Lorex CVC6930 Series Quick Start Manual

Camera Specifications
Image Sensor 1/4" Color
Video Format / Pixels NTSC: 640(H) x 480 (V)
Horizontal Resolution 420 TVL
Internal; 2:1 Interlace
Sync. & Scan. Systems
S/N Ratio > 48dB
Iris & Shutter Speed AES; 1/30 ~ 1/62,500 sec.
Minimum Illumination 0 LUX (IR LEDs on)
Video Output Comp. 1.0 Vpp @ 75ohm
Lens / Lens Mount 3.6 mm F1.8/ Fixed
FOV (diagonal) 64 Degrees
Termination Video: BNC Female
Power: Barrel Female
IR / Night Vision Range 18 IR LED/40 ft. / 12 m
Power Requirement 12V DC ±10%
Power Consumption 170 mA or 2W max
Operating Temp. -14°F ~ 122°F
(-10°C ~ 50°C)
Weight (with stand) 0.6 lbs. / 0.26 kg
Dimensions 2.6" x 4.2"" x 5.2"
WxLxH 66 mm x 107 mm x 132 mm
(with stand)
Dimensions
IT'S ALL ON THE WEB!
Product Information
Specification Sheets
User Manuals Software Upgrades
Firmware Upgrades
Quick Start Guides
VISIT
www.lorextechnology.com
Lorex Technologies Inc.
Copyright © 2010 Lorex Technologies Inc.
As our products are subject to continuous
improvement, Lorex reserves the right to
modify product design, specifications and
prices, without notice and without incurring
any obligation. E&OE
INDOOR / OUTDOOR
COLOR CAMERA
with Night Vision
MODEL: CVC6930 SERIES
QUICK START GUIDE
English Version 2.0
