SCHEMATIC
NOTE: CONDITION OF OVEN
1. DOOR CLOSED.
2. CLOCK APPEARS ON DISPLAY.
NOISE FILTER
SCHEMATIC
NOTE: CONDITION OF OVEN
1. DOOR CLOSED.
2. COOKING TIME PROGRAMMED.
3. START KEY TOUCHED.
NOISE FILTER
NOTE: " " indicates components with potential above 250V.
TEMPERATURE FUSE
120˚C (OVEN)
COM.
2ND. INTERLOCK
RELAY
A5
B2
2ND. INTERLOCK
RELAY CONTROL
SWITCH
THERMAL
CUT-OUT
95˚C (MG)
1ST. LATCH
SWITCH
Figure O-1 Oven Schematic-OFF Condition
TEMPERATURE FUSE
120˚C (OVEN)
COM.
2ND. INTERLOCK
RELAY
A5
B2
2ND. INTERLOCK
RELAY CONTROL
SWITCH
THERMAL
CUT-OUT
95˚C (MG)
1ST. LATCH 1ST. LATCH
SWITCH SWITCH
Figure O-2 Oven Schematic-ON Condition
25
N.O.
B1
N.O.
B1
R-212B
