Instruction manual
Instrucciones
Manuel d'instructions
To learn more about Porter-Cable visit
our website at:
http://www.porter-cable.com
Pour de plus amples renseignements
concernant Porter-Cable, consultez
notre site Web à l'adresse suivante:
http://www.porter-cable.com
Para obtener más información sobre
Porter-Cable, visite nuestro sitio web en:
http://www.porter-cable.com
Copyright © 2002 Porter-Cable Corporation
Manual de
ESPAÑOL: PÁGINA 9
FRANÇAIS: PAGE 17
Air Hammer
Martillo neumático
Marteau pneumatique
IMPORTANT
Please make certain that the person who is
to use this equipment carefully reads and
understands these instructions before
starting operations.
IMPORTANTE
Asegúrese de que la persona que va a usar esta
herramienta lea cuidadosamente y comprenda
estas instrucciones antes de empezar a
operarla.
IMPORTANT
Veuillez vous assurer que la personne qui
utilise cet outil lit attentivement et comprend
ces instructions avant de commencer à utiliser
l'outil.
MODEL PTH1
MODELO PTH1
MODÈLE PTH1
Part No. D22721-026-2
Advertisement
Table of Contents
Related Manuals for Porter-Cable PTH1
Summary of Contents for Porter-Cable PTH1
- Page 1 Air Hammer Manuel d'instructions Martillo neumático Marteau pneumatique MODEL PTH1 MODELO PTH1 MODÈLE PTH1 To learn more about Porter-Cable visit our website at: http://www.porter-cable.com IMPORTANT Pour de plus amples renseignements Please make certain that the person who is concernant Porter-Cable, consultez to use this equipment carefully reads and notre site Web à...
-
Page 2: Safety Guidelines - Definitions
SAFETY GUIDELINES - DEFINITIONS This manual contains indicates an imminently hazardous situation which, if not information that is avoided, will result in death or serious injury. important for you to know and indicates a potentially hazardous situation which, if not understand. - Page 3 HAZARD RISK OF LOSS OF HEARING WHAT COULD HAPPEN HOW TO PREVENT IT • Long term exposure to noise produced from the opera- • Always wear ANSI S3.19 hearing protection. tion of air tools can lead to permanent hearing loss. HAZARD RISK TO BREATHING INHALATION HAZARD WHAT COULD HAPPEN...
- Page 4 HAZARD RISK OF INJURY (continued) WHAT COULD HAPPEN HOW TO PREVENT IT • Improperly maintained tools and accessories can cause • Maintain the tool with care. serious injury. • Keep a cutting tool sharp and clean. A properly maintained tool, with sharp cutting edges reduces the risk of binding and is easier to control.
-
Page 5: Specifications
SPECIFICATIONS Blows Per Minute 3,000 BPM Maximum Working Pressure 90 PSI Air Inlet 1/4" NPT Recommended Hose Size 3/8" I.D. Replacement Chisels PTA5 - 5 pc chisel set (.401 Parker Taper chisels) Air Consumption @ 90 PSI 3.8 SCFM ASSEMBLY Accessories Required IMPORTANT: Line pressure or hose inside diameter should be increased to compensate for unusually long air hoses (over 25 feet). -
Page 6: Maintenance
MAINTENANCE Lubrication Air tools require lubrication throughout the life of the tool. The air motor and bearing uses compressed air to power the tool. Because moisture in compressed air will rust the air motor, you must lubricate the motor daily. An inline oiler is recommended. To lubricate the air motor manually: Remove chisel. -
Page 7: Repair Parts
REPAIR PARTS Part No. Description Spring Pin O-Ring Bushing O-Ring O-Ring Trigger Pin O-Ring Spring Trigger D25342 Handle Grip + Only available in Trigger Repair Kit D25357 Note: Parts not listed are not serviceable. D22721 7- ENG... -
Page 8: Limited Warranty
• Use reasonable care in the operation and maintenance of the product as described in the Owners Manual(s). • Deliver or ship the product to the nearest Porter-Cable Authorized Warranty Service Center. Freight costs, if any, must be paid by the purchaser.
