WJ200 Series Inverter
Quick Reference Guide
 Single-phase Input 200V class
 Three-phase Input
 Three-phase Input
Manual Number: NT3251EX
May 2020
Hitachi Industrial Equipment Systems Co., Ltd.
200V class
400V class
Refer to the Instruction Manual for detail
