Instructions for use
GB
English,1
WMBF 944
Contents
Installation, 2-3-4-5
Connecting the electricity and water supplies
Troubleshooting, 13-14
WASHING MACHINE
GB
1
Advertisement
Table of Contents
Related Manuals for Hotpoint WMBF 944
Summary of Contents for Hotpoint WMBF 944
-
Page 1: Table Of Contents
Precautions and tips, 7 General safety Disposal Description of the washing machine, 8-9 Control panel Display WMBF 944 Running a wash cycle, 10 Wash cycles and options, 11 Table of programmes and wash cycles Wash options Detergents and laundry, 12... -
Page 2: Installation
Installation ! Keep this instruction manual in a safe place 2. If the floor is not perfectly level, compensate for future reference. Should the appliance be for any unevenness by tightening or loosening the adjustable front feet (see figure); the angle sold, transferred or moved, make sure the of inclination, measured according to the instruction manual accompanies the washing... - Page 3 Connecting the drain hose • the supply voltage is included within the values indicated on the Technical Data Plate Connect the drain fixed on the machine. hose, without bending • the socket is compatible with the washing it, to a draining machine’s plug.
-
Page 4: The First Wash Cycle
Technical data If you are in any doubt regarding the electrical supply to your machine, consult a qualified Model WMBF 944 electrician before use. How to connect an alternative plug: width 59.5 cm The wires in this mains lead are coloured in... -
Page 6: Care And Maintenance
Care and maintenance Cutting off the water and Caring for the door and drum of electricity supplies your appliance • Turn off the water tap after every wash cycle. • Always leave the porthole door ajar in order This will limit wear on the hydraulic system to prevent unpleasant odours from forming. -
Page 7: Precautions And Tips
Precautions and tips This washing machine was designed and constructed in accordance with international safety regulations. The following information is provided for safety reasons and must therefore be read carefully. General safety • This appliance was designed for domestic use only. This appliance can be used by children •... -
Page 8: Description Of The Washing Machine
Description of the washing machine Control panel TEMPERATURE CLEANING LOCK ACTION button button button ON/OFF button DISPLAY START/PAUSE OPTION button and indicator SPIN button and WASH light Detergent dispenser drawer button indicator light CYCLE SELECTOR KNOB DELAY button Detergent dispenser drawer: used to dispense DELAY button: press to set a delayed start for the detergents and washing additives ( see “Detergents and... -
Page 9: Display
Display The display is useful when programming the machine and provides a great deal of information. The duration of the available wash cycles and the remaining time of a running cycle appear (the display will show the maximum duration of the cycle chosen, which may decrease after several minutes, since the effective duration of the programme varies depending on the wash load and the settings chosen);... -
Page 10: Running A Wash Cycle
Running a wash cycle For lightly-soiled garments or a more delicate treatment 1. SWITCH THE MACHINE ON. Press the button; of the fabrics, press button until the “Delicate” the START/PAUSE indicator light will flash slowly in a level is reached. The cycle will reduce drum rotation green colour. -
Page 11: Wash Cycles And Options
Wash cycles and options Table of programmes and wash cycles Detergents Max. Max. Description of the wash cycle temp. speed (°C) (rpm) CLEAN Plus Anti Stain 40° 1400 Anti Stain Quick 40° 1200 Whites 60° 1400 ... -
Page 12: Detergents And Laundry
Detergents and laundry Detergent dispenser drawer Whites: use this cycle 3 to wash white clothes. The programme is designed to maintain the brightness of white Successful washing results also depend on the correct clothes over time. Use powder detergent for best results. dose of detergent: adding too much detergent will not Anti Allergy: use programme 6 to remove major allergens necessarily result in a more efficient wash, and may in... -
Page 13: Troubleshooting
Troubleshooting Your washing machine could occasionally fail to work. Before contacting the Technical Assistance Service (see “ Service”), make sure that the problem cannot be solved easily using the following list. Problem: Possible causes / Solutions: The machine does not switch on. •... - Page 14 The machine is noisy. • There will always be some motor, pump and drum noise during spin. The machine wont spin properly. • Out of Balance detected when attempting to go into a spin cycle - If this happens the machine will continue to try to repeat the distribution of the load required before the machine will go into higher spin speeds - This will increase the programme time accordingly.
-
Page 15: Product Guarantee And Repair Information
Product Guarantee and Repair Information Guarantee Recycling and Disposal Information As part of Hotpoint’s continued commitment to 12 Months Parts and Labour Guarantee helping the environment, Hotpoint reserves the right Your appliance has the benefit of our manufacturer’s to use quality, recycled components to keep down guarantee, which covers the cost of breakdown customer costs and minimise material wastage. - Page 16 195131480.01 02/2015 - Xerox Fabriano Indesit Company Spa Viale Aristide Merloni, 47 60044 Fabriano (AN) Italy www.hotpoint.co.uk...
