settings Details Trip (after start) Select to change the average Total (after reset) Fuel economy type fuel consumption display and an item to be displayed as gadget. Tank (after refuel) Select to turn the multi-informa- tion display off. To turn the multi-information dis- Multi-information display off play on again, press any direc-...
Page 125 2. Instrument cluster Suggestion function Displays suggestions to the driver in the following situations. To select a response to a displayed suggestion, use the meter control switches. The suggestion function can be turned on/off. (Customizable features:P. 487) ■ Suggestion to turn off the headlights If the headlights are left on for a certain amount of time after the power switch has been turned off, if the headlight switch is in the “AUTO”...
Page 126 2. Instrument cluster ■ The Eco guide will not operate when The Eco guide will not operate in the following situations: ● The Hybrid System Indicator is not operating. ● The vehicle is being driven using the dynamic radar cruise control with full- speed range.
Page 127 2. Instrument cluster WARNING ■ Caution for use while driving ● When operating the multi-information display while driving, pay extra attention to the safety of the area around the vehicle. ● Do not look continuously at the multi-information display while driving as you may fail to see pedestrians, objects on the road, etc.
Page 128: Head-Up Display
2. Instrument cluster  Head-up display Summary of functions The head-up display is linked to the meters and navigation system and projects a variety of information in front of the driver, such as the current vehicle speed. Driving assist system status/navigation system-linked display area (P.
Page 129 2. Instrument cluster Using the head-up display Select on the multi-information display (P. 115) and then ◆ Enabling/disabling the head-up display Press to enable/disable the head-up display. ◆ Changing the head-up display settings Press and hold to change the following settings: ■...
Page 130 Displays the operational status of the following systems: • Dynamic radar cruise control with full-speed range (P. 284) • LTA (Lane Tracing Assist) (P. 266) • Toyota parking assist-sensor (P. 315) ◆ Navigation system-linked display area Displays the following items, which are linked to the navigation sys- tem: ■...
Page 131 2. Instrument cluster Information display area Displays the following items in the appropriate situation: ■ Warning/Message ● Alert from the LTA (Lane Tracing Assist) ● Dynamic radar cruise control with full-speed range ● Brake Override System/Drive-Start Control ● message Displayed when a suggestion/advice pop-up display is displayed on the multi-information display.
Page 132 2. Instrument cluster ■ Head-up display The head-up display may seem dark or hard to see when viewed through sunglasses, especially polarized sunglasses. Adjust the brightness of the head-up display or remove your sunglasses. ■ Display brightness The brightness of the head-up display can be adjusted on of the multi- information display.
Page 133 2. Instrument cluster NOTICE ■ To prevent damage to components ● Do not place any drinks near the head- up display projector. If the projector gets wet, electrical malfunctions may result. ● Do not place anything on or put stickers onto the head-up display projector.
Page 134: Energy Monitor/Consumption Screen
2. Instrument cluster Energy monitor/consumption screen The state of the hybrid system can be viewed on the multi-infor- mation display and navigation or multimedia system screen. The energy monitor and fuel consumption screen can be dis- played on the “Home” screen of the multimedia screen. Audio system screen Multi-information display Meter control switches...
Page 135 2. Instrument cluster ■ Reading the display The arrows will appear in accordance with the energy flow. When there is no energy flow, arrows will not be displayed. The color of the arrows will change as follows Green: When the hybrid battery (traction battery) is regenerated or charged.
Page 136 2. Instrument cluster  Audio system screen (“Home” screen) Gasoline engine Hybrid battery (traction bat- tery) Front tire The image shows the arrows as an example. The actual display will vary depending on conditions. ■ Remaining charge amount warning of hybrid battery (traction battery) ●...
Page 137 2. Instrument cluster Fuel consumption screen ■ Trip information  Without navigation function Press the “INFO” button. (P. 132) If the “Energy monitor” or “History” screen is displayed, select “Trip information”.  With navigation function Press the “MENU” button. (P. 132) Select “Information”...
Page 138 2. Instrument cluster ■ History Without navigation function  Press the “INFO” button. (P. 132) If the “Energy monitor” or “Trip information” screen is displayed, select “History”. With navigation function  Press the “MENU” button. (P. 132) Select “Information” on the “Menu” screen. Select “ECO”...
Page 139: Operation Of Each Component
Operation of each component 3-1. Key information Keys........138 3-2. Opening, closing and locking the doors Doors .........142 Trunk........149 Smart entry & start system .....153 3-3. Adjusting the seats Front seats......159 Rear seats ......161 Driving position memory ..163 Head restraints ....167 3-4.
Page 140: 3-1. Key Information
Unlocks all the doors (P. 142) Opens the windows and the 1, 2 panoramic moon roof (P. 142) Opens the trunk (P. 150) Sounds the alarm (P. 139) : If equipped : This setting must be customized at your Toyota dealer.
Page 141 ■ If you lose your keys New genuine keys can be made by your Toyota dealer using the other mechanical key and the key number stamped on your key number plate. Keep the plate in a safe place such as your wallet, not in the vehicle.
Page 142 ■ Confirmation of the registered key number The number of keys already registered to the vehicle can be confirmed. Ask your Toyota dealer for details. ■ If a wrong key is used The key cylinder rotates freely to isolate inside mechanism.
Page 143 Toyota dealer. ■ When an electronic key is lost If the electronic key remains lost, the risk of vehicle theft increases signifi- cantly. Visit your Toyota dealer immediately with all remaining electronic keys that were provided with your vehicle.
Page 144: Doors
Press and hold to close the win- dows panoramic 1, 2 moon roof Unlocks all the doors Press and hold to open the win- dows panoramic 1, 2 moon roof. : If equipped : This setting must be customized at your Toyota dealer.
Page 145 3-2. Opening, closing and locking the doors ■ Operation signals Doors: A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) Windows and panoramic moon roof: A buzzer sounds to indicate that the windows and panoramic moon roof are operating.
Page 146 3-2. Opening, closing and locking the doors Unlocking and locking the doors from the inside ◆ Door lock switches Locks all the doors Unlocks all the doors ◆ Inside lock buttons Locks the door Unlocks the door The driver's door can be opened by pulling the inside handle even if the lock button is in the lock position.
Page 147 3-2. Opening, closing and locking the doors Rear door child-protector lock The door cannot be opened from inside the vehicle when the lock is set. Unlock Lock These locks can be set to prevent children from opening the rear doors. Push down on each rear door switch to lock both rear doors.
Page 148 3-2. Opening, closing and locking the doors ■ Switching the door unlock function It is possible to set which doors the entry function unlocks using the wireless remote control. Turn the power switch off. When the indicator light on the key surface is not on, press and hold for approximately 5 seconds while pressing and holding The setting changes each time an operation is performed, as shown below.
Page 149 3-2. Opening, closing and locking the doors ■ Impact detection door lock release system In the event that the vehicle is subject to a strong impact, all the doors are unlocked. Depending on the force of the impact or the type of accident, how- ever, the system may not operate.
Page 150 3-2. Opening, closing and locking the doors WARNING ■ To prevent an accident Observe the following precautions while driving the vehicle. Failure to do so may result in a door opening and an occupant falling out, resulting in death or serious injury. ●...
Page 151: Trunk
3-2. Opening, closing and locking the doors Trunk The trunk can be opened using the trunk opener switch, entry function or wireless remote control. Opening the trunk from inside the vehicle Press and hold the trunk opener switch. Opening the trunk from outside the vehicle ◆...
Page 152 3-2. Opening, closing and locking the doors ◆ Wireless remote control Press and hold the switch. A buzzer sounds. When closing the trunk Using the trunk grip, lower the trunk without applying force to the side and push the trunk down from the outside to close it.
Page 153 3-2. Opening, closing and locking the doors ■ Open trunk warning buzzer If the vehicle reaches a speed of 5 km/h (3 mph), the master warning light flashes and a buzzer sounds to indicate that the trunk is not yet fully closed. ■...
Page 154 ● Do not attach any accessories other than genuine Toyota parts to the trunk lid. Such additional weight on the trunk lid may cause the lid to suddenly shut again after it is opened.
Page 155: Smart Entry & Start System
3-2. Opening, closing and locking the doors Smart entry & start system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. The driver should always carry the electronic key. ●...
Page 156 3-2. Opening, closing and locking the doors ■ Alarms and warning indicators A combination of exterior and interior alarms as well as warning messages shown on the multi-information display are used to prevent theft of the vehicle and accidents resulting from erroneous operation. Take appropriate mea- sures in response to any warning message on the multi-information display.
Page 157 3-2. Opening, closing and locking the doors ■ Electronic Key Battery-Saving Function When battery-saving mode is set, battery depletion is minimized by stopping the electronic key from receiving radio waves. Press twice while pressing and holding . Confirm that the electronic key indicator flashes 4 times.
Page 158 3-2. Opening, closing and locking the doors ● If window tint with a metallic content or metallic objects are attached to the rear window ● When the electronic key is placed near a battery charger or electronic devices ● When the vehicle is parked in a pay parking spot where radio waves are emitted.
Page 159 Fingernails may scrape against the door during operation of the door han- dle. Be careful not to injure fingernails or damage the surface of the door. : This setting can be customized at your Toyota dealer. ■ When the vehicle is not driven for extended periods ●...
Page 160 & start system antennas. (P. 153) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of the emitted radio waves.
Page 161: Adjusting The Seats
3-3. Adjusting the seats Front seats Adjustment procedure  Manual seat Seat position adjustment lever Seatback angle adjustment lever Vertical height adjustment lever (driver’s side only) Lumbar support adjustment switch (driver’s side only)  Power seat Seat position adjustment switch Seatback angle adjustment...
Page 162 3-3. Adjusting the seats WARNING ■ When adjusting the seat position ● Take care when adjusting the seat position to ensure that other passen- gers are not injured by the moving seat. ● Do not put your hands under the seat or near the moving parts to avoid injury.
Page 163: Rear Seats
3-3. Adjusting the seats Rear seats The seatbacks of the rear seats can be folded down. Folding down the rear seatbacks Pull the seatback lever in the trunk for the seatback you wish to fold down and then fold the seatback down.
Page 164 3-3. Adjusting the seats WARNING ■ When folding the seatbacks down Observe the following precautions. Failure to do so may result in death or serious injury. ● Do not fold the seatbacks down while driving. ● Stop the vehicle on level ground, set the parking brake and shift the shift lever to P.
Page 165: Driving Position Memory
3-3. Adjusting the seats  Driving position memory This feature automatically adjusts the driver’s seat, steering wheel and outside rear view mirrors to make entering and exit- ing the vehicle easier or to suit your preferences. Driving position memory Your preferred driving position (the position of the driver’s seat, steer- ing wheel and outside rear view mirrors) can be recorded and recalled by pressing a button.
Page 166 ■ When the recorded seat position cannot be recalled The seat position may not be recalled in some situations when the seat posi- tion is recorded in a certain range. For details, contact your Toyota dealer.
Page 167 3-3. Adjusting the seats Memory recall function Each electronic key can be registered to recall your preferred driving position. ■ Registering procedure Record your driving position to button 1 or 2 before performing the following: Carry only the key you want to register, and then close the driver’s door.
Page 168 3-3. Adjusting the seats ■ Cancelation procedure Carry only the key you want to cancel and then close the driver’s door. If 2 or more keys are in the vehicle, the driving position cannot be canceled properly. Turn the power switch to ON mode. While pressing the “SET”...
Page 169: Head Restraints
3-3. Adjusting the seats Head restraints Head restraints are provided for all seats.  Front seats Vertical adjustment Pull the head restraint up. Down Push the head restraint down while pressing the lock release button. Lock release button  Rear seats Head restraints cannot be adjusted or removed.
Page 170 3-3. Adjusting the seats ■ Adjusting the height of the head restraints Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears. WARNING ■ Head restraint precautions Observe the following precautions regarding the head restraints.
Page 171: Steering Wheel
3-4. Adjusting the steering wheel and mirrors Steering wheel Adjustment procedure  Manual type Hold the steering wheel and push the lever down. Adjust to the ideal position by moving the steering wheel hori- zontally and vertically. After adjustment, pull the lever up to secure the steering wheel.
Page 172 3-4. Adjusting the steering wheel and mirrors Auto tilt away (power type) When the power switch is turned off, the steering wheel returns to its stowed position by moving up and away to enable easier driver entry and exit. Turning power switch ACCESSORY or ON mode will...
Page 173: Inside Rear View Mirror
3-4. Adjusting the steering wheel and mirrors Inside rear view mirror The rear view mirror’s position can be adjusted to enable suffi- cient confirmation of the rear view. Adjusting the height of rear view mirror The height of the rear view mirror can be adjusted to suit your driving posture.
Page 174 3-4. Adjusting the steering wheel and mirrors  Auto anti-glare inside rear view mirror Responding to the level of brightness of the headlights of vehicles behind, the reflected light is automatically reduced. Changing automatic anti-glare function mode On/off When the automatic anti-glare function is in ON mode, the indica- tor illuminates.
Page 175: Outside Rear View Mirrors
3-4. Adjusting the steering wheel and mirrors Outside rear view mirrors Adjustment procedure To select a mirror to adjust, turn the switch. Left Right To adjust the mirror, operate the switch. Right Down Left Folding the mirrors  Manual type Push the mirror back in the direc- tion of the vehicle’s rear.
Page 176 3-4. Adjusting the steering wheel and mirrors  Power type Folds the mirrors Extends the mirrors Linked mirror function when reversing (vehicles with driving position memory) When the mirror select switch is in the “L” or “R” position, the outside rear view mirrors will automatically angle downwards when the vehicle is reversing in order to give a better view of the ground.
Page 177 3-4. Adjusting the steering wheel and mirrors WARNING ■ Important points while driving Observe the following precautions while driving. Failing to do so may result in loss of control of the vehicle and cause an accident, resulting in death or serious injury. ●...
Page 178: Opening And Closing
3-5. Opening and closing the windows Power windows Opening and closing procedures The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: Closing One-touch closing Opening One-touch opening : To stop the window partway, oper- ate the switch in the opposite direc- tion.
Page 179 1 second or more. If you release the switch while the window is moving, start again from the beginning. If the window reverses and cannot be fully closed or opened, have the vehicle inspected by your Toyota dealer.
Page 180 The power windows can be opened and closed using the wireless remote  control. P. 142) : These settings must be customized at your Toyota dealer. ■ Alarm The alarm may be triggered if the alarm is set and a power window is closed using the door lock linked power window operation function.
Page 181 3-5. Opening and closing the windows WARNING Observe the following precautions. Failing to do so may result in death or serious injury. ■ Opening and closing the windows ● The driver is responsible for all the power window operations, including the operation for the passengers.
Page 182: Panoramic Moon Roof
3-5. Opening and closing the windows  Panoramic moon roof Use the overhead switches to operate the panoramic moon roof and electronic sunshade. Opening and closing the electronic sunshade Opens the electronic sunshade Slide and hold the switch backward. The electronic sun- shade will fully open automati- cally.
Page 183 3-5. Opening and closing the windows Opening and closing the panoramic moon roof Opens the panoramic moon roof Slide and hold the switch backward. The panoramic moon roof and electronic sunshade will open automatically. The panoramic moon roof can be opened from the tilt-up position.
Page 184 ● The panoramic moon roof can be opened and closed using the wireless remote control. (P. 142) : These settings must be customized at your Toyota dealer. ■ Closing both the panoramic moon roof and electronic sunshade Slide the switch forward.
Page 185 3-5. Opening and closing the windows WARNING Observe the following precautions. Failing to do so may cause death or serious injury. ■ Opening and closing the electronic sunshade ● Check to make sure that all passengers do not have any part of their body in a position where it could be caught when the electronic sunshade is being oper- ated.
Page 186 3-5. Opening and closing the windows WARNING ■ Jam protection function ● Never use any part of your body to intentionally activate the jam protection function. ● The jam protection function may not work if something gets caught just before the panoramic moon roof or electronic sunshade is fully closed. Also, the jam protection function is not designed to operate while the switch is being pressed.
Page 187: Driving
Driving 4-1. Before driving 4-5. Using the driving support systems Driving the vehicle .....186 Toyota Safety Sense ..244 Cargo and luggage ....194 PCS (Pre-Collision Trailer towing .....195 System) ......250 4-2. Driving procedures LTA (Lane Tracing Power (ignition) switch..203 Assist)......266 EV drive mode ....209 RSA (Road Sign Assist)..280...
Page 188: Driving The Vehicle
4-1. Before driving Driving the vehicle The following procedures should be observed to ensure safe driving: Starting the hybrid system P. 203 Driving With the brake pedal depressed, shift the shift lever to D. (P. 212) Release the parking brake. (P. 219) Gradually release the brake pedal and gently depress the accelera- tor pedal to accelerate the vehicle.
Page 189 4-1. Before driving Sudden start restraint control (Drive-Start Control [DSC]) When the following unusual operation is performed with the accelera- tor pedal depressed, the hybrid system output may be restrained. ● When the shift lever is shifted to R ● When the shift lever is shifted from P or R to forward drive shift position such as D When the system operates, a message appears on the multi-informa- tion display and head-up display (if equipped).
Page 190 TRC (P. 303) so that the vehicle may become able to escape from the mud or fresh snow. ■ Breaking in your new Toyota To extend the life of the vehicle, observing the following precautions is recom- mended: ●...
Page 191 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When starting the vehicle Always keep your foot on the brake pedal while stopped with the “READY” indicator is illuminated. This prevents the vehicle from creeping. ■...
Page 192 ■ If you hear a squealing or scraping noise (brake pad wear indicators) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. Rotor damage may result if the pads are not replaced when needed.
Page 193 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When the vehicle is stopped ● Do not depress the accelerator pedal unnecessarily. If the shift lever is in any position other than P or N, the vehicle may accel- erate suddenly and unexpectedly, causing an accident.
Page 194 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When the vehicle is parked ● Always apply the parking brake, shift the shift lever to P, stop the hybrid system and lock the vehicle.
Page 195 Short in electrical components ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following: ● Brake function ●...
Page 196: Cargo And Luggage
4-1. Before driving Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load: WARNING ■ Things that must not be carried in the trunk The following things may cause a fire if loaded in the trunk: ●...
Page 197: Trailer Towing
Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. For towing purposes, when the total trailer weight is greater than the vehicle weight, we recommend use of a sway control device.
Page 198 4-1. Before driving ◆ Trailer tongue load The trailer cargo load should be distributed so that the tongue load is 9 to 11% of the total trailer weight, not exceeding 40 kg (88 lb.). (Tongue load / Total trailer weight x 100 = 9 to 11%) The total trailer weight and tongue load can be measured with plat- form scales found at a highway weighing stations, building supply companies, trucking companies, junk yards, etc.
Page 199 ■ Break-in schedule Toyota recommends that you do not use a new vehicle or a vehicle with any new power train components (engine, transmission, differential, wheel bear- ings, etc.) to tow a trailer for the first 800 km (500 miles) of driving.
Page 200 4-1. Before driving WARNING ■ To avoid accident or injury ● The total trailer weight (trailer weight plus the weight of cargo) must not exceed 400 kg (882 lb.). ● Do not exceed the trailer hitch assembly weight, gross vehicle weight, gross axle weight and trailer tongue load capacities.
Page 201 ■ When installing a trailer hitch ● Use only the position recommended by your Toyota dealer. Do not install the trailer hitch on the bumper; this may cause body damage. ● Do not use axle-mounted hitches, as they can cause damage to the axle housing, wheel bearings, wheels or tires.
Page 202 4-1. Before driving Trailer towing tips Your vehicle will handle differently when towing a trailer. In order to avoid accident, death or serious injury, keep the following in mind when towing: ● Before starting out, check the trailer lights and the vehicle-trailer connections.
Page 203 4-1. Before driving ● Take care when passing other vehicles. Passing requires consider- able distance. After passing a vehicle, do not forget the length of your trailer, and be sure you have plenty of room before changing lanes. ● Due to the added load of the trailer, your vehicle’s engine may over- heat on hot days (at temperatures over 30C [85F]) when driving up a long or steep grade.
Page 204 4-1. Before driving WARNING ■ To avoid an accident ● Observe the legal maximum speeds for trailer towing. ● Slow down and downshift before descending steep or long downhill grades. Do not make sudden downshifts while descending steep or long downhill grades.
Page 205: Driving Procedures
4-2. Driving procedures Power (ignition) switch Performing the following operations when carrying the elec- tronic key on your person starts the hybrid system or changes power switch modes. Starting the hybrid system Check that the parking brake is set. Check that the shift lever is in P. Firmly depress the brake pedal.
Page 206 4-2. Driving procedures Changing power switch modes Modes can be changed by pressing the power switch with brake pedal released. (The mode changes each time the switch is pressed.) The emergency flashers can be used. ACCESSORY mode Some electrical components such as the audio system can be used.
Page 207 If the hybrid system does not start ● The immobilizer system may not have been deactivated. (P. 81) Contact your Toyota dealer. ● Check that the shift lever is securely set in P. The hybrid system may not start if the shift lever is displaced out of P.
Page 208 ■ If the “READY” indicator does not come on In the event that the “READY” indicator does not come on even after perform- ing the proper procedures for starting the vehicle, contact your Toyota dealer immediately. ■ If the hybrid system is malfunctioning P.
Page 209 4-2. Driving procedures WARNING ■ When starting the hybrid system Always start the hybrid system while sitting in the driver’s seat. Do not depress the accelerator pedal while starting the hybrid system under any circumstances. Doing so may cause an accident resulting in death or serious injury. ■...
Page 210 Do not depress the accelerator pedal unnecessarily. ● If the hybrid system becomes difficult to start, have your vehicle checked by your Toyota dealer immediately. ■ Symptoms indicating a malfunction with the power switch If the power switch seems to be operating somewhat differently than usual, such as the switch sticking slightly, there may be a malfunction.
Page 211: Ev Drive Mode
4-2. Driving procedures EV drive mode In EV drive mode, electric power is supplied by the hybrid bat- tery (traction battery), and only the electric motor (traction motor) is used to drive the vehicle. This mode allows you to drive in residential areas early in the morning and late at night, or in indoor parking lots etc.
Page 212 4-2. Driving procedures ■ Switching to EV drive mode when the gasoline engine is cold If the hybrid system is started while the gasoline engine is cold, the gasoline engine will start automatically after a short period of time in order to warm up. In this case, you will become unable to switch to EV drive mode.
Page 213 4-2. Driving procedures WARNING ■ Caution while driving When driving in EV drive mode, pay special attention to the area around the vehicle. Because there is no engine noise, pedestrians, people riding bicy- cles or other people and vehicles in the area may not be aware of the vehi- cle starting off or approaching them, so take extra care while driving.
Page 214: Hybrid Transmission
4-2. Driving procedures Hybrid transmission Shifting the shift lever While the power switch is in ON mode and the brake pedal depressed , shift the shift lever while pushing the shift release button on the shift knob. Shift the shift lever while pushing the shift release button on the shift knob.
Page 215 4-2. Driving procedures Shift position purpose Shift position Objective or function Parking the vehicle/starting the hybrid system Reversing Neutral Normal driving S mode driving (P. 214) : To improve fuel efficiency and reduce noise, shift the shift lever to D for normal driving.
Page 216 4-2. Driving procedures Selecting the driving mode P. 333 Changing shift ranges in S mode When the shift lever is in the S position, the shift lever or paddle shift switches (vehicles with 7-inch display) can be operated as follows: Shift lever Paddle shift...
Page 217 4-2. Driving procedures Selecting shift ranges in the D position (vehicles with paddle shift switches) To drive using temporary shift range selection, operate the “-” paddle shift switch. The shift range can then be selected by operating the “-” and “+” paddle shift switches. Changing the shift range allows restric- tion of the highest gear, preventing upshifting and enabling the level of engine braking force to be selected.
Page 218 If the shift lever cannot be shifted even though the brake pedal is depressed and the shift release button is pushed, there may be a problem with the shift lock system. Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted.
Page 219 S This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by your Toyota dealer immediately. (In this situation, the transmission will operate in the same manner as when the shift lever is in D.) WARNING ■...
Page 220: Turn Signal Lever
4-2. Driving procedures Turn signal lever Operating instructions Left turn Lane change to the left (move the lever partway and release The left hand signals will flash 3 times. Lane change to the right (move the lever partway and release The right hand signals will flash 3 times.
Page 221: Parking Brake
4-2. Driving procedures Parking brake A mode can be selected from the following modes. Automatic mode The parking brake is set or released automatically according to the shift lever operation. Even when in automatic mode, the parking brake can be set and released manually.
Page 222 4-2. Driving procedures Manual mode The parking brake can be set and released manually. Sets the parking brake The parking brake indicator light and parking brake light will turn on. Pull and hold the parking brake switch if an emergency occurs and it is necessary to operate the park- ing brake while driving.
Page 223 Operate the parking brake switch. If the message does not disappear after operating the switch several times, the system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ Parking brake operation sound When the parking brake operates, a motor sound (whirring sound) may be heard.
Page 224 When the parking brake cannot be released due to a malfunction Driving the vehicle with the parking brake set will lead to brake components overheating, which may affect braking performance and increase brake wear. Contact your Toyota dealer immediately if this occurs.
Page 225: Brake Hold
4-2. Driving procedures Brake Hold The brake hold system keeps the brake applied when the shift lever is in D, S or N with the system on and the brake pedal has been depressed to stop the vehicle. The system releases the brake when the accelerator pedal is depressed with the shift lever in D or S to allow smooth start off.
Page 226 Make sure that the parking brake indicator light goes off. (P. 219) ■ When an inspection at your Toyota dealer is necessary When the brake hold standby indicator (green) does not illuminate even when the brake hold switch is pressed with the brake hold system operating condi- tions met, the system may be malfunctioning.
Page 227 4-2. Driving procedures WARNING ■ When the vehicle is on a steep incline When using the brake hold system on a steep incline, exercise caution. The brake hold function may not hold the vehicle in such a situation. ■ When stopped on a slippery road The system cannot stop the vehicle when the gripping ability of the tires has been exceeded.
Page 228: Headlight Switch
4-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Operating instructions Operating the switch turns on the lights as follows: The headlights, day- time running lights (P. 227) and all the lights listed below turn on and off automatically.
Page 229 4-3. Operating the lights and wipers Turning on the high beam headlights With the headlights on, push the lever away from you to turn on the high beams. Pull the lever toward you to the center position to turn the high beams off.
Page 230 4-3. Operating the lights and wipers ■ Automatic light off system ● When the headlights are on: The headlights and tail lights turn off 30 sec- onds after the power switch is turned to ACCESSORY mode or turned off and a door is opened and closed. (The lights turn off immediately if the key is pressed twice after all the doors are closed.) ●...
Page 231: Ahb (Automatic High Beam)
4-3. Operating the lights and wipers AHB (Automatic High Beam) The Automatic High Beam uses a front camera located behind the upper portion of the windshield to assess the brightness of the lights of vehicles ahead, streetlights, etc., and automatically turns the high beams on or off as necessary.
Page 232 4-3. Operating the lights and wipers Turning the high beams on/off manually ■ Switching to the high beams Push the lever away from you. The Automatic High Beam indi- cator will turn off and the high beam indicator will turn on. Pull the lever to its original posi- tion to activate the Automatic High Beam system again.
Page 233 4-3. Operating the lights and wipers ■ Conditions to turn the high beams on/off automatically ● When all of the following conditions are met, the high beams will be turned on automatically (after approximately 1 second): • The vehicle speed is approximately 30 km/h (19 mph) or more. •...
Page 234 4-3. Operating the lights and wipers ● In the following situations the system may not be able to correctly detect the surrounding brightness level. This may cause the low beams to remain on or the high beams to flash or dazzle pedestrians or vehicles ahead. In such a case, it is necessary to manually switch between the high and low beams.
Page 235: Windshield Wipers And Washer
4-3. Operating the lights and wipers Windshield wipers and washer Operating the wiper lever  Intermittent windshield wipers with interval adjuster Operating the lever operates the wipers or washer as follows. When intermittent windshield wiper operation is selected, wiper inter- val can be also adjusted.
Page 236 4-3. Operating the lights and wipers Washer/wiper dual oper- ation Pulling the lever operates the wip- ers and washer. The wipers will automatically oper- ate a couple of times after the washer squirts. (After operating several times, the wipers operate once more time after a short delay to prevent drip- ping.
Page 237 4-3. Operating the lights and wipers When “AUTO” is selected, the sensor sensitivity can be adjusted as follows by turning the switch ring. Increases rain-sensing windshield wiper sensitivity Decreases rain-sensing windshield wiper sensitivity Washer/wiper dual oper- ation Pulling the lever operates the wip- ers and washer.
Page 238 4-3. Operating the lights and wipers ■ Raindrop sensor (vehicles with rain-sensing windshield wipers) ● The raindrop sensor judges the amount of raindrops. An optical sensor is adopted. It may not operate properly when sunlight from the rising or setting of the sun intermittently strikes the windshield, or if bugs etc.
Page 239 Damage to the washer fluid pump may be caused if the lever is pulled toward you and held continually. ■ When a nozzle becomes blocked In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged.
Page 240 4-3. Operating the lights and wipers Changing the windshield wiper rest position/Lifting the wind- shield wipers When the windshield wipers are not being used, they retract to below the hood. To enable the windshield wipers to be lifted when parking in cold conditions or when replacing a windshield wiper insert, change the rest position of the windshield wipers to the service position using the wiper lever.
Page 241 4-3. Operating the lights and wipers ■ Lowering the windshield wipers to the retracted position With the windshield wipers placed on the windshield, turn the power switch to ON mode and then move the wiper lever to an operating position. When the wiper switch is turned off, the windshield wipers will stop at the retracted posi- tion.
Page 242: Refueling Opening The Fuel Tank Cap
4-4. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap: Before refueling the vehicle ● Close all the doors and windows, and turn the power switch off. ● Confirm the type of fuel. ■...
Page 243 4-4. Refueling WARNING ■ When refueling the vehicle Observe the following precautions while refueling the vehicle. Failure to do so may result in death or serious injury. ● After exiting the vehicle and before opening the fuel door, touch an unpainted metal surface to discharge any static electricity.
Page 244 4-4. Refueling Opening the fuel tank cap Press and hold the opener to open the fuel filler door. Turn the fuel tank cap slowly to remove it and hang it on the back of the fuel filler door. Closing the fuel tank cap After refueling, turn the fuel tank cap until you hear a click.
Page 245 WARNING ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 246: 4-5. Using The Driving Support Systems
■ Toyota Safety Sense The Toyota Safety Sense is designed to operate under the assumption that the driver will drive safely, and is designed to help reduce the impact to the occupants and the vehicle in the case of a collision or assist the driver in normal driving conditions.
Page 247 Do not subject the radar sensor or its surrounding area to a strong impact. If the radar sensor, front grille, or front bumper has been subjected to a strong impact, have the vehicle inspected by your Toyota dealer. ● Do not disassemble the radar sensor.
Page 248 Do not dirty or damage the front camera. When cleaning the inside of the windshield, do not allow glass cleaner to contact the lens of the front camera. Also, do not touch the lens. If the lens is dirty or damaged, contact your Toyota dealer.
Page 249 ● Do not attach any accessories to the hood, front grille or front bumper that may obstruct the front camera. Contact your Toyota dealer for details. ● If a surfboard or other long object is to be mounted on the roof, make sure that it will not obstruct the front camera.
Page 250 In the following situations, perform the actions specified in the table. When the normal operating conditions are detected, the message will disappear and the system will become operational. If the message does not disappear, contact your Toyota dealer. Situation Actions...
Page 251 If the message does not disappear, contact your Toyota dealer. • When the temperature around the radar sensor is outside of the opera- tional range, such as when the vehicle is in the sun or in an extremely cold environment •...
Page 252: Pcs (Pre-Collision System)
4-5. Using the driving support systems PCS (Pre-Collision System) The pre-collision system uses a radar sensor and front camera to detect objects (P. 250) in front of the vehicle. When the sys- tem determines that the possibility of a frontal collision with an object is high, a warning operates to urge the driver to take eva- sive action and the potential brake pressure is increased to help the driver avoid the collision.
Page 253 4-5. Using the driving support systems ■ Pre-collision braking If the system determines that the possibility of a frontal collision is extremely high, the brakes are automatically applied to help avoid the collision or reduce the impact of the collision. ■...
Page 254 4-5. Using the driving support systems ● When turn right/left, pedestrian is detected in the forward direction and esti- mated to enter your vehicle’s path (bicyclists detected.) WARNING ■ Limitations of the pre-collision system ● The driver is solely responsible for safe driving. Always drive safely, taking care to observe your surroundings.
Page 255 4-5. Using the driving support systems WARNING ■ Pre-collision braking ● When the pre-collision braking function is operating, a large amount of braking force will be applied. ● If the vehicle is stopped by the operation of the pre-collision braking func- tion, the pre-collision braking function operation will be canceled after approximately 2 seconds.
Page 256 4-5. Using the driving support systems WARNING ■ When to disable the pre-collision system In the following situations, disable the system, as it may not operate prop- erly, possibly leading to an accident resulting in death or serious injury: ● When the vehicle is being towed ●...
Page 257 4-5. Using the driving support systems Changing settings of the pre-collision system ■ Enabling/disabling the pre-collision system The pre-collision system can be enabled/disabled on (4.2-inch display) or (7-inch display) (P. 100, 115) of the multi-informa- tion display. The system is automatically enabled each time the power switch is turned to ON mode.
Page 258 4-5. Using the driving support systems ■ Changing the pre-collision warning timing The pre-collision warning timing can be changed on (4.2-inch display) or (7-inch display) (P. 100, 115) of the multi-informa- tion display. The warning timing setting is retained when the power switch is turned off.
Page 259 4-5. Using the driving support systems ■ Operational conditions for each pre-collision function The pre-collision system is enabled and the system determines that the pos- sibility of a frontal collision with a detected object is high. The system may not operate in the following situations: •...
Page 260 4-5. Using the driving support systems ● Pre-collision braking Relative speed Detectable objects Vehicle speed between your vehicle and object Preceding Approx. 10 to 180 km/h (7 to Approx. 10 to 180 stopped vehicles 110 mph) km/h (7 to 110 mph) Oncoming vehi- Approx.
Page 261 4-5. Using the driving support systems ● Intersection right/left turn assistance (pre-collision warning) When the turn signal lights are not flashing, support for turning left or right at an intersection which targets oncoming vehicles does not work. Relative speed Detectable Oncoming vehi- Vehicle speed between your...
Page 262 4-5. Using the driving support systems ■ Conditions under which the system may operate even if there is no pos- sibility of a collision ● In some situations such as the following, the system may determine that there is a possibility of a frontal collision and operate. •...
Page 263 4-5. Using the driving support systems • When a detectable object approaches very close and then stops before entering the path of your vehicle • If the front of your vehicle is raised or lowered, such as when on an uneven or undulating road surface •...
Page 264 4-5. Using the driving support systems • While making a right/left turn, when an oncoming vehicle turns right/left in front of your vehicle • While steering into the direction of oncoming traffic ■ Situations in which the system may not operate properly ●...
Page 265 4-5. Using the driving support systems • If a vehicle ahead is a motorcycle • If a vehicle ahead is narrow, such as a personal mobility vehicle • If a preceding vehicle has a small rear end, such as an unloaded truck •...
Page 266 4-5. Using the driving support systems • If the front of the vehicle is raised or lowered • If the wheels are misaligned • If a wiper blade is blocking the front camera • The vehicle is being driven at extremely high speeds •...
Page 267 4-5. Using the driving support systems ● In some situations such as the following, sufficient braking force or steering force may not be obtained, preventing the system from performing properly: • If the braking functions cannot operate to their full extent, such as when the brake parts are extremely cold, extremely hot, or wet •...
Page 268: Lta (Lane Tracing Assist)
4-5. Using the driving support systems LTA (Lane Tracing Assist) Summary of functions While driving on a road with clear white (yellow) lane lines, the LTA system warns the driver if the vehicle may deviate from the current lane or course , and also can slightly operate the steering wheel to help avoid deviation from the lane or course .
Page 269 Do not modify the suspension etc. If the suspension etc. needs to be replaced, contact your Toyota dealer. ● Do not install or place anything on the hood or grille. Also, do not install a grille guard (bull bars, kangaroo bar, etc.). ● If your windshield needs repairs, contact your Toyota dealer.
Page 270 4-5. Using the driving support systems WARNING ■ Conditions in which functions may not operate properly In the following situations, the functions may not operate properly and the vehicle may depart from its lane. Drive safely by always paying careful attention to your surroundings and operate the steering wheel to correct the path of the vehicle without relying solely on the functions.
Page 271 4-5. Using the driving support systems WARNING ● Vehicle is driven where the road diverges, merges, etc. ● Repair marks of asphalt, white (yellow) lines, etc. are present due to road repair. ● There are shadows on the road that run parallel with, or cover, the white (yellow) lines.
Page 272 4-5. Using the driving support systems WARNING ● Light from the headlights of an oncoming vehicle, the sun, etc. enters the camera. ● The vehicle is driven on a slope. ● The vehicle is driven on a road which tilts left or right, or a winding road. ●...
Page 273 4-5. Using the driving support systems Functions included in LTA system ◆ Lane departure alert function When the system determines that the vehicle might depart from its lane or course warning is displayed on the multi-information display, and a warning buzzer will sound to alert the driver.
Page 274 4-5. Using the driving support systems ◆ Steering assist function When the system determines that the vehicle might depart from its lane or course , the system provides assistance as necessary by operating the steering wheel small amounts for a short period of time to keep the vehicle in its lane.
Page 275 4-5. Using the driving support systems ◆ Lane centering function This function is linked with dynamic radar cruise control with full-speed range and pro- vides the required assistance by operating the steering wheel to keep the vehicle in its current lane.
Page 276 4-5. Using the driving support systems ■ Turning the LTA system OFF Press and hold the LTA switch The LTA indicator light turns off when the LTA is turned OFF. Press the switch again to turn the system on. The LTA is turned ON each time the power switch is turned to ON. However, the lane centering function keeps either the ON/OFF state prior to the power switch being turned OFF.
Page 277 4-5. Using the driving support systems Lane departure alert function display Displayed when the multi-information display is switched to the driving assist system information display. Inside of displayed lines is Inside of displayed lines is   white black Indicates that the system is recog- Indicates that the system is not nizing white (yellow) lines or a able to recognize white (yellow)
Page 278 4-5. Using the driving support systems ■ Operation conditions of each function ● Lane departure alert function This function operates when all of the following conditions are met. • LTA is turned on. • Vehicle speed is approximately 50 km/h (32 mph) or more. •...
Page 279 4-5. Using the driving support systems • The dynamic radar cruise control with full-speed range is operating in vehicle-to-vehicle distance control mode. • Width of traffic lane is approximately 3 to 4 m (10 to 13 ft.). • Turn signal lever is not operated. •...
Page 280 4-5. Using the driving support systems ■ Hands off steering wheel warning In the following situations, a warning mes- sage urging the driver to hold the steering wheel and the symbol shown in the illus- tration are displayed on the multi-informa- tion display to warn the driver.
Page 281 ● “LTA Malfunction Visit Your Dealer” The system may not be operating properly. Have the vehicle inspected by your Toyota dealer. ● “LTA Unavailable” The system is temporarily canceled due to a malfunction in a sensor other than the front camera.
Page 282: Rsa (Road Sign Assist)
4-5. Using the driving support systems RSA (Road Sign Assist) Summary of function The RSA system recognizes spe- cific road signs using the front camera to provide information to the driver via the display. Front camera If the system judges that the vehicle is being driven over the speed limit, according to the recognized road signs, it notifies the driver through a visual notification and notification buzzer : This setting needs to be customized.
Page 283 4-5. Using the driving support systems Indication on the multi-information display When the front camera recognizes a sign, the sign will be displayed on the multi-information display. ● When the driving assist system information is selected, a maxi- mum of 2 signs can be dis- played.
Page 284 4-5. Using the driving support systems Notification function In the following situations, the RSA system will notify the driver. ● When the vehicle speed exceeds the speed notification threshold of the speed limit sign displayed, the sign display will be emphasized and a buzzer will sound.
Page 285 ON. ■ If “RSA Malfunction Visit Your Dealer” is shown The system may be malfunctioning. Have the vehicle inspected by your Toyota dealer. ■ Customization Some functions can be customized. (P. 100, 115)
Page 286: Dynamic Radar Cruise Control With Full-Speed Range
4-5. Using the driving support systems Dynamic radar cruise control with full- speed range Summary of functions In vehicle-to-vehicle distance control mode, the vehicle automatically accelerates, decelerates and stops to match the speed changes of the preceding vehicle even if the accelerator pedal is not depressed. In constant speed control mode, the vehicle runs at a fixed speed.
Page 287 4-5. Using the driving support systems WARNING ■ Before using dynamic radar cruise control with full-speed range ● Driving safely is the sole responsibility of the driver. Do not rely solely on the system, and drive safely by always paying careful attention to your surroundings.
Page 288 4-5. Using the driving support systems WARNING ■ Cautions regarding the driving assist systems Observe the following precautions, as there are limitations to the assistance provided by the system. Failure to do so may cause an accident resulting in death or serious injury. ●...
Page 289 4-5. Using the driving support systems WARNING ■ Situations unsuitable for dynamic radar cruise control with full-speed range Do not use dynamic radar cruise control with full-speed range in any of the following situations. Doing so may result in inappropriate speed control and could cause an acci- dent resulting in death or serious injury.
Page 290 4-5. Using the driving support systems Driving in vehicle-to-vehicle distance control mode This mode employs a radar to detect the presence of vehicles up to approximately 100 m (328 ft.) ahead, determines the current vehicle- to-vehicle following distance, and operates to maintain a suitable fol- lowing distance from the vehicle ahead.
Page 291 4-5. Using the driving support systems When the turn signal lever is operated and your vehicle moves to an over- taking lane while driving at 80 km/h (50 mph) or more, the vehicle will accelerate to help to overtake a passing vehicle. The system’s identification of what is an overtaking lane may be deter- mined solely based on the location of the steering wheel in the vehicle (left side driver position versus right side driver position.) If the vehicle is driven...
Page 292 4-5. Using the driving support systems Adjusting the set speed ● Adjusting the set speed by the switch To change the set speed, press the “+ RES” or “- SET” switch until the desired set speed is displayed. Increases the speed (Except when the vehicle has been stopped by system control in vehi- cle-to-vehicle...
Page 293 4-5. Using the driving support systems Changing the vehicle-to-vehicle distance (vehicle-to-vehicle dis- tance control mode) Pressing the switch changes the Preceding vehicle-to-vehicle distance as fol- vehicle mark lows: Long Medium Short If a vehicle is running ahead of you, the preceding vehicle mark will also be displayed.
Page 294 4-5. Using the driving support systems Resuming follow-up cruising when the vehicle has been stopped by system control (vehicle-to-vehicle distance control mode) After the vehicle ahead of you starts off, press the “+ RES” switch. Your vehicle will also resume fol- low-up cruising if the accelerator pedal is depressed after the vehi- cle ahead of you starts off.
Page 295 4-5. Using the driving support systems Approach warning (vehicle-to-vehicle distance control mode) When your vehicle is too close to a vehicle ahead, and sufficient automatic deceleration via the cruise control is not possible, the display will flash and the buzzer will sound to alert the driver.
Page 296 4-5. Using the driving support systems ■ Operation display Displayed when the vehicle speed is being reduced. When the vehicle speed reduc- tion ends, the display will disap- pear. ■ Changing the settings of the curve speed reduction function The curve speed reduction function can be enabled/disabled and the vehicle speed reduction strength can be adjusted.
Page 297 4-5. Using the driving support systems Selecting constant speed control mode When constant speed control mode is selected, your vehicle will main- tain a set speed without controlling the vehicle-to-vehicle distance. Select this mode only when vehicle-to-vehicle distance control mode does not function correctly due to a dirty radar, etc.
Page 298 4-5. Using the driving support systems Dynamic Radar Cruise Control with Road Sign Assist When this function is enabled and the system is operating in vehicle- to-vehicle distance control mode (P. 288), when a speed limit sign is detected, the recognized speed limit will be displayed with an up/ down arrow.
Page 299 • The driver’s door is opened. • The vehicle has been stopped for about 3 minutes If vehicle-to-vehicle distance control mode is automatically canceled for any reasons other than the above, there may be a malfunction in the system. Contact your Toyota dealer.
Page 300 (For example: Pre-Collision System, Drive-Start Control) If constant speed control mode is automatically canceled for any reasons other than the above, there may be a malfunction in the system. Contact your Toyota dealer. ■ Situations in which the curve speed reduction function may not operate...
Page 301 4-5. Using the driving support systems ■ When the sensor may not be correctly detecting the vehicle ahead In the case of the following and depending on the conditions, operate the brake pedal when deceleration of the system is insufficient or operate the accelerator pedal when acceleration is required.
Page 302 4-5. Using the driving support systems ■ Conditions under which the vehicle-to-vehicle distance control mode may not function correctly In the case of the following conditions, operate the brake pedal (or accelera- tor pedal, depending on the situation) as necessary. As the sensor may not be able to correctly detect vehicles ahead, the system may not operate properly.
Page 303: Driving Assist Systems
4-5. Using the driving support systems Driving assist systems To keep driving safety and performance, the following systems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehi- cle.
Page 304 4-5. Using the driving support systems ◆ Hill-start assist control Helps to reduce the backward movement of the vehicle when start- ing on an uphill ◆ EPS (Electric Power Steering) Employs an electric motor to reduce the amount of effort needed to turn the steering wheel ◆...
Page 305 (P. 265) ■ When the message is displayed on the multi-information display show- ing that TRC has been disabled even if has not been pressed TRC is temporary deactivated. If the information continues to show, contact your Toyota dealer.
Page 306 4-5. Using the driving support systems ■ Operating conditions of hill-start assist control When the following four conditions are met, the hill-start assist control will operate: ● The shift lever is in a position other than P or N (when starting off forward/ backward on an upward incline) ●...
Page 307 4-5. Using the driving support systems ■ Automatic reactivation of TRC and VSC systems After turning the TRC and VSC systems off, the systems will be automatically re-enabled in the following situations: ● When the power switch is turned off ●...
Page 308 4-5. Using the driving support systems WARNING ■ The ABS does not operate effectively when ● The limits of tire gripping performance have been exceeded (such as excessively worn tires on a snow covered road). ● The vehicle hydroplanes while driving at high speed on wet or slick roads. ■...
Page 309 The ABS, TRC and VSC systems will not function correctly if different tires are installed on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■ Handling of tires and the suspension Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause a system to malfunction.
Page 310: Bsm (Blind Spot Monitor)
4-5. Using the driving support systems  BSM (Blind Spot Monitor) The Blind Spot Monitor is a system that uses rear side radar sen- sors installed on the inner side of the rear bumper on the left and right side to assist the driver in confirming safety when chang- ing lanes.
Page 311 4-5. Using the driving support systems Turning the BSM function on/off Press of the meter control switches, select Press of the meter control switches, select Press of the meter control switch. Each time is pressed, the function changes on/off. Setting the outside rear view mirror indicator brightness The brightness of the indicators on the outside rear view mirrors can be changed on (P.
Page 312 Do not attach accessories or stickers to the sensor or surrounding area on the bumper. ● Do not modify the sensor or surrounding area on the bumper. ● Do not paint the rear bumper any color other than an official Toyota color.
Page 313: Bsm Function
4-5. Using the driving support systems BSM function The BSM function uses radar sensors to detect the following vehicles traveling in an adjacent lane in the area that is usually not reflected in the outside rear view mirror (the blind spot), and advises the driver of the presence of such vehicles via the indicators on the outside rear view mirrors.
Page 314 4-5. Using the driving support systems BSM function detection areas The areas that vehicles can be detected in are outlined below. The range of the detection area extends to: Approximately 0.5 m (1.6 ft.) to 3.5 m (11.5 ft.) from either side of the vehicle The area between the side of the vehicle and 0.5 m (1.6 ft.) from the side of the vehicle cannot be detected...
Page 315 4-5. Using the driving support systems ■ The BSM function is operational when ● The BSM function is turned on ● Vehicle speed is greater than approximately 16 km/h (10 mph). ■ The BSM function will detect a vehicle when ●...
Page 316 4-5. Using the driving support systems • When there is a significant difference in height between your vehicle and the vehicle that enters the detection area • Directly after the BSM function is turned on ● Instances of the BSM function unnecessarily detecting a vehicle and/or object may increase under the following conditions: •...
Page 317: Toyota Parking Assist-Sensor
Press of the meter control switches, select Press of the meter control switch. When the Toyota parking assist-sensor function is disabled, the Toyota parking assist-sensor OFF indicator (P. 88) illuminates. To re-enable the system, select on the multi-information display, select and turn it on.
Page 318 • When the shift position is changed • When the vehicle speed exceeds a certain speed. • When the Toyota parking assist-sensor is turned off once and turned on again • When the power switch is turned off once and turned to ON mode again...
Page 319 4-5. Using the driving support systems Sensor detection display, object distance ■ Distance display Approximate distance to object Display Front corner sensor Rear corner sensor 50 cm (1.6 ft.) to 60 cm (2.0 ft.) to 42.5 cm (1.4 ft.) 45 cm (1.5 ft.) 42.5 cm (1.4 ft.) to 45 cm (1.5 ft.) to 35 cm (1.2 ft.)
Page 320 4-5. Using the driving support systems ■ Buzzer operation and distance to an object A buzzer sounds when the sensors are operating. ● The buzzer sounds faster as the vehicle approaches an object. When the vehicle comes within the following distance of the object, the buzzer sounds continuously: Approximately 35 cm (1.2 ft.).
Page 321 4-5. Using the driving support systems ■ The Toyota parking assist-sensor can be operated when ● The power switch is in ON mode. ● Toyota parking assist-sensor function is on. ● The vehicle speed is less than about 10 km/h (6 mph).
Page 322 4-5. Using the driving support systems WARNING ■ When using the Toyota parking assist-sensor Observe the following precautions. Failing to do so may result in the vehicle being unable to be driven safely and possibly cause an accident. ● Do not use the sensor at speeds in excess of 10 km/h (6 mph).
Page 323 The area directly under the bumpers is not detected. ● If objects draw too close to the sensor. ● A non-genuine Toyota suspension (lowered suspension, etc.) is installed. ● A backlit license plate is installed. In addition to the examples above, there are instances in which, because of their shape, signs and other objects may be judged by a sensor to be closer than they are.
Page 324 When using Toyota parking assist-sensor In the following situations, the system may not function correctly due to a sensor malfunction, etc. Have the vehicle checked by your Toyota dealer. ● The Toyota parking assist-sensor operation display flashes, and a buzzer sounds when no objects are detected.
Page 325: Rcta (Rear Cross Traffic Alert)
4-5. Using the driving support systems  RCTA (Rear Cross Traffic Alert) The RCTA function uses the BSM rear side radar sensors installed behind the rear bumper. This function is intended to assist the driver in checking areas that are not easily visible when backing up.
Page 326 4-5. Using the driving support systems Turning the RCTA function on/off Press of the meter control switches, select Press of the meter control switches, select Press of the meter control switch. Each time is pressed, the function changes on/off. Setting the buzzer volume The volume of the RCTA buzzer can be changed on (P.
Page 327: Rcta Function
RCTA icon display (if equipped) When a vehicle approaching from the right or left at the rear of the vehicle is detected, the following will be displayed on the audio sys- tem screen. Toyota parking Panoramic view Content assist monitor...
Page 328 4-5. Using the driving support systems WARNING ■ Cautions regarding the use of the system The driver is solely responsible for safe driving. Always drive safely, taking care to observe your surroundings. The RCTA function is only an assist and is not a replacement for careful driving.
Page 329 4-5. Using the driving support systems RCTA function detection areas The areas that vehicles can be detected in are outlined below. To give the driver a more consistent time to react, the buzzer can alert for faster vehicles from farther away. Example: Approximate Approaching vehicle...
Page 330 4-5. Using the driving support systems ■ Conditions under which the RCTA function may not function correctly ● The RCTA function may not detect vehicles correctly in the following condi- tions: • When the sensor is misaligned due to a strong impact to the sensor or its surrounding area •...
Page 331: Rear Camera Detection Function
4-5. Using the driving support systems  Rear Camera Detection Function When the vehicle is backing up, the rear camera detection func- tion can detect pedestrians in the detection area behind the vehicle. If a pedestrian is detected, a buzzer will sound and an icon on the audio system screen will be displayed to inform the driver of the pedestrian.
Page 332 4-5. Using the driving support systems When a pedestrian is detected If the rear camera detection func- tion detects a pedestrian in the detection area, the buzzer and icon will operate as shown in the following table: Area Buzzer Icon Sounds repeatedly When the vehicle is stationary: Blinks 3 times and then stays on...
Page 333 4-5. Using the driving support systems ■ Setting the buzzer volume The buzzer volume can be adjusted with the RCTA buzzer volume on the multi-information display. (P. 118) ■ Muting the buzzer sound The buzzer can be temporarily muted by pressing of the meter control switches while an object detection display is shown on the multi-information display.
Page 334 4-5. Using the driving support systems ● In some situations, such as the following, the Rear Camera Detection func- tion may operate even though there are no pedestrians in the detection area. • When a three dimensional object, such as a pole, traffic cone, fence, or parked vehicle, is detected •...
Page 335: Driving Mode Select Switches
4-5. Using the driving support systems Driving mode select switches The driving modes can be selected to suit driving condition. Normal mode Use for normal driving. While in Eco drive mode or sport mode, press the switch to change the driving mode to normal mode.
Page 336 4-5. Using the driving support systems ■ Operation of the air conditioning system in Eco drive mode Eco drive mode controls the heating/cooling operations and fan speed of the air conditioning system to enhance fuel efficiency (P. 342). To improve air conditioning performance, adjust the fan speed or turn off Eco drive mode.
Page 337: Driving Tips
4-6. Driving tips Hybrid vehicle driving tips For economical and ecological driving, pay attention to the fol- lowing points: ◆ Using Eco drive mode When using Eco drive mode, the torque corresponding to the accel- erator pedal depression amount can be generated more smoothly than it is in normal conditions.
Page 338 4-6. Driving tips ◆ When braking Make sure to operate the brakes gently and in a timely manner. A greater amount of electrical energy can be regenerated when slow- ing down. ◆ Delays Repeated acceleration and deceleration, as well as long waits at traffic lights, will lead to bad fuel economy.
Page 339 4-6. Driving tips ◆ Luggage Carrying heavy luggage will lead to poor fuel economy. Avoid carry- ing unnecessary luggage. Installing a large roof rack will also cause poor fuel economy. ◆ Warming up before driving Since the gasoline engine starts up and cuts out automatically when cold, warming up the engine is unnecessary.
Page 340: Winter Driving Tips
4-6. Driving tips Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a man- ner appropriate to the prevailing weather conditions. Preparation for winter ● Use fluids that are appropriate to the prevailing outside tempera- tures.
Page 341 If the shift lever can be shifted from P, there may be a problem with the shift lock system. Have the vehicle inspected by your Toyota dealer immediately. Selecting tire chains Vehicles with 17-inch tires ...
Page 342 4-6. Driving tips Regulations on the use of tire chains Regulations regarding the use of tire chains vary depending on loca- tion and type of road. Always check local regulations before installing chains. ■ Tire chain installation Observe the following precautions when installing and removing chains: ●...
Page 343: Interior Features
Interior features 5-1. Using the air conditioning 5-4. Other interior features system and defogger Other interior features..361 Automatic air conditioning • Sun visors......361 system ......342 • Vanity mirrors ....361 Seat heaters/ • Power outlet ....362 seat ventilators ....349 • USB charging ports ..363 5-2.
Page 344: Automatic Air Conditioning
5-1. Using the air conditioning system and defogger Automatic air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting. Air conditioning controls...
Page 345 5-1. Using the air conditioning system and defogger ■ Adjusting the temperature setting To adjust the temperature setting, turn clockwise to increase the temperature and counterclockwise to decrease the tempera- ture. is not pressed, the system will blow ambient temperature air or heated air.
Page 346 5-1. Using the air conditioning system and defogger Using automatic mode Press The dehumidification function begins to operate. Air outlets and fan speed are automatically adjusted according to the temperature set- ting. Adjust the temperature setting. To stop the operation, press ■...
Page 347 5-1. Using the air conditioning system and defogger Other functions ■ Switching between outside air and recirculated air modes Press The mode switches between outside air mode (indicator off) and recir- culated air mode (indicator on) each time is pressed. ■...
Page 348 5-1. Using the air conditioning system and defogger Air outlets ■ Location of air outlets The air outlets and air volume change according selected airflow mode. ■ Adjusting the position of and opening and closing the air out- lets Front Rear ...
Page 349 5-1. Using the air conditioning system and defogger ■ Using automatic mode Fan speed is adjusted automatically according to the temperature setting and the ambient conditions. Therefore, the fan may stop for a while until warm or cool air is ready to flow immediately after is pressed.
Page 350 5-1. Using the air conditioning system and defogger ■ Ventilation and air conditioning odors ● To let fresh air in, set the air conditioning system to the outside air mode. ● During use, various odors from inside and outside the vehicle may enter into and accumulate in the air conditioning system.
Page 351: Seat Heaters/ Seat Ventilators
5-1. Using the air conditioning system and defogger   Seat heaters /seat ventilators Seat heaters heat the seats and seat ventilators maintain good ventilation by pulling air through the seat upholstery. WARNING ● Care should be taken to prevent injury if anyone in the following categories comes in contact with the seats when the heater is on: •...
Page 352 5-1. Using the air conditioning system and defogger Seat heaters Each time the switch is pressed, the operation condition changes as follows. Hi (3 segments lit)  Mid (2 seg- ments lit)  Lo (1 segment lit)  The level indicator (amber) lights up during operation.
Page 353: Using The Interior Lights
5-2. Using the interior lights Interior lights list Front interior/personal lights (P. 352, 353) Shift lever light (if equipped) Inside door handle lights (if equipped) Rear interior light (if equipped) (P. 352) Rear personal lights (if equipped) (P. 353) Door courtesy lights (if equipped) Front center console light Footwell lights (if equipped) Instrument panel ornament light (if equipped)
Page 354: Interior Lights
5-2. Using the interior lights Interior lights ■ Front (if equipped) The rear personal lights (if equipped) turn on/off together with the front interior light. Turns the lights on/off linked to door positions Turns the lights on/off ■ Rear (if equipped) Turns the light off Turns the light on/off linked to door positions...
Page 355: Personal Lights
5-2. Using the interior lights Personal lights ■ Front Turns the lights on/off ■ Rear (if equipped) Turns the lights on/off ■ Illuminated entry system The lights automatically turn on/off according to the power switch mode, the presence of the electronic key, whether the doors are locked/unlocked, and whether the doors are open/closed.
Page 356: List Of Storage Features
5-3. Using the storage features List of storage features Bottle holders/door pockets Coin holder (P. 355) (P. 356) Auxiliary box/open tray Glove box (P. 355) (P. 358, 359) Auxiliary box (if equipped) Cup holders (P. 357) (P. 358) Console box (P.
Page 357: Glove Box
5-3. Using the storage features Glove box Unlock with the mechanical key Lock with the mechanical key Open (pull lever) The glove box light (if equipped) turns on when the tail lights are on. Console box Push the knob. Coin holder Pull the lever to open.
Page 358: Bottle Holders
5-3. Using the storage features Bottle holders Front Rear   ● When storing a bottle, close the cap. ● The bottle may not be stored depending on its size or shape. WARNING Do not place anything other than a bottle in the bottle holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
Page 359: Cup Holders
5-3. Using the storage features Cup holders Front Rear   Pull the armrest down. WARNING ■ Items unsuitable for the cup holder Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking, causing injury.
Page 360: Auxiliary Boxes
5-3. Using the storage features Auxiliary boxes Type A (if equipped) Type B   Push the lid. Opening: Push the tray forward until it locks. Closing: Push the tray forward to release the lock and the tray will auto- matically close.
Page 361: Open Tray
5-3. Using the storage features NOTICE ■ When opening or closing the tray (type B) ● To prevent damaging small items, when opening the tray while small items are placed on it, make sure the items will not get caught. ●...
Page 362: Trunk Feature
5-3. Using the storage features Trunk feature Grocery bag hooks NOTICE To prevent damage to the hooks, do not apply too much load to the hooks.
Page 363: Other Interior Features
5-4. Other interior features Other interior features Sun visors To set the visor in the forward position, flip it down. To set the visor in the side posi- tion, flip down, unhook, and swing it to the side. Vanity mirrors Slide the cover to open.
Page 364: Power Outlet
5-4. Other interior features Power outlet Please use as a power supply for electronic goods that use less than 12 VDC/10 A (power consumption of 120 W). Open the lid. ■ The power outlet can be used when The power switch is in ACCESSORY or ON mode. ■...
Page 365: Usb Charging Ports
5-4. Other interior features USB charging ports (if equipped) The USB charging ports are used to supply 2.1 A of electricity at 5 V to external devices (power consumption of 10.5 W). The USB charging ports are for charging only. They are not designed for data transfer or other purposes.
Page 366 5-4. Other interior features NOTICE ■ To prevent damage to the USB charging ports ● Do not insert foreign objects into the ports. ● Do not spill water or other liquids into the ports. ● When the USB charging ports are not in use, close the lids. If a foreign object or liquid enters a port may cause a short circuit.
Page 367: Armrest
5-4. Other interior features Armrest Fold down the armrest for use. NOTICE To prevent damage to the armrest, do not apply too much load on the arm- rest. Assist grips The assist grips installed on the ceiling can be used to support your body while sitting on the seat.
Page 368: Coat Hooks
5-4. Other interior features Coat hooks Coat hooks are provided on the rear assist grips. WARNING Do not hang coat hangers or other hard or sharp objects on the hook. If the SRS curtain shield airbags deploy, these items may become projectiles, causing death or serious injury.
Page 369 Maintenance and care 6-1. Maintenance and care Cleaning and protecting the vehicle exterior ..368 Cleaning and protecting the vehicle interior ...373 6-2. Maintenance Maintenance requirements....376 6-3. Do-it-yourself maintenance Do-it-yourself service precautions ......378 Hood ........380 Positioning a floor jack..381 Engine compartment..382 12-volt battery ....389 Tires........393 Tire inflation pressure ..396...
Page 370: Cleaning And Protecting The Vehicle Exterior
6-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition: ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 371 6-1. Maintenance and care ■ When using a car wash If the door handle becomes wet while the electronic key is within the effective range, the door may lock and unlock repeatedly. In that case, follow the fol- lowing correction procedures to wash the vehicle: ●...
Page 372 ■ Precaution regarding the rear bumper with Blind Spot Monitor (if equipped) If the paint of the rear bumper is chipped or scratched, the system may mal- function. If this occurs, avoid using the system and consult your Toyota dealer.
Page 373 6-1. Maintenance and care NOTICE ■ To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels, etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
Page 374 6-1. Maintenance and care NOTICE ■ When using a high pressure car wash ● When washing the vehicle, do not spray the camera or its surrounding area directly with a high pressure washer. Shock applied from high pres- sure water may cause the device to not operate normally. ●...
Page 375: Cleaning And Protecting The Vehicle Interior
6-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior ● Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water.
Page 376 ● Wring out any excess water from the cloth and thoroughly wipe off remaining traces of detergent and water. ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle's interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available.
Page 377 6-1. Maintenance and care NOTICE ■ Cleaning detergents ● Do not use the following types of detergent, as they may discolor the vehi- cle interior or cause streaks or damage to painted surfaces: • Areas other than the seats and steering wheel: Organic substances such as benzene or gasoline, alkaline or acidic solutions, dye, and bleach •...
Page 378: 6-2. Maintenance
■ Where to go for maintenance service? It makes good sense to take your vehicle to your local Toyota dealer for main- tenance service as well as other inspections and repairs. Toyota technicians are well-trained specialists receiving the latest service information through technical bulletins, service tips, and in-dealership training programs.
Page 379 ● Engine coolant temperature continually higher than normal If you notice any of these clues, take your vehicle to your Toyota dealer as soon as possible. Your vehicle may need adjustment or repair. WARNING ■...
Page 380: Do-It-Yourself
• Grease condition • Conventional wrench (for terminal clamp bolts) (P. 389) • “Toyota Super Long Life Coolant” or a similar high quality ethylene glycol-based non-silicate, non- Engine/power amine, non-nitrite and non-borate coolant with long- control unit cool- life hybrid organic acid technology ant level “Toyota Super Long Life Coolant”...
Page 381 6-3. Do-it-yourself maintenance WARNING The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions. ■ When working on the engine compartment ● Make sure that the “READY”...
Page 382: Hood
6-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Pull up the auxiliary catch lever and lift the hood. ■ Open hood warning buzzer If the vehicle reaches a speed of 5 km/h (3 mph), the master warning light flashes and a buzzer sounds to indicate that the hood is not fully closed.
Page 383: Positioning A Floor Jack
6-3. Do-it-yourself maintenance Positioning a floor jack When using a floor jack, follow the instructions in the manual provided with the jack and perform the operation safely. When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury.
Page 384: Engine Compartment
6-3. Do-it-yourself maintenance Engine compartment Fuse boxes (P. 411) Condenser (P. 387) Engine oil filler cap Power control unit coolant (P. 384) reservoir (P. 386) Engine oil level dipstick Engine coolant reservoir (P. 383) (P. 386) Radiator (P. 387) Washer fluid tank (P. 388) Electric cooling fan...
Page 385 6-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil Park the vehicle on level ground. After warming up the engine and turning off the hybrid system, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 386 6-3. Do-it-yourself maintenance ■ Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as that already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 387 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal. ●...
Page 388 If the coolant level drops within a short time of replenishing Visually check the radiators, hoses, engine/power control unit coolant reser- voir caps, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system.
Page 389 Radiator and condenser Check the radiator and condenser and clear away any foreign objects. If either of the above parts is extremely dirty or you are not sure of their condition, have your vehicle inspected by your Toyota dealer. WARNING ■...
Page 390 6-3. Do-it-yourself maintenance Washer fluid If the washer fluid level is at “LOW”, add washer fluid. ■ Using the gauge The washer fluid level can be checked by observing the position of the level on the liquid-covered holes in the gauge. Current If the level falls below the second hole fluid...
Page 391: 12-Volt Battery
6-3. Do-it-yourself maintenance 12-volt battery Location The 12-volt battery is located on the right-hand side of the trunk. Removing the 12-volt battery cover Remove the 12-volt battery cover. Exterior Make sure that the 12-volt battery terminals are not corroded and that there are no loose connections, cracks, or loose clamps.
Page 392 12-volt battery was disconnected. Make sure to turn off the power before disconnecting the 12-volt battery. Take extra care when connecting the 12-volt battery if the power switch mode prior to discharge is unknown. If the system will not start even after multiple attempts, contact your Toyota dealer.
Page 393 When replacing the 12-volt battery Use a 12-volt battery designed for this vehicle. Failure to do so may cause gas (hydrogen) to enter the passenger compartment, causing a fire or explosion. For replacement of the 12-volt battery, contact your Toyota dealer.
Page 394 6-3. Do-it-yourself maintenance NOTICE ■ When recharging the 12-volt battery Never recharge the 12-volt battery while the hybrid system is operating. Also, be sure all accessories are turned off.
Page 395: Tires
6-3. Do-it-yourself maintenance Tires Replace or rotate tires in accordance with maintenance sched- ules and treadwear. Checking tires Check if the treadwear indicators are showing on the tires. Also check the tires for uneven wear, such as excessive wear on one side of the tread.
Page 396 Front Front Rotate the tires in the order shown. To equalize tire wear and help extend tire life, Toyota recommends that tire rotation is carried out approximately every 10000 km (6000 miles). ■ When to replace your vehicle’s tires Tires should be replaced if: ●...
Page 397 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 398: Tire Inflation Pressure
Reduced tire life due to wear ● Reduced safety ● Damage to the drivetrain If a tire needs frequent inflating, have it checked by your Toyota dealer. ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ●...
Page 399 6-3. Do-it-yourself maintenance WARNING ■ Proper inflation is critical to save tire performance Keep your tires properly inflated. If the tires are not properly inflated, the following conditions may occur which could lead to an accident resulting in death or serious injury: ●...
Page 400: Wheels
● Used wheels ● Bent wheels that have been straightened Aluminum wheel precautions ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1600 km (1000 miles).
Page 401 6-3. Do-it-yourself maintenance WARNING ■ When replacing wheels ● Do not use wheels that are a different size from those recommended in the Owner’s Manual, as this may result in a loss of handling control. ● Never use an inner tube in a leaking wheel which is designed for a tube- less tire.
Page 402: Air Conditioning Filter
6-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. Removal method Turn the power switch off. Open the glove box. Slide off the damper. Push in each side of the glove box to disconnect the upper claws.
Page 403 6-3. Do-it-yourself maintenance Remove the filter case. There may be foreign objects on top of the air conditioning filter. Remove the air conditioning fil- ter from the filter case and replace it with a new one. The “UP” marks shown on the fil- ter and the filter case should be pointing up.
Page 404 6-3. Do-it-yourself maintenance NOTICE ■ When using the air conditioning system Make sure that a filter is always installed. Using the air conditioning system without a filter may cause damage to the system. ■ To prevent damage to the filter cover When moving the filter cover in the direc- tion of arrow to release the fitting, pay attention not to apply excessive force to...
Page 405: Cleaning The Hybrid Battery (Traction Battery) Air Intake Vent And Filter
6-3. Do-it-yourself maintenance Cleaning the hybrid battery (traction battery) air intake vent and filter To prevent the fuel economy from being affected, visually inspect the hybrid battery (traction battery) air intake vent peri- odically for dust and clogs. If it is dusty or clogged or if “Mainte- nance Required for Traction Battery Cooling Parts See Owner’s Manual”...
Page 406 6-3. Do-it-yourself maintenance Remove the air intake vent cover. Pull the cover as shown in the illustration to disengage the 7 claws, starting from the claw in the upper right cor- ner. Pull the cover toward the front of the vehicle to remove Remove the air intake vent fil- ter.
Page 407 6-3. Do-it-yourself maintenance Reinstall the filter to the cover. Engage the filter to the 2 claws as shown in the illus- tration. Engage the 3 claws to install the filter. Make sure that the filter is not crooked or deformed when install- ing it.
Page 408 After the hybrid system is started, it may be necessary to drive the vehicle up to approximately 20 minutes before the warning message disappears. If the warning message does not disappear after driving for appropriately 20 minutes, have the vehicle inspected by your Toyota dealer. WARNING ■...
Page 409 ● Carefully handle the removed filter so that it will not be damaged. If the filter is damaged, have it replaced with a new filter by your Toyota dealer. ● Make sure to reinstall the filter and cover to their original positions after cleaning.
Page 410: Electronic Key Battery
6-3. Do-it-yourself maintenance Electronic key battery Replace the battery with a new one if it is depleted. You will need the following items: ● Flathead screwdriver ● Small flathead screwdriver ● Lithium battery CR2032 Replacing the battery Release the lock and remove the mechanical key.
Page 411 Be careful not to lose the battery or any other small parts. ■ Use a CR2032 lithium battery ● Batteries can be purchased at your Toyota dealer, local electrical appliance shops or camera stores. ● Replace only with the same or equivalent type recommended by the manu- facturer.
Page 412 6-3. Do-it-yourself maintenance NOTICE ■ For normal operation after replacing the battery Observe the following precautions to prevent accidents: ● Always work with dry hands. Moisture may cause the battery to rust. ● Do not touch or move any other component inside the remote control. ●...
Page 413: Checking And Replacing Fuses
6-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as nec- essary. Turn the power switch off. Open the fuse box cover. ...
Page 414 6-3. Do-it-yourself maintenance Remove the fuse with the pull- out tool. Only type A fuses can be removed using the pullout tool. Check if the fuse is blown.  Type A  Type B Type C  Normal fuse Blown fuse Replace the blown fuse with a new fuse of an appropriate amperage rat- ing.
Page 415 If the lights do not turn on even after the fuse has been replaced, a bulb may need replacement. (P. 414) ● If the replaced fuse blows again, have the vehicle inspected by your Toyota dealer. ■ If there is an overload in a circuit The fuses are designed to blow, protecting the wiring harness from damage.
Page 416: Light Bulbs
Light bulbs You may replace the following bulbs yourself. The difficulty level of replacement varies depending on the bulb. If necessary bulb replacement seems difficult to perform, contact your Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer.
Page 417 6-3. Do-it-yourself maintenance Replacing light bulbs ■ Front turn signal lights (bulb type) Turn bulb base counterclockwise. Remove the light bulb. Install a new light bulb and then install the bulb base to the light unit by inserting it and turning it clockwise.
Page 418 6-3. Do-it-yourself maintenance ■ Back-up lights (bulb type) Open trunk remove the clips. Partly remove the trunk lid cover. Disconnect connector while depressing the lock release. (When replacing right side bulb only.) Turn bulb base counterclockwise.
Page 419 6-3. Do-it-yourself maintenance Remove the light bulb. Install a new light bulb and then install the bulb base to the light unit by inserting it and turning it clockwise. Connect connector. (When replacing right side bulb only.) Reinstall the trunk lid cover with the clips.
Page 420 6-3. Do-it-yourself maintenance ■ Rear turn signal lights (bulb type) Open the trunk and apply protective tape to the vehicle body around the light unit. Use masking tape, etc. Do not use duct tape, as it may leave residue or damage the paint when removed.
Page 421 6-3. Do-it-yourself maintenance Remove the light unit. Attach a long piece of packing tape to the light unit and fold the excess in half. Hold the folded portion and pull it toward the rear of the vehicle to remove the light unit. Turn bulb base...
Page 422 6-3. Do-it-yourself maintenance Install a new light bulb and then install the bulb base to the light unit by inserting it and turning it clockwise. Install the light unit. Align the tabs and push the light unit toward the front of the vehi- cle to install it.
Page 423 Remove the protective tape. ■ Replacing the following bulbs If any of the lights listed below has burnt out, have it replaced by your Toyota dealer. ● Headlights ● Daytime running lights/front position lights ● Front turn signal lights (LED type) ●...
Page 424 The lights other than the front turn signal lights (bulb type), back-up lights (bulb type) and rear turn signal lights (bulb type) consist of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced.
Page 425: When Trouble Arises
When trouble arises 7-1. Essential information Emergency flashers ...424 If your vehicle has to be stopped in an emergency....425 If the vehicle is submerged or water on the road is rising ........426 7-2. Steps to take in an emergency If your vehicle needs to be towed ......427 If you think something is wrong ......433...
Page 426: 7-1. Essential Information
7-1. Essential information Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has to be stopped on the road due to a breakdown, etc. Press the switch. All the turn signal lights will flash. To turn them off, press the switch once again.
Page 427: If Your Vehicle Has To Be Stopped In An Emergency
7-1. Essential information If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the follow- ing procedure: Steadily step on the brake pedal with both feet and firmly depress it. Do not pump the brake pedal repeatedly as this will increase the effort required to slow the vehicle.
Page 428: If The Vehicle Is Submerged Or Water On The Road Is Rising
Laminated glass is used in the windshield on this vehicle. Laminated glass cannot be shattered with an emergency hammer Tempered glass is used in the windows on this vehicle. : Contact your Toyota dealer or aftermarket accessory manufacturer for fur- ther information about an emergency hammer. WARNING ■...
Page 429: Steps To Take In An Emergency If Your Vehicle Needs To Be Towed
If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or commercial towing service, using a wheel-lift type truck or flatbed truck. Use a safety chain system for all towing, and abide by all state/ provincial and local laws.
Page 430 Situations when it is necessary to contact dealers before towing The following may indicate a problem with your transmission. Contact your Toyota dealer or commercial towing service before towing. ● The hybrid system warning message is shown on the multi-informa- tion display and the vehicle does not move.
Page 431 7-2. Steps to take in an emergency Towing with a wheel-lift type truck From the front From the rear   Release the parking brake. Use a towing dolly under the front wheels. Turn automatic mode off. (P. 219) NOTICE ■...
Page 432 7-2. Steps to take in an emergency Using a flatbed truck If your vehicle is transported by a flatbed truck, it should be tied down at the locations shown in the illustration. Covers are installed to the tie-down holes. After transporting the vehi- cle, make sure to reinstall the cov- ers to the holes.
Page 433 7-2. Steps to take in an emergency Emergency towing If a tow truck is not available in an emergency, your vehicle may be temporarily towed using cables or chains secured to the emergency towing eyelets. This should only be attempted on hard surfaced roads for short distances at under 30 km/h (18 mph).
Page 434 7-2. Steps to take in an emergency Tighten down the towing eyelet securely using a wheel nut wrench or hard metal bar. Securely attach cables or chains to the towing eyelet. Take care not to damage the vehicle body. Enter the vehicle being towed and start the hybrid system. If the hybrid system does not start, turn the power switch to ON mode.
Page 435: If You Think Something Is Wrong
7-2. Steps to take in an emergency If you think something is wrong If you notice any of the following symptoms, your vehicle proba- bly needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms ● Fluid leaks under the vehicle.
Page 436: If A Warning Light Turns On Or A Warning Buzzer Sounds
• The brake fluid level is low; or • The brake system is malfunctioning  Immediately stop the vehicle in a safe place and con- (Red) tact your Toyota dealer. Continuing to drive the vehi- cle may be dangerous. Brake system warning light Indicates a malfunction in: •...
Page 437 Warning light/Details/Actions ABS warning light Indicates a malfunction in: • The ABS; or • The brake assist system  Have the vehicle inspected by your Toyota dealer immediately. Inappropriate pedal operation warning light (warning buzzer) When a buzzer sounds: Indicates a malfunction in: •...
Page 438 PCS warning light When a buzzer sounds simultaneously: Indicates a malfunction has occurred in the PCS (Pre-Col- lision System).  Have the vehicle inspected by your Toyota dealer immediately. When a buzzer does not sound: The PCS (Pre-Collision System) has become temporarily (Flashes or unavailable, corrective action may be necessary.
Page 439 • The hill-start assist control system The light will flash when the ABS, VSC or TRC system is operating.  Have the vehicle inspected by your Toyota dealer immediately. Low fuel level warning light Indicates that remaining fuel is approximately 6.7 L (1.8 gal., 1.5 Imp.
Page 440 If the fuel tank is empty, refuel the vehicle immediately. The malfunction indicator lamp will go off after several trips. If the malfunction indicator lamp does not go off, contact your Toyota dealer as soon as possible. ■...
Page 441: If A Warning Message Is Displayed
Multi-information display Handling method Follow the instructions of the message on the multi-information display. If any of the warning messages are shown again after the appropriate actions have been performed, contact your Toyota dealer.
Page 442 Messages and warnings The warning lights and warning buzzers operate as follows depending on the content of the message. If a message indicates the need for inspection by a dealer, have the vehicle inspected by your Toyota dealer immediately. System...
Page 443 ● If the following messages are shown, there may be a malfunction. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Continuing to drive the vehicle may be dangerous. • “Low Braking Power Stop in a Safe Place See Owner’s Manual”...
Page 444 ● If the message is being displayed and the air intake vent and filter are not dirty, have the vehicle inspected at your Toyota dealer. ■ If “Traction Battery Needs to Be Protected Refrain from the Use of N Position”...
Page 445 If this message is displayed but you have not had a new electronic key regis- tered, ask your Toyota dealer to check if an unknown electronic key (other than those in your possession) has been registered.
Page 446 NOTICE ■ If “High Power Consumption Power to Climate Temporarily Limited” is frequently shown There is a possible malfunction relating to the charging system or the 12- volt battery may be deteriorating. Have the vehicle inspected by your Toyota dealer.
Page 447: If You Have A Flat Tire
7-2. Steps to take in an emergency If you have a flat tire Your vehicle is equipped with a spare tire. The flat tire can be replaced with the spare tire. For details about tires: P. 393 WARNING ■ If you have a flat tire Do not continue driving with a flat tire.
Page 448 7-2. Steps to take in an emergency Location of the spare tire, jack and tools Vehicles with a compact spare tire  Luggage floor cover Spare tire Wheel nut wrench Towing eyelet Jack Jack handle  Vehicles with a full-size spare tire Luggage floor cover Spare tire Jack...
Page 449 7-2. Steps to take in an emergency WARNING ■ Using the tire jack Observe the following precautions. Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading to death or serious injury. ● Do not use the tire jack for any purpose other than replacing tires or install- ing and removing tire chains.
Page 450 7-2. Steps to take in an emergency Taking out the jack Lift up the hook of the luggage floor cover on the trunk floor. Secure the luggage floor cover using the hook provided. Remove the jack.  Vehicles with a compact spare ...
Page 451 7-2. Steps to take in an emergency Taking out the spare tire Lift up the hook of the luggage floor cover on the trunk floor. Secure the luggage floor cover using the hook provided. Remove the tool tray.  Vehicles with a compact spare ...
Page 452 7-2. Steps to take in an emergency Vehicles with a full-size spare tire only: Remove the spare tire cover. Loosen the center fastener that secures the spare tire. When taking out or stowing the spare tire, make sure to firmly hold opposite end of the tire.
Page 453 7-2. Steps to take in an emergency Replacing a flat tire Chock the tires. Flat tire Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side In front of the front left-hand side tire...
Page 454 7-2. Steps to take in an emergency Assemble the jack handle. Raise the vehicle until the tire is slightly raised off the ground. Remove all the wheel nuts and the tire. When resting the tire on the ground, place the tire so that the wheel design faces up to avoid scratching the wheel surface.
Page 455 • When installing a tire, only use wheel nuts that have been specifically designed for that wheel. • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer.
Page 456 7-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, causing the tire to come off.
Page 457 7-2. Steps to take in an emergency ■ The compact spare tire (if equipped) ● The compact spare tire is identified by the label “TEMPORARY USE ONLY” on the tire sidewall. Use the compact spare tire temporarily, and only in an emergency. ●...
Page 458 • TRC • BSM (Blind Spot Monitor) • EPS • Toyota parking assist-sensor • AHB (Automatic High Beam) • Toyota parking assist monitor • Dynamic radar cruise control with • Panoramic view monitor full-speed range • Navigation system : If equipped ■...
Page 459 7-2. Steps to take in an emergency NOTICE ■ Be careful when driving over bumps with the compact spare tire installed on the vehicle. (if equipped) The vehicle becomes lower when driving with the compact spare tire com- pared to when driving with standard tires. Be careful when driving over uneven road surfaces.
Page 460: If The Hybrid System Will Not Start
7-2. Steps to take in an emergency If the hybrid system will not start Reasons for the hybrid system not starting vary depending on the situation. Check the following and perform the appropriate procedure: The hybrid system will not start even though the correct starting procedure is being followed.
Page 461 ● The 12-volt battery may be discharged. (P. 463) ● One or both of the 12-volt battery terminals may be disconnected. (P. 389) Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function...
Page 462: If The Electronic Key Does Not Operate Properly
Unlocks all the doors Opens the windows and the panoramic moon roof (turn and hold) : If equipped : This setting must be customized at your Toyota dealer. ■ Trunk Turn the mechanical key clock- wise to open.
Page 463 7-2. Steps to take in an emergency Starting the hybrid system Ensure that the shift lever is in P and firmly depress the brake pedal. Touch the Toyota emblem side of the electronic key to the power switch. When electronic detected, a buzzer sounds and the power switch will turn to ON mode.
Page 464 7-2. Steps to take in an emergency ■ Stopping the hybrid system Shift the shift lever to P and press the power switch as you normally do when stopping the hybrid system. ■ Replacing the key battery As the above procedure is a temporary measure, it is recommended that the electronic key battery be replaced immediately when the battery is depleted.
Page 465: If The Vehicle 12-Volt Battery Is Discharged
The following procedures may be used to start the hybrid sys- tem if the vehicle’s 12-volt battery is discharged. You can also call your Toyota dealer or a qualified repair shop. If you have a set of jumper (or booster) cables and a second vehicle with a 12-volt battery, you can jump start your vehicle by following the steps below.
Page 466 Maintain the engine speed of the second vehicle and start the hybrid system of your vehicle by turning the power switch to ON mode. Make sure the “READY” indicator comes on. If the indicator does not come on, contact your Toyota dealer.
Page 467 ■ When the 12-volt battery is removed or discharged Information stored in the ECU is cleared. When the 12-volt battery is depleted, have the vehicle inspected at your Toyota dealer. ■ When removing the 12-volt battery terminals When the 12-volt battery terminals are removed, the information stored in the ECU is cleared.
Page 468 (Depending on the 12-volt battery to be replaced, the exhaust hole may be plugged.) Exhaust hole plug Exhaust hole Exhaust hose Hole section of the vehicle For details, consult your Toyota dealer.
Page 469 Do not allow children near the 12-volt battery. ■ After recharging the 12-volt battery Have the 12-volt battery inspected at your Toyota dealer as soon as possi- ble. If the 12-volt battery is deteriorating, continued use may cause the 12-volt battery to emit a malodorous gas, which may be detrimental to the health of passengers.
Page 470 7-2. Steps to take in an emergency WARNING ■ When replacing the 12-volt battery After replacing, securely attach the exhaust hose and exhaust hole plug to the exhaust hole of the replaced 12-volt battery. If not properly installed, gases (hydrogen) may leak into the vehicle interior, and there is the possi- ble danger of the gas igniting and exploding.
Page 471: If Your Vehicle Overheats
If you do not see steam: Carefully lift the hood. After the hybrid system has cooled down sufficiently, inspect the hoses and radia- tor core (radiator) for any leaks. Radiator Cooling fan If a large amount of coolant leaks, immediately contact your Toyota dealer.
Page 472 (The fan may not operate in freez- ing temperatures.) If the fan is not operating: Stop the hybrid system immediately and contact your Toyota dealer. If the fan is operating: Have the vehicle inspected at the nearest Toyota dealer.
Page 473 (radiator) for any leaks. Radiator Cooling fan If a large amount of coolant leaks, immediately contact your Toyota dealer. The coolant level is satisfac- tory if it is between the “FULL” and “LOW” lines on the reservoir. Reservoir “FULL” line “LOW”...
Page 474 Stop the hybrid system and contact your Toyota dealer. If the message is not displayed: The hybrid system temperature has dropped and the vehicle may be driven normally. However, if the message appears again frequently, contact your Toyota dealer. WARNING ■...
Page 475: If The Vehicle Becomes Stuck
7-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt or snow: Stop the hybrid system. Set the parking brake and shift the shift lever to P.
Page 476 7-2. Steps to take in an emergency WARNING ■ When attempting to free a stuck vehicle If you choose to push the vehicle back and forth to free it, make sure the surrounding area is clear to avoid striking other vehicles, objects or people. The vehicle may also lunge forward or lunge back suddenly as it becomes free.
Page 477: Vehicle Specifications
Vehicle specifications 8-1. Specifications Maintenance data (fuel, oil level, etc.)...476 Fuel information ....486 8-2. Customization Customizable features ..487...
Page 478: Specifications Maintenance Data (Fuel, Oil Level, Etc.)
8-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions 4885 mm (192.3 in.) Overall length 4905 mm (193.1 in.) Overall width 1840 mm (72.4 in.) Overall height 1445 mm (56.9 in.) Wheelbase 2825 mm (111.2 in.) 1590 mm (62.6 in.) Front 1580 mm (62.2 in.) Tread...
Page 479 Vehicle identification number The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is also on the manufacturer’s label.
Page 480 8-1. Specifications Engine Model A25A-FXS Type 4-cylinder in line, 4-cycle, gasoline 87.5  103.4 mm (3.44  4.07 in.) Bore and stroke Displacement 2487 cm (151.8 cu. in.) Valve clearance Automatic adjustment Fuel Fuel type Unleaded gasoline only Research octane 95 or higher number Fuel tank capacity...
Page 481 5 minutes, and check the oil level on the dipstick. ■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat- isfy the following grade and viscosity.
Page 482 8-1. Specifications Oil viscosity (0W-16 is explained here as an example): • The 0W in 0W-16 indicates the characteristic of the oil which allows cold startability. Oils with a lower value before the W allow for easier starting of the engine in cold weather. •...
Page 483 (Reference)  Power control unit 1.8 L (1.9 qt., 1.6 Imp. qt.) Use either of the following: • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based Coolant type non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology Do not use plain water alone.
Page 484 3.9 L (4.1 qt., 3.4 Imp. qt.) Fluid type Toyota Genuine ATF WS : The fluid capacity is a reference quantity. If replacement is necessary, contact your Toyota dealer. NOTICE ■ Transmission fluid type Using transmission fluid other than the above type may cause abnormal...
Page 485 8-1. Specifications Brakes Pedal clearance 85 mm (3.3 in.) 1  6 mm (0.04  0.24 in.) Pedal free play Brake pad wear limit 1.0 mm (0.04 in.) SAE J1703 or FMVSS No.116 DOT 3 Fluid type SAE J1704 or FMVSS No.116 DOT 4 : Minimum pedal clearance when depressed with a force of 300 N (31 kgf, 67 lbf) while the hybrid system operating.
Page 486 8-1. Specifications Tires and wheels 17-inch tires  Tire size 215/55R17 94V Vehicle speed kPa (kgf/cm or bar, psi) Tire inflation pressure More than 160 km/h 270 (2.7, 39) (Recommended cold (100 mph) tire inflation pressure) 160 km/h (100 mph) 240 (2.4, 35) or less 17 ...
Page 487 8-1. Specifications  Compact spare tire (if equipped) Tire size T155/70D17 110M Spare tire inflation pressure 420 kPa (4.2 kgf/cm or bar, 60 psi) (Recommended cold tire inflation pressure) 17  4 T Wheel size Wheel nut torque 103 N•m (10.5 kgf•m, 76 ft•lbf) Light bulbs Light bulbs Type...
Page 488: Fuel Information
■ Use of ethanol blended gasoline in a gasoline engine Toyota allows the use of ethanol blended gasoline where the ethanol content is up to 10%. Make sure that the ethanol blended gasoline to be used has a Research Octane Number that follows the above.
Page 489: Customization Customizable Features
The settings of these fea- tures can be changed using the multi-information display, on the audio system screen, or at your Toyota dealer. Customizing vehicle features When customizing vehicle features, ensure that the vehicle is parked in a safe place with the shift lever in P and the parking brake set.
Page 490 Customizable features Some function settings are changed simultaneously with other func- tions being customized. Contact your Toyota dealer for further details. Settings that can be changed on the audio system screen Settings that can be changed by your Toyota dealer Definition of symbols: O = Available, —...
Page 491 8-2. Customization ■ Door lock (P. 142, 149, 460) Function Default setting Customized setting Driver’s door All doors Unlocking using unlocked in one step, unlocked in one — O mechanical key all doors unlocked in step two steps Speed linked door lock- ing function Shift position linked door locking function...
Page 492 8-2. Customization ■ Smart entry & start system (P. 142, 149, 153) Function Default setting Customized setting Smart entry & start sys- — O Smart door unlocking All the doors Driver’s door Time elapsed before unlocking all the door when gripping and hold- 2 seconds —...
Page 493 8-2. Customization ■ Power windows and panoramic moon roof (P. 176, 180) Function Default setting Customized setting Key linked operation — O Wireless remote control — O linked operation Wireless remote control linked operation signal — O (buzzer) : If equipped ■...
Page 494 Time elapsed before headlights automatically 30 seconds 60 seconds turn off after doors are closed 90 seconds ■ Toyota parking assist-sensor (P. 315) Function Default setting Customized setting Buzzer volume 1 to 3 — O If equipped ■ BSM (Blind Spot Monitor) (P.
Page 495 8-2. Customization ■ Illumination (P. 351) Function Default setting Customized setting Time elapsed before 15 seconds 7.5 seconds lights turn off 30 seconds Operation after — O power switch turned off Operation when — O doors are unlocked Operation when approach vehicle —...
Page 496 8-2. Customization...
Page 497 Index What to do if... (Troubleshooting) .....496 Alphabetical index ......500 For information regarding the equipment listed below, refer to “Navigation and Multimedia System Owner’s Manual”. • Navigation system • Audio/visual system • Toyota parking assist monitor • Panoramic view monitor...
Page 498 Toyota dealer. (P. 139) ● If you lose your electronic keys, the risk of vehicle theft increases signifi- cantly. Contact your Toyota dealer immediately. (P. 141) The doors cannot be locked or unlocked ● Is the key battery weak or depleted? (P. 408) ●...
Page 499 What to do if... (Troubleshooting) If you think something is wrong The hybrid system does not start ● Did you press the power switch while firmly depressing the brake pedal? (P. 203) ● Is the shift lever in P? (P. 205) ●...
Page 500 What to do if... (Troubleshooting) A warning buzzer sounds during driving ● The seat belt reminder light is flashing Are the driver and the passenger wearing the seat belts? (P. 437) ● The parking brake indicator is on Is the parking brake released? (P. 219) Depending on the situation, other types of warning buzzer may also sound.
Page 501 What to do if... (Troubleshooting) When a problem has occurred If you have a flat tire ● Stop the vehicle in a safe place and replace the flat tire with the spare tire. (P. 445) The vehicle becomes stuck ● Try the procedure for when the vehicle becomes stuck in mud, dirt, or snow.
Page 502 Alphabetical index Alphabetical index Side airbag precautions ..37 Side and curtain shield A/C..........342 airbags operating Air conditioning filter....400 conditions ......42 Automatic air conditioning Side and curtain shield system ........ 342 airbags precautions ....37 SRS airbags......35 (Anti-lock Brake System)..
Page 503 Alphabetical index Brake Brake Hold ......223 Back-up lights Fluid ........483 Replacing light bulb..416, 421 Parking brake......219 Wattage......... 485 Warning light......434 Battery (12-volt battery) ..389 Brake assist ......301 Battery checking ....389 Brake Hold........ 223 If the 12-volt battery is Warning light......
Page 504 Alphabetical index Rear door child-protectors ..145 Removed electronic key Care battery precautions..... 409 Exterior........368 Seat belt precautions ....34 Interior........373 Seat heater precautions..349 Seat belts ......374 Trunk precautions ....151 Wheels and wheel Child-protectors....... 145 ornaments......
Page 505 Alphabetical index Drive information....... 98 Drive-start control (DSC) ..187 Daytime running light Sudden start restraint system ........227 control......... 187 Defogger Driver’s seat belt Rear window ......345 reminder light ......437 Windshield ......345 Driver’s seat position Dimensions ......476 memory ........
Page 506 Alphabetical index Emergency, in case of If a warning buzzer ECO Accelerator Guidance..112 sounds........ 434 Eco drive mode ......333 If a warning light turns on..434 Eco-friendly driving If a warning message is information......110 displayed ......439 Eco guide........
Page 507 Alphabetical index Energy monitor ......132 Engine Flat tire........445 ACCESSORY mode ..... 204 Floor mats ........26 Compartment ......382 Fluid Engine switch......203 Brake ........483 Hood ........380 Hybrid transmission ....482 How to start the Washer ......... 388 hybrid system .....
Page 508 Alphabetical index Hybrid system......71 Emergency shut off system ..76 Gauges........91 Energy monitor/ Glove box ......... 355 consumption screen ... 132 Grocery bag hooks ....360 EV drive mode ...... 209 High voltage components ..75 Hybrid System Indicator..93 Hands-free system Hybrid system precautions ..
Page 509 Alphabetical index Jack Lane Tracing Assist (LTA) ..266 Positioning a floor jack ..381 Language (multi- Vehicle-equipped jack... 446 information display)..102, 121 Jack handle ......446 Lever Jam protection function Auxiliary catch lever....380 Electronic sunshade....181 Hood lock release lever ..380 Panoramic moon roof....
Page 510 Alphabetical index Multi-information display......95, 106 Maintenance Drive information..... 98 Do-it-yourself maintenance ... 378 Dynamic radar Hybrid battery cruise control with (traction battery) full-speed range....284 air intake vent ..... 403 Eco-friendly driving Maintenance data ....476 information......110 Maintenance Language......
Page 511 Alphabetical index Paddle shift switches ..214, 215 Radar cruise control Panic mode....... 139 (dynamic radar cruise Panoramic moon roof....180 control with full-speed Door lock linked panoramic range) ........284 moon roof operation ... 182 Radiator ........387 Jam protection function..181 Radio Operation ......
Page 512 Retractor ......32 Rain-sensing windshield How to wear your seat belt ..30 wipers ......... 236 How your child should wear Toyota parking the seat belt ......32 assist-sensor ...... 315 Pregnant women, proper Service plug ....... 75 seat belt use ......33 Shift lever .........
Page 513 Alphabetical index Snow tires......... 340 Electronic sunshade Spare tire ........445 switch ......... 180 Inflation pressure ....484 Emergency flasher Storage location ....446 switch ......... 424 Spark plug ........ 481 EV drive mode switch ... 209 Specifications ......476 Fuel door opener switch ..
Page 514 Emergency towing ....427 Wattage ........ 485 Towing eyelet......431 Turn signal lights Trailer towing ......195 Replacing light Toyota Connected Services..66 bulbs....415, 418, 421 Toyota parking Turn signal lever ....218 assist monitor Wattage ........ 485 Toyota parking assist-sensor ......
Page 515 Alphabetical index Upper anchorage strap .....64 Warning buzzers USB charging ports ....363 Approach warning....293 USB memory Downshifting ......215 USB port Electric power steering system ........ 435 Lane departure alert function....... 271 Vanity lights ......361 Light reminder....... 228 Wattage.........
Page 516 Alphabetical index Washer........233 Checking ....... 388 Preparing and checking before winter....... 338 Switch ........233 Washing and waxing ....368 Wheels ........398 Replacing ......398 Size ........484 Window glasses....... 176 Window lock switch....176 Windows ........176 Power windows .....
Page 517 Certifications  Toyota Safety Sense...
Page 518 50 L (13.2 gal., 11.0 Imp. gal.) (Reference) Fuel type P. 478, 486 Cold tire inflation P. 484 pressure Engine oil capacity (Drain and refill — P. 479 reference) “Toyota Genuine Motor Oil” or equivalent Engine oil type P. 479...

Toyota CAMRY HYBRID Owner's Manual

Quick Links

Related Manuals for Toyota CAMRY HYBRID

Summary of Contents for Toyota CAMRY HYBRID

Table of Contents
