TP-Link XZ000-G3 Quick Installation Manual

Quick Installation Guide
1-Port Gigabit GPON Terminal
©2022 TP-Link
Connect the Hardware
Register the Terminal
Connect to the Internet
Power adapter
XZ000-G3
7109505590 REV2.0.1
If the PON LED is solid on, please skip to Connect to the Internet.
1
Connect your computer to the Terminal via an Ethernet cable.
POWER RESET LAN
2
Configure TCP/IP Properties manually on your computer.
If the Terminal's LAN IP address is 192.168.1.1, please type
in IP address 192.168.1.x (x is from 2 to 253), subnet mask
255.255.255.0, and default gateway 192.168.1.1.
3
Register the Terminal via a web browser.
A
Launch a web browser and type in http://192.168.1.1 in the
address bar. Use admin for both username and password to
log in to the Terminal.
Establish your internet connection according to your ISP's instructions.
Note: If you need assistance, contact your ISP.
POWER RESET LAN
1
Ethernet Cable
PON
http://192.168.1.1
Internet
PON
Terminal
2
3
B
Go to Network Setting > PON Certification. Enter the
GPON Password and/or GPON SN provided by your ISP
(Internet Service Provider) to register the Terminal and
click Save.
PON Certification
GPON Password
GPON Password(Notice: Maximum 10 ASCII characters)
GPON SN
GPON SN(Notice: Must be 16 Hexadecimal Numbers)
Enjoy!
Verify that the hardware connection
is correct by checking these LEDs.
Power: On
PON: On or Flashing
LOS: Off
admin
admin
Login
Old Password: (0)characters
New Password:
Save
Old SN:
New SN:
Save
