- Page 1 A XOR Uno 45134009 E N ⁄ Instructions for use ⁄ assembly instructions A XOR Uno D E ⁄ Gebrauchsanleitung ⁄ Montageanleitung 38951009 I N S T A L L A T I O N...
- Page 2 S A F E T Y N O T E S O P E R A T I O N (see page 12) Gloves should be worn during installation to prevent Hansgrohe recommends not to use as drinking crushing and cutting injuries. water the first half liter of water drawn in the The product may only be used for bathing, hygienic morning or after a prolonged period of non-use. and body cleaning purposes. The hot and cold supplies must be of equal pressures. I N S T A L L A T I O N I N S T R U C T I O N S ⁄ Prior to installation, inspect the product for transport damages. After it has been installed, no transport or surface damage will be honoured.
- Page 3 S I C H E R H E I T S H I N W E I S E R E I N I G U N G (siehe Seite 13) Bei der Montage müssen zur Vermeidung von B E D I E N U N G (siehe Seite 12) Quetsch- und Schnittverletzungen Handschuhe getragen werden.
- Page 4 red / rot (3 Nm)
- Page 5 < Ø34 mm Ø34 mm (3 Nm)
- Page 6 SW 9 mm SW 23 mm (4 Nm) 58085000 (max. 7 Nm)
- Page 7 58085000 (max. 7 Nm) (50 Ncm) (50 Ncm) > 2 min (2 Nm)
- Page 8 A XOR Uno 38951009 Ø28 Ø28 Ø47 Ø28 Ø28 94139007 94139000 G 1 / 2 Ø30 Ø30-34 Ø30 A XOR Uno 38951009 0,60 0,55 0,50 0,45 0,40 0,35 0,30 0,25 0,20 0,15 0,10 0,05 0,00 9 12 15 18 21 24 27 30 Q = l/min Q = l/sec...
- Page 9 A XOR Uno 45134009 Ø28 Ø28 Ø47 Ø28 Ø28 94139007 G 1 / 2 94139000 Ø30 Ø30-34 Ø30 A XOR Uno 45134009 0,60 0,55 0,50 0,45 0,40 0,35 0,30 0,25 0,20 0,15 0,10 0,05 0,00 9 12 15 18 21 24 27 30 Q = l/min Q = l/sec...
- Page 10 A XOR Uno 38951009 92958000 98201000 (14x1,5) 98197000 96319000 (20x1,5) 92646000 98486000 98189000 (14x2,5) 93804000 95366000 97158000 95290000 92956000 92907000 (33x2,5) 98932000 98146000 (25x1,5) 98817000 92957000 92913000 (200 mm) 92907000 (33x2,5) 98749000 92191000 (26x4) 93020000 92914000 92909000 (450 mm) (400 mm) 92905000 92909000 94139000 94139007...
- Page 11 A XOR Uno 45134009 92959000 98201000 (14x1,5) 96319000 98486000 98189000 93805000 (14x2,5) 92646000 95366000 97158000 98987000 92956000 92907000 (33x2,5) 98146000 98932000 (25x1,5) 92957000 98817000 92913000 (200 mm) 92907000 (33x2,5) 98749000 92191000 (26x4) 92909000 93020000 92914000 (450 mm) (400 mm) 92905000 92909000 94139000 94139007...
- Page 12 open / öffnen close / schließen hot / warm cold / kalt...
- Page 13 w w w . a x o r - d e s i g n . c o m / w w w . a x o r - d e s i g n . c o m / w w w .
- Page 16 A XOR ⁄ Hansgrohe SE Auestraße 5–9 77761 Schiltach Deutschland info@axor-design.com axor-design.com...
