OLED Display
User Manual
AG276QZD
www.aoc.com
©
2023 AOC.All Rights Reserved
Based on the characteristics of OLED products, it is recommended
that you follow the user manual for screen maintenance to reduce
the risk of image retention.
1

Advertisement

Table of Contents
loading

Related Manuals for AOC AGON PRO AG276QZD

Summary of Contents for AOC AGON PRO AG276QZD

  • Page 1 Machine Translated by Google OLED Display Based on the characteristics of OLED products, it is recommended User Manual that you follow the user manual for screen maintenance to reduce the risk of image retention. AG276QZD www.aoc.com © 2023 AOC.All Rights Reserved...

  • Page 2: Table Of Contents

    Machine Translated by Google safety ......................................1 Logo Conventions ......................................1 Power supply ..................................2 Installation ......................................3 Cleaning ....................................4 Others ........................................5 settings ..........

  • Page 3: Safety

    Machine Translated by Google Safety logo convention The following subsections describe the notation conventions used in this document. Notes, Cautions and Warnings In this guide, blocks of text may have icons and be printed in bold or italics. These blocks of text are Notes, Notes, and Warnings, as follows: Note: A caution indicates important information that helps you make better use of your computer system.

  • Page 4: Supply

    Machine Translated by Google power supply The monitor should only be operated from the type of power source indicated on the label. If you are not sure about the type of power supplied to your home, check with your supplier or local power company. The monitor comes with a three-point grounding plug, one with a third (ground) pin.

  • Page 5: Installation

    Machine Translated by Google Install Do not place the monitor on an unstable cart, platform, tripod, stand or table. If the monitor falls, personal injury may result and serious damage to the product may result. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with this product.

  • Page 6: Cleaning

    Machine Translated by Google clean Clean the cabinet regularly with a cloth. Stains can be scrubbed with soft cleaners, not harsh cleaners, which can corrode the product case. When cleaning, do not allow cleaning agents to get into the product. The cloth should not be too rough as it will scratch the surface of the screen. Disconnect the power cord before disposing of the product.

  • Page 7: Others

    Machine Translated by Google other If the product emits a strange smell, strange sound or smoke, immediately disconnect the power plug and contact a service center. Make sure the ventilation holes are not blocked by tables or curtains. Please do not use the monitor under vibrating vortex or high impact conditions during operation. Please do not knock or drop the monitor while it is being operated or transported.
  • Page 8 Power Adapter power cable The supplied signal cables (DP, HDMI and USB cables) vary by country. Please check with your local dealer or AOC branch for confirmation. Note: Please keep the wall hanging iron parts and screws properly for future use.

  • Page 9: Brackets And Bases

    Machine Translated by Google Mounting Brackets and Bases Please follow the steps below to set up or remove the base. Install: tear down: Wall hanging iron parts: M4x10mm 100mm 100mm Wall hanging iron screw specification: M4*10mm Base screw specification: M6*13mm (effective thread 5.5mm) M=4.0Max M4-P0.7 L=10+0...
  • Page 10 Machine Translated by Google screen care Based on the characteristics of the OLED screen, please perform screen maintenance according to the following requirements to reduce the risk of image retention. Damages caused by failure to comply with the following instructions will not be eligible for free warranty service. •...
  • Page 11 Machine Translated by Google • When the monitor has been running for 4 hours in total, it will automatically perform screen compensation correction and image retention elimination after pressing the button to turn off or enter the standby state for 2 hours. The monitor will automatically run the screen compensation correction first, and then run the image sticking removal.
  • Page 12 Machine Translated by Google Adjust the viewing angle In order to achieve the best viewing effect, it is recommended that you face the front of the monitor and adjust the viewing angle according to your personal preferences. When changing the angle of the monitor, please support the arm so that it does not touch the monitor.
  • Page 13 Machine Translated by Google connect monitor Cable connections on the back of the monitor: 1. Power supply 2. HDMI 1 3. HDMI 2 4. DP1 5. DP2 6. USB upstream 7. USB3.2 Gen1 downstream + fast charge x1 USB3.2 Gen1 downstream x1 8. Headphone jack Connecting to a computer: 1.
  • Page 14 Machine Translated by Google G-SYNC Compatible function 1. This product supports G-SYNC Compatible function. G-SYNC Compatible function can run under DP interface. 2. To enjoy the perfect gaming experience brought by the G-SYNC function, you need to purchase an NVIDIA GPU graphics card that supports the G-SYNC function separately. G-SYNC system requires a desktop computer connected to a G-SYNC monitor: Supported graphics cards: G-SYNC functionality requires an NVIDIA GeForce®...

  • Page 15: Function

    Machine Translated by Google Adaptive-Sync function 1. This product supports Adaptive-Sync function. Adaptive-Sync function can run under HDMI/DP interface. 2. Compatible video card models are recommended as follows. Compatible graphics card models are constantly being updated, please consult the graphics card manufacturer for the actual situation, or visit https://www.amd.com for inquiries: graphics card •...

  • Page 16: Hdr

    Machine Translated by Google Compatible with input signals in HDR10 format. The monitor is automatically HDR enabled, but you need a compatible player and content. For information and content on HDR compatible devices, please contact the device manufacturer and content provider. When you don't want the HDR function to start automatically, please select "Off". Display settings: 1.

  • Page 17: Adjusting The Monitor

    Machine Translated by Google adjust monitor hotkey 1 Source switch/up 2 crosshairs/down 3 game modes/reduce/left 4 E-sports atmosphere light/increase/right 5 Power switch/menu/select Power Switch / Menu / Select When the display is off, press this key to turn on the display. When the monitor is on, press this key to activate the OSD menu or confirm function adjustment;...

  • Page 18: Settings

    Machine Translated by Google OSD settings OSD Button Guide Enter Move Exit Confirm: Use the Enter key to enter the next level of OSD Move: Use the Left/Up/Down keys to move the OSD Select Exit: Use the Right key to exit the OSD Enter Move Exit...
  • Page 19 Machine Translated by Google Enter Select Confirm: Use the Enter key to exit the OSD to the previous OSD Select: Use the Up/Down keys to adjust the OSD settings Enter Select Confirm: Use the Enter key to exit the OSD to the previous OSD Select: Use the Left/Right keys to adjust the OSD settings...
  • Page 20 Machine Translated by Google Basic and simple instructions on the control keys. PIP Seÿng Color Setup PIP Seÿng Audio Light FX Audio Extra Light FX OSD Setup Enter Move Exit Enter Move Exit 1) Press the Menu button to activate the OSD window.

  • Page 21: Settings)

    Machine Translated by Google Game Settings _ Game Setting Game Mode Shadow Control Shadow Boost Game Color Sniper Scope G-SYNC Low Input Lag Frame Counter Exit Enter Select Turn off Game Mode. Play FPS (First Person Shooter) games. Improve subject black level details. Playing RTS (real-time strategy) games, the image quality can be improved.
  • Page 22 Machine Translated by Google Turning off the frame buffer reduces input On (open) / Low input Lag lag. Note: Low input lag can be adjusted when the resolution is QHD 60Hz/ 120Hz/240Hz, and PIP/PBP, sniper scope and other functions are turned off.
  • Page 23 Machine Translated by Google Luminance Luminance Contrast Brightness ECO Mode Standard Gamma Gamma1 Exit Enter Select Contrast 0-100 Contrast adjustment. (contrast) Brightness 0-100 Backlight adjustment. Standard standard mode. Energy saving Text (energy saving) Internet (network) Eco Mode mode. network Game (brightness mode.
  • Page 24 Machine Translated by Google Note: When the "HDR Mode" is set to non-off, the "Contrast", "Brightness Profile", and "Gamma" items cannot be adjusted. When "HDR" is set to non-off, other items under "Brightness" cannot be adjusted. When the "Color Space" under "Color Settings" is set to "sRGB" or "DCI-P3", the "Contrast", "Brightness Profile", "Gamma", "HDR"/"HDR Mode" items cannot be adjusted .
  • Page 25 Machine Translated by Google PIP Setting (PIP setting) Off / PIP / PBP Close or enable PIP, PBP function. Main Source Select a primary screen source. (main source) Sub Source Select a secondary screen source. Size Small/Middle/large Select the secondary screen size. Right-up Position Right-down (lower right)
  • Page 26 Machine Translated by Google Color Setup Color Setup LowBlue Mode Warm Color Temp. Color Gamut Panel Native DCB Mode DCB Demo Green Blue Exit Enter Select Off / Multimedia LowBlue Mode (multimedia) / Internet Reduces blue light waves by controlling color temperature. (Internet) / Office (office) (Low Blue Light Mode) /Reading (reading)
  • Page 27 Machine Translated by Google Note: When "HDR Mode" or "HDR" under "Brightness" is set to non-off, all items under "Color Settings" cannot be adjusted. When the "Color Space" is set to "sRGB" or "DCI-P3", all other items under "Color Settings" cannot be adjusted.
  • Page 28 Machine Translated by Google Audio _ _ Audio Volume Exit Enter Select Volume 0-100 Adjust volume settings.

  • Page 29: Sports Atmosphere Light )

    Machine Translated by Google Light FX ( Esports Atmosphere Light ) Light FX Medium Light FX Static Light FX Mode Pattern Rainbow Foreground R Foreground G Foreground B Background R Background G Background B Exit Enter Select Off (closed) / Low Light FX (Low) / Medium (Medium) Select the intensity of the gaming ambient light.
  • Page 30 Machine Translated by Google Extra Extra Auto Input Select THAT Orbit Weak OFF-RS Off Timer Wide Image Ratio DDC/CI Resolution:2560(H)x1440(V) SDR H.Frequency:89 KHz V.Frequency:60 Hz Exit Enter Select Auto (automatic) / HDMI1 / Input Select Select the input signal source. HDMI2 / DP1 / DP2 On/Off Turns on/off the USB function.
  • Page 31 Machine Translated by Google Reset Yes (Yes) or No (No) Reset the menu to default. The Time after Off-RS time for the screen to be on after the last image sticking elimination is performed, in hours, and the user will be automatically reminded to perform (time after image retention is image sticking elimination after 4 hours.

  • Page 32: Setup)

    Machine Translated by Google OSD Setup (OSD Setup) OSD Setup Language English Timeout 1.2/1.4 DP Capability H.Position V.Position Transparency Break Reminder Exit Enter Select Language Select the OSD language. Timeout 5-120 Adjust the OSD display time. (display time) Select a compatible DP version.

  • Page 33: Indicators

    Machine Translated by Google LED indicator state Power indicator color boot mode White standby mode orange Image retention removal in progress Blinking white light (on for 1 second and off for 1 second) Screen compensation correction in progress White light flashes (3 seconds on and 3 seconds off) OLED panel not working properly Blinking orange (1 second on/1 second off) shutdown mode...

  • Page 34: Troubleshooting

    Confirm that the computer is operating. The power light is blinking orange OLED panel abnormality can not work normally. Please contact AOC after-sales service personnel for help. no painting Is it compatible with plug and play. Whether Unable to achieve plug and play the adapter is compatible with plug and play.

  • Page 35: Specifications

    Machine Translated by Google Specification main specifications AG276QZD Model name YOU ARE Drive System panel Viewable image size 67.3 cm diagonal pixel pitch 0.2292mm(H) x 0.2292mm(V) 1.07 billion Display the number of colors 30k~230kHz(HDMI) Horizontal scanning range 30k~255kHz(DP) 586.75 Horizontal scan size (maximum) 48~144Hz (HDMI) Vertical scanning range 48~240Hz (DP)
  • Page 36 Machine Translated by Google Note: 1) This product supports a maximum of 1.07 billion display colors, and the setting conditions are as follows (due to the output limitation of some graphics cards, there may be differences): HDMI2.0 Input signal version DisplayPort1.4 output color format YCbCr422...
  • Page 37 Machine Translated by Google Default display mode Resolution (±1Hz) standard Horizontal frequency (kHz) Vertical frequency (Hz) 31.469 59.940 640×480@60Hz 37.861 72.809 640x480@72Hz 37.500 75.000 640x480@75Hz 51.080 99.769 640x480@100Hz 60.938 119.720 640x480@120Hz 35.156 56.250 800x600@56Hz 37.879 60.317 800×600@60Hz 48.077 72.188 800x600@72Hz SVGA 46.875 75.000...
  • Page 38 Machine Translated by Google pin assignment 19- Pin color display signal line Pin No. Signal Name Pin No. Signal Name Pin No. Signal Name TMDS Data 2+ TMDS data 0- DDC/CEC ground TMDS Data 2 Shield TMDS Clock+ +5V power supply TMDS data 2- TMDS Clock Mask 19.
  • Page 39 Machine Translated by Google plug and play DDC2B Plug and Play Features This monitor has VESA DDC2B function according to VESA DDC standard. Depending on the level of DDC used, it allows the display to inform the host system of its identity, and to convey additional information about its display capabilities.
