19MD357B LCD TV
built-in DVD player
with DivX ®
Quick Use Guide Inside!
Guide d'usage Rapide Incluse!
Guía de Uso Rápido Incluida!
For Customer Use / À l'usage du client /
Para Uso del Cliente
Model/Modle/ModeloNo. :
Serial/Srie/Serie No.
:
P41T9015-813-1A

Advertisement

Table of Contents
loading

Related Manuals for Magnavox 19MD357B

Summary of Contents for Magnavox 19MD357B

  • Page 1 User Manual Manuel de l’utilisateur Guía del usuario 19MD357B LCD TV built-in DVD player with DivX ® Quick Use Guide Inside! Guide d’usage Rapide Incluse! Guía de Uso Rápido Incluida! For Customer Use / À l’usage du client / Para Uso del Cliente Model/Modle/ModeloNo.
  • Page 2 (Need a Cable? Philips has them at: www. shopping.philips.com/cables) Comment réaliser une bonne connexion (Besoin d’un câble ? Philips vous en propose à l’adresse suivante : www.shopping.philips.com/cables) Cómo realizar la mejor conexión (¿Necesita un cable? Philips lo tiene en: www.shopping.philips.com/cables)
  • Page 3 DC IN DC IN HDMI HDMI S-VIDEO S-VIDEO PC IN PC IN 19MD357B Écouteurs 75 / RF AV1 - Vidéo composante (YPbPr), Entrée audio G/D AV2 - Vidéo composite (entrée Vidéo) S-vidéo, entrée audio G/D Ordinateur - VGA, Audio HDMI Entrée CA...
  • Page 4 Set-Top Box to TV Boîtier de décodage vers téléviseur De la caja superior o caja de cable al TV HDMI OR/OU/O DVD Player/Recorder to TV Lecteur DVD/Enregistreur DVD vers téléviseur Del reproductor o grabador de DVD al TV HDMI Cover & Connection 3 HDMI PC IN HDMI...
  • Page 5 DVD Player or Recorder toTV Lecteur DVD ou Enregistreur vers téléviseur Del reproductor o grabador de DVD alTV Component Video Input /Entrée vidéo composant /Entrada de video componente DVD Player/Recorder/VCR to TV Lecteur DVD/Enregistreur DVD/Magnétoscope vers téléviseur Del reproductor/grabador de DVD/VCR al TV S-Video /S-Vidéo...
  • Page 6 DVD Player/Recorder/VCR to TV Lecteur DVD/Enregistreur DVD/Magnétoscope vers téléviseur Del reproductor/grabador de DVD/VCR al TV Composite Audio-video /Audio-Vidéo composite /Audio-Video compuesto Video Camera /Games Console to TV Caméra vidéo/Console de jeux vers téléviseur De la cámara de video/ Consola de juegos al TV Composite Audio-video /Audio-Vidéo composite /Audio-Video compuesto...
  • Page 7 Audio to Hi-fi System (Digital) Audio vers chaîne haute fidélité (Numérique) Audio al sistema Hi-fi (Digital) SPDIF PC connects to TV (as PC monitor) L’ordinateur se connecte sur un téléviseur (en tant que moniteur d’ordinateur) El computador (PC) se conecta al televisor (como monitor del computador).

  • Page 8: Serial No

    Return your Product Registration Card or register online at www.magnavox.com/usasupport today to get the very most from your purchase. Registering your model with MAGNAVOX makes you eligible for all of the valuable benefits listed below, so don’t miss out. Complete and return your Product Registration Card at once, or register online at www.magnavox.com/usasupport to ensure: *Proof of Purchase Returning the enclosed card...

  • Page 9: Important Safety Instructions

    Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with a dry cloth. Do not block any of the ventilation openings. Install in accordance with the manufacturers instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifi...

  • Page 10: Precaution

    Precaution ADDITIONAL SAFETY PRECAUTIONS • ENSURE that LCD TV stand is tightened properly to the set on the right way of tightening of the screw of the stand to the set. Improper tightening of screw may render the set unsafe. •...

  • Page 11: Table Of Contents

    TV’s model and serial number located on a sticker on the front of this User Manual or on the back side of the TV. Model: 19MD357B Serial No: Care of the screen See Tips, p. 45 End of life directives - Recycling Magnavox has paid a lot of attention to producing an environmentally friendly product.

  • Page 12: Preparation

    Preparation ANTENNA ANTENNA CABLE CABLE CABLE OR ANTENNA CABLE OR ANTENNA ANTENNA ANTENNA CABLE CABLE OUTPUT /OUT (TO TV) OUTPUT /OUT (TO TV) Cable box Do not insert the power plug in a wall socket before all connections are made. Place the TV on a solid surface.
  • Page 13 ANTENNA CABLE OUTPUT /OUT (TO TV) Cable box ANTENNA HDMI VIDEO S-VIDEO PC IN CABLE CABLE OR ANTENNA AV2: L+R+VIDEO SPLITTER Cable box Watching cable TV programs that don’t require the use of a cable box. Since you’ve connected the cable TV signal directly to the TV’s tuner, you can also watch unscrambled programs by simply tuning to the desired channel;...

  • Page 14: Remote Control

    ANTENNA CABLE CABLE OR ANTENNA ANTENNA CABLE CABLE OR ANTENNA OUTPUT Note: The first time /OUT (TO TV) (and only the first time) you turn on your set you see an installation introduction screen. The installation procedure consists of a series of screens that guide you through the process.

  • Page 15: Use Of The Remote Control-Tv

    Use of the remote control-TV Note: Pressing most buttons once will activate the assigned function. Pressing a second time will de-activate it. When a button enables multiple options, a small list will be shown. Press repeatedly to select the next item in the list. The list will be removed automatically after six seconds or press OK to remove immediately.
  • Page 16 FORMAT Press this button to display a list of available display formats. Available display formats are determined by the type of signal you are receiving. To choose the display format you prefer, press the FORMAT button repeatedly: Automatic, Super Zoom, 4:3, Movie expand 14:9, Movie expand 16:9, 16:9 subtitle and Widescreen.

  • Page 17: Use Of The Remote Control-Dvd

    Use of the remote control-DVD Press the “SOURCE” button repeatedly to select source DVD to activate DVD function. Make sure the source “DVD” is selected. DISC MENU Enter the disc contents menu. Switches on or off the playback control mode (for VCD version 2.0 only) AUDIO Select the DVD audio language.

  • Page 18: Buttons On The Top Of The Tv

    Buttons on the top of the TV PLAY/ EJECT STOP PAUSE Buttons on the DVD base PLAY/ EJECT STOP PAUSE Should your remote be lost or broken you can still change some of the basic settings with the buttons on the top of your TV. Press the power switch Press: •the + VOL -button to adjust volume;...

  • Page 19: To Use The Menus

    To use the menus Introduction When you use a menu or take an action, convenient instructions, help texts and messages will be displayed on your TV. Please, follow the displayed instructions and read the help text on the specifi c item highlighted. The color buttons perform different actions, when using on screen menu.

  • Page 20: Tv Menu-

    TV menu-Installation Settings Installation Language English Language Français Autoprogram Español Source Clock Weak channel installation Current software info Reset AV settings Info Settings I Installation Autoprogram Antenna Antenna Start now Cable Info Television Installation You can now start automatic installation. This procedure can take more than half an hour.

  • Page 21: Weak Channel Installation

    Note: Digital Channel selection delay Due to the tuning complexity of subchannel digital programming, the time to select and view a digital channel may take slightly longer than what the viewer is normally accustomed to (as compared to analog channel programs). Digital channel broadcasts contain program and system data information that must be processed before the channel selection can be displayed.

  • Page 22: Digital Audio Out

    Settings Installation Source Language Autoprogram Source Clock HDMI Weak channel installation Current software info Reset AV settings Info Settings Installation Clock Language Autoprogram Source CVBS Clock HDMI Weak channel installation S-VIDEO PC IN Current software info Reset AV settings HDMI Info Settings AV2:...

  • Page 23: Reset Av Settings

    Settings Installation Reset AV settings Language Start now Autoprogram Source Clock Weak channel installation Current software info Reset AV settings Info Reset AV settings This function allows you to reset most of the picture and sound settings to their default factory levels. Select Reset AV settings with the cursor down key.

  • Page 24: Features Menu

    TV menu-Features Settings Features Picture Closed captions Sound Caption service Features Digital caption service Digital caption options Parental Control Installation Preferred channels Exit Sleeptimer Info Settings Features Closed captions Closed captions Caption service Digital caption service On during mute Digital caption options Preferred channels Sleeptimer Info...

  • Page 25: Digital Caption Options

    Settings Features Digital caption service Closed captions CS-1 Caption service CS-2 Digital caption service CS-3 Digital caption options CS-4 Preferred channels CS-5 Sleeptimer CS-6 Info Settings Features Digital caption options Closed captions Reset to default Caption service Size Digital caption service Style Digital caption options Text...
  • Page 26 Settings Features Preferred channels Closed captions Caption service Digital caption service Digital caption options Preferred channels Sleeptimer Info Settings Features Sleeptimer Closed captions Caption service Digital caption service Digital caption options Preferred channels Sleeptimer Info Preferred channels A channel, when installed, is marked as preferred by default and added to the channel list.

  • Page 27: Picture Menu

    TV menu-Picture & Sound Settings Picture Picture Smart picture Sound Contrast Features Brightness Parental Control Color Installation Sharpness Exit Color temperature Tint Noise reduction Info Settings Picture Smart picture Smart picture Personal Contrast Rich Brightness Natural Soft Color Sharpness Power saver Color temperature Tint Noise reduction...

  • Page 28: Sound Menu

    Settings Sound Picture Smart sound Sound Sound mode Features Alternate audio Digital audio language Parental Control Installation Exit Info Settings Sound Smart sound Personal Smart sound Sound mode Speech Alternate audio Movies Digital audio language Info Sharpness This will adjust the sharpness of fi ne details in the picture. Color temperature This will increase or decrease Warm (red) and Cool (blue) colors to suit personal preferences.

  • Page 29: Sound Mode

    Settings Sound Sound mode Smart sound Mono Sound mode Stereo Virtual surround Alternate audio Digital audio language Info Settings Sound Alternate audio Smart sound Main Sound mode Alternate audio Digital audio language Info Settings Sound Digital audio language Smart sound English Sound mode Français...

  • Page 30: Parental Control Menu

    TV menu-Parental Control Settings Features Picture Channel lock Sound TV ratings lock Features Movie ratings lock Parental Control Region ratings lock Installation Clear Regions Lock Exit Change PIN Info Settings Parental control Channel lock Please enter your PIN Channel lock TV ratings lock Movie ratings lock Region ratings lock...
  • Page 31 Age-based Rating Content-based Rating none None none TV-Y none TV-Y7 (FV) Fantasy Violence TV-G none TV-PG (D) Dialog (L) Language (S) Sex (V) Violence TV-14 (D) Dialog (L) Language (S) Sex (V) Violence TV-MA (L) Language (S) Sex (V) Violence TV-Y TV-Y7 TV-Y7-FV...
  • Page 32 Settings Parental control Movie ratings lock Please enter your PIN Channel lock TV ratings lock Movie ratings lock Region ratings lock Settings I Parental control Clear Regions Lock Movie ratings lock Change PIN Channel lock TV ratings lock Movie ratings lock Info Region ratings lock Clear regions lock...

  • Page 33: Change Pin

    Settings Parental control Region ratings lock Please enter your PIN Channel lock TV ratings lock Movie ratings lock Region ratings lock Clear Regions Lock Settings I Parental control Change PIN Region ratings lock EntireAudience EntireAudience None Dialogue TV-G This allows you to control access to individual programs based on their Language TV-PG broadcasted regional rating.

  • Page 34: Dvd Menu

    DVD menu Settings Installation Language English Language Francais Source Reset AV settings Espanol Info Settings Installation Source Language Source Disc operations Reset AV settings HDMI IMPORTANT ! -Depending on the DVD or VIDEO CD, some operations may be different or restricted. -Do not put any objects other than disc in the disc player.
  • Page 35 Power PLAY/ EJECT STOP PAUSE Settings Installation Source Language Source Reset AV settings DivX VOD HDMI Info Playing discs Press the “SOURCE” button to select source DVD function. Make sure the source “DVD” is selected. Note: Make sure the TV power is Insert a disc into integrated DVD player.
  • Page 36 Selecting track/chapter (DVD/SVCD/VCD/CD) Press briefly during playback to go to the next chapter/ track. Press to go to the previous track (VCD/CD) or return to the beginning of the current chapter (DVD/SVCD). Subtitles Press SUBTITLE repeatedly to select different subtitle languages.
  • Page 37 00:15 04:54 192kpbs 003/006 AAAA BBBB CCCC DDDD EEEE FFFF 00:00 00:00 002/005 \PPPP CCCC DDDD EEEE FFFF GGGG DivX 00:00 00:00 002/005 \PPPP CCCC DDDD EEEE FFFF GGGG Forward/Reverse searching (DVD/SVCD/VCD) Press during playback to select the required speed: 2X, 4X, 8X, 16X or 32X (backward or forward).

  • Page 38: Playing A Divx Disc

    Special for JPEG picture CD When pictures are in “Slide show”, press STOP key and the screen will enter in “Preview” mode. Repeat (MP3/DivX/JPEG picture CD) – Press REPEAT continuously to access different ‘Play Mode’. • Shuffle: keep to play all files irregularly and no repeats.

  • Page 39: Picture Menu

    DVD menu-Picture & Sound Settings Picture Picture Smart picture Sound Contrast Parental Control Brightness Installation Color Exit Sharpness Color temperature Tint Noise reduction Info Settings Picture Smart picture Smart picture Personal Contrast Rich Brightness Natural Soft Color Sharpness Power saver Color temperature Tint Noise reduction...

  • Page 40: Sound Menu

    Sound Settings Picture Smart sound Sound Virtual Surround Parental Control Installation Exit Info Settings Smart sound Sound Personal Smart sound Speech Virtual Surround Movies Info Sharpness This will adjust the sharpness of fi ne details in the picture. Color temperature This will increase or decrease Warm (red) and Cool (blue) colors to suit personal preferences.
  • Page 41 Settings Sound Virtual Surround Smart sound Virtual Surround Info Virtual sound Adds greater depth and dimension to DVD sound.

  • Page 42: Parental Control Menu

    DVD menu-Parental Control Settings Parental Control Picture Movie ratings lock Sound Change PIN Parental Control Installation Exit Info Settings Parental control Movie ratings lock Please enter your PIN Movie ratings lock Change PIN Settings I Parental control Movie ratings lock Movie ratings lock Change PIN Info...
  • Page 43 Settings Parental control Change PIN Movie ratings lock Please enter your PIN Change PIN Here you can change the personal 4-digit access PIN that is used in the different lock functions of the TV. Important: you have forgotten your PIN! Select Change PIN in the Menu preferences menu and press the cursor right key.
  • Page 44 Press the OK button to erase settings and reset them to their default values. DivX VOD code Philips provides you with the DivX VOD (Video On Demand) registration code that allows you to rent and purchase videos using the DivX VOD service.

  • Page 45: Pc Menu

    PC menu-Installation Settings Installation Language English Language Français Source Picture adjustment Español Factory reset Info Settings Settings Installation Source Language Source Picture adjustment Factory reset HDMI Info Settings Installation Picture adjustment Auto adjust Language Manual adjust Source Picture adjustment Factory reset Info Settings Installation...

  • Page 46: Picture Menu

    PC menu-Picture Settings Picture Picture Contrast Sound Brightness Color temperture Installation Picture format Exit Info Settings Picture Color temperture Contrast Normal Brightness Warm Color temperture Cool Picture format Info Settings Picture Picture format Contrast Full screen Brightness Color temperture Picture format Info Picture menu Select Picture in the TV Settings menu.

  • Page 47: Sound Menu

    PC menu-Sound Settings Sound Picture Smart sound Sound Virtual surround Installation Exit Info Settings Sound Smart sound Personal Smart sound Speech Virtual surround Movies Info Settings Sound Virtual surround Smart sound Virtual surround Info Sound menu Select Sound in the TV Settings menu. Press the cursor right key to enter the sound menu.

  • Page 48: Record With Your Recorder

    Record with your recorder Recorder VIDEO To select connected devices Record a TV program You can record a TV program using your recorders tuner without affecting your TV. Select the channel number on your recorder. Set your recorder to record. See the handbook for your recorder.

  • Page 49: Trouble Shooting Tips

    Trouble Shooting Tips Symptoms Items to Check and Actions to follow “Ghost” or double • This may be caused by obstruction to the antenna due to high rise buildings or hills. images Using a highly directional antenna may improve the picture. No power •...

  • Page 50: Trouble Shooting Tips-Dvd

    Trouble Shooting Tips- DVD Symptoms Items to Check and Actions to follow No picture • Refer to your TV’s manual for correct Video In channel selection. Change the TV channel until you see the DVD screen. • Check if the TV is switched on. Distorted picture •...

  • Page 51: Glossary

    SDTV: 480i - The picture is 704x480 pixels, 480p - The picture is 704x480 pixels. HDTV: 720p - The picture is 1280x720 pixels, 1080i - The picture is 1920x1080 pixels, 1080p - The picture is 1920x1080 pixels. SPDIF SPDIF (Sony and Philips Digital Interconnect Format) is highly recommended for high quality digital sound output.

  • Page 52: Care And Cleaning

    Care And Cleaning WARNING concerning stationary images on the TV Screen: Do not leave fixed images on the screen for extended periods of time. This can cause uneven aging of the LCD panel. Normal use of the TV should involve viewing of programs that have constantly moving or changing images. Do not leave moving images on screen for extended periods of time.

  • Page 53: Regulatory

    FEDERAL COMMUNICATIONS COMMISSION (FCC) NOTICE (U.S. ONLY) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 54 Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio or televi- sion technician for help. Magnavox Philips Consumer Electronics North America P.O. Box 671539 Marietta, GA 30006-0026 1-888-PHILIPS (744-5477) Modifications- The FCC requires the user to be notified that any...

  • Page 55: Specification

    Specification - TV 19MD357B PICTURE/ DISPLAY Widescreen Aspect ratio Progressive Scan Picture Display Smart Picture (5 modes) Picture Enhancement Personal, Rich, Natural, Soft, Power saver SOUND Output Power (RMS) 2x3W Sound Enhancement Smart Sound Sound Mode Mono, Stereo, Virtual Surround...

  • Page 56: Limited Warranty

    WARRANTY COVERAGE: MAGNAVOX warranty obligation is limited to the terms set forth below. WHO IS COVERED: Magnavox warrants the product to the original purchaser or the person receiving the product as a gift against defects in materials and workmanship as based on the date of original purchase (“Warranty Period”) from an Authorized Dealer.
