Summary of Contents for AEG T6DB60378

  • Page 1 T6DB60378 User Manual Tumble Dryer USER MANUAL...

  • Page 2: Table Of Contents

    1369/2017........................21 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.

  • Page 3: Safety Information

    ENGLISH SAFETY INFORMATION Before beginning the installation and use of this appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.
  • Page 4 1.2 General Safety Do not change the specification of this appliance. • If the tumble dryer is put on top of a washing • machine, use the stacking kit. The stacking kit, available from your authorized vendor, can be used only with the appliance specified in the instructions supplied with the accessory.

  • Page 5: Safety Instructions

    ENGLISH Items that have been soiled with substances such as • cooking oil, acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes and wax removers should be washed in hot water with an extra amount of detergent before being dried in the tumble dryer. Items such as foam rubber (latex foam), shower caps, •...
  • Page 6 2.4 Care and cleaning • Do not pull the mains cable to disconnect the appliance. Always pull the mains plug. WARNING! • Do not touch the mains cable or the Risk of injury or damage to mains plug with wet hands.

  • Page 7: Product Description

    ENGLISH 3. PRODUCT DESCRIPTION Water container Airflow slots Control panel Condenser lid Appliance door Condenser cover Filter Adjustable feet Rating plate For ease of loading laundry or ease of installation the door is reversible. (see separate leaflet).

  • Page 8: Control Panel

    4. CONTROL PANEL Program dial Ein/Aus button Display Programs Start/Pause button Options 4.1 Display Symbol on the display Symbol description laundry maximum load delay start option on delay start selection (30min-20h) cycle time indication buzzer off...

  • Page 9: Programs

    ENGLISH Symbol on the display Symbol description child lock on laundry dryness: iron dry, cupboard dry, cupboard dry +, extra dry drain the water container indicator: clean the filter indicator: check the condenser indicator: time dry option on time programme selection (10min-2h) drying phase indicator: crease guard phase...
  • Page 10 Programme Properties / Fabric mark Load Single or double duvets and pil- Daunen 3 kg lows (with feather, down or syn- thetic fillings). Leisure clothing such as jeans, sweat-shirts of different material Jeans 7 kg thicknesses (e.g. at the neck, cuffs and seams).

  • Page 11: Options

    ENGLISH 5.2 Consumption data Energy consump- Program Spun at / residual humidity Drying time tion Baumwolle ECO7 kg 1400 rpm / 50% 107 min 3,63 kWh Schranktrocken 1000 rpm / 60% 127 min 4,23 kWh 1400 rpm / 50% 79 min 2,71 kWh Bügeltrocken 1000 rpm / 60%...

  • Page 12: Before First Use

    6.5 Zeitwahl Time of delay is on the display (e.g. if the program has to start after 12 For cottons, synthetics and mixed. Lets hours.) the user to set drying time from 3. To activate Zeitvorwahl option, touch minimum 10 min to maximum of 2 hours the Start/Pause button.
  • Page 13 ENGLISH 8.2 Loading the laundry 8.5 Setting a programme CAUTION! Ensure the laundry is not trapped between the appliance door and the rubber seal. 1. Pull open the appliance door. 2. Load the laundry one item at a time. 3. Close the appliance door. 8.3 Turning on the appliance Use the programme dial to set the programme.

  • Page 14: Hints And Tips

    8.7 Child lock option To start the program: Touch the Start/Pause button. The child lock can be set to prevent The appliance starts and the LED above children from playing with the appliance. the button stops flashing and stays on.

  • Page 15: Care And Cleaning

    ENGLISH • Always keep the airflow slots at the 5. To memorise the setting touch and bottom of the appliance clear. hold down the Trockengrad and • Make sure there is good airflow where Knitterschutz buttons at the same the appliance is to be installed. time for approximately 2 seconds.
  • Page 16 3. Use a moist hand to clean the filter. 2. Pull the plastic connection out and drain the water into a basin or equivalent receptacle. 3. Push the plastic connection back in and place the water container back into position.
  • Page 17 ENGLISH 7. Put the condenser back inside the bottom compartment. 8. Close the condenser lid. 9. Lock 2 levers until they snap. 10. Close the condenser cover. 10.4 Cleaning the drum WARNING! Disconnect the appliance before you clean it. 4. Lower the condenser lid. Use a standard neutral soap detergent to clean the inner surface of the drum and drum lifters.

  • Page 18: Troubleshooting

    11. TROUBLESHOOTING Possible cause Remedy Problem The tumble dryer is not connected Connect it to the mains socket. to the mains supply. Check the fuse in the fuse box (do- mestic installation). The door is open. Close the door.

  • Page 19: Technical Data

    ENGLISH Possible cause Remedy Problem Unexpected du- The drying duration is calculated This is automated - the appliance ration time ap- according to load size and damp- is working correctly. pears on the dis- ness. play. The water container is full. Drain the water container, push A programme is inactive.
  • Page 20 Drum volume 104 l Maximum load volume 7 kg Voltage 230 V Frequency 50 Hz Sound power level 65 dB Total power 2800 W Energy efficiency class Energy consumption on the standard cotton 4,23 kWh programme with the full load.

  • Page 21: Accessories

    ENGLISH 13. ACCESSORIES 13.1 Stacking kit Accessory name: DK11. Available from your authorised vendor (can be attached to some types of tumble dryer) For thorough draining of the condensed water into a basin, siphon, gully, etc. After installation, the water container is drained automatically.
  • Page 22 Trade Mark Model T6DB60378, PNC916097942 Rated capacity in kg Air vented or condenser tumble dryer Condenser Energy efficiency class Energy consumption in kWh per year, based on 160 drying cy- 503,50 cles of the standard cotton programme at full and partial load, and the consumption of the low-power modes.
  • Page 23 ENGLISH Sound power level in dB Built in appliance Y/N The information given in the chart above is compliant with the EU Commission regulation 392/2012 implementing directive 2009/125/EC. 15. ENVIRONMENTAL CONCERNS appliances marked with the symbol Recycle materials with the symbol with the household waste.
  • Page 24 www.aeg.com/shop...
