Canon imagePROGRAF iPF815 Service Manual page 227

J2601
Pin Number Signal name
11 PCK
12 PANEL_5V
13 /PCS
J2403
Pin Number Signal name
1 GND
2 /MEDIA_R
3 RGV10(MEDIA5V)
4 /ATUKAIJO_IN
5 GND
6 MENT_SDA
7 MENT_SCL
8 GND
9 RGV28(UMF3V)
10 RVG17(VM_26V)
11 KYUINFAN_ALARM_IN
12 KYUINFAN_PWM_ON
13 GND
14 RGV17(VM_26V)
15 MISTFAN_R_ALARM
16 MISTFAN_PWM
17 GND
J3003
Pin Number Signal name
1 /MAKITORI_UNIT
2 /MAKITORI_LOCK_SENS
3 /MAKITORI_VCC_ON
4 MAKITORI_VM_ON
5 /MAKITORI_ENB
6 PHOTO_SENS_OUT
7 RGV17(VM_26V)
8 RGV17(VM_26V)
9 GND
10 GND
11 RGV29(UMF5V)
J2401
Pin Number Signal name
1 INKBENM1_AM
2 INKBENM1_AP
3 RGV8(SNS3V)
4 GND
5 /INKBEN_OPEN_R
6 /TANK_COVER_R
7 GND
8 RGV8(SNS3V)
9 GND
10 /INKBEN_CAM_R
J3201
Pin Number Signal name
1 TANK_CLK
2 GND
3 OUT_TANK_DAT8
4 TANK_+3.3V
5 OUT_TANK_DAT7
6 OUT_TANK_DAT6
IN/OUT Function
OUT Panel IC clock signal
OUT Power supply(+5V)
OUT Panel IC chip select signal
T-6-8
IN/OUT Function
- GND
IN Media sensor output signal
OUT Power supply(+5V)
IN Pinch roller pressure release swiych output signal
- GND
IN/OUT Maintenance cartridge ROM control signal (data)
IN/OUT Maintenance cartridge ROM control signal (clock)
- GND
OUT Power supply (+3.3V)
OUT Power supply(+26V)
IN Suction fan alarm signal
OUT Suction fan duty control signal
- GND
OUT Power supply(+26V)
IN Mist fan(R) alarm signal
OUT Mist fan duty control signal
- GND
T-6-9
IN/OUT Function
IN Media take-up paper detection sensor
IN Media take-up on/off sensor output signal
OUT Power supply ON signal
OUT Power supply(+26V)
OUT Media take-up drive enable signal
IN Media take-up paper detection sensor output signal
OUT Power supply(+26V)
OUT Power supply(+26V)
- GND
- GND
OUT Power supply(+5V)
T-6-10
IN/OUT Function
OUT Valve motor drive signal AM
OUT Valve motor drive signal AP
OUT Power supply(+3V)
- GND
IN Valve open/close detection sensor output signal
IN Ink tank cover switch output signal
- GND
OUT Power supply(+3V)
- GND
IN Agitation cam sensor output signal
T-6-11
IN/OUT Function
OUT Ink tank clock signal
- GND
IN/OUT Ink tank data signal 8
OUT Power supply(+3.3V)
IN/OUT Ink tank data signal 7
IN/OUT Ink tank data signal 6
Chapter 6
6-5
