GE Electric Dryer 02 Installation Instructions Manual

Installation
Instructions
BEFORE YOU BEGIN
Read these instructions completely and
carefully.
• IMPORTANT-
Save these instructions
for local inspector's use.
• IMPORTANT-
Observe all governing
codes and ordinances.
• Note to Installer -
instructions with the customer.
• Note to Customer - Keep these instructions
with your Owner's Manual for future
reference.
•
or discarded, remove the dryer door.
• Service information and the wiring diagram
are located in the control console.
• Do not allow children on or in the appliance.
Close supervision of children isnecessary
when the appliance is used near children.
• Install the dryer where the temperature is
dryer control system.
• Product failure due to improper installation
is not covered under the Warranty.
TOOLS YOU
WILL NEED
SLIP JOINT PLIERS
FLAT BLADE SCREWDRIVER
PHILLIPS SCREWDRIVER
LEVEL
Minimum Clearance Other Than Alcove or Closet Installation
Consideration must be given to provide adequate clearance for installation and service.
Printed in Mexico
Questions on Installation? Call: 800.GE.CARES (US)
or visit our Web site at: www.GEAppliances.com (US)
• To reduce the risk of severe injury or death, follow all installation
instructions.
•
• Install the clothes dryer according to these instructions and in accordance
with local codes.
• This dryer must be exhausted to the outdoors.
• Use only rigid metal 4" diameter ductwork inside the dryer cabinet and use
only UL approved transition ducting between the dryer and the home duct.
•
and installed in accordance with the instructions found in "Connecting
materials are known to collapse, be easily crushed, and trap lint. These
• Do not install or store this appliance in any location where it could be
exposed to water and or weather.
•
NOTE: Installation and service of this dryer requires basic
mechanical and electrical skills. It is your responsibility to contact
MATERIALS YOU WILL NEED
4" DIA. METAL DUCT
(RECOMMENDED)
4" DIA. FLEXIBLE METAL (SEMI-RIGID)
UL LISTED TRANSITION DUCT
(IF NEEDED)
KIT WX08X10077 (INCLUDES 2 ELBOWS)
4" DIA. FLEXIBLE METAL (FOIL TYPE)
UL LISTED TRANSITION DUCT
(IF NEEDED.)
WARNING
RISK OF FIRE
4" DUCT
4" DIA. METAL
CLAMPS (2)
ELBOW
OR
4" SPRING
CLAMPS (2)
DUCT TAPE
4" COVER PLATE (IF NEEDED
(KIT WE1M454)
Electric Dryer
02
SAFETY DRYER POWER
EXHAUST
GLASSES
HOOD
(NOT PROVIDED
UL RATED
120/240V,30A
WITH 3 OR 4 PRONGS.
IDENTIFY THE PLUG
3/4" STRAIN
TYPE AS PER THE
RELIEF
GLOVES
HOUSE RECEPTACLE
UL RECOGNIZED
BEFORE PURCHASING
LINE CORD.
234D2008P002
31-16726-1
CORD KIT
WITH DRYER)
03-14 GE
