Cooper Lighting PROfile AR60S Specification Sheet

60 Amp Busway - Surface Mounted
One or Two Circuit - 12V / 120V / 277V
AR60S
Constructed of extruded aluminum channel with a continuous
insulator. Continuous access slot allows fixtures to be
attached at any location, as close together or as far apart as
desired. Made for mounting direct to interior surfaces.
• INSTALLS FLUSH TO CEILING SURFACE - NO GAP
BETWEEN BUSWAY AND CEILING
• COMPATIBLE WITH ALL PROFILE SERIES FIXTURES
Busway is offered in three voltage types and in one or two
circuits. Voltage can be mixed in two circuit configurations,
for example: Two circuit channel with 12 Volts on one circuit
and 277 Volts on the second circuit. Each circuit is rated for
300 Volts maximum. The housing serves as a 100% capacity
ground.
A full selection of powerfeeds and connectors are available.
• Manufactured with 6000 series aluminum
• 300V Rating
• Continuous Access Slot
• Internally Polarized
• Solid Copper Conductors
• Up to 10' Support Intervals
• Durable Powder Coat Finish
U.S. Patent Number: 6,517,363
Item
❑ AR60S 60 Amp Busway Section
for Surface Mounting
AR60S
Ordering Example: AR60S - 20 - 2-12-277 - IS
Description: 60 Amp Busway Section for Surface Mounting - 20 foot length - 2 Circuit (12 Volts + 277 Volts) - Industrial Silver Finish
www.rsalighting.com
BWSF4
Busway Length Circuits / Voltage
❑ Specify Length
❑ 1-12
❑ 1-120
_______________
❑ 1-277
(from 1 to 20 feet in 6"
❑ 2-12-12
increments)
❑ 2-12-120
❑ 2-12-277
❑ 2-120-120
❑ 2-120-277
❑ 2-277-277
_____
RSA Lighting 9660-9700 Topanga Canyon Blvd. Chatsworth, CA 91311
Toll Free: 800-356-3030 • 818-349-3030 • Fax: 818-349-3031
®
©2004 RSA Lighting • All Rights Reserved • Specifications are subject to change without notice
Catalog #
Type
Project
u12 Volts
u u
❑ 12 Volts 1 Circuit ❑ 120 Volts • 1 Circuit
u u u u
❑ 12 / 12 Volts • 2 Circuit ❑ 12 / 120 Volts • 2 Circuit
l l
❑ 120 / 120 Volts • 2 Circuit ❑ 120 / 277 Volts • 2 Circuit
������� ���������
1 Circuit / 12 Volts
1 Circuit / 120 Volts
1 Circuit / 277 Volts
2 Circuit / 12 Volts + 12 Volts
2 Circuit / 12 Volts + 120 Volts
2 Circuit / 12 Volts + 277 Volts
2 Circuit / 120 Volts + 120 Volts
2 Circuit / 120 Volts + 277 Volts
2 Circuit / 277 Volts+ 277 Volts
������� ���������
l120 Volts n277 Volts
l
❑ 277 Volts • 1 Circuit
l
u u u u
❑ 12 / 277 Volts • 2 Circuit
l
n n
❑ 277 / 277 Volts • 2 Circuit
�����
�����
Finish
❑ WH White
❑ BK Black
❑ IS Industrial Silver
❑ PT Custom Finish
_____
�����
�����
www.cooperlighting.com
n
n
n
REV 051604
