- Page 1 Circular Saw MODEL 5402 005426 I N S T R U C T I O N M A N U A L WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
-
Page 2: Specifications
SPECIFICATIONS Model 5402 Blade diameter 415 mm at 90° 157.5 mm Max. Cutting depth at 45° 106 mm 2,200 No load speed (min Overall length 615 mm Net weight 14 kg • Due to our continuing programme of research and development, the specifications herein are subject to change without notice. -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS ENA001-2 WARNING: When using electric tools, basic safety precautions, including the following, should always be followed to reduce the risk of fire, electric shock and personal injury. Read all these instructions before operating this product and save these instructions. For safe operations: tion and changing accessories. -
Page 4: Additional Safety Rules For Tool
ADDITIONAL SAFETY RULES FOR TOOL ENB036-4 Wear hearing protection. Use Rip Fence. Always use a fence or straight edge guide when Keep Guards In Place and In Working Order. ripping. Never wedge or tie lower guard open. Check 10. Guard Against Kickback. (Fig. 1 & 3) operation of lower guard before each use. - Page 5 control which could cause personal injury. Fig. 4 illustrates typical hand support of the saw. Fig. 6 17. Never attempt to saw with the circular saw held upside down in a vise. This is extremely danger- Fig. 4 ous and can lead to serious accidents. (Fig. 7) A typical illustration of proper hand support, workpiece support, and supply cord routing.
-
Page 6: Functional Description
FUNCTIONAL CAUTION: DESCRIPTION • Always be sure that the tool is switched off and unplugged before adjusting or checking function on the tool. Adjusting depth of cut 001347 CAUTION: • After adjusting the depth of cut, always tighten the lever securely. Loosen the lever on the depth guide and move the base up or down. - Page 7 • Use only the Makita wrench to install or remove the blade. To remove the blade, hold the outer flange with the wrench so that it cannot revolve, then use the hex wrench to loosen the hex bolt counterclockwise.
-
Page 8: Operation
005418 25.4 1. Mounting shaft 2. Inner flange 3. Outer flange 4. Hex socket head bolt 5. Saw blade OPERATION CAUTION: • Be sure to move the tool forward in a straight line gently. Forcing or twisting the tool will result in overheating the motor and dangerous kickback, possibly causing severe injury. -
Page 9: Maintenance
CAUTION: • These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose. - Page 10 Memo...
